Hitron TECHNOLOGIES CGNM2252 Wireless Cable Gateway User Manual
Hitron TECHNOLOGIES Wireless Cable Gateway
User Manual
Read me
first!
QUICK START GUIDE
HITRON
Connect to the network
CGNM-3552-ROG
Set up your wireless network
1
STEP
Check the box contents
1 CGNM-3552-ROG
QUICK START GUIDE
1 POWER ADAPTOR
2
STEP
Connect to the cable outlet
Use the coaxial (not included) to connect the device’s CABLE
connector to the cable outlet.
3
STEP
Connect to the power outlet
Use the power cord provided to connect the POWER port to power
outlet.
5
STEP
Connect with wireless devices (optional)
4
STEP
Connect to an Ethernet-equipped device (optional)
Use the Ethernet cable provided to connect one of the LAN ports
to an Ethernet-equipped device.
You can connect your wireless devices with the correct SSID
and Passphrase. If you have not changed them, the default
values are indicated on the sticker on the rear of the unit.
Connect options
6
STEP
User configuration
Your gateway has a configuration interface allowing complete
control over the device’s behavior. In a Web browser, enter
192.168.0.1 in the address bar. In the screen that displays, enter
cusadmin as the username and password as the password.
2.4GHz
SSID:XXXXXXXXXXXX
PassPhrase:XXXXXXXXXXXX
5GHz
SSID:XXXXXXXXXXXX
PassPhrase:XXXXXXXXXXXX
Wireless
Devices
Cable
Computer
Power Adaptor
P/N:0440010208N0(2A)
Safety Warnings
COPYRIGHT © 2015 HITRON TECHNOLOGIES, INC.
Setup Complete
Congratulations! You have successfully set up your gateway. If you have any problems, see the sections belowfor help identifying the problem.
IP addresses
If your gateway is successfully connected to the network (see LED display) but you cannot access the Internetfrom a connected computer, your computer’s IP
Address may be set up wrongly. In your computer’s control panel either ensure that the computer is configured to receive an IP address automatically
(recommended) or ensure that it has a static IP address in the range 192.168.0.10~192.168.0.254. Formore information, consult your Operating System’s document.
LED display
Connec
t power
Green-Blinking
Green-Steady
Blue-Steady
Off
The gateway is receiving power.
Not powered.
Green-Steady
Off
The gateway is searching for the downstream
frequency.
Downstream frequency is locked. (1 channel only)
Downstream frequency is locked. (channel bonding)
Not scanning
Power
Downsteam
Green-Blinking
Green-Steady
Blue-Steady
Off
The gateway is searching for the upstream
frequency.
Upstream frequency is locked. (1 channel only)
Upstream frequency is locked. (channel bonding)
Not scanning
Green-Blinking
Green-Steady
Off
Registration is in progress with cable company’s
head-end.
Gateway is operational for data transmission.
Gateway is offline.
Upsteam
Green-Blinking
Green-Steady
Off
The 5GHz wireless network is enabled, and data is
being transmitted or received.
The 5GHz wireless network is enabled, and no
data is being transmitted or received.
The 5GHz wireless network is not enabled.
Green-Blinking
Green-Steady
Off
The 2.4GHz wireless network is enabled, and data
is being transmitted or received.
The 2.4GHz wireless network is enabled, and no
data is being transmitted or received.
The 2.4GHz wireless network is not enabled.
Wireless
(2.4GHz)
Green-Blinking
Green-Steady
Off
A device is connected to one of LAN ports and is
transmitting or receiving data.
A device is connected to one of LAN ports but is
not transmitting or receiving data.
No device is connected to one of the LAN ports.
LAN
Wireless
(5GHz)
Green-Blinking
Green-Steady
Off
A USB device is connected to one of the USB ports,
and is transmitting or receiving data.
A USB device is connected to one of the USB ports,
and is not transmitting or receiving data.
No USB device is connected to eigher USB port.
USB
Online
FCC Statement:
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
this equipment.
This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor environment only.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For product
available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible.
This device and it's antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with
FCC multi-transmitter product procedures.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and
operated with minimum distance 21cm between the radiator & your body.
IC Statement:
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device
may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible.
Pour les produits disponibles aux États-Unis / Canada du marché, seul le canal 1 à 11 peuvent être exploités. Sélection d'autres canaux n'est pas
possible.
This device and it's antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance
with IC multi-transmitter product procedures.
Cet appareil et son antenne (s) ne doit pas être co-localisés ou fonctionnement en association avec une autre antenne ou transmetteur.
The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite
systems.
Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de
brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux.
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 26cm between the radiator & your body.
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être
installé et utilisé avec un minimum de 26cm de distance entre la source de rayonnement et votre corps.
WARNING
Risk of electrical shock. Do not expose the device to water or moisture.
The device is a high-performance communications device designed for home and office environments. Do not use the device outdoors. Keep the device in an environment between 0°C ~ 40°C (32°F ~104°F). To avoid overheating, do NOT place any
object on top of the device. Do not restrict the flow of air around the cable modem. The manufacturer assumes no liabilities for damage caused by any improper use of the device.
DISCLAIMER
The manufacturer assumes no liabilities with respect to the contents of this document. The manufacturer also reserves the right to revise this document orupdate the content thereof without any obligation to notify any person of such revisions or
amendments. Specifications subject to change without notice.
CAUTION
The cable distribution system should be grounded (earthed) in a accordance with ANS/NFPA 70, the National Electrical Code (NEC), in particular Section 820.93, Grounding of Outer Conductive Shield of a Coaxial Cable.
