Huawei Technologies HU01 FM Transmitter User Manual FM Transimitter EN 0714
Huawei Technologies Co.,Ltd FM Transmitter FM Transimitter EN 0714
Manual
13FM Transmitter
Your mobile phone supports the Frequency Modula-
tion (FM) function. With FM Transmitter, you can
transmit FM signal in a certain distance and receive
the signal through a wireless receiving device such
as an FM radio.
To use the FM Transmitter function on your mobile
phone, perform the following:
1Open the cover of the multi-purpose interface, as
shown in the following figure.
2Insert the FM Transmitter into your mobile
phone. The icon is displayed on the standby
screen. The following figure shows how to insert
the FM Transmitter.
3Select Organiser & Tools > FM Transmitter.
Scroll up or down to select an available transmit-
ting frequency.
4Select Options and you can perform the folllow-
ing:
• Select: Select a default transmitting frequency.
• Auto inching: Automatically search a proper
transmitting frequency.
• Manual inching: Manually tune a transmitting
frequency.
5Select Save to save the changes or Cancel to
cancel the changes.
Note
Tuning the frequency on the receiving
device to the same frequency as the FM
Transmitter. Then, the receiving device can
receive signals.
When playing audio files, you can select Options >
FM Transmitter to transmit the broadcasting to the
receiving device.
You can also transmit FM signal when there is an
active call. Press the OK key to select the FM mode.
Then the handset is shielded. The other party's voice
is broadcasetd through the FM radio. Your voice is
transmitted to the other party's mobile phone through
the microphone.
Note
• When charging the battery, please turn off
FM trasimitter.
• When using FM Transmitter, make sure
the distance between the FM ransmitter
and persons is at least 20cm.
With golden contact down.
Charger
connector
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equip-
ment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one of the following mea-
sures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is con-
nected.
• Consult the dealer or an experienced radio/TV
technician for help.
FCC Caution: Any changes or modifications not
expressly approved by the party responsible for com-
pliance could void the user's authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
