Huawei Technologies G7105A GSM Mobile Phone User Manual G7105 20120425

Huawei Technologies Co.,Ltd GSM Mobile Phone G7105 20120425

(G7105)User Manual_20120425

Copyright © Huawei Technologies Co., Ltd. 2011.
All rights reserved.
Trademarks and Permissions
, and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names
mentioned are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”.
EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
i
Contents
1 Getting to Know Your Phone ................................................1
Your Phone ........................................................................................... 1
Keys and Functions ........................................................................... 2
Screen Icons ......................................................................................... 3
2 Getting Started .......................................................................4
Installing the SIM Card and the Battery ................................... 4
Removing the Battery and the SIM Card ................................. 4
Installing and Removing a microSD Card................................ 5
Charging the Batter y ........................................................................ 5
Using Your Finger .............................................................................. 6
Calibrating the Screen ..................................................................... 6
Universal Serial Bus (USB) .............................................................. 7
Phone Lock ........................................................................................... 7
PIN and PUK ........................................................................................ 8
Switching Between Profiles Automatically .............................. 8
Locking the Screen and Keypad .................................................. 9
3 Voice Services .........................................................................9
Making a Call ....................................................................................... 9
Answering a Call ............................................................................... 10
4 Text Entry ............................................................................. 10
Changing the Text Input Mode .................................................. 10
Text Entry Screen.............................................................................. 11
ii
Entering Letters ................................................................................ 13
Entering Numbers ........................................................................... 13
Entering Symbols ............................................................................. 13
5 Messaging ............................................................................ 14
Writing and Sending a Text Message ..................................... 14
Writing and Sending a Multimedia Message ...................... 14
6 Phonebook ........................................................................... 15
Creating a Contact .......................................................................... 15
Searching for a Contact ................................................................ 16
Setting the Preferred Storage..................................................... 16
7 Camera .................................................................................. 17
8 Video Camera ....................................................................... 18
9 Sound Recorder ................................................................... 18
10 Media Player ...................................................................... 19
Creating a New Playlist ................................................................. 19
Adding Audio or Video Files to the Playlist ......................... 20
Playing an Audio or Video File .................................................. 20
11 FM Radio ............................................................................ 21
12 Network Services ............................................................... 22
WAP ....................................................................................................... 22
13 STK ...................................................................................... 23
14 Bluetooth ............................................................................ 23
Transferring Data ............................................................................. 23
Connecting a Bluetooth Headset to Your Phone ............... 24
iii
15 Warnings and Precautions ............................................... 24
1
1 Getting to Know Your Phone
Your Phone
The following figure shows the appearance of your phone and
it is for your reference only.
1 Screen 6 Microphone
2 Earpiece 7 End key
3 Volume/Scroll key 8 Menu key
4 Camera 9 Call/Answer key
2
5 Power key
Keys and Functions
Press ... To …
Call/Answer key
Make a call.
Answer a call.
View call logs in standby mode.
Menu key Access the main menu.
End key
End a call.
Return to the standby mode.
Volume/Scroll key
Scroll up and down the submenus on a
menu screen or the options on an
option screen.
Adjust the volume in standby mode,
during a call, while media is playing or
listening to FM radio.
Power key
Power on or off the phone.
Lock the keypad in standby mode.
3
Screen Icons
Icon Indicates …
Battery power level.
Keypad locked.
A microSD card inserted.
Earphone plugged in.
New text messages.
Missed calls.
Alarms enabled.
Bluetooth function enabled.
General profile activated.
Meeting profile activated.
Outdoor profile activated.
Silent profile activated.
My style profile activated.
4
2 Getting Started
Installing the SIM Card and the
Battery
When installing the subscriber identity module (SIM) card,
ensure that the golden contact area on the SIM card is facing
downward and the beveled edge of the SIM card is properly
aligned with that of the SIM card slot.
Removing the Battery and the SIM
Card
Before removing the battery and the SIM card, ensure that your
phone is powered off.
5
Installing and Removing a microSD
Card
Before installing or removing a microSD card, power off
the phone. Once the phone is powered on, it will indicate
whether the microSD card has been installed properly.
Your phone supports a microSD card to expand the memory
capacity of you phone. When installing a microSD card, ensure
that the golden contact area on the microSD card is facing
downward.
Charging the Battery
1. Connect the larger end of the USB cable to the charger.
2. Connect the charger to a power socket.
3. Connect the smaller end of the USB cable to the phone's
charger jack/USB port.
4. Wait until the battery is fully charged.
While the battery is charging, the charging icon is animated.
When the charging icon becomes static, the battery is fully
charged.
6
5. Unplug the charger from the power socket and then the USB
cable from the phone.
Using Your Finger
You can use your finger to perform various operations on the
touch screen by tapping and dragging.
Tap: Use your finger to touch the screen once to access a
menu or select an item.
Drag: Use your finger to touch & hold an icon on the main
menu, and then move the icon. You can also use your finger
to touch and move on the screen to scroll through a menu
or a Wireless Application Protocol (WAP) page.
Calibrating the Screen
The phone can respond to the touch of your finger on the
screen accurately after screen calibration.
1. In standby mode, tap key to access the main menu
and then select Settings > Pen calibration.
2. Tap in sequence that appears on the screen as
prompted to complete screen calibration.
During the calibration, tap every accurately to
ensure that the phone can respond to your tapping and
text entry on the screen correctly after the calibration.
7
Universal Serial Bus (USB)
When the phone is connected to a personal computer (PC)
through the USB cable, a series of options, such as Mass
storage, are displayed on the phone screen.
If Mass storage is selected, you can manage the files
stored on the phone and memory card.
Phone Lock
The phone lock protects your phone from unauthorized use.
The preset phone lock code is 1234. By default, the phone lock
is disabled. Once the phone lock is enabled, you are required to
enter the phone code each time you power on the phone.
In standby mode, tap key to access the main menu and
select Settings > Security settings > Phone security > Phone
lock. Input the phone lock code and tap OK to enable the
phone lock.
In standby mode, tap key to access the main menu and
select Settings > Security settings > Phone security >
Change password to change the preset phone lock code to
any numeric string of four to eight digits.
8
Do remember your phone lock code. If you forget it,
please contact your service provider.
PIN and PUK
The personal identification number (PIN) protects your SIM
card from unauthorized use. The PIN unblocking key (PUK)
unlocks the blocked PIN. Both the PIN and the PUK are
provided with the SIM card. For details, please contact your
service provider.
If you enter incorrect PINs three times consecutively,
the phone prompts you to enter the PUK. If you enter
incorrect PUKs ten times consecutively, the SIM card
will become permanently invalid. In this case, contact
your service provider for a new SIM card.
Switching Between Profiles
Automatically
You can set your phone to activate different profiles at different
times. The phone can automatically switch between profiles
according to your settings.
1. In standby mode, tap key to access the main menu
and select Profiles > Profile auto switch.
2. Select a clock.
3. Set the status, time, repetition days, and then assign a
profile.
9
4. Tap Done > Yes to save the settings.
Locking the Screen and Keypad
In standby mode, tap key to access the main menu and
select Settings > Security settings> Auto keypad lock. On
the Auto keypad lock screen, select a period (Off, 5 sec, 30 sec,
1 min, or 5 min).
To unlock the screen and keypad, slide
rightward on the screen.
3 Voice Services
Making a Call
1. In standby mode, tap at the bottom of the screen to
access the on-screen keypad.
2. Enter the phone number, or tap to access the Contacts
screen to select the desired contact number.
To make an international call, tap * key twice
to enter the international long-distance code (+), and
then enter the country code or region code, area code
and phone number in sequence.
10
To call an extension number, enter the phone
number, p (tap * three times), and extension number in
sequence.
3. Tap or to dial the number.
You can also make a call through Call log, Contacts,
and Messaging.
Answering a Call
When there is an incoming call, you can do as follows:
Tap Answer or to answer the call.
Tap Reject or to end the call.
Tap Silent to mute the call.
4 Text Entry
Changing the Text Input Mode
The indicator of the current text input mode is displayed in the
upper left corner of the screen. You can tap on the
QWERTY/Alphanumeric input screen to select the text input
mode.
Indicator Text Input Mode
ABC and abc Multi-tap input mode
11
sABC, sabc and sPredictive input mode
123 Number input mode
Text Entry Screen
1. When QWERTY Input Screen is enabled, do the following:
Tap once to clear the last entered character (Touch and
hold to clear all the entered characters).
Tap to move the cursor to the next line.
Tap to hide the keypad.
Tap to access the alphanumeric input screen.
Tap to access the symbol/number keypad.
12
Tap to access the Input method screen and you can
select the desired input method.
Tap to switch between upper case and lower case.
2. When Alphanumeric Input Screen is enabled, do the
following:
Tap once to clear the last entered character (Touch
& hold to clear all the entered characters).
Tap to access the number keypad.
Tap to switch between upper case and lower case.
Tap to access the QWERTY input screen.
13
Tap to hide the keypad.
Tap to access the Input method screen and you can
select the desired input method.
Tap to access the symbol keypad.
Entering Letters
In QWERTY input screen, enter the letters by respectively
tapping the key with the desired letter.
In Alphanumeric input screen, tap the key with the desired
letter and then select the desired letters.
Entering Numbers
In QWERTY input screen, tap to access the
number/symbol keypad and then enter the desired
numbers.
In Alphanumeric input screen, tap to access the number
keypad and then enter the desired numbers.
Entering Symbols
In QWERTY input screen, tap to access the
symbol/number keypad and the general symbols are
displayed on the keypad. Then tap to access the
complete symbol keypad and the expanded symbols are
displayed on the keypad.
In Alphanumeric input screen, tap to access the
symbol keypad. There are four pages of symbols on the
14
symbol keypad and you can tap or to access the
page with your desired symbol.
5 Messaging
Writing and Sending a Text Message
1. In standby mode, tap at the bottom of the screen to
access the Messaging screen and then select Write
message.
2. Enter the phone number of one or more recipients in the
recipient bar, or tap to access the Contacts screen
and then select one or more recipients.
3. Edit the message contents.
4. Tap to send the message.
Writing and Sending a Multimedia
Message
1. In standby mode, tap at the bottom of the screen to
access the Messaging screen and then tap Write message.
2. Tap Options and then select Switch to MMS.
15
If you tap Add picture, Add sound, or Add video,
the message will automatically switch to a
multimedia message.
If you tap Header info, and Cc, Bcc or Subject is
selected, the message will also automatically switch
to a multimedia message.
3. Enter the phone number of one or more recipients in the
recipient bar, or tap to access the Contacts screen
and then select one or more recipients.
4. If Cc or Bcc is selected, enter the phone number of one or
more recipients respectively.
5. If Subject is selected, enter the subject of the message.
6. Edit the message contents.
You can add picture, sound, or video, or insert text
template, attachment, contact number, contact name or
bookmark by tapping .
7. Tap to send the message.
6 Phonebook
Creating a Contact
In standby mode, tap at the bottom of the screen to
access the Contacts screen.
To add a contact to your SIM card, do as follows:
16
1. On the Contacts screen, tap Add new contact.
2. Edit the Name and Number.
3. Select Options > Save > Yes .
To add a contact to your phone, do as follows:
1. On the Contacts screen, tap Add new contact.
2. Edit the Name, Number, Email address, Caller picture, and
Caller ringtone.
3. Select Options > Save > Yes .
Searching for a Contact
1. In standby mode, tap at the bottom of the screen to
access the Contacts screen.
2. Enter the first letter of the contact name in the searching bar,
and then the contacts whose names start with that letter will
be found.
3. Tap to hide the keypad, and then find the desired
contacts from the list.
Setting the Preferred Storage
1. In standby mode, tap at the bottom of the screen to
access the Contacts screen.
2. On the Contacts screen, select Options > Phonebook
settings > Preferred storage.
3. On the Preferred storage screen, select the storage (SIM,
Phone or Both).
17
7 Camera
In standby mode, tap key to access the main menu and
then select Camera.
On the Camera screen, you can do as follows:
Tap to access the Options screen to view the
photos or to configure relevant settings.
Tap to take a picture.
Tap to adjust the brightness.
Tap to zoom in and zoom out.
Tap to set the image size.
Tap to set the image quality.
Tap to set the image effect.
Tap to adjust the white balance.
Tap to select the scene mode.
Tap to set the delay timer.
Tap to set continuous shot.
Tap to exit the camera.
18
8 Video Camera
In standby mode, tap key to access the main menu and
then select Video camera.
On the Video camera screen, you can do as follows:
Tap to access the Options screen to
configure relevant settings.
Tap to start recording.
Tap to adjust the exposure
compensation.
Tap to zoom in or zoom out.
Tap to set the video quality.
Tap to set the night mode.
Tap to adjust the white balance.
Tap to set the audio recording.
Tap to exit the video camera.
9 Sound Recorder
In standby mode, tap key to access the main menu and
then select Applications > Sound recorder.
On the Sound recorder screen, you can do as follows:
19
Tap to access the Options screen to
configure relevant settings.
Tap to start the recording.
In the recording, you can tap to pause the
recording, and tap to stop the recording.
Tap to view the recording list.
Tap to exit the sound recorder.
Tap to play the audio when it is saved.
10 Media Player
You can play audio or video files stored on the phone or
memory card by media player. You can also add audio or video
files stored on the phone or memory card to the user-defined
playlist.
In standby mode, tap key to access the main menu and
then select Media player.
Creating a New Playlist
1. On the Media player screen, tap My playlists.
2. Select Options > New and then name the playlist.
20
3. Select Options > Done to complete the creation of the new
playlist.
Adding Audio or Video Files to the
Playlist
1. On the Media player screen, tap My playlists and then
select the playlist to which you want to add audio or video
files.
2. Select Options > Open and then tap Add >
Phone/Memory card to select an audio or video file.
3. Tap OK to add the selected audio or video file to the playlist.
Playing an Audio or Video File
1. On the Media player screen, tap My playlists and then
select the desired playlist.
2. Select Options > Open and then select the audio or video
file you want to play.
3. Select Options > Play to play the selected audio or video
file.
On the playing screen, you can do the as follows:
Tap to access the Options screen to perform the
relevant settings.
Tap or to switch to the previous or next audio or
video file.
Touch & hold or to rewind or fast-forward the
audio or video file.
21
Tap to start playing an audio or video file.
Tap to pause the playing of the audio or video file.
Tap to stop the playing of the audio or video file.
Tap to access the full-screen mode.
Tap to exit the media player.
11 FM Radio
In FM (frequency modulation) radio, the headset cable also
functions as an antenna. To ensure good radio reception, please
do not disconnect the headset from the phone or severely bend
the headset cable.
In standby mode, tap key to access the main menu and
then select FM.
On the FM radio screen, you can do as follows:
Tap to access the Options screen to perform relevant
settings.
Tap to turn on or turn off the FM radio.
Tap or to switch to the previous or next channel
in the channel list.
Tap or to adjust the frequency downwards or
upwards by 0.1 MHz according to the tuning mode you
have selected.
22
Tap to record the current radio program.
12 Network Services
WAP
You can access Wireless Application Protocol (WAP) sites and
use WAP-based services on the phone. To browse WAP pages,
you need to subscribe to the corresponding service from your
service provider and configure the relevant settings on your
phone.
In standby mode, tap at the bottom of the screen to
access the Internet service screen.
Tap Settings > Data account to select your service provider.
Tap Homepage to access the homepage.
Tap Bookmarks to select a WAP site from the list, and then
tap Options > Go to.
Tap Input address to enter an address, and then tap
Options > Go to.
Tap Recent pages to view WAP pages that you browse
recently.
23
13 STK
In standby mode, tap key to access the main menu and
then select STK.
The SIM Tool Kit (STK) function is available only if your service
operator provides it. It is a value-added service provided by
your operator, which allows you to send text messages, view
news, and use other applications. For further details, contact
your network operator.
14 Bluetooth
Your phone supports Bluetooth. Through Bluetooth devices,
you can synchronize files between your phone and a computer,
transfer data between your phone and other Bluetooth devices,
and talk on the phone by using a Bluetooth headset.
In standby mode, tap key to access the main menu and
then select Bluetooth.
Transferring Data
1. On the Bluetooth screen, set Power to On.
2. Select My device > Search new device to search for other
Bluetooth devices in range and pair a device with your
phone.
24
If the device selected is the first time for pairing, a
password is required for authentication. When the
device is paired with your phone, data can be
transferred between your phone and the device.
Connecting a Bluetooth Headset to
Your Phone
1. On the Bluetooth screen, set Power to On.
2. Tap Search audio device.
3. Stoke to the desired Bluetooth headset, and then tap Pair.
4. Enter the password for pairing the Bluetooth headset with
your phone.
When the Bluetooth headset is connected to your phone, the
headset icon is displayed on the standby screen, indicating that
you can use the headset.
No Bluetooth headset is included in the product
package. If you want to use a Bluetooth headset, you
need to purchase it individually.
15 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains
25
information about how to use the device safely. Read this
information carefully before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not
use the device when using the device causes danger or
interference with electronic devices.
Medical Device
Follow rules and regulations set forth by hospitals and
health care facilities. Do not use your device when using the
device is prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on
the opposite side of the pacemaker and do not carry the
device in your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas
that may have potentially explosive atmospheres include the
areas where you would normally be advised to turn off your
vehicle engine. Triggering of sparks in such areas could cause
an explosion or a fire, resulting in bodily injuries or even deaths.
Do not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio
equipment in fuel depots, storage, and distribution areas, and
chemical plants. In addition, adhere to restrictions in areas
26
where blasting operations are in progress. Before using the
device, watch out for areas that have potentially explosive
atmospheres that are often, but not always, clearly marked.
Such locations include areas below the deck on boats, chemical
transfer or storage facilities, and areas where the air contains
chemicals or particles such as grain, dust, or metal powders.
Ask the manufacturers of vehicles using liquefied petroleum
gas (such as propane or butane) whether this device can be
safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
Concentrate on driving. Your first responsibility is to drive
safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the vehicle at
the road side before using your device.
RF signals may affect electronic systems of motor vehicles.
For more information, consult the vehicle manufacturer.
In a motor vehicle, do not place the device over the air bag
or in the air bag deployment area. Otherwise, the device
may hurt you owing to the strong force when the air bag
inflates.
Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless
27
devices in an aircraft may cause danger to the operation of
the aircraft and disrupt the wireless telephone network. It
may also be considered illegal.
Operating Environment
Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may
result in a malfunction of the circuit.
The device complies with the RF specifications when the
device is used near your ear or at a distance of 1.5 cm from
your body. Ensure that the device accessories such as a
device case and a device holster are not composed of metal
components. Keep your device 1.5 cm away from your body
to meet the requirement earlier mentioned.
On a stormy day with thunder, do not use your device when
it is being charged, to prevent any danger caused by
lightning.
When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the
standby time are reduced.
While using the device, observe the local laws and
regulations, and respect others' privacy and legal rights.
Keep the ambient temperature between 0°C and 40°C while
the device is being charged. Keep the ambient temperature
between 0°C to 40°C for using the device powered by a
battery.
28
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset
volume to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may
be dangerous, as it may present a choking hazard. Ensure that
small children are kept away from the device and accessories.
Accessories
Use the accessories delivered only by the manufacturer. Using
accessories of other manufacturers or vendors with this device
model may invalidate any approval or warranty applicable to
the device, result in the non-operation of the device, and cause
danger.
Battery and Charger
Unplug the charger from the electrical plug and the device
when not in use.
The battery can be charged and discharged hundreds of
times before it eventually wears out. When the standby time
and the talk time are shorter than the normal time, replace
the battery.
Use the AC power supply defined in the specifications of the
charger. An improper power voltage may cause a fire or a
malfunction of the charger.
29
Do not connect two poles of the battery with conductors,
such as metal materials, keys, or jewelries. Otherwise, the
battery may be short-circuited and may cause injuries and
burns on your body.
Do not disassemble the battery or solder the battery poles.
Otherwise, it may lead to electrolyte leakage, overheating,
fire, or explosion.
If battery electrolyte leaks out, ensure that the electrolyte
does not touch your skin and eyes. When the electrolyte
touches your skin or splashes into your eyes, wash your eyes
with clean water immediately and consult a doctor.
If there is a case of battery deformation, color change, or
abnormal heating while you charge or store the battery,
remove the battery immediately and stop using it. Otherwise,
it may lead to battery leakage, overheating, explosion, or
fire.
If the power cable is damaged (for example, the cord is
exposed or broken), or the plug loosens, stop using the
cable at once. Otherwise, it may lead to an electric shock, a
short circuit of the charger, or a fire.
Do not dispose of batteries in fire as they may explode.
Batteries may also explode if damaged.
Danger of explosion if battery is incorrectly replaced. Recycle
or dispose of used batteries according to the local
regulations or reference instruction supplied with your
device.
30
Cleaning and Maintenance
The device, battery, and charger are not water-resistant.
Keep them dry. Protect the device, battery, and charger from
water or vapor. Do not touch the device or the charger with a
wet hand. Otherwise, it may lead to a short circuit, a
malfunction of the device, and an electric shock to the user.
Do not place your device, battery, and charger in places
where they can get damaged because of collision. Otherwise,
it may lead to battery leakage, device malfunction,
overheating, fire, or explosion.
Do not place magnetic storage media such as magnetic
cards and floppy disks near the device. Radiation from the
device may erase the information stored on them.
Do not leave your device, battery, and charger in a place
with an extreme high or low temperature. Otherwise, they
may not function properly and may lead to a fire or an
explosion. When the temperature is lower than 0°C,
performance of the battery is affected.
Do not place sharp metal objects such as pins near the
earpiece. The earpiece may attract these objects and hurt
you when you are using the device.
Before you clean or maintain the device, power off the
device and disconnect it from the charger.
Do not use any chemical detergent, powder, or other
chemical agents (such as alcohol and benzene) to clean the
device and the charger. Otherwise, parts of the device may
be damaged or a fire can be caused. You can clean the
31
device and the charger with a piece of damp and soft
antistatic cloth.
Do not dismantle the device or accessories. Otherwise, the
warranty on the device and accessories is invalid and the
manufacturer is not liable to pay for the damage.
Emergency Call
You can use your device for emergency calls in the service area.
The connection, however, cannot be guaranteed in all
conditions. You should not rely solely on the device for
essential communications.
Certification Information (SAR)
This mobile phone meets the government’s requirements for
exposure to radio waves.
This phone is designed and manufactured not to exceed the
emission limits for exposure to radio frequency (RF) energy set
by the Federal Communications Commission of the U.S.
Government.
The exposure standard for wireless mobile phones employs a
unit of measurement known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC is 1.6W/kg. *Tes ts for SAR
are conducted using standard operating positions accepted by
the FCC with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the
32
maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the poser
required to reach the network. In general, the closer you are
to a wireless base station antenna, the lower the power output.
Head:PCE 1.11 W/kg, DSS 0.011 W/kg; Sum-SAR = 1.121 W/kg
Body:PCE 1.3 W/kg, DSS 0.006 W/kg; Sum-SAR = 1.306 W/kg
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and can
be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID: QISG7105.
For body worn operation, this phone has been tested and
meets the FCC RF exposure guidelines for use with an accessory
that contains no metal and the positions the handset a
minimum of 1.5 cm from the body. Use of other accessories
may not ensure compliance with FCC RF exposure guidelines.
If you do not use a body-worn accessory and are not holding
the phone at the ear, position the handset a minimum of 1.5 cm
from your body when the phone is switched on.
33
FCC Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician for
help.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
34
Caut ion
Changes or modifications made to this device not expressly approved by
Huawei Technologies Co., Ltd. may void the FCC authorization to operate
this device.

Navigation menu
