Huawei Technologies HG8245HE GPON Terminal User Manual 1
Huawei Technologies Co.,Ltd GPON Terminal 1
User Manual
![](/img.php?id=3064980&img=bg1.png)
EchoLife HG8245H,an intelligent routing-type ONT
Smart
service Smart
interconnection
Smart O&M
A Smarter Way
for Your Broadband Life
![](/img.php?id=3064980&img=bg2.png)
GPON
Port
Dimensions (HxWxD)
• Class B+
• Receiver sensitivity: -27 dBm
• Wavelengths: US 1310 nm, DS 1490 nm
• WBF
• Flexible mapping between GEM Port and TCONT
• GPON: consistent with the SN or password
authentication defined in G.984.3
• Bi-directional FEC
• SR-DBA and NSR-DBA
Device Parameters Product Function
Interface Parameters
176 mm x 138 mm x 26 mm
(without an external antenna)
Ethernet
Port
•Ethernet port-based VLAN tags and tag removal
• 1:1 VLAN, N:1 VLAN, or VLAN transparent
transmission
• QinQ VLAN
• Limit on the number of learned MAC addresses
• MAC address learning
POTS
Port
•Maximum REN: 4
• G.711A/μ, G.729a/b and G.722
encoding/decoding
• T.30/T.38/G.711 fax mode
• DTMF
• Emergency calls (with the SIP protocol)
USB
Port
• USB2.0
• FTP-based network storage
Smart interconnection
•Smart Wi-Fi coverage
•SIP/H.248 auto-negotiation
•Any port any service
•Parental control
•L2/L3 (IPv4) forwarding: 1G uplink, 2G downlink
Smart service
•Smart Wi-Fi sharing:
Portal/802.1x authentication
SoftGRE-based sharing
•Association of one account with two POTS ports
Smart O&M
•IPTV video quality diagnosis
•Variable-length OMCI messages
•Active/Passive rogue ONT detection and isolation
•Call emulation, and circuit test and loop-line test
•PPPoE/DHCP simulation testing
•WLAN emulation
Layer 3 Features
•PPPoE/Static IP/DHCP
•NAT/NAPT
•Port forwarding
•ALG, UPnP
•DDNS/DNS server/DNS client
•IPv6/IPv4 dual stack, and DS-Lite
•Static/Default routes
•Multiple services on one WAN port
Weight
Operating temperature
Operating humidity
Power adapter input
System power supply
Static power consumption
Maximum power consumption
Ports
Indicators
about 1000 g
0°C to +40°C
5% RH to 95% RH (non-condensing)
100 –240 V AC, 50 –60 Hz
11 –14 V DC, 2 A
5 W
15.5 W
2POTS + 4GE + Wi-Fi+ USB
POWER/PON/LOS/LAN/TEL/USB
/WLAN/WPS
WLAN
• IEEE 802.11 b/g/n
• 2 x 2 MIMO
• Antenna gain: 5 dBi
• WMM
• Multiple SSIDs
• WPS
• Air interface rate:
2. 4G: 300 Mbps
Multicast
•IGMP v2/v3 proxy /snooping
•MLD v1/v2 snooping
•Multicast services through Wi-Fi
•Ethernet port rate
limitation
•802.1p priority
•SP/WRR/SP+WRR
•Broadcast packet
rate limitation
QoS Security
•SPI firewall
•Filtering based on
MAC/IP/URL addresses
•OMCI/Web UI/TR069
•Dual-system software
backup and rollback
Common O&M Power Saving
•Indicator power saving
•Scheduled Wi-Fi
shutdown
![](/img.php?id=3064980&img=bg3.png)
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
This device complies with FCC radiation exposure limits set forth for an uncontrolled
environment and it also complies with Part 15 of the FCC RF Rules. This transmitter must
not be co-located or operating in conjunction with any other antenna or transmitter. This
equipment should be installed and operated with a minimum distance of 20 centimeters
between the radiator and your body.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause
undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate
the equipment.
