User’s manual-This cleaner should only be

used for its intended purpose as described in

these instructions. Ensure that these are fully

understood before operating this appliance.

Only use attachments recommended or

supplied by Hoover.

When using cleaning tools ensure that the

cleaner is kept in the upright (parked)

position.This will avoid possible damage to

the carpet or floor covering.When cleaning

stairs DO NOT position the cleaner above

you.

STATIC ELECTRICITY. Some carpets can

cause a small build up of static electricity.Any

static discharge is not hazardous to health.

DO NOT use your cleaner out of doors or

on any wet surface or for wet pick up.

Air freshener pads must be kept away from

children. DO NOT suck, swallow or chew air

freshener pads.

Keep hands, feet, loose clothing and hair away

from rotating brushes.

DO NOT pick up hard or sharp objects,

matches, hot ashes, cigarette ends or other

similar items.

DO NOT pick up flammable liquids such as

cleaning fluids, petrol etc. or their vapours.

Aerosol sprays may be flammable. DO

NOT spray near cleaner.

SUPPLY CORD. D

ONOT

run over the

supply cord when using your cleaner or

remove the plug by pulling on the supply

cord.

FAULTS. DO NOT continue to use your

cleaner if it appears to be faulty. If the supply

cord is damaged stop using the cleaner

IMMEDIATELY.The supply cord must be

replaced by an authorised Hoover service

engineer to avoid a safety hazard.

AFTER USE. Switch the cleaner off and

remove the plug from the electricity supply.

Always switch off and remove the plug before

cleaning the appliance or attempting any

maintenance task.

HOOVER SERVICE. To ensure the continued

safe and efficient operation of this appliance

we recommend that any servicing or repairs

are only carried out by an authorised Hoover

service engineer.

IMPORTANT SAFETY REMINDERS

Use only HOOVER paper bags and filters PurePower

Congratulations on the purchase of your

new Hoover PurePower.

This highly advanced machine - with new

technology unique to Hoover - makes

cleaning easier and more efficient.

You’ll find it kinder to your carpets - and

to you!

Please take the time to read this manual

carefully.

You’ll be ready to make the most of the

special features only the new Hoover

PurePower can offer!

WARNING!

ELECTRICITY CAN BE

EXTREMELY DANGEROUS

This appliance is double insulated and must not be

earthed.

The plug is fitted with a 13 amp fuse.

IMPORTANT:The wires in the mains lead

are coloured in accordance with the

following code:

Blue - NEUTRAL

Brown - LIVE

HOOVER SERVICE 08705 400 600

HOOVER SPARES 01204 556 111

-2-

Pure Power-ok 2004.4.16 10:55 AM Page 2

Insert handle into body of cleaner. Slide into

position.

Ensure handle is flush with body of cleaner.

Tighten large screw (pre-fitted to handle

upper hole). Insert small screw into handle

lower hole and tighten.

Locate hose end, turn clockwise to lock.

Locate hose retainer on lower hose support.

Position hose over hose supports

Push handgrip firmly into socket.

Clip tools to back of cleaner.

Check that paper bag is fitted, if not fit new

one (See ‘Changing the paper bag’ overleaf).

The carpet height selector raises or lowers the height of

the nozzle.The nozzle height will not change until the

handle is released.Try various settings until you get the

best results for each of your carpets.

Ensure that cleaner

is in the upright

(parked position).

Slide knob to position

best suited to depth

of carpet pile.

Using this cleaner for

carpets with pile greater than

30mm is not recommended.

Unlock the handle by pressing

down on pedal with foot.

For cleaning under low

furniture and some

maintenance tasks

simply press

pedal again and

lower handle

to floor.

PREPARING TO USE YOUR CLEANER CARPET HEIGHT SELECTOR

!IMPORTANT: When cleaning hard floors

such as vinyl or linoleum, move the “Height

Right” selector knob to the hard floor

position. Failure to do so may cause

damage to the floor surface.

HANDLE LOCK RELEASE

POWER SWITCH SETTINGS

Switching on and off

Push bottom of switch to switch on.

Push top of switch to switch off.

2

1

3

4

5

1

2

3

4

5

-4-

Pure Power-ok 2004.4.16 10:55 AM Page 4

This cleaner is unlikely to become blocked, except

by overfilling of the dust container or accidentally

picking up large solid objects. Clearing a blockage is

simple.

If cleaning tools were in

use, check cleaning tool

and extension tube first.

Next check hose

handgrip; to remove grip

ribbed ring as shown,

turn in direction of

arrow and ease apart.

To check the hose, stretch it

to full length and switch on

the cleaner; the suction will

dislodge most obstructions.

If this is unsuccessful, switch

off and unplug the cleaner.

Remove the hose by turning

it anti-clockwise as shown.

Detach cassette and remove

blockage.

For blockages in cleaner base:

1.Turn the cleaner

over and check that

the brushes are

free to rotate.

2. Check for a

blockage in hose

socket. Use a

piece of wire or a

blunt flexible rod

to remove any

obstructions.

!IMPORTANT: Switch the cleaner off

and remove the plug from the

electricity supply before dismantling

cleaner.

CLEARING A BLOCKAGE

IMPORTANT: Switch cleaner off and

remove plug from electricity supply before

checking the brushes or removing hood.

12

CHANGING BELT OR BRUSHES

Refit brush assembly

•Hold the brush assembly

and stretch the belt until

brush mountings slot down

into the cleaner housing

Rotate the brush to ensure

free movement of the belt.

4

a

b

-6-

If your cleaner is not picking up efficiently, the

belt or brushes (or both) may need replacing,

but first make sure you have:

•Emptied the dust container

•Cleaned filters

•Checked for blockages

Replace belt

•Loop the new belt around

the motor spindle

then around the brush

channel.

2

1

Refit hood

•Refit hood, ensuring the

lugs along the front of

hood are located in the

slots along the front edge

of baseplate.

•Secure hood, using screws

A and B.

Refit carpet-care control

knob

•Ensure the raised face (T) is

towards the front of the

cleaner.

Remove hood

•Prise off carpet-care control knob

•Remove hood screws A and B

Lift off hood

Remove brush assembly

•Inspect belt for signs of wear.

•To remove, pull brush cleaner assembly

upwards out of cleaner housing. Remove belt

from motor spindle then from brush assembly.

5

3

Removing a blockage from the ‘Pet hair remover’

(Certain models only)

Open clip and lift cover

to remove blockage.

Page_06.ai 22/3/05 3:36:04 pm

C

M

Y

CM

MY

CY

CMY

K

Dust_Manager_6.eps 19/10/05 17:16:31Dust_Manager_6.eps 19/10/05 17:16:31

User checklist

If your cleaner is not working properly run through the

following checklist.

1. Is there a working electricity supply to the cleaner?

Check with another electrical product.

2. Is the bag full or choked with fine dust?

3. Is the hose blocked?

4. Is there a blockage in the cleaner base?

5. Are the filters blocked?

6. Is the nozzle height set correctly?

7. Are the brushes rotating correctly?

8. Has the cleaner overheated? If so, it will take about 30

minutes to reset.

If there is any doubt call your local Hoover Service Office for

advice. They may be able to assist you over the telephone.

WARNING!

A thermal cut out switches off the cleaner to prevent

overheating if it is used when full or there is a blockage or

dirty filters. If this should happen switch off, unplug and

correct the fault.

It will take about 30 minutes for the cut out to

automatically reset.

Bag check indicator

(certain models only)

For an accurate reading of the bag check indicator ensure that:

●flexible hose handgrip is pushed firmly into

its socket.

●On Variable Power models control is set to maximum.

The continuous red light of the bag check indicator will

come on if:

●Bag needs replacement. If picking up fine powders more

frequent replacement will be required even although the bag

does not appear well filled.

●Filters are dirty.

●There is a blockage.

The light may flicker on and off during normal use.

IMPORTANT: Do not run cleaner

over the supply cord as this could

damage the supply cord insulation.

Hoover Limited

Pentrebach

Mer thyr Tydfil

Mid-G lamorgan

C F48 4TU

C opyright 2001

Registered Trade Mark

Part no: 05655202
