User Manual

HUAWEI C5589

CDMA 1X Mobile Phone

USER GUIDE

Safety Precautions

Before using the phone, read safety precautions and inform your children

about using the phone correctly and safely. For details, see "Warnings and

Precautions" on page 67.

Do not switch on your phone when using the phone is prohibited or

when using the phone may cause interference or danger.

Do not use your phone while driving.

Follow the rules or regulations set forth by the hospitals and health

care facilities. Switch off your phone near medical apparatus.

Switch off your phone in an aircraft. The phone may cause

interference to control signals of the aircraft.

Switch off your phone near high-precision electronic devices. The

phone may affect the performance of these devices.

Do not attempt to disassemble your phone or its accessories. Only

qualified personnel are allowed to service or repair the phone.

Do not place your phone or the accessories in containers with strong

electromagnetic field.

Do not place magnetic storage media near your phone. Radiation

emitted from the phone may erase the information stored on the

magnetic storage media.

Do not place your phone in a high-temperature place or where it can

come in contact with flammable gas, such as a gas station.

Keep your phone and its accessories away from children. Do not

allow children to use your phone without guidance.

Use only approved batteries and chargers to avoid explosion.

Observe the laws or regulations on using the phone. Respect others'

privacy and legal rights when using your phone.

rights reserved.

No part of this document may be reproduced or transmitted in any

form or by any means without prior written consent of Huawei

Technologies Co., Ltd.

The product described in this manual may include copyrighted

software of Huawei Technologies Co., Ltd and possible licensors.

Customers shall not in any manner reproduce, distribute, modify,

decompile, disassemble, decrypt, extract, reverse engineer, lease,

assign, or sublicense the said software, unless such restrictions are

prohibited by applicable laws or such actions are approved by

respective copyright holders under licenses.

Trademarks and Permissions

, HUAWEI, and are trademarks or registered

trademarks of Huawei Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned

are the property of their respective owners.

Notice

Some features of the product and its accessories described herein

rely on the software installed, capacities and settings of local

network, and may not be activated or may be limited by local

network operators or network service providers, thus the

descriptions herein may not exactly match the product or its

accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify

any information or specifications contained in this manual without

prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS".

EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO

WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,

INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, ARE MADE IN RELATION TO THE ACCURACY,

RELIABILITY OR CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,

IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE

LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR

CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,

REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and

regulations and will obtain all necessary governmental permits and

licenses in order to export, re-export or import the product mentioned

in this manual including the software and technical data therein.

Conventions

Term Conventions

This manual refers to HUAWEI C5589 CDMA 1X mobile phone as "the

phone" or "your phone".

Operation Conventions

Operation Meaning

Press and

hold Press a key for two to three seconds and then release it.

Press Press a key and release it quickly.

GUI Conventions

Format Meaning

Bold Any string displayed on the phone screen is in boldface,

such as "Menu".

Multi-level menus are spearated by ">". For example,

"Menu > Messages" indicates "Messages" is the submenu

of "Menu".

Symbols

Symbol Description Meaning

Caution Warnings and precautions for operations

 Note Complementary descriptions for operations

Table of Contents

1 Getting to Know Your Phone............................................ 1

Your Phone...........................................................................................1

Keys and Functions..............................................................................3

Screen Icons .........................................................................................6

Interfaces..............................................................................................8

2 Getting Started ................................................................... 9

Installing the UIM Card and Battery ...................................................9

Installing the microSD Card ................................................................9

Charging the Battery..........................................................................10

Powering On/Off the Phone............................................................... 11

Using the Function Menu ..................................................................11

3 Voice Services ................................................................... 12

Making a Call.....................................................................................12

Answering a Call................................................................................12

Operations During a Call ...................................................................13

4 Text Entry......................................................................... 15

Text Input Modes ...............................................................................15

Entering English.................................................................................15

Entering Numbers ..............................................................................16

Entering Symbols...............................................................................17

5 SMS ................................................................................... 18

Writing and Sending a Message ........................................................18

Reading a Message ............................................................................19

6 MMS.................................................................................. 20

Writing and Sending a Multimedia Message.....................................20

Receiving a Multimedia Message......................................................20

Viewing a Multimedia Message ........................................................21

7 Contacts ............................................................................ 22

Adding a Contact ...............................................................................22

Searching for a Contact......................................................................22

Searching for a Contact by Location .................................................23

8 Alarm Clock...................................................................... 24

Activating an Alarm Clock ................................................................24

Deactivating an Alarm Clock.............................................................25

9 Security ............................................................................. 26

Activating/Deactivating the Phone Lock...........................................26

Changing the Phone Lock Code ........................................................26

PIN and PUK .....................................................................................26

Locking the Keypad...........................................................................27

10 Music ............................................................................... 29

Adding a Playlist................................................................................29

Launching the Music Player ..............................................................30

Selecting a Playlist.............................................................................30

iii

Playing Music ....................................................................................31

Setting the Equalizer ..........................................................................32

11 Video Player.................................................................... 33

Selecting a Video File ........................................................................33

Playing a Video File...........................................................................33

12 Recorder.......................................................................... 35

Recording a Sound Clip.....................................................................35

Playing a Sound Clip .........................................................................35

13 Radio ............................................................................... 37

Switching On/Off the Radio ..............................................................37

Searching for a Channel.....................................................................38

Deleting a Channel.............................................................................40

14 Camera............................................................................ 41

Taking a Picture .................................................................................41

Taking Multiple Pictures by One Press .............................................43

Viewing a Picture ...............................................................................43

Setting the Auto Timer .......................................................................44

Setting the Effect................................................................................45

Selecting a Fun Frame .......................................................................45

15 Video ............................................................................... 46

Recording a Video Clip......................................................................46

Playing a Video Clip ..........................................................................47

Setting the Effect................................................................................48

16 Bluetooth®....................................................................... 49

Sending Data Through the Bluetooth Connection.............................49

Receiving Data Through the Bluetooth Connection..........................51

Other Bluetooth Operations...............................................................51

17 Menu Commands ........................................................... 53

18 Troubleshooting ............................................................. 65

19 Warnings and Precautions ............................................ 67

1 Getting to Know Your Phone

Your Phone

The Front View

Earpiece

*Key

Camera

Shortcut Key

Confirm Key

Right Soft Key

Clear Key

End/Power Key

microSD

Card Slot

#Key

Microphone

Screen

Navigation Keys

Left Soft Key

Music Key

Talk/Send Key

Number Keys

The Back View

Volume

Control Keys

Music

Control Keys

Charger Interface

/Data Cable Connector

/Headset Jack

Camera

 The preceding figure is for your reference only.

Keys and Functions

Press… To…

z View the call log in standby mode.

z Make a call or answer an incoming call.

z Power on or off the phone (by pressing and holding the

key).

z End a call or reject an incoming call.

z Return to the standby mode.

z In text input mode, clear one character to the left of the

cursor, or clear all characters (by pressing and holding

the key).

z Clear the selected item.

(Left)

z Select the option displayed on the lower left corner of

the screen.

z In standby mode, access the Menu screen.

(Right)

z Select the option displayed on the lower right corner of

the screen.

z In standby mode, access the phonebook.

…

z Enter numbers, letters, and symbols.

z In standby mode, call the voice mail center (by

pressing and holding the 1 key).

z In standby mode, speed dial a phone number (by

pressing and holding the 2-9 keys).

z Select a submenu item labeled with the corresponding

number.

Press… To…

z Enter the symbol *, symbol +, letter P, or letter T (by

pressing the key once, twice, three times or four times).

z In standby mode, switch between the Meeting profile

and the current profile (by pressing and holding the

key).

z Enter the # symbol.

z In standby mode, lock the keypad (by pressing and

holding the key).

z Change input modes when editing texts.

z In standby mode, visit WAP sites (This function is

network dependent).

z Select an item.

In standby mode, access the music player.

z In standby mode, launch the music player (by pressing

and holding the key).

z Play or pause an audio or a video program.

z Play the previous audio or video program.

z Rewind the current audio or video program (by

pressing and holding the key).

z Play the next audio or video program.

z Fast forward the current audio or video program (by

pressing and holding the key).

Press… To…

z Increase the volume during a call.

z Increase the volume when playing audio files, video

files, and radio programs.

z Decrease the volume during a call.

z Decrease the volume when playing audio files, video

files and radio programs.

In standby mode, launch the camera (by pressing and

holding the key).

z In standby mode, access Alarms ( ); Radio

(); Calendar ( ); Messages ( ).

z During a call, increase the volume ( or );

decrease the volume ( or ).

z In focus mode of the camera, zoom in ( ); zoom

out ( ); switch to the video camera ( );

switch back to the camera ( ).

Screen Icons

Icon Indicates…

The signal strength. The more the bars are, the stronger the

signal is.

The CDMA 1X network is activated.

There is an incoming or ongoing call.

The data service is activated.

A new message is received.

The inbox is full.

A new voice mail is received.

A new emergent message is received.

A new MMS is received.

A new push message is received.

The phone is in roaming state.

The Bluetooth function is activated.

The microSD (secure digital) card is inserted.

Icon Indicates…

An alarm clock is activated.

The General profile is activated.

The Silence profile is activated.

The Meeting profile is activated.

The Outdoor profile is activated.

The My Profile 1 profile is activated.

The My Profile 2 profile is activated.

The battery power level. The more the bars are, the higher the

remaining battery level is.

The battery power level is extremely low.

The keypad is locked.

Interfaces

Interface Description

Charger

interface/Data cable

connector/ Headset

jack

Located at the bottom of the phone. You can

connect the charger or the data cable or the

headset to it.

microSD card slot Located at the lower right side of the phone. You

can insert a microSD card into it.

2 Getting Started

Installing the UIM Card and Battery

Make sure that the golden area on the UIM card is facing downwards and

the cut-off edge is correctly aligned with the card holder.

123

Installing the microSD Card

Install the microSD card correctly to avoid damaging your

phone or the microSD card.

Charging the Battery

To charge the battery, do as follows:

1. Connect the charger connector to the charger interface at the bottom of

the phone.

2. Connect the power plug of the charger to an AC power socket. During

the charging process, appears on the upper right corner of the

screen in an animated status.

3. Wait until the phone is fully charged. When becomes static, the

battery is fully charged.

4. power socket. Disconnect the power plug of the charger from the AC

5. Disconnect the charger connector from the phone.

z Do not use a damaged battery or charger.

z Before using the travel charger, ensure that the battery is

installed in your phone.

Powering On/Off the Phone

z When the phone is powered off, press and hold to power it on.

z When the phone is powered on, press and hold to power it off.

Using the Function Menu

To use the function menu, do as follows:

1. In standby mode, press (Menu).

2. Press (Select) or to display the selected menu.

3. Display the submenu in either of the following methods:

z Press or to select a submenu. Then press

(Select) or to display it.

z Press the key corresponding to the sequence number of a submenu to

display it.

4. Press (Back) to return to the previous menu or exit the function

menu.

5. Press to return to the standby mode.

3 Voice Services

Making a Call

1. In standby mode, press number keys to enter a phone number.

z To make an international call, press twice to enter +. Then

enter the international long distance code, the country code, the area

code and phone number in a sequence.

z To call a phone number with an extension, press three times

to insert P or press four times to insert T between the phone

number and the extension number.

2. Press to call the number.

3. Press or (End) to end the call or cancel the call.

 z When the phone is locked, enter the lock code to unlock the

phone first; otherwise, you can only make emergency calls or

answer calls.

z In standby mode, press to view Calls. Select a record

and press to call the number.

z Select a contact from the contacts and press to call the

number.

z Select a message in the inbox and press to call the

message sender.

Answering a Call

When there is an incoming call, you can select the following options:

z Press , (Answer), or to answer it. Press

to reject it.

z If your phone is in silence or meeting mode, press (Reject) to

reject it. If your phone is not in silence or meeting mode, press

(Silence) to mute the ringtone, and press (Reject) again to

reject it.

z If the Any Key Answer function is enabled, press any key (except

and ) to answer it.

z If the headset is connected to the phone properly, press the button on the

headset to answer an incoming call; press the button again to end the

call.

z If the headset mode and the Headset Auto Answer function are enabled,

and the headset is connected to the phone properly, the phone answers

an incoming call automatically.

Operations During a Call

When there is an ongoing call, you can press to activate or

deactivate the speaker, or press (Options) for the following

options:

z Mute/Unmute: Allows you to mute or unmute your voice during a call.

At first, the option is Mute. If you select it, the other party can not hear

your voice during the call.

If you access the Options menu again, the option is Unmute. If you

select it, the other party can hear your voice again. This function is

available only after the call is set up. You can not mute/unmute the

ringtone.

z Start Record: Allows you to record the call. You can select This Side

or The Other Side.

z Save Number: Allows you to enter a phone number and save it to the

phonebook.

z Contacts: Allows you to search for or create a contact.

z Messages: Allows you to access the SMS menu.

z Memo: Allows you to access the Memo menu.

z Voice privacy: Allows you to set the privacy mode, including Standard

and Enhanced.

4 Text Entry

Text Input Modes

The indicator of the current input mode is displayed on the upper left

corner of the screen. You can press to change the input mode.

Indicator Text Input Mode Indicator Text Input Mode

En Smart English Abc Alphabetical text

123 Numbers - -

 In editing mode, press once to delete the letter to the left

of the cursor. Alternatively, press and hold to clear all

letters at a time. If there is no letter to delete, you can press

(Back) to return to the previous menu.

Entering English

Smart English Input

You can enter English letters as follows:

1. According to the sequence of the word, press each corresponding key

only once for one letter. Then the phone displays the common words

according to the numeric sequence of key presses.

2. Press to view alternative words.

3. Press to switch between the uppercase and lowercase.

4. Press or to confirm the selection; or press to

confirm the selection and enter a space after the word.

 z Press to enter a full stop or symbols.

z Press to enter a space and press and hold it to enter 0.

z Press to display the symbol list. Then you can enter

symbols.

Alphabetical Text Input

The alphabetical text input allows you to enter uppercase or lowercase

English letters. You can press the key labeled with the required letter once

to enter the first letter on the key, twice to enter the second letter on the key,

and so on.

If the letter you want to enter is labeled on the same key as the previous

one, you can enter the latter letter only after the cursor appears again or

press to move the cursor to the next space.

 z Press repeatedly to enter a common punctuation.

z Press once to enter a space, twice to enter 0.

Entering Numbers

z In "123" input mode, directly press the number key labeled with the

required number.

z In "Abc" input mode, press a number key repeatedly or press and hold it

until the required number appears on the screen.

z In "En" input mode, press a number key and then press until the

required number appears on the screen. Or you can press and hold the

key until the required number appears on the screen.

Entering Symbols

In any input mode, you can enter a symbol as follows:

1. Press to display a symbol list.

2. Press or to select a symbol.

3. Press or the corresponding number key to enter the symbol.

5 SMS

Writing and Sending a Message

To write and send a message, do as follows:

1. Select Menu > Messages > SMS > Create Message. In standby mode,

you can also press , select SMS > Create Message.

2. Write a message. You can enter up to 160 English letters.

When writing a message, press (Options) for the following

options:

z Send: Allows you to send the message.

z Save: Allows you to save the message to Drafts.

z Insert Template: Allows you to insert a common phrase.

z Insert Contact: Allows you to select a contact from the phonebook

and insert the phone number into the message.

z Priority: Allows you to set a priority for the message sent to the

recipients. The priorities are Normal, Urgent and Emergency. The

message priority function is network dependent.

z Delivery Report: Allows you to receive a message delivery report

from the short message service center (SMSC).

3. Press in the text editing screen to send the message directly, or

age. select Options > Send to send the mess

4. Enter the phone number of a recipient.

following methods: Up to 100 recipients can be added in the

z Enter the phone number(s) directly.

z Press (Options). Then select Contacts to select the phone

number(s).

z Press (Options). Then select Groups to select a group.

z Press (Options). Then select abc to enter lowercases.

z Press (Options). Then select ABC to enter uppercases.

5. Press to send the message.

Reading a Message

To read a message stored in the inbox, do as follows:

1. Select Menu > Messages > SMS > Inbox.

2. Press to select a message.

3. Press to read the message, or press (Options) for the

following options:

z View: Allows you to read the message.

z Reply: Allows you to edit a message and reply the message sender.

z Delete: Allows you to delete the message.

z Delete Multiple: Allows you to delete multiple messages at a time.

z Forward: Allows you to forward the message.

z Extract: Allows you to extract the number contained in the message,

or the number of the message sender. For the number, you can select

the option Edit Before Call, Call or Save.

z Move To Phone/Move To R-UIM: Allows you to move the message

to the phone or to the UIM card.

z Copy To Phone/Copy To R-UIM: Allows you to copy the message

to the phone or to the UIM card.

6 MMS

Writing and Sending a Multimedia Message

1. Select Menu > Messages > MMS > New Message. In standby mode,

you can also press , select MMS > New Message.

2. Enter the content of a multimedia message in the following fields:

z Recipient: Allows you to enter the message recipients. You can add

up to 20 recipients.

z Subject: Allows you to enter the subject of the message.

z Slides: Allows you to insert images, audio files, video files and texts

into a slide. You can set the duration of displaying each slide for your

preview.

z Timing: Allows you to set the duration of switching the slides.

 The capacity of a multimedia message can be up to 300 KB,

including the slides.

3. After you edit the multimedia message, select Options > Send and

press to send it.

Receiving a Multimedia Message

If you select MMS > Settings > Receive options > Download timing >

Manual, a notification can be received in the inbox and you can press

to view the notification. Then select Options > Receive to receive

the multimedia message.

nload timing >

in the inbox directly.

If you select MMS > Settings > Receive options > Dow

Automatic, the multimedia message is downloaded

Viewing a Multimedia Message

To view dia messages stored in multime the inbox, do as follows:

1. Select > Messages > MMS > Inbox.

Press

to select a message.

3. Press to view contents of the message or press (Op

for the following options:

tions)

essage sender.

nder

ge.

folders.

o the

date or address.

z Filter View: Allows you to view the specified message(s).

z Open: Allows you to view contents of the message.

Reply: Allows you to reply the me

z ssage to the m

z Reply all: Allows you to reply the message to the message se

and all other message recipients.

z Forward: Allows you to forward the messa

z Move: Allows you to move the message(s) to My

z Delete: Allows you to delete the message.

Delete All: Delete all the messages in the inbox.

z Sort: Allows you to sort the messages in the inbox according t

7 Contacts

Adding a Contact

To add a contact, do as follows:

1. Select Menu > Contacts > Add New.

2. Press to enter information in Name, and then press

(OK).

3. Enter the necessary information about a contact.

You can enter information in Mobile Number, Home Number, Office

Number, and Fax Number. (At least one number field is required). You

can enter the email of a new contact and select a group, notes, a

customized tone, and an image for the contact.

4. Press (Save) to save the contact to the phonebook.

Searching for a Contact

To search for a contact, do as follows:

1. Select Menu > Contacts > Search.

2. Enter the name of a contact. Then press (Search) or .

After the 3. contact is found, press (Options) for the following

options:

z View: Allows you to view the details.

z Edit: Allows you to edit the contact.

z Add New: Allows you to add a new contact.

z Send Message: Allows you to send a message to the contact.

he contact by Bluetooth.

z lows you to copy the

Eu call.

 z ode, press

z Send Via Bluetooth: Allows you to send t

z Delete: Allows you to delete the contact.

Copy To Phone/Copy To UIM Card: Al

contact to the phone or to the UIM card.

z Call: Allows you to call the number of the contact.

z dit Before Call: Allows you odify the number before yo

In standby m

to m

(Contacts) to access the

z key

phonebook.

To quick rch for tact, you can press the number

(except

ly sea a con

and ) to enter the first letter of the

contact name. Then the phone lists English contacts that start

with the letter.

Searching for a Contact by Location

You can quickly search for a contact according to the sequence number.

ique sequence number.

2. en press

Each contact in the phonebook has a un

To search for a contact, do as follows:

1. Select Menu > Contacts > Search By Location.

he sequence er of the contact directly, and th

Enter t numb

(View) or to view details of the contact.

8 Alarm Clock

After the alarm clock is activated, the phone notifies you at the preset time.

You can set up to five alarm clocks.

Activating an Alarm Clock

1. Select Menu > Tools > Alarms.

2. Press to select an alarm clock.

3. Press (On) to activate the alarm clock, or press for the

following options:

z Title: Allows you to set the title.

z Time: Allows you to set the time.

z Cycle: Allows you to set the alerting mode.

z Ring: Allows you to set the alarm tone.

4. Press (Save) to save the settings of the alarm clock.

 z When the alarm clock alerts, press (Stop) to stop it or

press (Snooze) to snooze it for five minutes.

z If no operation is performed to the alarm clock when it alerts,

the alarm clock stops temporarily after 45 seconds and alerts

again five minutes later. It alerts five times before it stops

thoroughly.

z If you select Cycle > Custom, press to scroll from

Sunday to Saturday and press to select the days; press

again to deselect the days. Then press (OK) to

confirm.

Deactivating an Alarm Clock

1. Select Menu > Tools > Alarms.

2. Press to select an alarm clock.

3. Press (Off) to deactivate the alarm clock.

 Select Menu > Tools > Alarms > Cancel All to deactivate all

alarm clocks.

9 Security

Activating/Deactivating the Phone Lock

The phone lock protects your phone from unauthorized use. By default, the

phone lock function is not activated. You can change the default phone

lock code 0000 to any numeric string of 4 digits.

1. Select Menu > Settings > Security Settings > Phone Lock.

2. Select one of the following phone lock modes:

z Immediate: The phone is locked immediately.

z Power On: The phone lock is activated when the phone is powered

on next time.

z Off: The phone lock is deactivated.

Changing the Phone Lock Code

Do remember your phone lock code. If you forget it, contact your local

dealer.

1. Select Menu > Settings > Security Settings > Change Phone Code.

2. Enter the correct phone lock code and pres (OKs ).

3. Enter the new phone lock code and press (OK).

4. (OK). Enter the new phone lock code again and press

PIN and PUK

The personal identification number (PIN) protects your UIM card from

unauthorized use. The PIN unlocking key (PUK) can unblock the blocked

PIN. Both the PIN and PUK are delivered with your UIM card. For details,

consult your service provider.

If you enter wrong PINs for a specified number of times consecutively, you

are required to enter the PUK.

If you enter wrong PUKs for a specified number of times consecutively,

the UIM card is invalidated permanently. Contact your service provider for

a new card.

Locking the Keypad

When the keypad is locked, you can still answer an incoming call by

pressing (Answer), or , and you can make

emergency calls by pressing .

Manually Locking the Keypad

In standby mode, press and hold to lock the keypad.

Automatically Locking the Keypad

If the auto keyguard function is enabled, after the phone has been idle for a

preset period in standby mode, the keypad is locked automatically.

1. Select Menu > Settings > Phone Settings > Auto Keyguard.

2. Press for the following options:

z Off: Allows you to disable the auto keyguard function.

z 15 Seconds, 30 Seconds or 1 Minute: In standby mode, when the

phone has been idle for the selected time, the keypad is locked

automatically.

3. Press (Select) to save the settings.

Unlocking the Keypad

In standby mode, press (Unlock) and then press to unlock

the keypad.

10 Music

Adding a Playlist

1. In standby mode, select Menu > Multimedia > Music Player >

Playlists. Then press (Add) to add a new playlist.

 If you have already saved a playlist on your phone, press

(Options) and select Add New Playlist.

2. Enter the name of the playlist, and then press (OK).

3. Press (Add) to add songs.

 If you have already saved a playlist on your phone, press

(Options) and select From My Files or From Playlists to add

songs. If you select From Playlists, press to select a

playlist, and then press (Add) to add all the songs in the

selected playlist to the new playlist. You can also press

to enter the selected playlist and select one or more songs. Then

you can press (Add) to add the selected songs.

4. Press to select the phone or the microSD card as the memory in

use.

5. Press to select or deselect the songs in the playlist.

6. Press (Options), and select Add to save the settings.

Launching the Music Player

In standby mode, you can launch the music player in either of the

following methods:

z Press and hold .

z Select Menu > Multimedia > Music Player > Music NOW!.

Selecting a Playlist

After launching the music player, you can do as follows:

1. Press (Add Tracks) to add tracks.

2. Press to select From My Files or From Playlists.

z If you select From My Files, press to select the phone or the

microSD card as the memory in use. Press to select or

deselect the songs. Press (Options) and select Add. Then the

phone loads the playlist.

z If you select From Playlists, press to select a playlist and

press (Play) to add and play the songs in the selected playlist.

You can also press to enter the selected playlist and select one

or more songs. Then you can press (Play) to add and play

the songs.

 z If a playlist already exists in the music player, press

(Options) and select Current Playlist to access the Current

Playlist screen. Then press (Options) and select Add

Tracks to add tracks.

z You can also select a playlist directly. Press

(Options) and select Play to load the playlist.

Playing Music

On the music player screen, you can do as follows:

1. Press or to play a song.

z Press or to play the next song.

z Press and hold or to fast forward the song.

z Press or to play the previous song.

z Press and hold or to rewind the song.

z Press or to pause the song; press or again

to continue playing the song.

z Press to load the current playlist.

z Press to stop playing.

z Press to increase the volume.

z Press to decrease the volume.

2. Press (Minimize) to minimize the music player. You can use

other functions while the phone is playing music.

3. Press to return to the standby mode and the music is still

playing.

 If music playing is stopped in the music player, you can press

to exit the music player directly.

Setting the Equalizer

1. In standby mode, select Menu > Multimedia > Music Player > Music

Now! to launch the music player.

2. Press ( ) and select for

Shuffle: Allows you to set the shuffle mode.

Options Settings the following options:

z Loop: Allows you to set the loop mode.



qualizer: Allows you to set the equalizer.

When the phone is playing songs, press the button on the headset

to play the next song.

11 Video Player

Selecting a Video File

1. In standby mode, select Menu > Multimedia > My Files > Videos.

2. Press to select the phone or the microSD card as the memory in

use.

3. Press to select a video file.

 If you want to select a video file from the microSD card, the

microSD card must be inserted into your phone beforehand.

Playing a Video File

On the video screen, after you select a video file, you can do as follows:

1. Press or to play a video file.

z Press or to play the next video file.

z Press and hold or to fast forward the video.

z Press or to play the previous video file.

z Press and hold or to rewind the video.

z Press or to pause the video; press or again

to cont ying the video.

inue pla

Press to stop playing.

z Press to display the full screen.

z Press to increase the volume.

z Press to decrease the volume.

2. Press (Back) to switch off the video player and return to the

previous screen.

12 Recorder

Recording a Sound Clip

1. In standby mode, select Menu > Multimedia > Recorder.

2. Press to start recording; press again to pause.

3. Press (Back) to stop recording, with displaying a prompt to

confirm:

z Press (Ye s ) to save the sound clip to the recorder folder

under Menu > Multimedia > My Files > Music.

z Press (No) to return to the previous menu.

 z When recording a sound clip, you can press (Stop) to

save the sound clip to the recorder folder under Menu >

Multimedia > My Files > Music automatically.

z When recording a sound clip, keep the microphone of your

phone near the sound source for a better recording effect.

Playing a Sound Clip

1. In stan ode, select Menu >

dby m Multimedia > Recorder.

Press (Voice Folder).

Press

3. to select the memory: phone or micr rd.

oSD ca

Press to select a sound clip and then press to play it; or

press (Options) and select Play to play it.

5. Press (Options) for the following options:

z u

z s you to copy the

/Copy To Phone or

me of the

6. Press

z Play: Allows you to play the sound clip.

Set: Allows you to set the sound clip as the ringtone, contact tone,

SMS tone, or MMS tone.

Send: Allows you to select Send As MMS or Bluetooth, that is, yo

can send the sound clip as a multimedia message or through

Bluetooth.

Move To Memory Card/Move To Phone: Allows you to move the

sound clip to the microSD card or to the phone.

Copy To Memory Card/Copy To Phone: Allow

sound clip to the microSD card or to the phone

z Delete: Allows you to delete the sound clip.

Mange Multiple: Allows you to Play, Move To Memory

Card/Move To Phone, Copy To Memory Card

Delete multiple sound clips at a time.

z Rename: Allows you to rename the sound clip.

Sort: Allows you to sort the sound clips according to the name, size,

or date.

File Info: Al

z lows you to view the name, size and creation ti

sound c . lip

(Minimize) to view the list of sound clips.

13 Radio

Your phone integrates a frequency modulation (FM) radio. Before listening

to the radio, insert the headset into the headset jack.

 The headset cable functions as the antenna. When listening to the

radio, do not bind or wind the headset cable. Keep the headset

cable straight for a better effect.

Switching On/Off the Radio

Switching On the Radio

1. Insert the headset to the headset jack properly.

2. In standby mode, select Menu > Multimedia > Radio. You can also

press to load the radio. After loading, the phone plays a

program.

 When you listen to the radio for the first time, no channel is

stored on the phone. You need to press (Tuning) and

then select Automatic Tuning, Manual Tuning, Fine Tuning or

Set Frequency to search for channels.

3. Press (Options) and select Speaker On to activate the speaker.

4. On the radio screen, you can do as follows:

z Press or to increase the volume.

z Press or to decrease the volume.

z Press to change the channel.

z Press to load the channel list.

 z When the radio is switched on, if the phone returns to the

standby mode, the program is still being played and the radio

frequency is displayed on the screen.

z When you listen to the radio through the loudspeaker, do not

plug out the headset. Otherwise, the phone stops the radio

program temporarily.

z If the headset is disconnected from the phone for more than

two minutes, the radio switches off automatically.

Switching Off the Radio

1. In standby mode, select Menu > Multimedia > Radio.

2. Press (Options) and select Switch Off to switch off the radio

and return to the previous screen.

 In standby mode or on the radio screen, press the button on the

headset to change the channel; press and hold the button on

the headset to switch off the radio.

Searching for a Channel

Automatic Tuning

1. On the radio screen, press (Options) and select Tuning.

2. Press to select Automatic Tuning.

3. The phone automatically searches for channels and saves them to the

channel list.

Manual Tuning

1. On the radio screen, press (Options) and select Tuning.

2. Press to select Manual Tuning.

3. Press to tune from 87.5 MHz to 108.0 MHz.

Fine Tuning

1. On the radio screen, press (Options) and select Tuning.

2. Press to select Fine Tuning.

3. Press to tune by 0.1 MHz each time.

Setting a Frequency

1. On the radio screen, press (Options) and select Tuning.

2. Press to select Set Frequency.

3. Enter a frequency.

The frequency must range from 87.5 MHz to 108.0 MHz. After you

enter three digits for the integer part, the cursor moves to the decimal

part automatically. If you enter only two digits for the integer part, press

to move the cursor to the decimal part.

4. Press (Listen) to listen to the program of the channel. Press

(Back) to return to the radio screen again.

5. Press (Save) and return to the Save Channel screen. Press

to select a channel to be saved, and press (Save) to save

the settings.

Deleting a Channel

1. On the radio screen, press (Options) and select Delete

Channel.

2. Press to select a channel to be deleted from the channel list.

3. Press (Delete) or to delete the channel. Press

(Back) to return to the radio screen.

14 Camera

Taking a Picture

1. In standby mode, select Menu > Multimedia > Camera, or press and

hold to launch the camera.

 z The phone can memorize the screen (the camera or video

camera screen) that was displayed last time. For example,

access the camera, press to enter the video camera

screen, and exit. When you access the camera next time, the

video camera screen is displayed.

z By default, the phone takes a picture in landscape mode.

2. Press (Options) for the following options:

z Portrait/Landscape: Allows you to switch between the portrait

mode and the landscape mode.

z Switch to Video Camera: Allows you to use the functions of the

video camera on your phone. For details, see "Video" on page 46.

You can also switch to video camera by pressing in the

preview mode.

z Shot Mode: Allows the phone to take four or nine pictures in rapid

succession, if you select 4 Shots or 9 Shots. If you select Normal,

the multi-shot mode is deactivated.

z Resolution: Allows you to select the resolution.

z Frame: Allows you to select a fun frame for pictures.

z Auto Timer: Allows you to set the countdown time for the phone to

take a picture automatically. If the auto timer is activated, you can

select 5 Seconds or 10 Seconds that indicates the duration after

which the phone takes a picture automatically.

z Night Mode: Allows you to activate or deactivate the night mode.

z Effect: Allows you to set the effect. You can set Color,

Monochrome, Negative and Sepia.

z Shortcut Guide: Allows you to view the shortcut keys.

z Settings: Allows you to set Quality, Shutter Tone, Auto Timer

Ton e, Save Location, and Reset All.

z Go To My Files: Allows you to access the picture folder under My

Files to view pictures.

3. Focus the lens on the scene and press or to take a picture.

Then you can preview the picture and save it.

4. Press (Options) for the following operations:

z Delete: Allows you to delete the picture.

z Send: Allows you to send the picture as a multimedia message or

through Bluetooth.

z Set: Allows you to set the picture as the wallpaper or contact image.



z When focusing the lens, press to zoom in; press

to zoom out; press to decrease the luminance;

and press to increase the luminance.

z The camera can not be zoomed when the resolution is 1280 ×

1024 or 1280 × 960.

z The phone automatically switches the resolution to 320 × 240

when the frame function is enabled. The original resolution is

retrieved when the frame function is disabled.

z In the upper left corner of the camera screen, the number

ranging from 0 to 1000 indicates the estimated number of

pictures that you can take; 1000+ indicates that you can take

more than 1000 pictures.

Taking Multiple Pictures by One Press

1. Select Menu > Multimedia > Camera > Options > Shot Mode.

If you select 4 Shots or 9 Shots, the phone can take four or nine pictures

in rapid succession after you press or . If you select Normal,

the multi-shot mode is deactivated.

2. After focusing the camera lens on an object, press or , then

the phone takes multiple pictures in a rapid succession and saves them.

Viewing a Picture

1. In standby mode, select Menu > Multimedia > Camera.

2. Press (Options). Then select Go To My Files to access the

phone a . lbum

3. Press to select the phone o

use.

r the microSD card as the memory in

4. Press to select a picture.

5. Press to view the picture, and then press to change to

the previous or the next picture.

Press (Options) for the following options:

z et the picture as the wallpaper or contact image.

edia message or

z o delete the current picture.

solution and create

z Full Screen: Allows you to set the picture into the full screen.

z Rotate: Allows you to rotate the picture.

Set: Allows you to s

z Send: Allows you to send the picture as a multim

through Bluetooth.

Delete: Allows you t

z File Allows you to view the name, size, re Info:

time of the picture.

7. Press (Back) to return to the picture list.

Setting the Auto Timer

Select Menu > Multim1. edia > Camera.

2. Press (Options) and select Auto Timer. Then select 5 Seconds

or 10 Seconds.

3. Press . After 5 seconds or 10 seconds (according to your

selection), the phone takes a picture and saves the picture automatically.

Setting the Effect

1. In standby mode, select Menu > Multimedia > Camera.

2. Press (Options) and select Effect.

3. Press to scroll to Color, Monochrome, Negative or Sepia.

4. Press to select an effect.

Selecting a Fun Frame

1. In standby mode, select Menu > Multimedia > Camera.

2. Press (Options) and select Frame.

3. Press to scroll the mes.

4. Press

fun fra

(Select) or to select a fun frame and the selected

fun frame is displayed. Press (Back) to cancel the operation.

15 Video

Recording a Video Clip

1. In standby mode, select Menu > Multimedia > Camera to access the

camera preview screen, or press and hold to launch the camera.

Then press to switch to the video camera.

 The phone can memorize the screen (the camera or video

camera interface) that was displayed last time. For example,

access the camera, press to enter the video camera

screen, and exit. When you access the camera next time, the

video camera screen is displayed.

2. Press (Options) for the following options:

z Switch To Camera: Allows you to use the functions of the camera

on your phone. For details, see "Camera" on page 41.

In preview mode, you can also press to switch to the camera.

z Video Size: Allows you to set the video size. You can select MMS

Limit, 3 Minutes or 5 Minutes.

z Night Mode: Allows you to activate or deactivate the night mode.

z Effect: Allows you to set the effect. You can set Color,

Monochrome, Sepia and Negative.

z Shortcut Guide: Allows you to view the shortcut keys.

z Settings: Allows you to set Video Quality, Audio Setting and Reset

All.

z Go To My Files: Allows you to access the video folder under My

Files to view videos.

3. Press to start recording.

4. Press (Stop) to stop recording, and save the video clip to the

video folder automatically.

5. Press (Options) for the following options:

z Play: Allows you to view the video clip.

z Send As MMS: Allows you to send the video clip as a multimedia

message.

z Send As Bluetooth: Allows you to send the video through Bluetooth.

z Delete: Allows you to delete the current video clip.

z Go To My Files: Allows you to access the video folder under My

Files to view videos.

 Your phone supports video recording for up to five minutes.

When five minutes is up, the phone stops recording and saves the

recorded video clip automatically. Then it returns to the video

preview screen.

Playing a Video Clip

1. In standby mode, select Menu > Multimedia > Camera to access the

camera preview screen, and then press to switch to the video

camera.

2. Press (Options). Then select Go To My Files to access the

video screen.

3. Press to select the phone or the microSD card as the memory in

use.

Press 4. to select a video clip.

5. (Options) and Press to play the video clip; or press

select Play.

6. Press (Back) to return to the list of video clips.

ia > Camera to access the

w s

etting the Effect

In standb1. ode, select Menu > Multimedy m

camer creen, and then press a previe to switch to the video

camera.

2. Press (Options) and select Effect.

3. Press to scroll to Color, Monochrome, Sepia or Negative.

4. Press to select an effect.

16 Bluetooth®

You can use the built-in Bluetooth function of your phone to synchronize

data between a PC and your phone, or exchange data with other Bluetooth

devices. You can also call by using the Bluetooth headset or Bluetooth

loudspeaker.

Bluetooth supports a wireless connection between Bluetooth devices

within a distance of 10 m; however, the Bluetooth wireless connection can

be disturbed by other electronic devices and blocked by obstacles, such as

walls.

In certain areas, using Bluetooth devices might be restricted or prohibited.

Observe applicable laws and regulations.

Do not accept the connection request of an unknown device. Thus, you can

prevent your mobile phone from the intrusion of destructive contents.

 The Bluetooth function supported by your phone meets the

requirements of Bluetooth Specification 2.0. It works normally

only when you use it with compatible Bluetooth devices. For

more information, refer to the user manuals of related devices,

or consult the manufacturers of related devices.

Sending Data Through the Bluetooth Connection

 You can set up only one Bluetooth connection each time.

1. Select Menu > Settings > Phone Settings > Bluetooth > Switch

On/Off > On to activate Bluetooth.

age to another device, you need to launch the My

3. Sele

2. Launch the application that contains the be sent. For example, if

you want to send an im

file to

Fil application.

ct the file you want to send. Press (Options) and select

Send

 If tooth function is not activated, the phone displays

z vate Bluetooth and access the Device List

4. Select nnect with from the device list.

 ur

> Bluetooth.

the Blue

"Switch On Bluetooth?" on the screen.

Select Yes to acti

screen.

z Select No to reject activation of Bluetooth and return to the

previous screen.

ice you want to co the dev

z If the devices on the device list are already paired with yo

phone, select the device that is to be connected with, and press

to transfer data.

When the device list is null or the device that is to be z

connected with does not exist on the list, press

(Search) to search for other Bluetooth-activated devices in the

effective range. Then the names of the found devices are

displayed on the screen. Press to stop searching.

5. If the device that is to be connected with requests identity authen

before connection, your phone displays "Enter PIN code:" on th

Create a shared password. After the sam

tication

e screen.

e password is entered on both

tion is set up, information about the data being

devices, the Bluetooth connection is set up.

6. After the connec

transferred is displayed on your phone.

Receivin ta Through the Bluetooth g Da

e your

z P

onnection

1. Wh

n other device sends data to your phone through Bluetooth,

e displays "Receive File?" on the screen.

ress (Ye s ) to receive the data. The filename and receiving

ogress are displayed on the screen.

ress

z P (No) to reject the data.

For the first time to co

 nnect with another device through

Bluetooth, your phone displays "Enter PIN code:" on the scree

for you to authenticate the identity of the device. Enter th

password of one to eight digits, and press (Select). Afte

the same password is entered on the other device, your phone

starts to receive data.

sful!" on the screen, it

under My Files.

2. When your phone displays "Receive Succes

indicates that the data is received and saved

 If a microSD card is installed on your phone, the phone saves

the received data in the microSD card by default. Otherwise, the

phone saves the received data in the phone memory.

Other Bluetooth Operations

You can set the basic settings for the Bluetooth functions. Select Menu >

ttings > Phone Settings > Bluetooth for the followinSe g options:

le the Bluetooth function.

z Switch On/Off: Allows you to enable or disab

z Search: Allows you to search for new Bluetooth devices.

Device List: Allows you to view all paired Bluetooth devices.

ib y other

device

z Renam

z My de view the detailed information

abou



th headset, you can only have a call rather than listen

to audios, such as .mp3 music.

z Files or VCard files can be transferred between your phone

and a Bluetooth device that supports the OPP function.

z Your phone only support the FTP Server rather than the FTP

Client.

z Vis ility: Allows you to set whether your phone can be found b

s when the Bluetooth function is enabled.

e: Allows you to rename your phone.

vice Information: Allows you to

t your phone, such as the device name and device address.

The Bluetooth headsets that comply with the Bluetooth z

standards are all compatible with your phone. By using a

Bluetoo

17 Menu Commands

Calls

All Calls

Missed Calls

Received Calls

Dialled Calls

Allows you to view all the missed calls, received

calls or dialled calls.

Allows you to view, edit, save and delete call

records, send messages, make calls to the

corresponding numbers.

Contacts

Search Allows you to find a phone number from the

phonebook.

By Location

Allows you to find a contact according to the

sequence number. Each contact in the phonebook has

an independent sequence number. You can quickly

search a contact by the sequence number.

Add New Allows you to add new contacts to the phonebook.

The phone memory can save up to 1000 contacts.

Groups Allows you to set up to 10 groups.

Speed Dial Allows you to make a call by pressing and holding

only one number key (except 0 and 1) in the standby

mode.

My Number Allows you to view your own phone number.

Contacts

Management

Show Contacts From: Allows you to choose the

current storage location of the contacts.

Delete Multiple: Allows you to delete multiple

contacts at a time.

Copy Multiple: Allows you to copy multiple

contacts at a time.

Send Via Bluetooth: Allows you to send the

contacts through Bluetooth.

Memory Status: Allows you to check total space

and the remaining space for contacts in the phone

and the UIM card.

Messages

SMS

Create Message Allows you to write and send a message.

Inbox Allows the phone to store received messages.

Allows you to view, reply, delete, and forward the

messages stored in the inbox. Allows you to call and

save the phone numbers of the message senders.

Outbox Allows the phone to store the messages successfully

sent, if the auto save function is activated.

Allows you to delete, resend and forward the

messages in the outbox.

Drafts Allows the phone to store drafts and the messages

failed to be sent.

Allows you to edit, send, and delete the messages in

the draft.

Voice Mail Voice Message: Allows you to view and receive

voice messages.

Voice Mail Number: Allows you to set the voice

mail center number.

Clear Voice Mail Notification: Allows you to clear

the voice mail notifications.

Templates Allows you to insert or edit the phrases. The phone

includes 10 templates.

Settings Send Settings: Allows you to set Auto Save,

Priority, Delivery Report, Signature, Deferred

Delivery and Validity Period.

Auto Delete: If this function is activated, the phone

automatically deletes the earliest messages to spare

room for a new message when the message memory

is full. If it is deactivated, the phone can not receive

new messages when the memory is full.

Statistics: Allows you to view the number of the sent

messages, the received messages, and the time when

you clear the statistics the last time. You can press

(Clear) to clear all the statistics.

Save Location: Allows you to choose the phone or

the UIM card to save the messages.

Memory Status: Allows you to view the memory

usage of the phone and the UIM card (both the used

memory and the total memory). The phone can save

up to 1000 messages.

Delete All Allows you to delete all the messages stored in the

inbox, the outbox, the draft, the UIM card, or the

phone, or delete all the messages.

MMS

New Message Allows you to create and send a multimedia

message.

Inbox Allows the phone to store the received multimedia

messages.

Outbox Allows the phone to store the multimedia messages

sent unsuccessfully.

Drafts Allows the phone to store the newly-created

multimedia messages before sending them.

Sent Allows the phone to store the multimedia messages

successfully sent.

My folders Allows you to store the multimedia messages that are

moved from the inbox.

Settings Allows you to set Receive options, Send reports,

Validity, Delivery Time, Server Address, Proxy

Server and Reset Settings.

Music

Allows you to access the music player and enjoy the songs.

Vbytes

Allows you to enter Voice Services, Data Services, SMS Services and

Tring Tunes. For more information, please contact service provider.

Multimedia

Music Player Music NOW!: Allows you to play the music.

All Tracks: Allows you to view all tracks on the

phone.

Artists: Allows you to view all the artists of the

music on the phone.

Playlists: Allows you to view all the playlists on the

phone.

My Files Pictures: Allows the phone to store the pictures.

Allows you to view, rename, and delete a picture, set

a picture as the wallpaper, set a picture as the contact

image, send a picture as a multimedia message or

through Bluetooth, delete all pictures, and view the

information about a picture.

Videos: Allows the phone to store video files.

Allows you to view, rename, and delete a video file,

send a video file as a multimedia message or through

Bluetooth, delete all video files, and view the

information about a video file.

Music: Allows the phone to store and play audio

files. Allows you to set an audio file as the incoming

ringtone, rename an audio file, send an audio file as a

multimedia message or through Bluetooth, delete an

audio file or delete all the audio files, and view the

information about an audio file.

Others: Allows the phone to store other kinds of

files.

Memory Card: Allows you to view and sort the files

stored in the memory card.

Memory Status: Allows you to view total memory,

the used memory, and free memory of the phone and

the microSD card.

Recorder For details, see "Recorder" on page 35.

Radio Switch Off: Allows you to switch off the radio.

Speaker On/Speaker Off: Allows you to activate or

deactivate the speaker.

Tuning: Allows you to set Automatic Tuning,

Manual Tuning, Fine Tuning, and Set Frequency.

Delete Channel: Allows you to delete a channel.

Rename Channel: Allows you to rename a channel.

Camera When you access the Camera screen, you can do as

follows:

Portrait/Landscape: Allows you to switch between

the portrait mode and the landscape mode.

Switch to Video Camera: Allows you to use

functions of the video camera on the phone.

Shot Mode: Allows the phone to take four or nine

pictures in rapid succession, if you select 4 Shots or

9 Shots. If you select Normal, the multi-shot mode

is deactivated.

Resolution: Allows you to select the resolution.

Frame: Allows you to select a fun frame.

Auto Timer: Allows you to activate the auto timer

and set the time for the camera to release the shutter,

or to deactivate the auto timer.

Night Mode: Allows you to activate or deactivate

the night mode.

Effect: Allows you to set the effect.

Shortcut Guide: Allows you to view the shortcut

keys.

Settings: Allows you to set Quality, Shutter Tone,

Auto Timer Tone, Save Location and Reset All.

Go To My Files: Pictures that are not deleted are

automatically saved to the folder.

When you access the Camcorder screen, you can do

as follows:

Switch To Camera: Allows you to use functions

of the camera on the phone.

Video Size: Allows you to set the video size.

Night Mode: Allows you to activate or deactivate

the night mode.

Effect: Allows you to set the effect.

Shortcut Guide: Allows you to view the shortcut

keys.

Settings: Allows you to set Video Quality, Audio

Setting and Reset All.

Go To My Files: Videos that are not deleted are

automatically saved to the folder.

Tools

Alarms Allows you to set up to five alarm clocks. When the

phone is powered on, an alerting tone is played at the

preset time.

Calendar Allows you to store up to 20 appointments on the

phone. The phone reminds you at the specified time.

Calculator Allows you to do some basic calculations.

Memo Allows you to write memos on the phone.

Stopwatch Allows you to measure time.

World Clock Allows you to view the local time and the time of

other major cities/areas around the world.

Ducati For details, see help of the games.

Topgun For details, see help of the games.

Settings

Phone Settings Profiles: Allows you to set the profiles of the phone.

Allow you to set the alerting mode and other

sound/vibration-related features. Your phone

supports the following profiles: General, Silence,

Meeting, Outdoor, My Profile 1 and My Profile 2.

Auto Keyguard: After you enable the function, the

keypad locks automatically if there is no operation

on the phone after 15 Seconds, 30 Seconds, or 1

Minute.

Recorder Location: Allows you to select the phone

or the microSD card as the memory to save the

recorded files.

Auto Power On/Off: Allows you to set a time for

powering on/off the phone. Then the phone

automatically powers on/off at the preset time.

Power Save: When the phone enters the power

saving mode, it can turn off the keypad backlight

automatically between 9:00 to 17:00.

Bluetooth: For details, see "Bluetooth®" on page 49.

Phone Mode: Allows you to set the phone mode.

Version: Allows you to view the software version.

Display Settings Wallpaper: Allows you to set a picture stored in the

phone as the wallpaper.

Date & Time: Allows you to set the date and time

format.

Backlight: Allows you to select backlight time,

including 10 Seconds, 20 Seconds, and 30 Seconds.

Banner: Allows you to enable or disable the

function. If you enable the function, you can edit a

banner.

Call Settings Call Waiting: Allows you to enable or disable the

function. The function is network dependent. For

details, contact your service provider.

Call Forwarding: Allows you to enable or disable

the function. If you enable the function, incoming

calls are forwarded to a specified phone number or a

voice mailbox.

Any key Answer: Allows you to enable or disable

the function. If you enable the function, you can

press any key (except and ) to answer

an incoming call.

Minute Alert: If you enable the function, the phone

notifies you of the call duration by giving an alert 15

seconds, 10 seconds or 5 seconds before the end of

each minute.

Voice Privacy: Allows you to set the privacy mode,

including Standard and Enhanced.

Call Timer: Allows the phone to display the

duration of the current call.

Headset Auto Answer: Allows the headset to

answer the call automatically when no one answers it

in 2 Seconds, 5 Seconds, or 10 Seconds, if this

function is enabled.

International Code: Allows you to select the mode

of setting the international code, including

Automatic and Manual.

Security Settings PIN Code Request: Allows you to set the PIN,

enable or disable the PIN. The PIN can protect your

UIM card from authorized use. The PIN code is

provided by your service provider.

Change PIN Code: Allows you to change the

default PIN code.

Phone Lock: Protects the phone from unauthorized

use, if it is activated.

z Immediate: Allows you to lock the phone

immediately.

z Power On: Allows the phone lock to be activated

when the phone is powered on next time.

z Off: Allows you to deactivate the phone lock.

Change Phone Code: Allows you to change the

default phone lock code (0000) into any numeric

string of four digits.

Restore Factory Settings: Allows you to restore the

phone to the factory settings after you enter the

correct phone code.

Restrict Outgoing Calls: Allows the phone restrict

the outgoing calls except the emergency calls, if this

function is enabled.

Games & Apps

Access downloaded games and applications.

18 Troubleshooting

If you encounter any problem when using the phone, try to solve the

problem according to the following table. If the problem still occurs,

contact the service provider or the dealer.

Problem Ensure that…

The battery can not be charged. The charger is properly connected to

the phone and the power socket.

The phone can not be

powered on.

z The battery power is enough.

z The battery is properly installed.

z Press and hold .

You can not make a call

except an emergency call.

z The phone number is correct.

z You are in the network service area.

z You do not enable the call restriction

function.

Bad call quality. z The signal strength is strong enough.

z If you are staying indoors, move near

to a window.

During a call, the other side

can not hear your voice. The microphone is not covered.

The signal strength is not

strong enough or the phone is

often offline.

z The antenna is in good condition.

z Move near to a place with strong

signal strength.

Problem Ensure that…

Other Bluetooth devices can

not be found; the phone

fails to send or receive data.

z The Bluetooth function is activated

on both devices.

z The distance between the two

devices is less than 10 m.

z No obstacles exist between the two

devices.

z The other device is not in the hidden

state.

The phone displays "No

service found", "Service

unavailable" or "Network

problem".

z You are not in an area with weak

magnetic field (in a tunnel or

surrounded by buildings). If so, move

to another area and try again.

z Do not visit the service option

without obtaining authorization from

your service provider.

19 Warnings and Precautions

This section contains important information pertaining to the operating

instructions of your device. It also contains information about how to use

the mobile safely. Read this information carefully before using your

device.

Electronic Device

Power off your device if using the device is prohibited. Do not use the

device when it causes danger or interference with electronic devices.

Medical Device

z Power off your device and follow the rules and regulations set forth by

the hospitals and health care facilities.

z Pacemaker manufacturers recommend that a minimum distance of 15

cm be maintained between a device and a pacemaker to prevent

potential interference with the pacemaker. If you are using a pacemaker,

use the device on the opposite side of the pacemaker and do not carry

the device in your front pocket.

z Some wireless devices may affect the performance of the hearing aids.

For any such problems, consult your service provider.

Potentially Explosive Atmospheres

Switch off your device in any area with a potentially explosive atmosphere,

and comply with all signs and instructions. Areas that may have potentially

explosive atmospheres include the areas where you would normally be

advised to turn off your vehicle engine. Triggering of sparks in such areas

could cause an explosion or fire, resulting in bodily injuries or even deaths.

Do not switch on the device at refueling points such as service stations.

Comply with restrictions on the use of radio equipment in fuel depots,

storage, and distribution areas, and chemical plants. Also, adhere to

restrictions in areas where blasting operations are in progress. Before using

the device, watch out for areas that have potentially explosive atmosphere

that are often, but not always, clearly marked. Such locations include areas

below the deck on boats, chemical transfer or storage facilities and areas

where the air contains chemicals or particles such as grain, dust, or metal

powders. Ask the manufacturers of vehicles using liquefied petroleum gas

(such as propane or butane) if this device can be safely used in their

vicinity.

Traffic Security

Observe local laws and regulations while using the device. Also, if using

the device while driving a vehicle, please comply with the following

guidelines:

z Concentrate on driving. Your first responsibility is to drive safely.

z Do not talk on the device while driving. Use hands-free accessories.

z When you have to make or answer a call, park the vehicle at the road

side before using your device.

z RF signals may affect electronic systems of motor vehicles. For more

information, consult the vehicle manufacturer.

z In a motor vehicle, do not place the device over the air bag or in the air

bag deployment area. Otherwise, the device may hurt you owing to the

strong force when the air bag inflates.

z Do not use your device while flying in an aircraft. Switch off your

device before boarding an aircraft. Using wireless devices in an aircraft

may be dangerous to the operation of the aircraft, disrupt the wireless

telephone network, and may be considered illegal.

Operating Environment

z Do not use or charge the device in dusty, damp or dirty places or places

with magnetic fields. Otherwise, the circuit may not function properly.

z The device complies with the RF specifications when the device is used

near your ear or at a distance of 1.5 cm from your body. Ensure that the

device accessories such as a device case and a device holster are not

composed of metal components. Keep your device 1.5 cm away from

your body to meet the requirement earlier mentioned.

z On a thunder and stormy day, do not use your device when it is being

charged, to prevent any danger caused by lightning.

z When you are on a call, do not touch the antenna. Touching the antenna

affects the call quality and results in increase in power consumption. As

a result, the talk time and standby time are reduced.

z While using the device, observe the local laws and regulations, and

respect others' privacy and legal rights.

z Use accessories authorized by manufacturers. Using unauthorized

accessories will render the warranty null and void.

z Keep the ambient temperature between 0°C and 45°C while the device

is being charged. Keep the ambient temperature between -20°C to 60°C

for using the device powered by battery.

Preventing Hearing Damage

Using the receiver, earbuds, headphones, speakerphone, or earpieces at

high volume can result in permanent hearing loss. Be extremely careful

when listening at high decibel levels. Set the volume to a safe level. If you

experience strange sounds in your ears like ringing or if you hear muffled

speech, get your hearing checked. If you continue to use high volume, your

hearing will soon get affected.

Hearing experts offer the following suggestions to protect your hearing:

z Reduce the time you use the receiver, earbuds, headphones,

speakerphone, or earpieces at high volume.

z Do not increase the volume to block noisy surroundings.

z Reduce the volume if you can’t hear people speaking near you.

Safety of Children

Please comply with all precautions with regard to children's safety. Letting

the child play with your device or its accessories, which may include parts

that can be detached from the device, may prove dangerous, as it may

present a choking hazard. Make sure that small children are kept away

from the device and accessories.

Environment Protection

Follow all the local regulations regarding the disposal of your devices or

electrical accessories (such as chargers, headsets, or batteries). Recycle

them. Do not dispose of an exhausted battery or a used device in a garbage

can.

Accessories

Use only the accessories, such as the charger, battery, and headset,

delivered by manufacturer. Using accessories of other manufacturers or

vendors with this device model might invalidate any approval or warranty

applicable to the device, might result in the non-operation of the device,

and might be dangerous.

Battery and Charger

z The battery can be charged and discharged hundreds of times before it

eventually wears out. When the standby time and talk time are shorter

than normal, replace the battery.

z Use the AC power supply defined in the specifications of the charger.

An improper power voltage may cause fire or the charger may not

function properly.

z Do not connect two poles of the battery with conductors such as metal

materials, keys or jewelries. Otherwise, the battery may be

short-circuiting and may cause injuries and burns on your body.

z Do not disassemble the battery or solder the battery poles. Otherwise, it

may lead to electrolyte leakage, overheating, fire, or explosion.

z If battery electrolyte leaks out, make sure that the electrolyte does not

touch your skin and eyes. When the electrolyte touches your skin or

splashes into your eyes, wash your eyes with clean water immediately

and consult a doctor.

z If the battery is damaged, or the color changes or gets abnormally

heated while you charge or store the battery, remove the battery

immediately and stop using it. Otherwise, it may lead to battery leakage,

overheating, explosion, or fire.

z If the power cable is damaged (for example, the lead is exposed or

broken), or the plug loosens, stop using the cable at once. Otherwise, it

may lead to electric shock, short-circuit of the charger, or a fire.

z The travel charger of this device can meet safety requirements of the

UL60950-1 certification. Comply with the security specifications in the

UL manual.

z Do not dispose of batteries in fire as they may explode. Batteries may

also explode if damaged.

Clearing and Maintenance

z The device, battery, and charger are not water-resistant Keep them dry.

Protect the device, battery and charger from water or vapor. Do not

touch the device and charger with a wet hand. Otherwise, it may lead to

short-circuit or malfunction of the device and electric shock to the user.

z Do not place your device, battery, or charger in places where it can get

damaged because of collision. Otherwise, it may lead to battery leakage,

device malfunction, overheating, fire, or explosion.

z If the ambient temperature is considerably low or high, the capacity and

life of the battery is reduced. When the temperature is lower than 0°C,

performance of the battery is affected.

z Do not place magnetic storage media such as magnetic cards and floppy

disks near the device. Radiation from the device may erase the

information stored on them.

z Do not leave your device, battery, or charger in a very hot or cold place.

Otherwise, they may not function properly and may lead to a fire or an

explosion.

z Do not place sharp metal objects such as pins near the earpiece. The

earpiece may attract these objects and hurt you when you are using the

device.

z Before you clean or maintain the device, power off the device and

disconnect it from the charger.

z Do not use any chemical detergent, powder, or other chemical agents

(such as alcohol and benzene) to clean the device and the charger.

Otherwise, parts of the device may get damaged or a fire can be caused.

You can clean the device and the charger with a piece of damp and soft

antistatic cloth.

z Do not dismantle the device or accessories. Otherwise, manufacturer is

not liable to pay for damages as the device and accessories are not

covered by warranty.

Emergency Call

You can use your device for emergency calls in the service area. The

connection, however, cannot be guaranteed in all conditions. You should

not rely solely on the device for essential communications.

Certification Information (SAR)

THIS DEVICE MEETS THE GOVERNMENT'S REQUIREMENTS FOR

EXPOSURE TO RADIO FREQUENCY ELECTROMAGNETIC FIELD.

Your device is a low-power radio transmitter and receiver. When it is

turned on, it emits low levels of radio frequency energy (also known as

radio waves or radio frequency fields).

Governments around the world have adopted comprehensive international

safety guidelines, developed by scientific organizations, e.g. International

Commission on Non-Ionizing Radiation Protection (ICNIRP) and Institute

of Electrical and Electronics Engineers Inc. (IEEE), through periodic and

thorough evaluation of scientific studies. These guidelines establish

permitted levels of radio wave exposure for the general population. The

levels include a safety margin designed to assure the safety of all persons,

regardless of age and health, and to account for any variations in

measurements.

Specific Absorption Rate (SAR) is the unit of measurement for the amount

of radio frequency energy absorbed by the body when using a device. The

SAR value is determined at the highest certified power level in laboratory

conditions, but the actual SAR level of the device while being operated can

be well below the value. This is because the device is designed to use the

minimum power required to reach the network.

Before a device model is available for sale to the public, it must be tested

and certified by the Federal Communications Commission (FCC), ensuring

that it does not exceed the limit established by the government-adopted

requirement for safe exposure. The tests are performed in positions and

locations (that is, at the ear and worn on the body) as required by the FCC

for each model. For body worn operation, this device has been tested and

meets FCC RF exposure guidelines when the handset is positioned a

minimum of 15 mm from the body with an accessory that contains no

metal part. Use of other accessories may not ensure compliance with FCC

RF exposure guidelines.

The SAR limit adopted by USA and Canada is 1.6 watts/kilogram (W/kg)

averaged over one gram of tissue. The highest SAR value reported to the

FCC and IC for this device type when tested for use at the ear is 1.04 W/kg,

and when properly worn on the body is 1.3 W/kg.

The SAR limit adopted by the CNIRP is 2.0 W/kg over one gram of tissue.

The value guarantees a safe distance to protect device users and the

difference caused by measurement errors. Under different test requirements

and frequency, the value varies.

Statement

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules.

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. The operation is subject to

the condition that this device does not cause harmful interface.

This equipment generates, uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. There is no guarantee,

however, that interference does not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

z Reorient or relocate the receiving antenna.

z Increase the separation between the equipment and receiver.

z Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

z Consult the dealer or an experienced radio/TV technician for help.

Warning: Changes or modifications made to this equipment not expressly

approved by manufacturer may void the FCC authorization to operate this

equipment.

Version: V100R001C16_01 Part Number: 31019967

Please refer color and shape to product.

Huawei reserves the right to make changes or improvements to any of the products without prior notice.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base, Bantian, Longgang, Shenzhen 518129, People's Republic of China

Tel: +86-755-28780808 Global Hotline: +86-755-28560808

E-mail: mobile@huawei.com Website: www.huawei.com

Huawei Technologies C5589 CDMA 1x Digital Mobile Phone with BT User Manual C5589 User Guide En

Huawei Technologies Co.,Ltd CDMA 1x Digital Mobile Phone with BT C5589 User Guide En

User Manual

Navigation menu

Namespaces

Views

Navigation
