User Manual
Wi-Mic
HB-1303
User Manual
1
1. Power button
2. Mute button
3. Charging/Power LED
4. External Mic port
5. Internal Mic
6. Hook for neck loop
7. Reset button
8. Charging port for Base Unit
9. Micro-USB charging port
10. Wireless pair button
Wi-Mic
123
6
5
4
7 8 9
Identifying parts
10
2
Charging the Wi-Mic
1. Turn o the Wi-Mic.
2. Plug the micro-USB charger into micro-USB charging port of the Wi-Mic. RED charging/power
LED lights up during charging.
(Optional: The Wi-Mic can be charged when placed it into the charging port of the Base Unit.)
3. The charging/power LED is o when charging is completed.
3
Basic operation
Power On
Press and hold the power button for 2 seconds until GREEN power LED lights up.
Power o
Press and hold the power button for 2 seconds until power LED is o.
Mute On
To mute the internal/external Mic, press the mute button once. The GREEN power LED is ashing when Wi-Mic is in mute mode.
Mute o
To cancel the mute status of Wi-Mic, press mute button once. The GREEN power LED lights up and stops ashing.
4
Pairing with Personal Audio Enhancer (PAE-300)
1. Turn on both Wi-Mic and PAE-300.
2. First, press the TV function button on all of the PAE-300 needed for wireless pairing to set
them into TV mode. Then, press and hold the Wireless Pair Button on those PAE-300 until the
GREEN power LED on those PAE-300 is ashing.
3. Second, press and hold the Wireless Pair Button of the Wi-Mic until the GREEN power LEDs on
both PAE-300 and Wi-Mic are fast ashing for pairing.
4. The GREEN power LEDs on both Wi-Mic and PAE-300 are lit solid when the pairing succeeds.
Note:
please follow the above procedures; otherwise, it will result in pairing failure.
5
How Wi-Mic Works
• Spokesman can speak to the internal mic on Wi-Mic.
The voice of the spokesman will go through the
Wi-Mic, and then is transmitted to all PAE-300 which
are paired with the Wi-Mic. The PAE-300 users are able
to listen to the spokesman’s voice through the
PAE-300 headset.
• External mic can be used by inserting it into the
external mic port on the Wi-Mic. Spokesman can
speak to the external mic instead of the internal mic
without holding the Wi-Mic all the time.
Wi-Mic
Wireless
PAE-300
6
Reset Wi-Mic
When the Wi-Mic cannot be operated in any situation, press the reset button by a small pin object
to reset the Wi-Mic.
www.vitasound.com
info@vitasound.com
1-877-967-0742
