Honeywell ZIG100ND Zigbee Module ZIG100ND User Manual
Honeywell International Inc. Zigbee Module ZIG100ND
User manual
METROLOGIC INSTRUMENTS, INC.
Zigbee Module with Mesh Network
Model No.: ZIG100ND
FCC ID:LW5ZIG100ND
IC:3114A-ZIG100ND
Communication User Guide
Feb 29, 2008.
Copyright@ 2008 Metrologic Instruments, Inc. All rights reserved.
1. Introduction
This document describes how to communicate with Metrologic ZigBee kits
which have been designed to provide a low cost, low power IEEE802.15.4
wireless mesh networking solution.
2. Command conventions
To simplify the communication with Metrologic ZigBee kit, a Reg-style set is
used.
Each command with 80 bytes size must be preceded by the <ST> prefix, then
CMD_TY and Form Data, the end by <ET> suffix. Any command not following
this pattern is either not accepted by the module or will cause a timeout in
response.
3. Register Map
Registers List and Default Values
RO = read-only; R/W = programmable; - = undefined
Address Description Data Access Default
(hex)
0 Firmware Version Major RO 0x00
1 Firmware Version Minor RO 0x00
2 Hardware Version Major RO 0x00
3 Hardware Version Minor RO 0x00
4 Power Level
0x00 – Low
0x01 – Middle
0x00
5 Class ID Major RW 0x00
6 Class ID Minor RW 0x00
7 Operating Mode
0x00 – Short Sleep Mode
0x01 – Long Sleep Mode
RW 0x00
8
Property
Bit 0:Background
0 – Black
1 – Gray
Bit1~3:Color Bit Count
000 – 1 bit
001 – 8 bits
010 – 16 bits
100 – 24 bits
0x00
9 ~ 40 0x00
41~63 Reserved 0x00
64 ~ 255 0x00
Integrators Responsibility
1) The Zigbee Module has a limited module approval and should not be changed
without recertification.
2) The MPE calculations need to be checked based on the location of the unit with
reference to the user. See applicable FCC/IC guidelines governing MPE and SAR
testing.
3) The end product needs to included “ This product contains FCC ID
LW5ZIG100ND/ IC:3114A-ZIG100ND
4) All applicable FCC/IC warnings need to be in the end users manual.
FCC & IC RF Radiation Exposure Statement for both module and OEM integrator:
1. This Transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
2. This equipment complies with FCC & IC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator and your body.
IC statements:
Operation is subject to the following two conditions: (1) this devicemay not cause
interference, and (2) this device must accept any interference, including interference that
may cause undesired operation of the device.
