Quick Start Guide
MHA-L09
MHA-L29
Your phone at a glance
Before you start, let's take a look at your new phone.
•
To turn on your phone, press and hold the power button
until your phone vibrates and the screen turns on.
•
To turn off your phone, press and hold the power button,
and then touch .
To forcibly restart your phone, press and hold the power
button until your phone vibrates.
If your phone does not respond when you press the
power button, this indicates that the battery is empty.
Charge your battery for at least 10 minutes using a
genuine Huawei charger, and then turn on your phone.
Status indicator
Earpiece
Front camera
Infrared sensor
Volume button
Power button
USB-C port
Headset jack
Dual-lens camera
Laser sensor
Dual-tone flash
Microphone 2#
fingerprint sensor
Microphone 1#
Getting started
Follow the instructions in the following figures to set up your
phone. Do not insert or remove a SIM card while your phone
is on.
Please exercise caution when using the SIM ejector pin to
avoid hurting your fingers or damaging your phone.
Store your pin in a safe place out of the reach of children
to prevent them from swallowing it or injuring
themselves by accident.
Caution
Insert the SIM card into the correct card slot to ensure
that it can be recognized by the phone.
/BOP4*.
NJDSP4%
/BOP4*.
/BOP4*.
0S
3.'2
/BOP4*.
NJDSP4%
3.'2
Dual card dual standby single
pass
Your phone supports only dual card dual standby single pass,
which means you cannot use both SIM cards for calls or data
services simultaneously.
•
When you are on a call using SIM card 1, SIM card 2
cannot be used to make or answer calls. If someone calls
SIM card 2, the caller will hear a voice message similar to
"The subscriber you dialed is out of the service area" or
"The subscriber you dialed cannot be connected for the
moment, please try again later." The actual message will
vary by service provider.
•
When you are using SIM card 1's data service, SIM card
2's data service will be disabled.
Your phone's single pass feature helps reduce power
consumption and increase your phone's standby time. It is
not related to your service provider's network conditions.
It may be a good idea to contact your service provider and
subscribe to missed call reminder and related assistance
services to avoid the conflicts mentioned above.
Safety Information
Please read all of the safety information carefully before
using your device to ensure its safe and proper operation and
to learn how to dispose of your device properly.
Operation and safety
•
To prevent possible hearing damage, do not listen at
high volume levels for long periods.
•
Using an unapproved or incompatible power adapter,
charger, or battery may damage your device, shorten its
lifespan, or cause a fire, explosion, or other hazards.
•
Ideal operating temperatures are XX °C to XX °C. Ideal
storage temperatures are XX °C to XX °C.
•
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If using a pacemaker, hold the device on the
side opposite the pacemaker and do not carry the device
in your front pocket.
•
Keep the device and the battery away from excessive
heat and direct sunlight. Do not place them on or in
heating devices, such as microwave ovens, stoves, or
radiators.
•
Observe local laws and regulations while using the
device. To reduce the risk of accidents, do not use your
wireless device while driving.
•
While flying in an aircraft or immediately before
boarding, only use your device according to instructions
provided. Use of a wireless device in an aircraft may
disrupt wireless networks, present a hazard to aircraft
operation, or be illegal.
•
To prevent damage to your device's parts or internal
circuits, do not use it in dusty, smoky, damp, or dirty
environments or near magnetic fields.
•
When charging the device, make sure the power adapter
is plugged into a socket near the devices and is easily
accessible.
•
Unplug the charger from electrical outlets and the device
when not in use.
•
Do not use, store or transport the device where
flammables or explosives are stored (in a gas station, oil
depot, or chemical plant, for example). Using your device
in these environments increases the risk of explosion or
fire.
•
Dispose of this device, the battery, and accessories
according to local regulations. They should not be
disposed of in normal household waste. Improper
battery use may lead to fire, explosion, or other hazards.
FCC Regulatory Compliance
Body worn operation
The device complies with RF specifications when used near
your ear or at a distance of 1.5 cm from your body. Ensure
that the device accessories, such as a device case and device
holster, are not composed of metal components. Keep the
device away from your body to meet the distance
requirement.
Certification information (SAR)
This device is also designed to meet the requirements for
exposure to radio waves established by the Federal
Communications Commission (USA).
The SAR limit adopted by the USA is 1.6 W/kg averaged over
one gram of tissue. The highest SAR value reported to the
FCC for this device type complies with this limit.
MHA-L09:
The highest SAR value reported to the FCC for
this device type when using at the ear is 1.42 W/kg, and
when properly worn on the body is 0.6 W/kg, and when
using the Wi-Fi hotspot function is 1.39 W/Kg.
MHA-L29:
The highest SAR value reported to the FCC for
this device type when using at the ear is 1.42 W/kg, and
when properly worn on the body is 0.6 W/kg, and when
using the Wi-Fi hotspot function is 1.39 W/Kg.
FCC statement
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and
receiver.
--Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
--Consult the dealer or an experienced radio/TV technician
for help.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must
accept any interference received, including interference that
may cause undesired operation.
Caution:
Any changes or modifications to this device not
expressly approved by Huawei Technologies Co., Ltd. for
compliance could void the user's authority to operate the
equipment.
Industry Canada compliance
Body worn operation
The device complies with RF specifications when used near
your ear or at a distance of 1.5 cm from your body. Ensure
that the device accessories, such as a device case and device
holster, are not composed of metal components. Keep the
device away from your body to meet the distance
requirement.
MHA-L09:
The highest SAR value reported to the IC for this
device type when using at the ear is 1.41 W/kg, and when
properly worn on the body is 0.6 W/kg, and when using the
Wi-Fi hotspot function is 1.39 W/Kg.
MHA-L29:
The highest SAR value reported to the IC for this
device type when using at the ear is 1.41 W/kg, and when
properly worn on the body is 0.6 W/kg, and when using the
Wi-Fi hotspot function is 1.39 W/Kg.
IC Statement
This device complies with CAN ICES-3 (B)/NMB-3(B).
This device complies with Industry Canada licence-exempt
RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of the
device.
Restrictions in the 5 GHz band:
Within the 5.15 to 5.25 GHz band, UNII devices will be
restricted to indoor operations to reduce any potential for
harmful interference to co-channel Mobile Satellite System
(MSS) operations.
, , and are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Manufactured under license from Dolby Laboratories. Dolby
and the double-D symbol are registered trademarks of Dolby
Laboratories.
The N-Mark is a trademark or registered trademark of NFC
Forum, Inc. in the United States and in other countries.
LTE is a trademark of ETSI.
Wi-Fi
®
, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are
trademarks of Wi-Fi Alliance.
Privacy Policy
To better understand how we protect your personal
information, please see the privacy policy at
http://consumer.huawei.com/privacy-policy.
Copyright © Huawei Technologies Co., Ltd. 2015.
All rights reserved.
THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY,
AND DOES NOT CONSTITUTE ANY KIND OF WARRANTIES.
All pictures and illustrations in this guide, including but
not limited to the phone color, size, and display content,
are for your reference only. The actual product may vary.
Nothing in this guide constitutes a warranty of any kind,
express or implied.
底边留5mm
Please visit
http://consumer.huawei.com/en/support/hotline
for recent updated hotline and email address
in your country or region.
Model: MHA-L09
MHA-L29
For DTS patents, see http://patents.dts.com.
Manufactured under license from DTS
Licensing Limited. DTS, the Symbol, & DTS and
the Symbol together are registered
trademarks, and DTS Sound is a trademark of
DTS, Inc. © DTS, Inc. All Rights Reserved.
Note: Remember the Google account your phone
last logged in to.
During an untrusted factory settings restoration or
microSD card–based update, Google's anti-theft
mechanism requires you to enter the Google account
your phone last logged in to on the startup
navigation screen for identity authentication. Your
phone can properly power on only after the identity
authentication passes.
