User Manual Part 2

Charging the Battery
7
2
Getting Started
Before charging the battery with a cable charger,
ensure that the battery has been properly loaded into
your phone. To charge the battery, do as follows:
1Insert the plug of the charger into the connector
of the phone as shown in the following figure.
2Plug in the connector of the charger to a power
socket.
Note
• The plug of the charger is in trapezium
shape. Reversely inserting the plug may
damage the mobile phone and charger. The
connection methods of USB data cable and
headset are the same as the charger.
• When the battery power level is very low, the
phone makes alert sounds and displays a
prompt. When the battery power level is too
low, the phone will power off automatically.
• When the battery is being charged, the
charging indicator blinks continuously. When
the charging indicator stops blinking, it
indicates that the battery is full.
Loading/Removing a Memory
Card
The U7310 phone supports a memory card (micro-
SD) with a capacity up to 2 GB.
1Insert the memory card into the slot, as shown in
the following figure.
2To remove a memory card, press the memory
card gently. Now the memory card will pop up
automatically. Then take it out as shown in the
following figure.
With metallic contact upward
Powering On/Off
8
Powering On/Off
Powering On
Ensure that the SIM card is in your phone and that
the battery has been charged.
Press and hold to power on your phone.
Powering Off
Press and hold to power off your phone.
Access Codes
For setting and changing the access codes, please
refer to "Settings/Security" on page 41.
◆Phone Password
The phone password is used to protect your phone
from unauthorized use. The phone password is
preset as 0000 for your U7310 phone.
◆PIN
The personal identification number (PIN) code is
used to protect your SIM card from unauthorized use.
The PIN code is usually provided when you get the
SIM card. If you have not received a PIN code or if
you have forgotten it, contact your local customer
care centre.
◆PIN2
Some SIM cards provide a PIN2 code. Some special
functions such as the "Fixed Dialer Number" are not
available until you enter the PIN2 code. At the same
time, your SIM card should support these functions.
◆PUK
To unlock a locked SIM card, you need to enter the
PIN Unblocking Key (PUK) code. The PUK code is
usually provided when you get the SIM card. If you
have not received a PUK code or if you have forgot-
ten it, contact your local customer care centre.
◆PUK2
Some SIM cards provide a PUK2 code that is used to
unlock a locked PIN2 code. The PUK2 code is usu-
ally provided when you get the SIM card. If you have
not received a PUK2 code or if you have forgotten it,
contact your local customer care centre.
9
3Call Service
Making or Answering Calls
Making a Voice or Video Call
You can make a video call to other person whose
phone also supports video calls.
1Enter or edit a phone number in one of the fol-
lowing ways:
• Enter a phone number through the keypad.
• Select a number from the Calls screen.
• Select a number from the Contacts screen.
• Select Menu > Video call > Options, then
select a number form Calls or Contacts.
2To make a voice call or video call.
• Press to make a voice call.
• Select Options > Call > Video Call to make a
video call.
3Press to end the call.
Note
To delete a wrong number, press once
to delete the digit to the left of the cursor.
Making Voice Calls Using SDN
You can make a voice call through speed dialing.
Select Contacts > Options > Advanced > Speed
dial number to set the speed dialing number(SDN).
To make a call by SDN, press and hold the number
key until the phone dials the corresponding phone
number.
Answering or Rejecting Calls
The following describes how to answer or reject a call
in different answer modes:
Operation Description
Answer a
call
• If the answer mode is Any key,
press any key except .
• If the answer mode is Send key,
press .
• If the answer mode is Slide up,
slide the phone.
• If the headset is in use, press the
control key on the headset.
Operations During a Voice Call
10
Note
When the phone is closed and there is no
ongoing call, you can press and hold the cam-
era key to mute the ringtone of an incoming
call. You can also press and hold the volume
keys to reject the call.
You can also set the auto answer mode to Immedi-
ate answer, Text message or Recorded voice.
Operations During a Voice Call
Icon Description
: A call is ongoing.
: The call is on hold.
Operations
During a voice call, you can select Options to per-
form the following operations.
•Hold active call/Resume: To hold or resume the
call during a call.
•End: To end all calls, the active call, the current
call or the on hold call.
•Handsfree/Earpiece: To switch between the
Handsfree and the Earpiece modes during a call.
•Start recording/Stop recording: to record or stop
recording the conversation.
• Other applications: To access the Contacts
screen, the Messaging screen, the Calls screen or
the Calendar screen.
•Answer/Reject: Your phone allows you to handle
two calls simultaneously. During a call, if there is a
new incoming call, select Options > Answer to
answer it or select Options > Reject to reject it.
•Swap: To swap between calls during a 3-party call.
Reject a call Press or select Options > Reject.
End a call Press to end the call
Reply by
message
To send a predefined message to the
caller.
Operation Description
Operations During a Video Call
11
3
Call Service
•Conference call/Private call: To switch to the con-
ference call during a 3-party call or to talk with a
party privately during a conference call.
Operations During a Video Call
Icon Description
Operations
During a video call, you can press to hold the call
and send a preset file to the other party. You can
press again to resume the call. Before you use
the function, you can preset a file in Settings/Video
call/Send image.
During a video call, you can select Options to per-
form the following operations.
•Switch camera off/on: To forbid or allow the video
from your side.
•Switch to outer/inner camera: To switch between
the main lens and the assistant lens.
•Picture mode: To switch display.
•Image quality: To set the image quality to fine qual-
ity or more smooth.
•Play file: To play a media file.
•Switch to handsfree/earpiece: Switch between
the loudspeaker mode and the earpiece mode.
• Start recording: To record a video clip. A recorded
video clip is saved to the My Files/Videos direc-
tory.
• Other applications: To access the Contacts
screen, the Messaging screen, the Calls screen or
the Calendar screen.
Icon Description
Press the up or down scroll key to adjust
the brightness.
Press the left or right scroll key to zoom
in or zoom out.
Press the volume keys to adjust the vol-
ume.
/Press to switch between the loud-
speaker mode and the earpiece mode.
Calls
12
Calls
The recently dialed calls, received calls and missed
calls are saved automatically.
Select Calls in the main menu and then press the
left/right scroll key to select All calls , Missed ,
Received or Dialed . Then select Options for
the following options.
•Send message: To send a message or MMS.
•Save number: To save the number of the selected
record.
•Call: To make a voice call or a video call.
•Delete: To delete the selected record.
•Mark/Unmark: To mark/unmark a record or all
records.
•Advanced: To set the display mode of all records
or view calls status.
13
4Text Input
You can use the keypad to enter alphanumeric char-
acters and symbols. For example, you can add
entries to the contacts, write messages or schedule
events on the calendar.
Note
While entering text:
• Press to switch between input methods.
• Press and hold the key to enable or dis-
able the T9 input mode
• Press to display the symbols list.
Press and hold the key to set the
input language.
• Press to delete the letter before the
cursor.
T9® Input Method
With the T9 input method, you can easily and quickly
enter words. T9 is a predictive text entry mode. Press
the relevant key that corresponds to the desired letter
and T9 will offer you candidate words.
Press each key carrying the desired letter once, and
then the predictive text scheme will present the can-
didate words composed by the letters you have
entered in the drop-down menu.
For example, to enter the word "good" with the T9
input method, follow these steps.
1Press successively the keys , , , and
which "g", "o", "o", and "d" belong to, and the
candidate words "good", "home" etc. composed
by these letters will be shown in the drop-down
menu.
2Use the up/down scroll key to select "good".
Note
Press repeatedly and you will see "T9
abc", "T9 Abc" and "T9 ABC" on the upper
left corner of the screen successively. It indi-
cates the words to be entered will be in
lower case, first letter capitalized or in upper
case.
Traditional Input Method
When T9 input method is off, you can use the tradi-
tional input method for entering alphabetic charac-
"123" Numeric Input Method
14
ters. Repeatedly press the key that carries the letter
to be entered when it appears on the screen.
For example, to enter the word "Hello" with the tradi-
tional input method, follow these steps.
1Press that carries "h" repeatedly and all let-
ters carried by this key will be displayed succes-
sively on the screen. You can scroll through this
list and select the character you want. Stop when
you see an "h" on the screen.
2After entering the first letter, you can directly
press another key (except ) to enter the
next letter. If the next desired letter is on the
same key as the current one, wait until the cur-
sor appears to the right of the current letter and
then you can enter the next one.
3Enter "e", "l", "l" and "o" in the same way.
Note
Press repeatedly and you will see "abc",
"Abc" or "ABC" on the upper left corner of
the screen successively. It indicates the
words to be entered will be in lower case,
first letter capitalized or in upper case.
"123" Numeric Input Method
In a text editing screen, press and hold the character/
number keys to enter corresponding numeric charac-
ters. You can also press successively the key to
switch to the "123" numeric input method, and enter
corresponding numeric characters by pressing the
character/number keys.
Symbol Input Method
You can press to display the symbols list and
then select symbols to input.
You can also press to input the commonly-used
symbols in a text editing screen.
Input Different Languages
In a text editing screen, Press and hold the key
to set the language for the text.
15
5Contacts
Contacts enables you to save and manage such
information as phone numbers and addresses of your
contacts. You can save such information in your
phone or your SIM card.
Making Calls from the Contacts
You can make a voice/video call with a contact
selected from the contacts list.
1In the Contacts screen, press the left/right scroll
key to select Contacts.
2Select a contact and select Options > Call.
Then, you can select Voice Call or Video Call to
make a call.
Searching for a Contact
You can find a contact from the contacts list easily
and quickly by using this function on the Contacts
screen. Select Options >Advanced >Search
contacts, and then enter the contact name you are
searching for. The contact is displayed.
You can also use quick search in the contacts list
screen. You can find a contact by entering the initials
of the first name or the last name of the contact. For
example, to find a contact named "Alice Green",
enter the initials "a" or "g". This contact is displayed in
the candidate list.
Other Operations
In the Contacts screen, select Options for the fol-
lowing options.
•View: To view the detailed information of the con-
tact.
•Call: To make a voice call or a video call.
•Send message: To send a message or Email to the
selected contact.
•Send contact: To send a contact to other devices
supporting Message or Bluetooth.
•Add new contact: To create a new contact.
•Delete: To delete the selected contact.
•Mark/Unmark: To mark/unmark a record or all
records in your phone and SIM card.
•Advanced: To access the advanced options.
• Settings: To set the default contact list displayed in
the contact screen, to sort the contacts on the
Contacts screen.
Groups
16
•Memory status: To view the memory status of both
your phone and SIM card.
Groups
Adding/Deleting Group Members
1In the Contacts screen, press the left/right scroll
key to select Groups.
2Select a group and press OK key to view the
details.
3Select Options > Add contact. Select a contact
and press Add. The member you added is dis-
played in the group member list.
To delete a group member, select a member from the
group member list, and then select Options >
Remove.
Managing a Group
In the Contacts screen, press the left/right scroll key
to select Groups. Select a group and select Options
for the following options: Details, Rename, Send
message and Remove all members.
17
6Messaging
Messages
The maximum content for a single text message is
160 characters. If the characters you enter exceed
this limit, the text is divided into two or more continu-
ous messages when it is sent.
Creating a Message
With this option, you can create new SMS, MMS.
1Select Messaging > Create message in the
main menu to access the SMS or MMS editing
screen.
2During editing a message, you can press down
scroll key to add attachment files.
3Press left/right scroll key to switch, then press
OK key to select file from My Files or preview
the message.
4After editing the message, select OK key to add
a recipient’s number.
5Press OK key to send the message.
Messages Mailboxes
The phone provides four mailboxes for messages,
namely, Inbox, Drafts, Outbox, Sent.
◆Inbox
You can save the received messages in Inbox.
Icons in Inbox
Icon Description
a read SMS or a read message report
an unread SMS or an unread message
report
a read MMS
an unread MMS
A read Push message
An unread Push message
Messages
18
Viewing Messages in Inbox
1Select Messaging > Inbox.
2Press the up/down scroll key to view the mes-
sages and then press OK key to view the details.
3You can select Options for the following opera-
tions.
• Play: To play the multimedia message.
• Reply: To reply the message.
• Forward: To forward the message.
• Delete: To delete the message.
• Call sender: To call the message sender by a
voice call or a video call.
• Extract.: To select Add to Contacts, Send
Message, and Edit before call.
• Save picture: To save the picture of the MMS.
• Save as template: To save this message as a
template.
◆Drafts
The Draft box is used to save the messages you cre-
ated and saved.
Icons in Drafts
: A text message saved to the phone.
: A multimedia message saved to the phone.
: A postcard message saved to the phone.
Viewing and Editing Messages in the Draft
1Select Messaging > Drafts.
2Press the up/down scroll key to select a mes-
sage and press OK key to edit it.
◆Sent
Sent is used to save the messages that have been
sent successfully.
Icons in Sent
: A text message has been sent.
: A multimedia message has been sent.
Viewing Messages in Sent
1Select Messaging > Sent.
Email
19
6
Messaging
2Press the up/down scroll key to select a mes-
sage and press OK key to view the details.
3You may select Options the following opera-
tions.
• Forward: To forward the message.
• Delete: To delete the message.
• Save as template: To save this message as a
template.
◆Outbox
Outbox is used to save the messages that failed to
be sent.
Icons in Outbox.
: A message that fails to be sent.
Viewing and Editing Messages in the Outbox
1Select Messaging > Outbox.
2Press the up/down scroll key to select a mes-
sage and press OK key to edit it.
Message Settings
You can change the message settings by performing
the following steps.
1Select Messaging > Settings > SMS & MMS
from the main menu.
2Set the parameters related to messages.
Email
Email Settings
1Select Messaging > Settings > Email and
select an account.
2The related account information contains: Gen-
eral, Incoming, Outgoing and Online help.
3Return to the Account screen. Select Options >
Set as default to activate this account.
After completing all settings, press Back.
Note
For the account settings, contact your local
customer care centre.
Email
20
Creating an Email
1Select Email > Create Email to access the
email editing screen.
2Select To and press OK key. Select Enter recip-
ient or Add from Contacts to select an email
address.
3In the email editing screen, select Subject and
press OK key to edit the contents.
4In the email editing screen, select the Message
text box to edit the content.
5In the email editing screen, select Options >
Add attachment to attach picture, music, video,
eBook, or etc.
6In the email editing screen, select Options >
Send to send the email.
Mailboxes
Your Phone provides five mailboxes for email,
namely, Inbox, Drafts, Sent, Outbox and Blocked.
◆Inbox
All Emails received are saved in the Inbox.
Icons in Inbox
: A read email.
: An unread email.
Viewing and Editing Emails in Inbox
1Select an email and press OK key to view the
content.
2In the Details screen, select Options for the fol-
lowing operations:
• View: To view the content.
• Reply: To reply to the email sender.
• Reply all: To reply to the email sender and all
email receivers except the replier.
• Forward: To forward the selected email.
• Delete: To delete the selected email.
◆Drafts
The saved new emails are saved in the Drafts.
Icon in Drafts
: Emails to be sent.
Broadcast Inbox
21
6
Messaging
Viewing and Editing Emails in Drafts
1Select the desired email in the Drafts and press
OK key to access the editing screen.
2Edit the related information. For details, perform
the same operations as in creating an email.
◆Sent
The emails sent to server are saved in the sent box.
Icon in Sent
: A read email.
Viewing and Editing Emails in Sent
1Select an email and press OK key to view the
details.
2You may select Options to perform the same
operations as those of the Inbox.
◆Outbox
Those emails which failed to be sent are retained in
the Outbox.
Icon in Outbox
: Emails failed to send.
Viewing and Editing Emails in Outbox
1Select an email and press OK key to access the
editing screen.
2Edit the related information. For details, perform
the same operations as in creating an email.
◆Blocked
The blocked emails are saved in this folder. You can
select Email> Email Wizard to set the blocking con-
ditions.
Broadcast Inbox
The broadcast messages are saved in the broadcast
inbox. You can select Messaging > Settings >
Broadcast to set the broadcast message.
Templates
You can save the frequently-used SMS or MMS as
template for your convenience.
22
7Music
Music enables you to manage your music files easily
and conveniently.
Music
In the music, you can find a great variety of music to
download onto your mobile phone.
Recently Played
Select this option, you can play the recently played
music file.
Music Library
You can play various music files, including those sup-
plied with the phone, recorded by using the phone,
downloaded from the Internet, and attached to email.
In music library, you can add the music files in the
handset or memory card to the playlists.
Screen Operations During Playing
During playing the music file, you can perform the fol-
lowing operations on the music file.
Operation Description
Press the up scroll key to access the
playlist.
Press the down scroll key to go back to
the beginning of the current music file.
Press the right scroll key to access the
next music file. Press and hold the right
scroll key to fast forward the current
music file.
Press the left scroll key to access the
last music file. Press and hold the left
scroll key to fast backward the current
music file.
/Press OK key to pause the playing.
Press OK key again to resume the play-
ing.
Press the volume keys to adjust the vol-
ume.
23
8Organiser & Tools
This function provides you with various helpful tools.
You can select Organiser & Tools from the main
menu.
Alarms
Setting Alarm Clocks
Enter alarm function, you can select one alarm from
the list, and then press OK key to set an alarm clock.
Alarm Prompt
When it is time for an alarm clock to ring, the selected
alarm tone is played and a prompt is displayed. You
can stop the ringing and snooze by pressing any key
(except left function key and power key), or by closing
or opening your phone.
If your phone is powered off, the alarm clock will still
ring. When the alarm rings, you can choose to power
on the phone.
Stopping the Alarm Clock
Select an alarm clock from the list, and press the left
function key or power key to deactivate it.
Calendar
Enter calendar function, you can select Options >
New to create the schedule events for the current
day. The schedule prompt is the same with alarm
prompt. In the calendar view screen, you can select
Options > View to view the events.
Task
The tasks are classified into three kinds: pending,
done, and all tasks. You can define up to 1000 tasks
on your phone.
To define a new task, press OK key or select
Options > New on the Tasks screen. The task
prompt is the same with alarm prompt.
Memo
You can store important events on your phone. You
can save up to 100 such memos.
Synchronise
24
On the Memo screen, you can perform the following
operations: Edit, New, Delete, Send, Memory sta-
tus and Delete all.
Synchronise
You can synchronise contacts with your personal
phone book in the network. Before use the synchro-
nise function, you may need to set a profile.
1To create a profile, select Options > New to cre-
ate a profile.
2Press the scroll key to switch between Synchro-
nise Items, Server Setting, and Network Pro-
file.
3In the Synchronise Items screen, select the
item to be synchronised and press OK key to
confirm it. Then, enter the Database name,
User name, and Password of the synchronisa-
tion items.
4In the Server Setting screen, enter Server
Address, User name, Password.
5In the Network profile screen, enter the proxy
server address and the port. Then, enter the net-
work access point and select a desired profile.
6Return to the previous menu and select Options
> Synchronize to start synchronising.
Note
This service is not available in all networks. For
details, contact your local customer care centre.
Calculator
You can perform addition, subtraction, multiplication,
division and extraction operations on your phone.
• Press the scroll key to enter the operators.
• Press the left function key to clear.
• Press the right function key to exit Calculator.
• Press to enter a radix point.
• Press to delete the character to the left.
• Press to perform extraction.
• Press OK key to enter an equal mark.
Unit Converter
25
8
Organiser & Tools
Unit Converter
You can convert units of length and weight between
different systems on your phone. Press the up/down
scroll key to switch between the setup items and
press the left/right scroll key to select weight or
length. Select CE to clear the numeric values you
entered.
Currency Converter
You can convert a value from one currency to another
using your phone. Press the up/down scroll key to
switch between the setup items. Press to clear
the numeric values you entered.
Voice Recorder
You can record voices or sounds on your phone.
•Record/Pause: During recording, press OK key to
pause, and press OK key again to resume.
• Stop and save: During recording, press the left func-
tion key to stop recording. The audio file is saved in
My Files\Music automatically.
• Play an audio file instantly: After recording is com-
plete, select Option > Play to play the audio file.
World Time
You can view the time of important cities around the
world. To switch among the time zones, press the left/
right scroll key.
Stopwatch
You can use the stop watch function. On the
Stopwatch screen, you can perform the following
operations: Start, Save, Pause, Continue, Reset.
Timer
You can set a timer for up to 99 hours and 59 min-
utes. After you have set it, the timer is displayed on
the home screen.

Navigation menu
