ES- Español

MANUAL DEL USUARIO

Antes de utilizar el televisor, por favor lea este manual

detenidamente y consérvelo para futuras referencias.

English

ES-

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance

with the manufacturer's instructions.

8. Do not install near any heat sources such as radiators,

heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with

one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the

third prong are provided for your safety. If the provided

plug does not fit into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the

point where they exit from the apparatus.

11. Only use attachments/accessories specified by the

manufacturer.

12. Use only with cart, stand, tripod,

bracket, or table specified by the

manufacturer, or sold with the

apparatus. When a cart is used,

use caution when moving the cart/

apparatus combination to avoid injury

from tip-over.

13. Unplug this apparatus during lightning storms or when

unused for long periods of time.

14. Refer all servicing to qualified service personnel.

Servicing is required when the apparatus has been

damaged in any way, such as power-supply cord or plug

is damaged, liquid has been spilled or objects have fallen

into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been

dropped.

15. Apparatus should not be exposed to dripping or

splashing, and objects filled with liquids, such as vases,

should not be placed on the apparatus.

16. An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or

power circuits, or where it can fall into such power lines

or circuits. When installing an outside antenna system,

extreme care should be taken to keep from touching

such power lines or circuits, as contact with them might

be fatal.

17. Do not overload wall outlets and extension cords, as this

can result in a risk of fire or electric shock.

18. Do not push objects through any openings in this unit,

as they may touch dangerous voltage points or short out

parts that could result in fire or electric shock. Never spill

or spray any type of liquid into the unit.

19. If an outside antenna or cable system is connected to the

unit, be sure the antenna or cable system is grounded to

provide some protection against voltage surges and built-

up static charges, Section 810 of the National Electrical

Code, ANSI/NFPA 70, provides information with respect

to proper grounding of the mast and supporting structure,

grounding of the lead-in wire to an antenna discharge

unit, size of grounding conductors, location of antenna

discharge unit, connection to grounding electrodes, and

requirements for the grounding electrode.

20. When replacement parts are required, be sure the service

technician uses replacement parts specified by the

manufacturer or those that have the same characteristics

as the original part. Unauthorized substitutions may result

in fire, electric shock or other hazards.

21. Upon completion of any service or repairs to this unit,

ask the service technician to perform safety checks to

determine that the unit is in proper operating condition.

The lightning flash with arrowhead symbol, within an

equilateral triangle is intended to alert the user to the

presence of uninsulated dangerous voltage within the

product's enclosure that may be of sufcient magnitude

to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

Important Safety Instructions

Your TV also contains material that can be recycled and

reused. For disposal or recycling information, contact your

local authorities or the Electronic Industries Alliance at

www.eia.org to find a recycler in your area.

End of life directives

Power source

WARNING

Do not connect this unit to the power using any device

other than the supplied AC cord. This could cause fire,

electrical shock, or damage.

Do not use with a voltage other than the power voltage

specified. This could cause fire, electrical shock, or

damage.

TO USE AC POWER

1. The power cord is attached to the TV at the factory.

2. Connect the AC cord into an AC outlet.

CAUTION

When this unit is not used for a long time, (e.g., away on

a trip) in the interest of safety, be sure to unplug it from

the AC outlet.

Do not plug/unplug the AC cord when your hands are

wet. This may cause electrical shock.

The LCD panel contains almost 3 million thin film transistors,

which provide exceptionally sharp video quality. Occasionally,

a few non-active pixels may appear on the screen as a

fixed black (in the case of a dead pixel), blue, green, or red

point. These non-active pixels do not adversely affect the

performance of your TV, and are not considered defects.

Non-active pixels

22. When you connect the product to other equipment, turn

off the power and unplug all of the equipment from the

wall outlet. Failure to do so may cause an electric shock

and serious personal injury. Read the owner's manual of

the other equipment carefully and follow the instructions

when making any connections.

23. Sudden high volume sound may cause hearing or

speaker damage. When you use headphones, (if the unit

is equipped with a headphone jack) keep the volume at a

moderate level. If you use headphones continuously with

high volume sound, it may cause hearing damage.

CONDENSATION:

Moisture will form in the operating section of the unit if the

unit is brought from cool surroundings into a warm room or

if the temperature of the room rises suddenly. When this

happens, unit's performance will be impaired. To prevent

this, let the unit stand in its new surroundings for about an

hour before switching it on, or make sure that the room

temperature rises gradually.

Condensation may also form during the summer if the unit is

exposed to the breeze from an air conditioner. In such cases,

change the location of the unit.

HOW TO HANDLE THE LCD PANEL:

Do not press hard or jolt the LCD panel. It may cause the

LCD panel glass to break and injury may occur.

If the LCD panel is broken, make absolutely sure that you

do not touch the liquid in the panel. This may cause skin

inflammation.

If the liquid gets in your mouth, immediately gargle and

consult with your doctor. Also, if the liquid gets in your eyes

or touches your skin, consult with your doctor after rinsing

for at least 15 minutes or longer in clean water.

Possible Adverse Effects on LCD Panel:

If a fixed (non-moving) pattern remains on the LCD Panel

for long periods of time, the image can become permanently

engrained in the LCD Panel and cause subtle but permanent

ghost images. This type of damage is NOT COVERED BY

YOUR WARRANTY. Never leave your LCD Panel on for long

periods of time while it is displaying the following formats or

images:

Fixed Images, such as stock tickers, video game patterns,

TV station logos, and websites.

Special Formats that do not use the entire screen. For

example, viewing letterbox style (16:9) media on a normal

(4:3) display (black bars at top and bottom of screen); or

viewing normal style (4:3) media on a widescreen (16:9)

display (black bars on left and right sides of screen).

The following symptoms are not signs of malfunction

but technical limitation. Therefore we disclaim any

responsibility for these symptoms.

LCD Panels are manufactured using an extremely high

level of precision technology, however sometimes parts

of the screen may be missing picture elements or have

luminous spots.

This is not a sign of a malfunction.

Do not install the LCD Panel near electronic equipment that

produces electromagnetic waves. Some equipment placed

too near this unit may cause interference.

Effect on infrared devices - There may be interference

while using infrared devices such as infrared cordless

headphones.

Declaration of Conformity

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference and (2)

This device must accept any interference received, including

interference that may cause undesired operation.

Important Safety Instructions

When Installing the TV Against a Wall or Enclosed Area

Install with stand

Never install the TV set as follows:

Install on the wall

Make sure that your TV has adequate air circulation. Allow enough space around the TV as shown below. Avoid operating the

TV at temperatures below 41°F (5°C).

Leave at least this much

space around the set.

Leave at least this much

space around the set.

4 inches

(10cm)

4 inches

(10cm) 4 inches

(10cm)

4 inches

(10cm)

4 inches

(10cm)

2 3⁄8 inches

(6cm)

12 inches

(30cm) 12 inches

(30cm)

Wall Wall

Air circulation is blocked.

Inadequate air circulation can lead to overheating of the TV and

may cause damage to your TV or cause a re.

Legal Notices

FCC Statement

NOTE:

This equipment has been tested and found to comply with

the limits for a class B digital Device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio Communications. However, there is

no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the

receiver.

Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician

for help.

FCC ID Number WiFi Module: WWMMN42756IV2

The WiFi Module complies with FCC radiation exposure

limits set forth for an uncontrolled environment. This device

should be installed and operated with a minimum distance of

20 centimeters between the radiator and your body.

Hisense and associated logos where applicable are registered trademarks of Hisense Group in the United States and/or other

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

* Specications subject to change without notice.

This TV incorporates High-Denition Multimedia Interface (HDMITM) technology.

HDMI, the HDMI logo and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

WARNING

The manufacturer is not responsible for any radio or TV

interference caused by unauthorized modifications to

this equipment. Such modifications could void the user's

authority.

Energy Star

Your Hisense TV is ENERGY

STAR ® qualified in the “Energy

Savings” mode. It meets strict energy

efficiency guidelines set by the U.S.

Environmental Protection Agency

and Department of Energy. ENERGY

STAR is a joint program of these

government agencies, designed to

promote energy efficient products and practices. Changes to

certain features, settings, and functionalities of this TV (i.e.

TV Guide, Picture, Sound) can increase or change the power

consumption. Depending upon such changed settings, the

power consumption may exceed the limits required for the

ENERGY STAR qualification in the “Energy Savings” mode.

NOTE

Where the MAINS plug or an appliance coupler is used

as the disconnect device, the disconnect device shall

remain readily operable.

Contents

Getting Started

Viewing the Remote Control ............................................................................3

Installing Batteries in the Remote Control .......................................................4

Making Connections ........................................................................................ 5

Network Connection ........................................................................................8

Basic Features

Turning your TV on or off ................................................................................10

Turning the TV On for the First Time .............................................................. 10

Changing Channels / Volume ......................................................................... 11

Selecting the Input Source ............................................................................. 11

Shortcuts Instructions ..................................................................................... 12

To Use the Menu ............................................................................................13

Using the Picture Menu ..................................................................................13

Using the Audio Menu ....................................................................................14

Using the TV Menu ......................................................................................... 15

Using the Setup Menu .................................................................................... 15

Using the Network Menu ................................................................................17

Advanced Features

DLNA Setting .................................................................................................. 19

Media Share Settings in Computer.................................................................19

Setting to Share Files .....................................................................................20

Network Function............................................................................................21

Using the Home Menu ....................................................................................22

Movies ............................................................................................................22

Apps ...............................................................................................................22

AccuWeather ..................................................................................................22

YouTube .........................................................................................................22

VUDU Movies ................................................................................................. 23

Contents

Advanced Features

VUDU Apps ....................................................................................................23

Netflix..............................................................................................................24

Vimeo .............................................................................................................24

Pandora .......................................................................................................... 25

Twitter ............................................................................................................. 25

Picasa .............................................................................................................25

Opera..............................................................................................................26

Opera Apps.....................................................................................................28

Digital Media Receiver (HiBeam) ...................................................................29

Digital Media Player(HiMedia) ........................................................................ 29

Browse Pictures..............................................................................................30

Enjoy Video Files ............................................................................................ 30

Enjoy Music Files............................................................................................32

Other Information

Troubleshooting .............................................................................................. 32

Remote Control Button Layout

NOTES

FOR ILLUSTRATION ONLY.

[RED/GREEN/YELLOW/BLUE] buttons are used for Electronic Program Guide (EPG).

After pressing the [GUIDE] button when viewing digital channels, the same color buttons will appear with explanations in the

on-screen display (OSD). Follow the steps shown in the OSD.

Power on/off

Decrease volume

Media content control function buttons

Return to the previous menu

Launch Vudu HD Movies

Launch Netix

Increase volume

Adjust Closed Caption (CCD) mode

Audio select button

MENU button

Dash button

Select a digital sub-channel

▲/

▲

Navigate Up / Down / Left / Right

or adjust OSD settings

Set the sleep timer

Select picture mode

Select sound mode Display the information banner

Conrm selections

MUTE button

ASPECT button

Close the menu

Next channel

Display the favorite channel list

Go to the previous channel

Enter TV source

Previous channel

HiMedia (Digital Media Player)

Open the HiSmart Home Menu

Select input source

Infra-red transmitter

Open the DTV program guide

(if available)

Select VGA / HDMI source

Special function buttons (see Notes)

Direct channel selection

Getting Started

Launch YouTube App

Installing Batteries in the Remote Control

1. Press the release button on the back of the remote control to remove the battery compartment cover.

2. Insert two AAA size batteries. Make sure to match the (+) and ( - ) ends of the batteries with the (+) and ( - ) ends indicated in

the battery compartment.

3. Replace the battery compartment cover.

NOTES

1. Dispose of your batteries in a designated disposal area. Do not throw the batteries into a fire.

2. Remove depleted batteries immediately to prevent leakage into the battery compartment.

3. If you do not intend to use the remote control for a long time, remove the batteries.

4. Batteries should not be exposed to excessive heat, such as sunshine, heat registers, or fire.

5. Battery chemicals can cause a rash. If the batteries leak, clean the battery compartment with a cloth. If chemicals touch your

skin, wash immediately.

6. Do not mix old and new batteries.

7. Do not mix alkaline, standard (carbon-zinc) or rechargeable (ni-cad, ni-mh, etc.) batteries.

Program Your Universal Cable or Satellite Remote Control to Operate Your New Hisense Television!

If you would like to program your other household remote controls to your new Hisense television, please consult the User’s

Manual supplied by your Cable or Satellite provider. The Cable or Satellite providers’ User’s Manuals should include instructions

on how to program their remote to your television.

Below is a list of Hisense codes for the most common Cable and Satellite providers. Use the Hisense code that is associated

with your Cable or Satellite provider(if applicable).

DIRECTV ................................................... 0178 or 10019

Time Warner Cable ........................................386 or 0178

Comcast .................................................... 0178 or 10178

Cox Communications ............................................... 0178

Dish Network ................................................... 627 or 505

AT&T U-verse ........................................................... 1346

If the Hisense code associated with your Cable or Satellite provider is not listed above, if the code above does not work, or if

you cannot locate the instructions for programming your household remote to your television, call your local Cable or Satellite

provider’s customer service center.

If your Cable or Satellite provider does not have an Hisense code available, please visit http://www.hisense-usa.com for

additional codes.

Change the batteries

1Remove the battery compartment cover 2Insert the batteries

1. The remote control distance: up to 26 feet in front of the TV set.

2. The remote control angle: +/- 30-degrees (horizontal and vertical).

The effective range of remote control

Getting Started

Making connections

Getting Started

NOTES

Check the jacks for position and type before making any connections. Loose connections can result in image or color

problems. Make sure that all connections are tight and secure.

Not all A/V devices have the ability to connect to a TV, please refer to the user manual of your A/V device for compatibility

and connections procedure.

Always unplug the power cord when connecting external equipment.

Connecting an antenna, cable or cable/satellite box

Connecting an A/V Device with Composite Cable

or ANT OUT

Cable

EXTERNAL DEVICESTV JACK

1. Turn off the TV before connecting the antenna.

2. Connect one end of a coaxial cable (not included) to the RF OUT jack on the antenna, cable or cable/satellite box. If you are

using an antenna with twin-lead cable, you may need a 300-75 ohm adapter (not provided) to connect it to the back of your

TV. Likewise, if you are using several antennas, you may need a combiner (not provided).

3. Connect the other end of the cable to the ANT/CABLE jack on the side of your TV.

1. Use the audio and video cables to connect the external A/V device’s composite video/audio jacks to the TV’s jacks. (Video =

yellow, Audio Left = white, and Audio Right = red)

NOTE

Connect the yellow video plug to the Green Y-input jack on the TV.

2. Plug the connected devices into the mains socket before switching on the TV.

3. Select the corresponding source from the TV.

ANT/CABLE

Equipment with A/V jacks

DVD Player/Recorder

Video

Camera

EXTERNAL DEVICES

Set-top box

Satellite Receiver

Satellite

antenna

cable

VCR

A/V OUT

Video

White(L)

Yellow(Video)

Red(R)

TV JACK

AV Cable

(not included)

YPBPR

L -AUDIO- RVIDEO

AV IN

COMPONENT IN

Getting Started

Connecting an A/V Device with Component (YPBPR) Cable

Connecting an A/V Device with HDMI Cable

1. Use a component cable to connect the external A/V device’s component output jacks to the TV’s YPBPR jacks. Use an audio

cable to connect the external A/V device’s component audio jacks to the TV’s AUDIO (L/R) jacks.

2. Plug the connected devices into the mains socket before switching on the TV.

3. Select the corresponding source from the TV.

Support digital connections between HDMI - enabled A/V devices such as PVR, DVD, Blu-ray, AV receiver and digital

devices.

Some devices such as PVR or DVD player require HDMI signal to be set to output in the device's settings.

Please consult your device user manual for instructions.

1. Use an HDMI cable to connect the A/V device’s HDMI output jack to the TV’s HDMI jack.

2. Plug the connected devices into the mains socket before switching on the TV .

3. Select the corresponding source from the TV.

NOTE

The HDMI connector provides both video and audio signals, it’s not necessary to connect the audio cable.

Equipment with A/V jacks

DVD Player/Recorder

Video

Camera

EXTERNAL DEVICES

Set-top box

Satellite Receiver

Satellite

antenna

cable

VCR

White(L)

Red(R)

Audio Cable

(not included)

Component Cable

(not included)

HDMI

TV JACK

EXTERNAL DEVICES

DVD Player/Recorder

Set-top box

Equipment with HDMI jacks

HDMI Cable

(not included)

TV JACK

Component

PR/CR

PB/CB

Connecting a headphone

Headphones can be connected to the /AUDIO OUT output

on your set. (While the headphone is connected, the sound

from the built-in speakers is disabled.) AUDIO OUT

EXTERNAL DEVICESTV JACK

YPBPR

L -AUDIO- RVIDEO

AV IN

COMPONENT IN

Getting Started

Connecting a PC with VGA Cable

1. Use a VGA cable to connect the PC’s VGA output jack to the TV’s VGA jack. Use an audio cable to connect the PC’s audio

output jack to TV’s PC/DVI AUDIO IN jack.

2. Plug the connected devices into the mains socket before switching on the TV.

3. Select the corresponding source from the TV.

NOTES

Primarily this unit is intended for use as an LCD TV. If you want to use it as a monitor, please contact the manufacturer of the

PC Video/Graphic's card for further support. Perfect compatibility is not guaranteed.

The VGA cable is not supplied with the product.

We strongly recommend the use of a VGA cable with two ferrite cores to reduce interference. (as shown in the illustration).

EXTERNAL DEVICES

Computer

TV JACK

Audio Cable

(not included)

VGA Cable

(not included)

Connecting an Audio Receiver with Audio cable

1. Use an audio Optical cable to connect the A/V device’s digital audio in jack to the TV’s DIGITAL OUTPUT (Optical) jack. Or

use an RCA Y-cable (1/8”-stereo mini to L/R phono - not provided) to connect analog sound system to the TV’s /AUDIO

OUT jack.

2. Plug the connected devices into the mains socket before switching on the TV.

3. Select the corresponding source from the TV.

NOTES

When a digital audio system is connected to the DIGITAL OUTPUT (Optical) jack, decrease the volume of both the TV and

the system.

5.1 CH (channel) audio is available when the TV is connected to an external device supporting 5.1 CH.

When the receiver (home theater) is set to on, you can hear sound output from the TV’s digital audio out jack. When the TV

is receiving a DTV signal, the TV will send 5.1 CH sound to the home theater receiver. When the source is connected to the

TV via HDMI, only 2 CH audio will be heard from the home theater receiver. If you want to hear 5.1 CH audio, connect the

digital audio out jack from your DVD/Blu-ray player/cable box/STB satellite receiver directly to an amplifier or home theater.

PC IN

VGA PC/DVI AUDIO IN

TV JACKS EXTERNAL DEVICES

Powerless

Bass Speaker

Speaker

Audio Amplier

AUDIO OUT

White(L)

Red(R)

Audio Cable

(not included)

Audio Cable

(not included)

DIGITAL

OUTPUT

(Optical)

Getting Started

Network Connection

You can set up your TV so that it can access the Internet through your local area network (LAN) with a Ethernet or wireless

connection.

You can attach your TV to your LAN by one of the three following ways:

You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an external modem using a Cat 5

LAN cable. See the diagram below.

You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an IP Sharer which is connected

to an external modem. Use LAN cable for the connection. See the diagram below.

Depending on how your network is configured, you may be able to attach your TV to your LAN by connecting the LAN port

on the back of your TV directly to a network wall outlet with a Cat 5 cable. See the diagram below. Note that the wall outlet

is attached to a modem or router elsewhere in your house.

If you have a Dynamic Network, you should use an ADSL modem or router that supports Dynamic Host Configuration Protocol

(DHCP). Modems and routers that support DHCP automatically provide the IP address, subnet mask, gateway, and DNS, so

you don’t have to enter them manually. Most home networks are Dynamic Networks.

Some networks require a Static IP address. If your network requires a Static IP address, you must enter the IP address, subnet

mask, gateway, and DNS values manually on your TV’s Cable Setup Screen when you set up the network connection. To get

the IP address, subnet mask, gateway, and DNS values, contact your Internet Service Provider (ISP).

If you have a Windows computer, you can also get these values through your computer.

The Modem Port on the Wall

Modem Cable LAN Cable

LAN Port on TV

External Modem

(ADSL / VDSL / Cable TV)

LAN

The Modem Port on the Wall

Modem Cable LAN Cable LAN Cable

LAN Port on TV

External Modem

(ADSL / VDSL / Cable TV)

IP Sharer (Router)

(with DHCP server)

LAN

The LAN Port on the Wall LAN Port on TV

LAN Cable

LAN

NOTE

You can use ADSL modems that support DHCP if your network requires a Static IP address. ADSL modems that support

DHCP also let you use Static IP addresses.

Connecting to a Wired Network

To connect your TV to your network wirelessly, you need a wireless router or modem. See the illustration below.

Hisense’s built-in Wireless LAN Adapter supports the IEEE 802.11 b/g/n communication protocols. Hisense recommends using

IEEE 802.11n router. When you play the video over a IEEE 802.11b/g connection, the video may not play smoothly.

NOTES

You must use the Hisense’s built-in Wireless LAN Adapter to use a wireless network, the set doesn’t support external USB

network adapter.

To use a wireless network, your TV must be connected to a wireless IP sharer. If the wireless IP sharer supports DHCP, your

TV can use a DHCP or static IP address to connect to the wireless network.

Select a channel for the wireless IP sharer that is not currently being used. If the channel set for the wireless IP sharer is

currently being used by another device nearby, this will result in interference and communication failure.

If you apply a security system other than the systems listed below, it will not work with the TV.

If Pure High-throughput (Greenfield) 802.11N mode is selected and the Encryption type is set to WEP, TKIP or TKIP-AES

(WPS2 Mixed) for your Access Point (AP), this player will not support a connection in compliance with new Wi-Fi certification

specifications.

If your AP supports WPS (Wi-Fi Protected Setup), you can connect to the network via PBC (Push Button Configuration) or

PIN (Personal Identification Number). WPS will automatically configure the SSID and WPA key in either mode.

Connection Methods: You can setup the wireless network connection three ways.

-Scan

-Manual

-Auto

Connecting to a Wireless Network

Wireless IP Sharer(Router)

(with DHCP Server)

LAN Cable

Wireless LAN Adapter

built-in TV set

The LAN Port on

the Wall

Getting Started

Basic Features

Turning the TV On for the First Time

The Setup Wizard menu appears the first time you turn

on the TV. It will assist you to specify the menu language,

country setting, Use Mode, Network Setting and Channel

Installation.

IMPORTANT: Make sure that the antenna or cable is

connected and a wired or wireless Internet connection

is available.

1. Make sure that you have:

Installed the remote control batteries.

Connected the power cord.

Connected to an antenna or cable TV signal.

NOTE

The customer will be prompted to connect a Network

cable in the Select Network wizard screen.

2. Connect your TV’s power cord to a power outlet, then

press power. The Initial Setup screen opens.

3. Please press [ENTER] to start the wizard, then press

[▲/

▲

] button to select your language: English, Spanish

or French, select [Next] to confirm and move to the

Welcome screen.

1. Language setting Next: Country Setting

Language settings

English

Español

Français

The Welcome screen displays the available input devices

and interfaces.

4. Select the country where you will operate the TV.

Previous Next

2.Country setting Next: Time Zone Setting

Country setting

USA

Canada

Mexico

5. Select the local time zone according to your region.

Previous Next

3.Time zone setting Next: Use Mode

Time Zone settings

Pacic Time

Mountain Time

Central Time

Eastern Time

Hawaii

Daylight Saving Time

Daylight Saving: Set the Daylight Saving time for your area.

6. Select Use Mode Setting: Home Mode or Retail Mode.

Home Mode is the recommended setting which offers full

functionality of the television.

Previous Next

4.Use Mode Next: Network Setting

Use Mode

Home mode

Retail mode

Home mode default settings are recommended

for in-home use.ENERGY STAR ® qualied.

If you select Retail Mode, a message appears “Are you

sure to change to retail mode?” Select “OK” to continue,

or select “Cancel” to change your selection.

Home Mode is the recommended setting which offers full

functionality of the television. If you selected Retail Mode,

Energy Savings are not realized.

To turn your TV on or off (standby mode):

1. Plug the power cord into an AC power outlet.

2. Press [POWER] button. Your TV turns on.

3. Press [POWER] button again to turn off your TV. When

you turn off your TV, it goes into standby mode.

Turning your TV on or off

WARNING

When your TV is in standby mode, it is still receiving

power. To completely disconnect power, unplug the power

cord.

NOTE

If your TV does not receive an input signal for several

minutes, it automatically goes into standby mode.

8. The Channel Search.

Press [▲/

▲

] to select your Tuner Mode: Antenna or

Cable, press [ENTER] button to confirm.

Channel Search

Please allow 30 minutes to complete.

30%

Stop

6. Channel Search

ATV Channels added:0

DTV Channels added:0

Press [

▲

] to set the Channel Installation: Scan or Skip

Scan, press [ENTER] button to confirm.

If you select “Scan”, your TV automatically starts

Channel Installation available in your viewing area.

If you select “Skip Scan”, your TV does not scan for

channels.

1. Press the [CH

/V] (or [CH +/-]) on the TV/remote control

to change the channel.

2. Press the [VOL

/V] (or [VOL +/-]) on the TV/remote

control to adjust the volume.

3. Press the numeric buttons on the remote control to

display the corresponding channels.

Changing Channels / Volume

The first time you turn on your TV, you must select the TV

signal source. Your TV stores this information, so you do not

need to change the TV signal source unless it changes. For

example, you change from an outside antenna to cable TV.

To select the video input source:

1. Turn on your TV, then press [INPUT] button on the remote

or on the TV. The Input Source menu opens.

2. Press [▲/

▲

] button to highlight the input source, then

press [ENTER] button.

Selecting the Input Source

NOTE

Changing the channels can also be achieved by directly

entering the channel number using the numeric keys on

the remote control. If you are entering a two or three digit

channel number, the time between key presses should be

less than 3 seconds.

7. Select Network : Connect your TV to access the

network.

5.Select Network Next: Channel Search

END USER TERMS AND CONDITIONS AND PRIVACY POLICY FOR

HISMART SERVICES. The product/device you have purchased from Hisense

USA Corp., or its Parent Company, afliates and/or Subsidiary Company, its

successors and/or assigns (hereinafter referred to as “Hisense”) provides direct

access to the internet through one or more internet provider services (hereinafter

referred “Web Service(s)”).All content and services accessible through this

device belong to Hisense USA Corp., “Hisense” is sometimes also referred to

herein as “we” or “us”) or third parties and are protected by copyright, patent,

trademark and/or other intellectual property laws. Such content and services

are provided solely for your personal non-commercial use. You may not use

Select Network

AgreeDisagree

When the Network Setting menu opens, Hisense Service

Terms and Conditions will appear. Press [◄/►] to scroll

through the pages. Please read it carefully.

If you want to access the internet, press the [Agree]

button to set your TV’s network connections. Otherwise,

press the [Disagree] button to enter the Channel search

menu.

Previous Next

5.Select Network Next: Channel Search

Select Network

Wired Network

Wireless Network

Connect a wireless network with Wi-Fi

Skip

You can select the network conguration in this menu

or choose to skip network conguration. For more

information or to setup the network conguration later, see

“Network Connection” and “Network Setup”.

Depending on the reception condition, it may take

up to 30 minutes or more to complete memorizing

channels. Please allow the process to complete

without interruption.

After the Channel Search, a summary of the current

settings will be displayed. Select “go” to exit the wizard.

Aspect - Select the screen aspect ratio from Normal, Wide,

Zoom, Cinema , 1:1 Pixel Map, and Auto.

Normal: The original 4:3 aspect

ratio (1.33:1 signal) is preserved,

so black bars are added to the left

and right of the image. Standard TV

broadcasts are displayed with a 4:3

aspect ratio.

Wide: When watching a standard

broadcast or full-frame movie in

this mode, the display image is

stretched proportionately to fill

the TV screen. When watching a

widescreen (1.78:1 signal) program

or movie, the display image fills the

TV screen.

Auto: Automatically adjusts the

image based on the screen size and

the TV program.

Zoom: Stretch the 4:3 aspect ratio

image vertically and horizontally to

fill the screen at 1:1.78 aspect ratio.

Cinema: Stretch the 4:3 aspect ratio

image vertically and horizontally to

fill the screen at 1:2.35 aspect ratio.

1:1 Pixel Map: Displays the native

signal format pixel-by-pixel without

any video processing or scaling. In

this mode, 1920 x 1080 resolution

sources fill the screen while all

other resolutions are centered and

surrounded by black bars.

Picture - Press this button to set the picture mode. It can be

set as Vivid, Standard, Energy Savings, Game, Theater or

Custom. This mode achieves a certain image display effect

by setting the brightness, contrast and Speech.

Sound - Press this button to set the sound mode. It can be

set as Standard, Speech, Music and Custom.

Mute - Press this button to turn the sound off, press this

button again to turn the sound back on. This function is used

to switch off sound temporarily.

Shortcuts Instructions Sleep - It can set the TV to let it enter into the Standby

state automatically. Press this button repeatedly to select

the proper sleeping clock mode, and the clock tells you the

remaining time before the TV enters Standby state.

Display - Press this button to display the information

including channel number, channel name, current system

time, tuner mode, audio stream, video format, audio

language, closed caption mode, parental lock rating,

program details, etc.

CCD - Press the [CCD] button to the Closed Caption mode:

CC Off, CC On or CC On When Mute.

MTS - Press the [MTS] button to selec the default audio

stream: Mono, Stereo or SAP.

Using the Picture Menu

You can adjust:

Picture Mode - Adjust the Picture Mode. You can select

Vivid, Standard, Energy Savings, Theater, Custom or Game

mode.

NOTE

The option of the Picture Mode is different in different

inputs. (For more information, see “Shortcuts

Instructions”)

Brightness - Increase or decrease the brightness of the

picture. Increasing the brightness can add more light to dark

areas of the picture, while decreasing the brightness can

add more darkness to light areas of the picture.

Contrast - Increase or decrease the contrast of the picture.

Increase the contrast to adjust the white areas of the picture

or decrease the contrast to adjust the black areas of the

picture.

Color - Adjust the level of color in the picture.

Tint - Adjust the hue of the picture.

Sharpness - You can increase the sharpness level for clearer

images or decrease the sharpness level for smoother images.

Basic Features

To Use the Menu

1Press the [MENU] button to open the main menu.

2Press [▲/

▲

] to select a menu option, then press [

▲

ENTER] button to enter the menu.

3In each menu, you can:

Press [▲/

▲

] to select an item,

Press [

▲

] to adjust the value, or

Press [

▲

/ENTER] to enter the submenu,

Press [MENU] to back the previous menu.

4Press [EXIT] to exit the menu.

NOTE

The menus in the user manual may vary slightly from the actual screen.

Advanced Video - Access advanced video settings such

as Color Temperature, Noise Reduction, Dynamic Backlight

Control (DCR) and Adaptive Contrast.

Color Temperature : Change the color temperature. You

can select a preset color temperature: Cool, Normal and

Warm (when set to cool, whites are bluer; when set to

warm, whites are yellower)

Noise Reduction : Optimize the picture quality by

filtering signal interference. You can select Off, Low, Auto,

Medium or High.

Dynamic Backlight Control (DCR) : Enhances the

contrast ratio between light and dark areas of the picture.

You can select Off, Low or High.

Adaptive Contrast : Automatically adjusts the contrast

level of the selected input source.

Overscan: In DTV mode, Select ON to extend the image

beyong the display so the picture edges are not visible.

Reset Picture Settings - Resets all Picture settings to the

factory defaults.


Personalize the

picture to suit your

preferences and

viewing conditions.

Picture Mode

Brightness

Contrast

Color

Tint

Sharpness

Advanced Video

Reset Picture Settings

Energy Savings


Personalize the

picture to suit your

preferences and

viewing conditions.

Picture Mode

Brightness

Contrast

Color

Tint

Sharpness

Advanced Video

Reset Picture Settings

Energy Savings

Basic Features

Using the Audio Menu

You can adjust:

Sound Mode - Select the Sound Mode: Standard, Speech,

Custom or Music .

Balance - Adjust the volume of the left and right speakers.

Equalizer - Soften or enhance the sound at specific

frequency points.

Auto Volume Control - Automatically adjusts volume to a

consistent level; attenuates loud passages.

Advanced Audio - Access Advanced Audio settings such as

Digital Audio Output, MTS/SAP, Audio Language, Speaker

select.

Digital Audio Output: Send digital audio to an external

audio system. You can select PCM, RAW or Off.

PCM: PCM outputs two channel audio regardless of

the input format.

RAW: When the data stream carries Dolby signal,

digital SPDIF outputs Dolby data stream. When the

data stream carries no Dolby signal, it transports PCM

data stream.

MTS/SAP: Select the default audio stream, you can

select Mono, Stereo or SAP (Second Audio Program).

MONO: Select this option if there is noise or static on

weak stereo broadcasts.

STEREO: Select this option for programs broadcast in

stereo.

SAP: Depending on the particular program being

broadcast, you can listen to a foreign-language

translation.

Audio Language - Change the default value for audio

language. (Digital channels only)

Speaker select -Selects where to play TV audio. You

can select On (default setting) to play audio through TV

speakers, or select Off to play audio through the speakers

on an external audio system.

Reset Audio Settings - Resets all Audio Settings to the

factory defaults.

Audio

Personalize the audio

to suit your prefer-

ences and listening

conditions.

Sound Mode

Balance

Equalizer

Auto Volume Control

Advanced Audio

Reset Audio Settings

Standard

Off

Audio - Equalizer

10 DB

0 DB

-10 DB

120Hz 500Hz 1.5KHz 5KHz 10KHz

00 0 0

You can adjust:

Tuner Mode - Select the TV signal source. You can select

Antenna or Cable.

Auto Channel Search - Scans for channels that have

signals and stores the channels information in memory.

Digital Channels: The scanned TV program in digital

signals.

Analog Channels: The scanned TV program in analog

signals.

Channel Skip - You can cancel a channel stored in memory.

NOTE

When you press [CH V/V] (or [CH +/-]) button, your TV

skips the channel you cancelled. You can still tune to the

channel using the number buttons on the remote control.

Favorite List - Display your Favorite List. You can add or

delete channels to create your favorite list.

NOTE

When you press [CH V/V] (or [CH +/-]) button, your TV

skips the channel you cancelled. You can still tune to the

channel using the number buttons on the remote control.

Signal Strength - This menu is used to check the signal

strength of your antenna system. Usually strengths of above

75% indicates an acceptable signal for your TV to display

correct image. Each channel may vary in signal / quality

strengths and its common for broadcast strengths to change

in your area. The signal strength of the channel on the

screen is displayed.

NOTE

If lower than 75% we advise to have your antenna system

checked by qualified personnel.

Using the TV Menu

Channels

Personalize the local

television services

settings.

Tuner Mode

Auto Channel Search

Channel Skip

Favorite List

Signal Strength

Antenna

Using the Setup Menu

You can adjust:

Menu Settings - You can set On-screen menu system.

Language: You can select the menu’s language to

English,Español or Français.

Timeout: Select the display time of the menu: 10-20-...-

60 seconds.

Time Setup - Set the time zone, daylight saving, time and

sleep timer.

Country: Select your local Country.

Time Zone: Select your local time zone: Eastern Time,

Indiana, Central Time, Mountain Time, Arizona, Pacific

Time, Alaska or Hawaii.

Daylight Savings: Set the Daylight Saving time for your

area.

Date/Time: Set the current year/month/day/time.

Sleep Timer: Select the amount of time before the TV to

turns off automatically.

Parental Controls - Prevent unauthorized users, such as

children, from watching unsuitable programs.

When you first use this function, the default password is

[0000]. Once you input this password, you can set options.

You can change password in the Lock submenu.

Channel Block : Block selected Channels on the TV.

Program Block : Block selected Programs on the TV.

Rating Enable: Block or unblock TV ratings.

U.S. TV Ratings: Restrict TV programs by USA

Ratings.

U.S. Movie Ratings: Restrict movies by USA Ratings.

Canadian English/French Ratings: Restrict movies

and TV programs by Canadian Ratings.

Open V-Chip: Display an advanced V-Chip ratings

table for digital channels (USA only).

Block Unrated: Block unrated TV programs.

Input Block - Block selected Input source on the TV.

Button Lock(On/Off) - Block or unblock use of the

remote control.

Settings

Personalize the

general TV setting.

Menu Settings

Time Setup

Parental Controls

Caption

CEC Function

Demo Mode

Power LED

Version Info

Reset Settings

Off

Basic Features

Caption - Adjust Closed Captioning settings.

Caption Control: Select the Closed Caption mode: CC Off,

CC On or CC On When Mute by press the CC button.

Analog Closed Caption: Select an Analog Caption setting:

CC1~CC4: Closed captioning appears in a small banner

across the bottom of the screen. CC1 is usually the

“printed” version of the audio. CC2~CC4 display content

are provided by the broadcaster.

Text1~Text4: Closed captioning that covers half or all of

the screen. Text1~Text4 display content are provided by

the broadcaster.

Off: To turn off the Analog Caption.

Digital Closed Caption: Select a Digital Caption setting:

Service1~Service6 or Off.

Digital Caption Style: Customize the look of digital Closed

Captioning.

Caption Style:

Set the look of Digital CC. “As

Broadcaster” uses broadcaster’s style.

Font Size/Style/Color/Opacity:

Select the size/style/

color/opacity level of font.

Background Color/Opacity:

Select the color/opacity

level of the background.

Window Color/Opacity:

Select the color of the window.

CEC Function :

This feature allows you to add devices to

your TV and control them with your TV remote control.

Basic Features

Following is the description of these ratings.

U.S. Movie Ratings

Rating Defined as

G General audience

PG Parental Guidance suggested

PG-13 Parents strongly cautioned

R Restricted

NC-17 No one 17 and under admitted

X Adult audience only

U.S. TV Ratings

Age Defined as

TV-Y All children

TV-Y7 Directed to older children

TV-G General audience

TV-PG Parental Guidance suggested

TV-14 Parents Strongly cautioned

TV-MA Mature Audience only

Contents Defined as

AAll of the ratings below that rating set blocked

automatically

D Suggestive dialogue

L Strong language

S Sexual situations

V Violence

FV Fantasy Violence

Canadian English Ratings

Rating Description

C Children

C8+ Children 8 years and older

GGeneral Programming, suitable for all audiences

PG Parents Guidance

14+ Viewers 14 years and older

18+ Adult Programming

Canadian French Ratings

Rating Description

G General

8 ans+ 8+General; Not recommended for young

children

13 ans+ Programming may not be suitable for children

under the age of 13

16 ans+ Programming is not be suitable for children

under the age of 16

18 ans+ Programming restricted to adults

NOTE

As you block rating, all rating higher than the ones you

select are blocked as well. E.g. if you choose to block

the MPAA rating R, the higher ratings, NC-17 and X,

are automatically blocked too.

Change Password - If you want to change the default

password, first enter the new password then enter the

same password again.

Reset Parental Control - You can reset all locks to

factory mode.

Reset to Factory Default- Restores the TV configuration

to factory settings. You will need to complete the setup

for such things as Tuner/Channel settings, Network

connection, Date/Time and other user preferences.

You can adjust:

Configuration - Select On or Off. When On mode is

selected, the following options are available.

Internet Connection : Setting the Internet Connection.

Interface : You can set up your TV so that it can access

the Internet through your local area network (LAN) with a

Ethernet or wireless connection.

Wireless Setting : You can set up your TV’s wireless

connection.

Information : Display network configuration information.

IP Setting : Allows you to set IP address, subnet mask,

gateway, primary and secondary DNS.

Connection Test : Press the [ENTER] button to test

network status.

Basic Features

CEC function: Press [►] to set On/Off.

Auto turn off: Your added devices can be off automatically

by turning off the TV

TV Auto On:

Your TV can be on automatically by turning

on your added devices.

Audio Receive:

Turning ARC function on or off.

NOTES

HDMI cables must be used to connect HDMI CEC-

compatible devices to your TV.

The connected device’s HDMI CEC feature must be

turned on.

If you connect an HDMI device that is not HDMI CEC-

compatible, all the HDMI-CEC Control features do not

work.

Depending on the connected HDMI device, the HDMI-

CEC Control feature may not work.

Demo Mode -

Displays a banner at the top of the screen

which describes the key features of the TV.

Power LED - Select this feature to turn off or On the Power

LED indicator on the front panel on your TV.

Version Info - View the software version information.

Reset Settings - Restores the TV configuration to factory

settings.

Using the Network Menu

Auto Upgrade - Update the software using the Internet.

Configure your network. For detailed procedures on using

the Network Setup, refer to the “Connecting to the Internet

or a network” instructions. If you want the Network Update

to work automatically, please select Auto Updates (On).

If you want to do the Network Update manually, please

select Auto Updates (Off).

If the Internet connection doesn’t operate properly, check

the Network Configuration settings and try again. If the

problem persists, use the USB method below to update.

Firmware Upgrade - Insert a USB drive containing the

software update file, downloaded from the Hisense website.

(www.hisense-usa.com).

Please be careful not to disconnect the power or remove

the USB drive until updates are complete. The TV will

be turned off and on automatically after completing the

software update. When software is updated, video and

audio settings you made will return to their default settings

and your personal settings will be deleted. We advise you

to write down your settings so that you can easily reset

them after the update.

Applications - Network application.

DLNA: Digital Media Player (Hi-DMP) feature of Digital

Living Network Alliance. Press the [◄/►] buttons to set

DLNA to On.

Network

Personalize the

network connection

settings.

Configuration

Auto Upgrade

Firmware Upgrade

Applications

Off

Basic Features

Connecting to a Wired Network

Network Setup (Auto)

Use the Automatic Network Setup to connect the TV to a

network that supports DHCP. To set up your TV’s network

connection automatically, follow these steps:

How to set up automatically

1. Connect your TV to your LAN as described in the

previous section.

2. Turn on your TV, operate according to the description in

the Settings menu until the Network screen appears.

3. On the Network screen, select Configuration and press

[ENTER] button to enter the submenu.

4. Set Internet Connection to On and Interface to Ethernet.

5. Select IP Setting and press [ENTER] button to enter it.

6. Set Address Type to Auto.

7. Auto acquires and enters the necessary connection

values automatically.

8. If the connection values are not automatically entered,

please check your modem and router manuals for

directions to enable automatic IP addressing by DHCP.

Or, follow the steps listed in the following section,

Network Setup (Manual), to manually configure the

network connection.

Network Setup (Manual)

Use the Manual Network Setup when connecting your TV to

a network that requires a Static IP address.

Getting the Network Connection Values

To get the network connection values on most windows

computers, follow these steps:

1. Right click the Network icon in the bottom right of the

screen.

2. In the pop-up menu that appears, click Status.

3. On the dialog that appears, click the Support tab.

4. On the Support tab, click the Details button. The network

connection values are displayed.

How to manually setup the network connection

To set up your TV’s network connection manually, follow

these steps:

1. Follow Steps 1 through 5 in the “How to set up

automatically” procedure.

2. Set Address Type to Manual.

3. Press [▲/▼] button to select IP Address and press [◄/►]

button to move the cursor to the entry field. Then press

0~9 buttons to enter the numbers.

4. Press [MENU] button to exit IP Address and press [▲/▼]

button to select the next options to enter the numbers.

5When done, press [MENU] button to return to the

previous menu.

6. Select Connection Test to check the internet connectivity.

Wireless Setting

How to set up

1. Turn on your TV, press Menu and select Settings Network.

2. On the Network screen, select Configuration and press

the [ENTER] button to enter the submenu.

3. Set Internet Connection to On and Interface to Wireless.

4. Select Wireless Setting and press the [ENTER] button

you can select: Scan / Manual / Auto.

5. If you select Scan, a screen will appear listing all of the

wireless networks within range of the TV. Use the [▲/▼]

button to select the wireless network with your router SSID

and press the [ENTER] to confirm. Proceed to Step 7.

6. If you select Manual, a screen will appear prompting

you to enter the SSID of your wireless network. Press

[ENTER] and an on-screen keyboard will pop up. Enter

the SSID and select OK. Press [ENTER] and a screen

will appear prompting you select the security mode for

your wireless network. Use the [▲/▼] button to select

the proper security mode and press [ENTER] to confirm.

If you selected None for the security mode, proceed to

step 9.

7. A screen will appear prompting you to enter the password

for the selected security mode. Press [ENTER] and an

on-screen keyboard will pop up. Enter the password and

select OK. Press [ENTER] to confirm. Proceed to Step 9.

Netflix: Deactivate Netflix and display the exclusive

Netflix ESN.

VUDU: Deactivate VUDU.

PANDORA: Deactivate Pandora.

My Shared Devices: Allow or deny content sharing from

other devices on your network.

NOTES

•Software Update can also be performed via downloading

the latest software to a USB memory device.

•Please be careful not to disconnect the power or remove

the USB drive until updates are complete. The TV will

be turned on automatically after completing the software

update. When software is updated, video and audio

settings you made will return to their default settings and

your personal settings will be deleted. We advise you

to write down your settings so that you can easily reset

them after the update.

Network

Personalize the

network connection

settings.

Configuration

Auto Upgrade

Firmware Upgrade

Applications

Off

Advanced Features

You can use DLNA Certified computers, TVs, and other

devices to play or transfer the videos, pictures, and music

stored on your phone , tablet or other devices connected to

your network. For more about DLNA (Digital Living Network

Alliance), visit www.dlna.org. Make sure your phone and TV

are both connected to the same Wi-Fi network.

Set DLNA to On:

1. On the Network screen, select Applications and press

the [ENTER] button to enter the submenu.

2. Press the [◄/►] buttons to set DLNA to On.

DLNA Setting

If your computer does not support DLNA, you may install

software that supports DLNA such as TVersity or Windows

Media Player (Version V11 or higher). We recommend

Windows Media Player as the installation and setup is

easier.

1. On the PC taskbar, click Start.

2. Point to All Programs, and then click Windows Media

Player.

3. Click “Library” tab and then “Add to Library...” as shown in

the following screen shot.

4. In the Add To Library dialog box, click “Add” as shown in

the following screen shot.

Media Share Settings in Computer

8. If you select Auto, a screen will appear prompting you

to select PIN (personal identification number) or PBC

(push button configuration) setup. Choose the method

supported by your wireless access point.

If you choose PIN, an identification number will

appear on the screen for you to enter into the access

point. After entering the PIN, press the [►] button. If

the PIN is in use by another device, select [REFRESH]

to obtain a new PIN and enter it into the access point.

After entering the PIN, press the [►] button.

If you choose PBC, a screen will appear prompting

to press [►] button. After pressing the [►] button you

have two minutes to locate and press the Push Button

on your access point to connect to the TV.

9. Press the [MENU] button to return to the previous menu.

10. Select Connection Test to check the Internet connectivity.

Advanced Features

5. Select a folder and click “OK”.

6. Click “Close” to close the dialog.

1. Click “Library” and move the cursor to select “Media

Sharing...” as shown in the following screen shot.

2. In the Media Sharing dialog box, select the Share my

media check box and click “OK”.

3. After turnnig on media sharing, you need to select the

devices that should have access to your Player library. An

equipment icon will appear on the white area if the DLNA

Settings have been correctly set. Select a device and

then click “Allow” as shown in the following screen shot.

4. Then the TV can access to the shared files in the

computer.

For information about how to customize what media you

share with the device, see "Change settings for sharing

media" in Windows Media Player Help.

Setting to Share Files

Advanced Features

Network Function

NOTICE

To access Internet streaming video services, please note

the follow requirements.

1. Use of Internet services requires a working broadband

Internet connection (1 to 2 Mbps for SD video, 2.25 to 4.5

Mbps for HD video and 4.5 to 9 Mbps for 1080p and 3D

video.).

2. Internet-based services are not provided by Hisense,

may change or be discontinued at any time and may be

subject to restrictions imposed by your Internet service

provider. The quality, functionality, or availability of such

services may be affected by the capacity of your Internet

connection. Use of video-on-demand and other Internet

services may require the creation of a separate account

through a computer with internet access.

3. Certain services may not be available for this TV model.

4. Video-on-demand and other Internet services may require

payment of one-time and/or recurring charges.

5. You are solely responsible for any charges incurred as a

result of using Internet-based content, including, without

limitation, communications charges for the provision of

Internet or network services and any charges incurred

for third-party Internet content services, such as video on

demand or subscription services. All third-party services

are provided in accordance with whatever terms and

conditions are established between such third-party

providers and you.

6. HISENSE MAKES NO REPRESENTATIONS OR

WARRANTIES ABOUT THE CONTENT, AVAILABILITY

OR FUNCTIONALITY OF THE VUDU SERVICE OR

OTHER INTERNET DELIVERED THIRD-PARTY

SERVICES AND DOES NOT WARRANT THAT ANY

OF THEM WILL BE UNINTERRUPTED, ERROR FREE

OR SATISFACTORY. ANY IMPLIED WARRANTY,

INCLUDING BUT NOT LIMITED TO ANY IMPLIED

WARRANTY OF MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE OF ANY THIRD PARTY

CONTENT OR SERVICE, IS EXPRESSLY EXCLUDED

AND DISCLAIMED. UNDER NO CIRCUMSTANCES

WILL HISENSE BE LIABLE IN CONTRACT, TORT OR

UNDER ANY OTHER THEORY FOR ANY DAMAGES

ARISING OUT OF OR IN CONNECTION WITH YOUR

USE OF ANY CONTENT OR SERVICE PROVIDED

BY ANY THIRD PARTY, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES.

Operational buttons

Button Description

Press to launch VUDU Movies App directly.

Open the HiSmart Hub with links to various

Internet Services.

Open the digital multimedia player.

Press to launch YouTube App directly.

Open the menu.

Close the menu.

Return to the previous menu.

▲/▼/◄/► Navigate Up / Down / Left / Right or adjust

OSD settings.

Confirm selections.

Press to launch NETFLIX App directly.

Display the TrickPlay screen and fast

reverses playback.

Display the TrickPlay screen and fast

forwards playback.

Play the previous one.

Play the next one.

Pause playback. Press the button to return

to playback.

Stop playback and display the file title

screen.

Advanced Features

1. Press the [Hi-Smart] button to display Home menu.

2. Press [◄/►/▲/▼] button to select the interface you

want to view and press [ENTER] to enter the following

description.

No Interface description

①Launcher Bar (Movies/Apps/HiMedia)

②Functional application

③Advertising

④Network (Display or set the network status.)

3. Press [EXIT] button exit the home mode.

Using the Home Menu

AccuWeather

Display VUDU recommend newest movies information.

Press the [◄/►] button select the movie and press enter

to confirm.

Brief introduction

Apps contains all pre-loaded applications of the TV.

Operation introduction

Press the [▲/▼/◄/►] button select the app and press

[ENTER] to confirm.

Movies

Apps

Brief introduction

Operation introduction

Brief introduction

This application provides local and international weather

forecasts, world class weather radar plus up-to-date

weather reports and current conditions.

Operation instructions

AccuWeather.com®10/10

21℃

Sydney

Mostly Cloudy

5 24MPH

2:28 PM Updated

Today

1/29/2013

20/28℃20/27℃20/27℃20/29℃20/29℃20/26℃

1/30/2013 1/31/2013 1/32/2013 1/33/2013 1/34/2013

Wednesday

Del this city Add a city ˚C/˚F City List Change Set default

Saturday SundayThursday Friday

1. Press the [◄/►] buttons to move the cursor to select

service items in AccuWeather screen and the [ENTER]

button to confirm.

2. To use other features, press the button shown in the help

bar.

3. Press the [Return] button to return to the upper menu, or

the [Exit] button to close the App.

YouTube

Brief introduction

The YouTube app allows you to watch original videos,

music videos, feature length movies, previews and trailers

on your TV screen. Search or browse recommendations

with the TV remote.

Operation instructions

To activate your YouTube account for your TV:

Select "Sign in" and "Settings" from the toolbar on the

left side of the application, then go to www.youtube.com/

activate and enter the code you see on the TV screen.

While you enter the code the screen should remain

open, otherwise the code will no longer be valid. Once

completed your account will be activated and you will be

signed in.

To control YouTube from your tablet or smartphone:

Please first check if your mobile device supports YouTube

TV and use the same network connection. To pair your

device to the YouTube screen, you will be prompted

to go to www.youtube.com/pair on your mobile device.

The screen guide to "Pair with TV" will appear. Enter the

pairing code or enter the value of the scanned QR code

on the SmartTV. While you enter the code the screen

should remain open, otherwise the code will no longer

be valid. Select a name for your device then click "Add

TV". Once complete, the YouTube app will show that your

mobile device has been paired. You can now select a

video to watch on YouTube TV using your mobile device.

Advanced Features

VUDU Movies

VUDU is an on-demand service that offers high-definition

movies via the web.

To enjoy movies, please register and log in to your account.

To access Vudu HD Movies: You can access the VUDU HD

Movies by the following method:

1. Press the [Hi-Smart] button to display home menu.

2. Press [◄/►] button to select the VUDU HD Movies icon

and press [ENTER] to enter it, or press [VUDU] button to

enter directly.

3. Select the Sign Up Now icon on the VUDU HD Movies

interface, and press [ENTER] to enter.

4. Enter your email address to start your VUDU experience.

(Refer to “How to Input the Email Address” on page 23.”)

5Press [▲/▼/◄/►] button to move the cursor to select

service items in the VUDU HD Movies home page, and

press [ENTER] button to confirm.

6. While watching a movie, press [ENTER] button to display/

exit the tool bar, press [◄/►] button to select the function

icon, and press [ENTER] button to confirm.

7Press [RETURN] button to return the upper menu, or

press [EXIT] button to close the menu.

Brief introduction

Operation instructions

How to Input the Email Address

Tool Bar

1Press [ENTER] button to enter and press [◄/►] button to

select the chapter.

2Stop playback.

3Fast backward. Press [ENTER] to select the backward

speed. You can press [ ] button to achieve the function.

4Play/Pause. You can press [►II] button to play/pause

directly when there is no control bar on the screen.

5Fast forward. Press [ENTER] button to select the forward

speed. You can press [ ] button to achieve the function.

6Progress bar. The progress bar when playing.

7Press [ENTER] button to select the movies quality HDX, HD

or SD.

1. Press [▲/▼/◄/►] button to move the cursor to the

address bar and press [ENTER] button to confirm.

a b c d e f g h i j k l m

n o p q r s t u v w x y z

0123456789@.com

Symbols Space Shift

Enter email address

Back Done

Enter email address

Enter email address to begin enjoying VUDU!

3. Press [▲/▼/◄/►] button to move the cursor to the

characters you want to select and then press [ENTER]

button to confirm.

If you want to delete one character, move the cursor to

Back key and press [ENTER] button to confirm.

4. Move the cursor to Done key and press [ENTER] button

to confirm if you have completed the address input. Then

the new address will appear on the address bar.

2. Press [ENTER] button to display the keyboard.

There are some shortcuts on the bottom of the keyboard

so that you can input part of the address often used

directly.

Other keys are used as the keyboard of your computer.

Brief introduction

VUDU Apps

The applications platform for connected TVs.

VUDU Apps provides customers with access to a wide

range of Internet services and applications including

streaming video, music on demand, photo browsing,

social networking and more.

VUDU Apps supports the development of responsive

apps designed specifically for use on home HD

televisions.

VUDU Apps uses a unique, cloud-based architecture

optimized for consumer electronics devices, including

delivering the latest applications to consumers without

the need for software downloads or frequent firmware

updates.

Operation instructions

You can access the VUDU Apps by the following methods:

1. Press the [Hi-Smart] button to display home menu.

2. Press [◄/►] button to select the VUDU Apps icon and

press [ENTER] to enter it.

3. Press [◄/►/▲/▼] button to select the widget you want to

access, and press [ENTER] to enter it.

4. You can press [RETURN] to return the upper menu or

press [EXIT] button to close the Widgets display.

0:00:56 0:02:32

1 2 3 4 5 67

HDX

Advanced Features

Netflix

Netix unlimited membership required.

Instantly watch thousands of TV episodes & movies

streaming over the Internet from Netflix. Unlimited

membership required.

NOTES

For more information on Netflix visit http://www.netflix.

com/help or login to your Netflix account and click “Help”

at the top of the page.

Picture quality depends on the network speed and

original bit rate.

Illustrations are examples and may differ from the actual

Netflix screens. The display and operations may change

as a result of a software update. Use Netflix without

configuring a proxy server. Part or all of Netflix may not

be available when connecting to the Internet via a proxy

server.

Operation instructions

1. Press the [Hi-Smart] button to display home menu.

2. Press [◄/►] button to select the Netflix icon and press

[ENTER] to enter it, or press [NETFLIX] button to enter

Netflix website directly.

3. Input Email and Password in following window to sign in.

(Refer to “How to Input the Email Address” on page 23)

4. Press [▲/▼/◄/►] button to move the cursor to select

service items in the Netflix home page, and [ENTER]

button to confirm.

5. While watching a movie, press operational buttons to

control the movie.

6. Press [RETURN] button to return the upper menu, or

press [EXIT] button to close the menu.

Brief introduction

Vimeo

Vimeo App provides a variety of HD video. All these video

are mainly divided into two parts: Featured Video and

Categories Video which includes Activism & Non Profits,

Animation &Motion Graphics, Art, Comedy, Education & DIY,

Everyday Life, Experimental, Films, HD, Music, Products &

Equipment, Science & Tech, Sports and others.

When you sign in this App , you can bookmark you favorite

movie and watch the movie last watched.

1. You can choose the movie you like to watch in Featured

and Categories in home page.

2. If you want to sign in vimeo , please choose Setting.

3. After signing in vimeo, you can save your favorite video

to My Stuff or Watch Later.

4. Choose Search to search the name of movie or music

you love.

5To use other features, press the button showed in the

help bar.

6Press [RETURN] button to return to the upper menu, or

[EXIT] button to close the App.

Brief introduction

Operation introduction

Advanced Features

Pandora is a personalized radio service that streams music

on your TV. Just start with the name of one of your favorite

artists, songs, comedians, or composers and Pandora will

create a custom station that plays similar tracks. Pandora

features hundreds of music and comedy genre stations.

Create up to 100 stations so you can easily switch between

favorites.

For enjoying more movies, please register and log in to your

account.

1. Press the [Hi-Smart] button to display home menu.

2. Press [◄/►] button to select the Pandora icon and press

[ENTER] to enter it.

3. Input Email and Password in following window to sign in.

(Refer to “How to Input the Email Address” on page 23)

4. Press [▲/▼/◄/►] button to move the cursor to select

service items in the Pandora home page, and [ENTER]

button to confirm.

5. Press [RETURN] button to return the upper menu, or

press [EXIT] button to close the menu.

Pandora

Brief introduction

Operation introduction

With Picasa you can explore featured photos in Google

Picasa Web Album, also you can search your favorite photos

in Google Picasa Web Album. If you have already had a

Google Picasa account, you can enjoy your private photos

stored in Google Picasa Web Album.

1. Press the [Hi-Smart] button to display home menu.

2. Press [◄/►] button to select the Picasa icon and press

[ENTER] to enter it.

3. Press [▲/▼/◄/►] button to move the cursor to select

service items in Picasa screen and [ENTER] button to

confirm.

4. To use other features, press the button showed in the

help bar.

5. Press [RETURN] button to return to the upper menu, or

[EXIT] button to close the App.

Picasa

Brief introduction

Operation introduction

Twitter

Operation introduction

1. Press the [Hi-Smart] button to display the home menu.

2. Press [◄/►] button to select the Twitter icon and press

[ENTER] to enter it.

3. Input Email and password in the following window to sign

in.

4. Press [▲/▼/◄/►] button to move the cursor to select

service items in the Twitter home page, and [ENTER]

button to confirm.

5. Press [ENTER] button to return the upper menu, or press

[EXIT] button to close the menu.

Advanced Features

Opera

Brief introduction

The opera browser allows you to browse any URL, edit

or delete folders, add bookmarks and select websites

from the "Favorites" folder.

Operation instructions

How to enter the Opera Browser

1. Press the [Hi-Smart] button to display the home menu.

2. Press the [◄/►/▲/▼] buttons to select the opera icon

and press the [ENTER] button to enter it.

3. Then the default interface will appears on the screen.

There are some function icons on the bottom of the

screen:

21 3 4 5 6 7 9 10

8 Address bar

The function of the buttons on the screen:

1. Main page.
