HP VMware Utilities User Guide

VMware ESXi 5.0 U2 and 5.0 U3 for September

2013

HP Part Number: 670557-407

Published: September 2013

Edition: 9

© Copyright 2007, 2013 Hewlett-Packard Development Company, L.P.

Confidential computer software. Valid license from HP required for possession, use or copying. Consistent with FAR 12.211 and 12.212, Commercial

Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under

vendor's standard commercial license. The information contained herein is subject to change without notice. The only warranties for HP products

and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as

constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. UNIX is a registered

trademark of The Open Group.

Acknowledgments

Microsoft Windows is U.S. registered trademarks of Microsoft Corporation.

UNIX is a registered trademark of The Open Group.

Contents

1 Introduction...............................................................................................4

Installing offline bundles on an ESXi 5.0 and updates host using vSphere CLI 5.0 esxcli utility.............4

Prerequisites........................................................................................................................4

Installing offline bundles on an ESXi 5.0 and updates host using VMware vCenter Update

Manager.................................................................................................................................4

HPONCFG utility......................................................................................................................5

HPONCFG command-line syntax...........................................................................................5

HPONCFG return codes.......................................................................................................6

HPONCFG command file contents.........................................................................................6

Obtaining an entire configuration..........................................................................................6

Obtaining a specific configuration.........................................................................................7

Setting a configuration.........................................................................................................8

HPONCFG command-line examples.......................................................................................8

HPBOOTCFG utility..................................................................................................................9

HPBOOTCFG command-line syntax........................................................................................9

HPBOOTCFG ESXCLI syntax..................................................................................................9

HPBOOTCFG return codes..................................................................................................10

HPBOOTCFG command-line examples..................................................................................10

HPSSACLI utility......................................................................................................................10

HPSSACLI command-line syntax...........................................................................................10

HPSSACLI ESXCLI syntax.....................................................................................................11

HPTESTEVENT utility................................................................................................................13

HPTESTEVENT command-line syntax.....................................................................................13

HPTESTEVENT ESXCLI syntax...............................................................................................14

HPTESTEVENT return codes.................................................................................................14

HPTESTEVENT command-line examples.................................................................................14

Generating an ADU report (diagnostics) from within HPSSACLI for ESXi 5.0 and updates.................14

2 Support and other resources......................................................................16

Contacting HP .......................................................................................................................16

Before you contact HP........................................................................................................16

HP contact information.......................................................................................................16

Subscription service............................................................................................................16

Documentation feedback....................................................................................................16

New and changed information in this edition ............................................................................17

Related information.................................................................................................................17

Documents........................................................................................................................17

Websites..........................................................................................................................17

Typographic conventions.........................................................................................................17

Index.........................................................................................................19

Contents 3

1 Introduction

This section provides information about the utilities supported on VMware ESXi 5.0 and updates.

The following utilities are supported on VMware ESXi 5.0 and updates host:

•HPONCFG — Command line utility used for obtaining and setting ProLiant iLO configurations.

•HPBOOTCFG — Command line utility used for configuring ProLiant server boot order.

•HPSSACLI – Command line utility used for configuration and diagnostics of ProLiant server

SmartArrays.

•HPTESTEVENT – Command line utility used to request the HP Insight Management WBEM

Providers generate the Informational Test Indication with ProviderName “HP Test” and EventID

1, and the CPQ SNMP test trap with OID 1.3.6.1.4.1.232.11.2.8.1.0.11003.

Installing offline bundles on an ESXi 5.0 and updates host using vSphere

CLI 5.0 esxcli utility

This section provides information about installing the VMware ESXi 5.0 and updates offline bundles

on the ESXi host. You can use the esxcli utility in conjunction with offline bundles or with a depot.

Prerequisites

Install VMware vSphere Command-Line Interface 5.0(vSphere CLI) on Microsoft

Windows or Linux system. For information about importing or installing the vSphere CLI 5.0,

see the VMware vSphere Command-Line Interface Installation and Reference Guide available at:

http://pubs.vmware.com/vsphere-50/topic/com.vmware.vcli.ref.doc_50/vcli-right.html.

To install the offline bundle on an ESXi host, perform the following steps:

1. Power off any virtual machines that are running on the host, and set the host into maintenance

mode.

2. Transfer the bundle onto the ESXi host local path, or extract it onto an online depot.

3. Install the bundle on the ESXi host using any of the following command line:

•Install remotely from client, with offline bundle available as online depot

~# esxcli -s <server> -u root -p mypassword software vib install

-d <depotURL/bundle-index.xml>

•Install remotely from client, with offline bundle available on ESXi host

~# esxcli -s <server> -u root -p mypassword software vib install

-d <ESXi local path><bundle.zip>

•Install from ESXi host, with offline bundle available on ESXi host

~# esxcli software vib install -d <ESXi local path><bundle.zip>

4. After the bundle is installed, reboot the ESXi host to initialize the utilities.

Installing offline bundles on an ESXi 5.0 and updates host using VMware

vCenter Update Manager

The offline bundle can also be installed from VMware vCenter Update Manager as a patch. For

more information and detailed instructions, see the VMware vCenter Update Manager Administration

Guide available at:

http://pubs.vmware.com/vsphere-50/topic/com.vmware.vsphere.update_manager.doc_50/

GUID-F7191592-048B-40C7-A610-CFEE6A790AB0.html.

4 Introduction

HPONCFG utility

The HPONFCG utility only supports HP ProLiant 300/500/700/900 Server series, 100 Series

Gen8 servers, and HP ProLiant BL Servers that are listed in the ESXi Server Support Matrix. To visit

the ESXi Server Matrix page, go to www.hp.com/go/vmware and select Certified ProLiants under

Tools/Resource section.

HP offers support for the iLO 2, iLO 3 and iLO 4 features available on ProLiant servers with the

HPONCFG utility.

HPONCFG is an online configuration tool used to set up and reconfigure iLO 2, iLO3 and iLO 4

without requiring a reboot of the server operating system. The utility runs in a command-line mode

and must be executed from an operating system command-line.

Observe the following requirements before using HPONCFG:

•The iLO 2, iLO 3 or iLO 4 Management Interface Driver must be loaded on the server. HPONCFG

displays a warning if the driver is not installed.

•HPONCFG requires minimum iLO 2, iLO 3 and iLO 4 firmware versions. To determine the

minimum firmware version required, see the HP SmartStart Scripting Toolkit Linux and Windows

Editions Support Matrix.

For more information, see the Remote Management website:http://www.hp.com/servers/lights-out

HPONCFG command-line syntax

Use the following format at the command line:

hponcfg -f filename [-l filename] [-v] [-m minFw] -g [-m minFw] -w

filename [-m minFw] -r [-m minFw ] -h -?

The HPONCFG utility can be accessed from the location: /opt/hp/tools.

IMPORTANT: Because the-w argument does not capture certain types of information, such as

the administrator password, data files created with HPONCFG using the-w argument cannot then

be used as input files for HPONCFG, unless they are modified first.

Table 1 hponcfg Command Line Arguments

FunctionArgument

This argument captures complete Management Processor configuration to the

file. This option should be used along with the "-w" option.

-a, --all

This argument Get/Set Management Processor Configuration from the XML

input received through the standard input stream.

-i --input

This argument substitutes variables present in the input configuration file with

the values specified in "namevaluepairs".

-s,--substitute

This argument sets the iLO 2, iLO 3 or iLO 4 configuration based on the

information in the XML input file named filename.

-f, - -file=filename

This argument logs replies to the text log file named filename.-l, - -log=filename

Writes all the responses from iLO 2, iLO 3 or iLO 4.-v, - -xmlverbose

This argument returns the host server name and serial number.-g, - -get_hostinfo

This argument indicates to HPONCFG the minimum firmware level that must be

present in the management device to execute the RIBCL script. If the minimum

-m, - -minfwlevel

level is not met, HPONCFG returns an error without performing any additional

actions.

This argument writes the iLO 2, iLO 3 or iLO 4 configuration obtained from the

device to the XML output file named filename.

-w, - -writeconfig=filename

HPONCFG utility 5

Table 1 hponcfg Command Line Arguments (continued)

FunctionArgument

This argument resets the iLO 2, iLO 3 or iLO 4 to factory defaults.-r, - -reset

These arguments display simple help messages.-h, - -help, - -?

HPONCFG return codes

This section provides description about the return code after running the command.

Table 2 hponcfg return codes

MeaningValue

ERROR: A general system error detected while running HPONCFG-1

Script succeeded.0

Script failed1

ERROR : Unable to shutdown the iLo Channel Interface2

Firmware flash is in progress. Please wait for a while.3

General error detected while checking firmware flash.4

iLO Lights-Out functionality is Disabled.5

Please enable Lights-Out functionality before using this software.

To Enable Lights-Out functionality:

Set iLO Security Override Switch to ON and

Use iLO ROM-based Setup Utility or iLO Browser interface to enable lights-out

functionality.

You are not a root/superuser. Only root/superuser can access the utility.7

ERROR: Please specify firmware level as numeric input9

Could not get status of the Lights-Out Functionality10

ERROR: Failed to capture the configuration13 - 20

If the script itself fails, errors are reported in the log file created by HPONCFG.

HPONCFG command file contents

The hponcfg command can be used to perform the following tasks:

•Obtain an entire configuration

•Obtain a specific configuration

•Set a configuration

Obtaining an entire configuration

The hponcfg command can be used to obtain an entire configuration from an iLO 2, iLO 3 or

iLO 4. In this case, the utility executes from the command line without specification of an input file.

The name of the output file is given on the command line. For example:

/opt/hp/tools # ./hponcfg -w config.xml

In this example, the utility indicated that it obtained the data successfully and wrote it to the output

file as requested. The following is a typical example of the contents of the output file:

<HPONCFG VERSION="1.1">

<!–Generated 04/15/04 15:20:36—>

6 Introduction

<MOD_DIR_CONFIG>

<DIR_AUTHENTICATION_ENABLED VALUE="N" />

<DIR_LOCAL_USER_ACCT VALUE="Y" />

<DIR_SERVER_ADDRESS VALUE=""/>

<DIR_SERVER_PORT VALUE="25"/>

<DIR_OBJECT_DN VALUE=" "/>

<DIR_OBJECT_PASSWORD VALUE=""/>

<DIR_USER_CONTEXT_1 VALUE=""/>

<DIR_USER_CONTEXT_2 VALUE="_"/>

<DIR_USER_CONTEXT_3 VALUE=""/>

</MOD_DIR_CONFIG>

<MOD_NETWORK_SETTINGS>

<SPEED_AUTOSELECT VALUE="Y"/>

<NIC_SPEED VALUE="100"/>

<FULL_DUPLEX VALUE="Y"/>

<IP_ADDRESS VALUE="XX.XXX.XXX.XX"/>

<SUBNET_MASK VALUE="xxx.xxx.xxx.x"/>

<GATEWAY_IP_ADDRESS VALUE="XX.XXX.XXX.X"/>

<DNS_NAME VALUE="ILOD234KJ44D002"/>

<PRIM_DNS_SERVER value="xx.xx.x.xxx"/>

<DHCP_ENABLE VALUE="Y"/>

<DOMAIN_NAME VALUE="americas.cpqcorp.net"/>

<DHCP_GATEWAY VALUE="Y"/>

<DHCP_DNS_SERVER VALUE="Y"/>

<DHCP_STATIC_ROUTE VALUE="Y"/>

<DHCP_WINS_SERVER VALUE="Y"/>

<REG_WINS_SERVER VALUE="Y"/>

<PRIM_WINS_SERVER value="xx.xx.x.xxx"/>

<STATIC_ROUTE_1 DEST="0.0.0.0" GATEWAY="0.0.0.0"/>

<STATIC_ROUTE_2 DEST="0.0.0.0" GATEWAY="0.0.0.0"/>

<STATIC_ROUTE_3 DEST="0.0.0.0" GATEWAY="0.0.0.0"/>

</MOD_NETWORK_SETTINGS>

<ADD_USER

USER_NAME="Administrator"

USER_LOGIN="Administrator"

PASSWORD="">

</ADD_USER>

<ADD_USER

USER_NAME="Landy9"

USER_LOGIN="mandy9"

PASSWORD="">

</ADD_USER>

<RESET_RIB VALUE="Y"/>

</HPONCFG>

For security reasons, the user passwords are not returned.

Obtaining a specific configuration

A specific configuration can be obtained using the appropriate XML input file. For example, here

are the contents of a typical XML input file, get_global.xml:

<!-- Sample file for Get Global command -->

<RIBCL VERSION="2.0">

<LOGIN USER_LOGIN="x" PASSWORD="x">

<RIB_INFO MODE="read">

<GET_GLOBAL_SETTINGS />

</RIB_INFO>

</LOGIN>

</RIBCL>

The XML commands are read from the input file get_global.xml and are processed by the

device:

/opt/hp/tools # ./hponcfg -f get_global.xml -l log.txt > output.txt

HPONCFG utility 7

The requested information is returned in the log file, which, in this example, is named log.txt.

The contents of the log file are shown below:

<GET_GLOBAL_SETTINGS>

<SESSION_TIMEOUT VALUE="30"/>

<ILO_FUNCT_ENABLED VALUE="Y"/>

<F8_PROMPT_ENABLED VALUE="Y"/>

<REMOTE_CONSOLE_PORT_STATUS VALUE="3"/>

<REMOTE_CONSOLE_ENCRYPTION VALUE="N"/>

<PREFER_TERMINAL_SERVICES VALUE="N"/>

<HTTPS_PORT VALUE="443"/>

<HTTP_PORT VALUE="80"/>

<REMOTE_CONSOLE_PORT VALUE="23"/>

<TERMINAL_SERVICES_PORT VALUE="3389"/>

<VIRTUAL_MEDIA_PORT VALUE="17988"/>

<MIN_PASSWORD VALUE="4"/>

</GET_GLOBAL_SETTINGS>

Setting a configuration

A specific configuration can be sent to the iLO 2, iLO 3 or iLO 4 by using the command format:

/opt/hp/tools # ./hponcfg -f add_user.xml -l log.txt

In this example, the input file has contents:

<!–Add user with minimal privileges to test default setting of assigned privileges to 'N'—>

<RIBCL version="1.2"/>

<LOGIN USER_LOGIN="x" PASSWORD="x">

<USER_INFO MODE="write">

<ADD_USER USER_NAME="Landy9" USER_LOGIN="mandy9"

PASSWORD="floppyshoes">

<RESET_SERVER_PRIV value="Y" />

<ADMIN_PRIV value="Y" />

</ADD_USER>

</USER_INFO>

</LOGIN>

</RIBCL>

The specified user will be added to the device.

HPONCFG command-line examples

This section provides sample examples to run the utility.

Table 3 hponcfg command-line examples

DescriptionCommand-line argument

This argument displays help information.hponcfg -h

This argument returns the host server name and serial number.hponcfg -g

To view the command usage options, run the following command:

/opt/hp/tools # ./hponcfg —h

All options supported by the command are listed in the output.

To get the host server name and serial number, run the following command:

/opt/hp/tools # ./hponcfg —g

The following output is displayed:

Firmware Revision = 2.05 Device type = iLO 2 Driver name = hpilo

Host Information:

Server Name: localhost.americas.hpqcorp.net

Server Number: 000000000

To set the minimum firmware level, run the following command:

8 Introduction

/opt/hp/tools # ./hponcfg —m 2

The following output is displayed:

Firmware Revision = 2.05 Device type = iLO 2 Driver name = hpilo

HPBOOTCFG utility

The hpbootcfg utility only supports HP ProLiant 300/500/700/900 Server series, 100 Series

Gen8 servers, and HP ProLiant BL Servers that are listed in the ESXi Server Support Matrix. To visit

the ESXi Server Matrix page, go to www.hp.com/go/vmware and select Certified ProLiants under

Tools/Resource section.

This utility allows an application to set the device for the next subsequent boot of the system.

HPBOOTCFG command-line syntax

Use the following format at the command line:

hpbootcfg [-F -C -H -T] [-S -Q -R -P] [-r -d -n -b]

Table 4 hpbootcfg Command Line Arguments

FunctionArgument

Sets default device as the boot option-D

Sets Floppy Drive as the first boot device for the system boot-F

Sets CD-ROM Drive as the first boot device for the system boot-C

Sets Hard Drive as the first boot device for the system boot-H

Sets Tape Drive as the first boot device for the system boot-T

Sets system configuration utility as the boot device for the current boot-S

Sets quick configuration utility as the boot device for the current boot-Q

Sets ROM-Based Setup Utility (RBSU) as the boot device for the current boot-R

Sets PXE client as the boot device for the current boot-P

Sets remote configuration as the boot device for the current boot-r

Sets remote dial out as the boot device for the current boot-d

Sets remote network as the boot device for the current boot-n

Bypasses F1 / F2 prompts-b

HPBOOTCFG ESXCLI syntax

The hpbootcfg utility is supported by the ESXCLI utility.

To view the command usage options, run the following command:

# esxcli hpbootcfg

The following output is displayed:

Usage: esxcli hpbootcfg {cmd} [cmd options]

Available Commands:

execute execute — hpbootcfg command with options parameter

help — show hpbootcfg help

show — show current hpbootcfg settings

To view the current boot settings, run the following command:

# esxcli hpbootcfg show

HPBOOTCFG utility 9

The following output is displayed:

00 00: Normal Device first, normal boot process

To set the command parameter values, use the "execute" cmd and one of the options listed in

Table 4. The following is an example of the command to set the defaults:

# esxcli hpbootcfg execute -D

The following output is displayed:

00 00: Normal Device first, normal boot process

HPBOOTCFG return codes

This section provides description about the return code after running the command.

Table 5 hpbootcfg return codes

MeaningValue

Indicates success0

Indicates failureNon zero

HPBOOTCFG command-line examples

This section provides sample examples to run the utility.

Table 6 hpbootcfg command-line examples

DescriptionCommand-line argument

This argument displays help information./opt/hp/tools/hpbootcfg -h

This argument sets the default values./opt/hp/tools/hpbootcfg -D

HPSSACLI utility

The HPSSACLI utility supports HP ProLiant 300/500/700 and Blade servers with integrated

SmartArray controllers and option controllers. The utility supports reporting and configuration of

the SmartArray. Configuration includes the ability to create arrays; create, expand, and delete

logical drives and many other advanced operations. The information provided in the guide is

introductory and example focused . For more information, see Configuring Arrays on HP Smart

Array Controllers Reference Guide available at:http://h20000.www2.hp.com/bc/docs/support/

SupportManual/c00729544/c00729544.pdf.

Additional references to HP Smart Storage Administrator guides and white papers are available

at:

http://h20000.www2.hp.com/bizsupport/TechSupport/DocumentIndex.jsp?lang=en&cc=us&

contentType=SupportManual&prodTypeId=18964&prodSeriesId=468780&docIndexId=64179.

HPSSACLI command-line syntax

Using VMware esxcli requires knowledge about the CLI usage. The VMware vSphere command

line documentation is available at: http://www.vmware.com/support/developer/vcli/.

The following is an overview of the ESXCLI command-line format:

# esxcli {namespace} {object} {command} {cmd options} “command-string”

10 Introduction

Table 7 HPSSACLI Command-Line Arguments

FunctionArgument

The esxcli application.esxcli

Each plugin must have an associated namespace which defines any environment or other system

variables required by the application.

namespace

A plugin must have one or more associated objects which defines a single operation.object

Prepares the esxcli target to accept a command-line string.command

Additional switches associated with the command itself (if necessary).cmd options

This is the string which dictates the operation that should be executed by the target application itself.“command-string”

The current namespace and command names are: hpssacli and cmd respectively. The {cmd

options} parameter can be cmdopts or -q. There is no need for an {object} type for

hpssacli since the application operates on internal commands supplied in the command-string.

HPSSACLI ESXCLI syntax

The HPSSACLI utility is supported by the ESXCLI utility.

Use the following command syntax for all commands:

# esxcli –server=”servername or IP” –user=”username” –password=”root

password” hpssacli cmd -q “command-string”

The command-string parameter supports same commands that are specified at the HPSSACLI

interactive command-line interface.

Example 1 This example shows the information about all the SmartArray controller on the server.

esxcli –server=”servername or IP” –user=”username” –password=”root

password” hpssacli cmd -q “controller all show status ”

The following output is displayed:

Smart Array P212 in Slot 9

Controller Status: OK

Smart Array P410i in Slot 0 (Embedded)

Controller Status: OK

Cache Status: OK

Battery/Capacitor Status: OK

Example 2 This example shows the detailed configuration information for the SmartArray controller

in slot 0.

# esxcli –server=”servername or IP” –user=”username” –password”root

password” hpssacli cmd -q “controller slot=0 show config detail”

The following output is displayed:

Smart Array P410i in Slot 0 (Embedded)

Bus Interface: PCI

Slot: 0

Serial Number: 5001438013A25C90

Cache Serial Number: PBCDF0CRH0J7SD

RAID 6 (ADG) Status: Disabled

Controller Status: OK

Hardware Revision: C

HPSSACLI utility 11

Firmware Version: 3.70

Rebuild Priority: Medium

Expand Priority: Medium

Surface Scan Delay: 15 secs

Surface Scan Mode: Idle

Queue Depth: Automatic

Monitor and Performance Delay: 60 min

Elevator Sort: Enabled

Degraded Performance Optimization: Disabled

Inconsistency Repair Policy: Disabled

Wait for Cache Room: Disabled

Surface Analysis Inconsistency Notification: Disabled

Post Prompt Timeout: 0 secs

Cache Board Present: True

Cache Status: OK

Accelerator Ratio: 25% Read / 75% Write

Drive Write Cache: Disabled

Total Cache Size: 1024 MB

Total Cache Memory Available: 912 MB

No-Battery Write Cache: Disabled

Cache Backup Power Source: Capacitors

Battery/Capacitor Count: 1

Battery/Capacitor Status: OK

SATA NCQ Supported: True

Array: A

Interface Type: SAS

Unused Space: 0 MB

Status: OK

Logical Drive: 1

Size: 136.7 GB

Fault Tolerance: RAID 1

Heads: 255

Sectors Per Track: 32

Cylinders: 35132

Strip Size: 256 KB

Full Stripe Size: 256 KB

Status: OK

Array Accelerator: Enabled

Unique Identifier: 600508B1001CB65083D63C5E781ABF65

Disk Name: vmhba2:C0:T0:L1

Mount Points: None

Logical Drive Label: A00D1AF35001438013A25C90F0BA

Mirror Group 0:

physicaldrive 1I:1:1 (port 1I:box 1:bay 1, SAS, 146 GB, OK)

Mirror Group 1:

physicaldrive 1I:1:2 (port 1I:box 1:bay 2, SAS, 146 GB, OK)

physicaldrive 1I:1:1

Port: 1I

Box: 1

Bay: 1

Status: OK

Drive Type: Data Drive

Interface Type: SAS

Size: 146 GB

Rotational Speed: 10000

Firmware Revision: HPDE

Serial Number: 6SD3FJVL0000B145MFXB

Model: HP EG0146FAWHU

Current Temperature (C): 36

Maximum Temperature (C): 46

PHY Count: 2

PHY Transfer Rate: 6.0GBPS, Unknown

12 Introduction

physicaldrive 1I:1:2

Port: 1I

Box: 1

Bay: 2

Status: OK

Drive Type: Data Drive

Interface Type: SAS

Size: 146 GB

Rotational Speed: 10000

Firmware Revision: HPDE

Serial Number: 6SD3EVBH0000B144Q7RD

Model: HP EG0146FAWHU

Current Temperature (C): 37

Maximum Temperature (C): 49

PHY Count: 2

PHY Transfer Rate: 6.0GBPS, Unknown

unassigned

physicaldrive 1I:1:3

Port: 1I

Box: 1

Bay: 3

Status: OK

Drive Type: Unassigned Drive

Interface Type: SAS

Size: 146 GB

Rotational Speed: 10000

Firmware Revision: HPDE

Serial Number: 6SD3FK4A0000B145J6JK

Model: HP EG0146FAWHU

Current Temperature (C): 37

Maximum Temperature (C): 48

PHY Count: 2

PHY Transfer Rate: 6.0GBPS, Unknown

...

These examples are not inclusive of all the capabilities of the HPSSACLI command. Commands

and options for additional operations using the HPSSACLI, such as creating a logical drive, are

documented in the Configuring Arrays on HP Smart Array Controllers Reference Guide.

HPTESTEVENT utility

The hptestevent utility allows an application to request the HP Insight Management WBEM

Providers generate the Informational Test Indication with ProviderName “HP Test” and EventID 1,

and the CPQ SNMP test trap with OID 1.3.6.1.4.1.232.11.2.8.1.0.11003.

The HP Insight Management WBEM Providers must be installed, enabled and running on the system

where this utility is executed. The WBEM Providers must be configured to send indications to the

listener. VMware SNMP traps must be enabled and configured to use WBEM indications as a

source for SNMP traps.

The Informational Test Indication and the CPQ Test SNMP trap will be sent to any listener configured

to receive indications from the system.

See the HP Insight Management WBEM Provider Datasheets for information on the test indication,

and the SNMP Data Migration Guide for information on the test SNMP trap on the BSC (Business

Support Center).

HPTESTEVENT command-line syntax

Use the following format at the command line:

hptestevent

HPTESTEVENT utility 13

There are no command options for the hptestevent utility.

HPTESTEVENT ESXCLI syntax

The hptestevent utility is supported by the ESXCLI utility.

To view the command usage options, run the following command:

# esxcli hptestevent

The following output is displayed:

Usage: esxcli hptestevent {cmd} [cmd options]

Available Commands:

execute execute the hptestevent command

To request a test indication and test SNMP trap to be generated, run the following command:

# esxcli hptestevent execute

The following output is displayed:

Request successful. Test event will be generated.

HPTESTEVENT return codes

This section provides description about the return code after running the command.

Table 8 hptestevent return codes

MeaningValue

Indicates success0

Request failed. No test event will be generated.1

Request failed, must be root. No test event will be generated.2

Request failed, couldn't determine if HP WBEM Providers are installed and running. No test

event will be generated.

3

Request failed, HP WBEM Providers are not installed and running. No test event will be

generated.

4

HPTESTEVENT command-line examples

This section provides sample examples to run the utility.

Table 9 hptestevent command-line examples

DescriptionCommand-line

Run command directly on the ESXi host/opt/hp/tools/hptestevent

Use esxcli to run the commandesxcli hptestevent execute

Generating an ADU report (diagnostics) from within HPSSACLI for ESXi

5.0 and updates

The HPSSACLI application contains the ability to generate a diagnostic report of the system and

its Smart Array storage configuration. The following steps are required in order to obtain an ADU

report from a remote machine running ESXi 5.0 and updates.

14 Introduction

1. Obtain and install the HP Smart Storage Administrator Diagnostics Utility (HP SSADU) CLI:

1. Browse to http://www.hp.com

2. Click on Support & Drivers

3. Select Drivers & Software

4. In the search box, type HP Smart Storage Administrator Utility

5. Select the operating system of the client machine that will be used to remotely access the

machine running ESXi 5.0 and updates.

6. Under the Software – System Management menu, proceed to download the HP Smart

Storage Administrator Diagnostics Utility (HP SSADU) CLI by clicking on the link.

NOTE: The desired version is 9.x or newer.

7. Install the Windows component or Linux RPM package onto the client machine.

2. The location where the package has installed the included applications and then update your

system path to include this location.

3. The client machine used to access the remote ESXi 5.0 and updates machine must also have

the vSphere CLI esxcli command line tool installed and must be accessible through the

system path. Ensure that the client machine location is included in the path.

4. Use the following tool and associated command-line parameters to perform the creation and

retrieval of the report:

hpssaduesxi --server=<server_ip_address> --user=<username>

--password=<password> <targetfile.zip>

Example Usage:

hpssaduesxi --server=10.12.132.5 --user=root --password=root.123

myreport.zip

The hpssaduesxi application uses the supplied parameters to remotely obtain the report from your

target ESXi 5.0 and updates machine and saves the data into the target zip file. The zip file can

then be opened with any third-party zip application or with the unzip command under Linux.

The hpssaduesxi application also contains onboard help which can be obtained by typing

hpssaduesxi with no parameters.

Generating an ADU report (diagnostics) from within HPSSACLI for ESXi 5.0 and updates 15

2 Support and other resources

This chapter provides information about the contact details and reference documents.

Contacting HP

This section provides information about the prerequisites to be verified before contacting HP and

mechanism supported by the organization for sharing the feedback.

Before you contact HP

Be sure to have the following information available before you call contact HP:

•Technical support registration number (if applicable)

•Product serial number

•Product model name and number

•Product identification number

•Applicable error message

•Add-on boards or hardware

•Third-party hardware or software

•Operating system type and revision level

HP contact information

For the name of the nearest HP authorized reseller:

•See the Contact HP worldwide (in English) webpage (http://welcome.hp.com/country/us/

en/wwcontact.html).

For HP technical support:

•In the United States, for contact options see the Contact HP United States webpage (http://

welcome.hp.com/country/us/en/contact_us.html). To contact HP by phone:

◦Call 1-800-HP-INVENT (1-800-474-6836). This service is available 24 hours a day, 7

days a week. For continuous quality improvement, calls may be recorded or monitored.

◦If you have purchased a Care Pack (service upgrade), call 1-800-633-3600. For more

information about Care Packs, refer to the HP website (http://www.hp.com/hps).

◦In other locations, see the Contact HP worldwide (in English) webpage (http://

welcome.hp.com/country/us/en/wwcontact.html).

Subscription service

HP recommends that you register your product at the Subscriber's Choice for Business website:

http://www.hp.com/country/us/en/contact_us.html After registering, you will receive email

notification of product enhancements, new driver versions, firmware updates, and other product

resources.

Documentation feedback

HP welcomes your feedback. To make comments and suggestions about product documentation,

send a message to docsfeedback@hp.com. Include the document title and manufacturing part

number. All submissions become the property of HP.

16 Support and other resources

New and changed information in this edition

•Wording added for hponcfg and hpbootcfg to identify both tools support execution on

ProLiant Series 100 Gen 8.

•Additional arguments for hponcfg command line.

Related information

Following documents and websites provide related information:

Documents

Following documents are supported for the product:

•HP VMware ESXi 5.0 Release Notes

•HP VMware ESXi 5.0 and Updates Getting Started Guide

Websites

HP documents regarding VMware are available at the following location:

https://h20392.www2.hp.com/portal/swdepot/searchProducts.do.

Typographic conventions

This document uses the following typographical conventions:

%,$, or #A percent sign represents the C shell system prompt. A dollar sign

represents the system prompt for the Bourne, Korn, and POSIX

shells. A number sign represents the superuser prompt.

audit(5) A manpage. The manpage name is audit, and it is located in

Section 5.

Command A command name or qualified command phrase.

Computer output Text displayed by the computer.

Ctrl+x A key sequence. A sequence such as Ctrl+x indicates that you

must hold down the key labeled Ctrl while you press another key

or mouse button.

ENVIRONMENT VARIABLE The name of an environment variable, for example, PATH.

ERROR NAME The name of an error, usually returned in the errno variable.

Key The name of a keyboard key. Return and Enter both refer to the

same key.

Term The defined use of an important word or phrase.

User input Commands and other text that you type.

Variable The name of a placeholder in a command, function, or other

syntax display that you replace with an actual value.

[] The contents are optional in syntax. If the contents are a list

separated by |, you must choose one of the items.

{} The contents are required in syntax. If the contents are a list

separated by |, you must choose one of the items.

... The preceding element can be repeated an arbitrary number of

times.

 Indicates the continuation of a code example.

| Separates items in a list of choices.

New and changed information in this edition 17

WARNING A warning calls attention to important information that if not

understood or followed will result in personal injury or

nonrecoverable system problems.

CAUTION A caution calls attention to important information that if not

understood or followed will result in data loss, data corruption,

or damage to hardware or software.

IMPORTANT This alert provides essential information to explain a concept or

to complete a task

NOTE A note contains additional information to emphasize or supplement

important points of the main text.

18 Support and other resources

Index

D

document

related documentation, 17

R

related documentation, 17

19
