Hunter Douglas Window Fashions 1DX Communications Module User Manual Rev 3

Hunter Douglas Window Fashions Communications Module Users Manual Rev 3

Users Manual Rev 3

Confidential
1DX
Installation Manual
1
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
FCC ID of this product is as follows.
FCC ID: UXU1DX
IC No. of this product is as follows.
IC : 7316A-1DX
For OEM integration only – device cannot be sold to general public.
Therefore we will ask OEM to include the following statements required
by FCC and IC on the product and in the Installation manual Notice.
Contents
1.Voltage
2.Antenna
3.Notice
2
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
Confidential
1.Supply Voltage
Specification Voltage
VBAT 3.0 3.6 4.8 V
VDDIO 1.71 1.8or3.3 3.63 V
3
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
Confidential
2.Antenna
■Please perform the antenna design that followed the specifications of the
antenna.
The concrete contents of a check are the following three
points.
１）It is the same type as the antenna type of antenna
specifications. The trace reference
design section is provided under a separate non-disclosure agreement
２）An antenna gain is lower than a gain given in antenna
specifications.
Measure the gain, and confirm the peak gain is less than the application value
(1.4dBi)
３）The emission level is not getting
worse.
Measure the spurious, and confirm degradation of less than 3dB than spurious value
of
worst of report used for the application. However it is spurious defined
below.
Please send those reports to
Hunter Douglas.
4
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
Confidential
3.Notice
For OEM integration only – device cannot be sold to general public.
Therefore we will ask OEM to include the following statements required
by FCC/IC on the product and in the Installation manual Notice.
Please describe the following warning on the final product which contains this module.
Contains Transmitter Module FCC ID: UXU1DX
or
Contains FCC
ID: UXU1DX
and
Contains
IC: 7316A-1DX
5
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
Confidential
3.Notice
●Please describe the following warning to the
manual.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1)
This
device may not cause harmful interference, and (2) this device must accept
any interference received,
including
interference that may cause undesired operation.
FCC
CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the
equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
※When the product is small, as for these words mentioned above, the posting to a manual is possible.
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two
conditions:
(1) This device may not cause interference;
and
(2) This device must accept any interference, including interference that may cause undesired
operation of
the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts
de
licence.
L’exploitation est autorisée aux deux conditions suivantes
:
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible
d’en compromettre le
fonctionnement.
※When the product is small, as for these words mentioned above, the posting to a manual is possible.
6
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
Confidential
3.Notice
●When installing it in a mobile equipment. Please describe the following warning to the
manual.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment
and
meets
the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and
operated keeping
the
radiator at least 20cm or more away from person’s body.
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and
meets
RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and
operated
keeping
the radiator at least 20cm or more away from person’s body.
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un
environnement
non
contrôlé et respecte les règles d’exposition aux fréquences radioélectriques (RF)
CNR-102 de l’IC. Cet équipement doit être installé et utilisé en gardant une distance de 20 cm ou plus
entre le radiateur et le corps
humain.
RF Exposure requirements are met when installed in mobile
equipment.
This module cannot be installed in portable equipment without further testing
and
a change to FCC's grant of authorization.
Contact Murata regarding portable
applications.
7
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
Confidential
3.Notice
●When installing it in a portable
equipment.
It is necessary to take a SAR test with your set mounting this
module.
Class II permissive change application is necessary using the SAR report.
Note)
Portable equipment : Equipment for which the spaces between human body and antenna are used within 20cm.
Mobile equipment : Equipment used at position in which the spaces between human body and antenna exceeded 20cm.
8
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
Confidential
3.Notice
This device is intended only for OEM integrators under the following conditions: (For module device
use)
1) The antenna must be installed such that 20 cm is maintained between the antenna and users,
and
2) The transmitter module may not be co-located with any other transmitter or antenna.
3)The use of an antenna with gain less than 1.4
dBi.
As long as 3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is
still
responsible for testing their end-product for any additional compliance requirements required with this module
installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes: (Pour
utilisation
de dispositif
module)
1)L'antenne doit être installée de telle sorte qu'une distance de 20 cm est respectée entre l'antenne et les utilisateurs, et
2)Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou
antenne.
Tant que les 3 conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas
nécessaires.
Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes exigences
de
conformité supplémentaires requis pour ce module installé.
9
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
Confidential
3.Notice
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or
co-
location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be
used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end
product
(including the transmitter) and obtaining a separate FCC
authorization.
End Product
Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may
be
maintained between the antenna and users. The final end product must be labeled in a visible area with the following:
“Contains FCC ID: UXU1DX”. The grantee's FCC ID can be used only when all FCC compliance requirements are
met.
Manual Information To the End
User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this
RF
module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this
manual.
10
Copyright © Hunter Douglas Window Fashions All rights reserved.
28 April 2016
Confidential
IMPORTANT
NOTE:
In the event that these conditions can not be met (for example certain laptop configurations or co-location with
another transmitter), then the Canada authorization is no longer considered valid and the IC ID can not be used
on the
final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end
product (including
the
transmitter) and obtaining a separate Canada authorization.
NOTE
IMPORTANTE:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines configurations
d'ordinateur portable ou de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est plus
considéré
comme
valide et l'ID IC ne peut pas être utilisé sur le produit final. Dans ces circonstances,
l'intégrateur OEM sera chargé de réévaluer le produit final (y compris l'émetteur) et l'obtention d'une autorisation
distincte au
Canada.
End Product
Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20
cm
may
be maintained between the antenna and users. The final end product must be labeled in a visible area
with the following: “Contains IC:
7316A-1DX
”.
Plaque signalétique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne peut être
installée
de
telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les utilisateurs. Le
produit final doit
être
étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC:
7316A-1DX".
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove
this
RF module in the user’s manual of the end product which integrates this
module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Manuel d'information à l'utilisateur
final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon d'installer
ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce
module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements comme
indiqué dans ce
manuel.
