Donotstoreorusegasolineorother
flammablevaporsandliquidsinthevicinityof
thisoranyotherappliance.
WHATTODOIFYOUSMELLGAS
Donottrytolightanyappliance.
Donottouchanyelectricswitch,donot
useanyphoneinyourbuilding.
Immediatelycallyourgassupplierfroma
neighbor'sphone.Followthegas
supplier'sinstructions.
Ifyoucannotreachyourgassupplier,call
thefiredepartment.
Installationandservicemustbeperformed
byaqualifiedinstaller,serviceagencyorthe
gassupplier.
HydroSmart115
“MicroBoiler”forRadiantHeating
InstallationManualandOwner’sGuide

H
y
droSmart115
Ifyouhaveanyquestions,please
callorwriteto:
HydroSmartInc.
10725165thAveNW,
Elk River, MN 55330
WARNING
Iftheinformationinthese
instructionsisnotfollowed
exactly,afireorexplosion
mayresultcausing
propertydamage,personalinjuryordeath.
PleasemakesurethepropergaspressureguidelinesandrecommendationfromHydro
Smartfailuretodosocancauseafireorexplosionandmayresult,causingproperty
damage,personalinjury,ordeath.
ANSI Z21.10.3 andCSA4.3
Contents
2Page
CONTENTS
SPECIFICATIONS…………………………………………………………………………………………..………………………...
INTRODUCTION…………………………………………………………………………………………………..………………….
SAFETYGUIDELINES…………….………………………………………………………………………………………..………..
INSTALLATION………………………………………………………………………………………………..…………………..….
General………………………………………………………………………………………………………………………..…..…
Clearances…………………………………………………………………………………………………………………………..
IncludedAccessories…………….………………………………………………………………………………………..…..
OptionalItems…………………………………………………………………………………………………………………….
WarningforInstallations…………………………………………………………………………………………………….
HighAltitudeInstallations…………………………………………………………………………………………………..
VentingInstructions…………………………………………………………………………………………………………...
GasSupplyandGasPipeSizing………........................................................................................
WaterConnections……………..………………………………………………………………………………………………
ElectricalConnections……………………………………………………………………..…………………………….......
RemoteControllerConnections……..……………………………………………………………………….………..…
APPLICATIONS...………………………………………………………………………………………………………………..……
INITIALOPERATION..………………………………………………………………………………………………………….……
OPERATINGSAFETY…………………………………………………………………………………………………………………
NORMALOPERATION…………………………………………………………………………………………………………..…
General………..……….………….…………………………………………………………………………………………………
Operation……………………………………………………………………………………………………………………….....
TemperatureSettings.…….……..…………………………………………………………………………………………
Flow…………………………………………………………………………………………………………………………………….
FreezeProtectionSystem…….…………………………………………………………………………………………..…
MaintenanceandService………………………………………………………………………………………………….…
UnitDraining…………………………………………….…………………………………………………………………………
TROUBLESHOOTING……..……………………………………………………………………………………………………..…
General………..……….………….…………………………………………………………………………………………………
ErrorCodes.…………………….…..………………………………………………………………………………………………
COMPONENTSDIAGRAM……………………………………………………………………………………………………..…
PARTSLIST………………….………………………………………………………………………………………………..…………
OUTPUTTEMPERATURECHART…………………………………………………………………………………………...…
LIMITEDWARRANTY…………………………………………………………....…………………………………………….….
3
4
5
6
6
8
8
9
10
11
12
17
20
21
22
23
25
26
28
28
28
29
30
30
31
31
32
32
34
37
39
41
42
InstallationManual
Owner’sGuide
Specifications
3Page
SPECIFICATIONS
ModelHydroSmart115
NaturalGasInput
(OperatingRange)
Min:19,500Btu/h
Max:140,000Btu/h
PropaneInput
(OperatingRange)
Min:19,500Btu/h
Max:140,000Btu/h
GasConnection¾”NPT
WaterConnections¾”NPT
WaterPressure15‐150psi*
NaturalGas
InletPressure
Min.5.0”WC
Max.10.5”WC
Propane
InletPressure
Min.8.0”WC
Max.14.0”WC
Manifold
Pressure**
Natural2.0”WC
Propane2.5”WC
Weight33lbs.
DimensionsH20.5”xW13.8”xD6.7”
IgnitionElectricIgnition
Electric
Supply120VAC/60Hz
Consumption
Operation73.1W/0.61A
Standby6.2W/0.05A
Freeze
Protection111W/0.93A
*40psioraboveisrecommendedformaximumflow.
**TheManifoldPressureisthefactorysettingandgenerallyshouldnotneedadjustment.
NOTE:
Checktheratingplatetoensurethisproductmatchesyourspecifications.
InaccordancewithANSIZ21.10.3,COemissiondoesnotexceed400PPMfor
normalinput.
HydroSmartreservestherighttodiscontinue,orchangeatanytime,
specificationsordesignswithoutnoticeandwithoutincurringobligations.
I
I
I
n
n
s
s
s
t
t
t
a
a
l
l
l
l
l
l
a
a
t
t
t
i
i
i
o
o
n
n
M
M
M
a
a
n
n
u
u
a
a
l
l
l
Introduction
4Page
INTRODUCTION
Thismanualprovidesinformationnecessaryfortheinstallation,operation,and
maintenanceofthewaterheater.
Themodeldescriptionislistedontheratingplatewhichisattachedtothefrontpanel
ofthewaterheater.
Pleasereadallinstallationinstructionscompletelybeforeinstallingthisproduct.
Ifyouhaveanyproblemsorquestionsregardingthisequipment,consultwithHydro
Smart.
HydroSmart115isawaterheaterdesignedtobeusedwithradiantheatingina
combinationHydroPanel.
1. Ahotwatertapisturnedon.
2. Waterenterstheheater.
3. Thewaterflowsensordetectsthewaterflow.
4. Thecomputerinitiatesthefanmotorandsendsasignaltotheignitertocreateanignition
spark.
5. Thegasignitesandflamesappearwithintheburnerchamber.
6. Watercirculatesthroughtheheatexchangerandthengetshot.
7. Usingthermistorstomeasuretemperaturesthroughoutthewaterheater,thecomputer
modulatesthegasandwatervalvestoensureproperoutputwatertemperature.
8. Whentheta
p
isturnedoff
,
theunitshutsdown.
Theprinciplebehindtanklesswaterheatersissimple:
Pleasereadallinstallationinstructionscompletelybeforeinstallingthisproduct.
ThisproductisonlytobeusedwithHydroSmartHeatingPanels,“Integrator”.
*Thisdiagram
illustratestankless
waterheaterdesign
conceptsonlyand
doesnotaccurately
representtothewater
heater’sphysical
description.
Watersupply
Heatingpanel“Integrator” Strainer
Gasvalve
Thermistor
Burner
HydroSmart115
GAS
Airvent
Expansiontank
Flowsensor
Watercontrolvalve
Pumpcontroller
Primarypump
Secondarypump
Radiantheating
Checkvalve
SafetyGuidelines
5Page
Watertemperaturesover125°F (52
°
C) cancausesevereburnsinstantlyordeath
fromscalding.Thewatertemperatureissetat122°F(50°C)fromthefactoryto
minimizeanyscaldingrisk.Beforebathingorshoweringalwayscheckthewater
temperature.
Donotstoreorusegasolineorotherflammables,vapors,orliquidsinthevicinity
ofthisappliance.
Donotreversethewaterand/orgasconnectionsasthiswilldamagethegas
valvesandcancausesevereinjuryordeath.Followthediagramonp.20when
installingyourwaterheater.
Donotusethisapplianceifanyparthasbeenincontactwithorbeenimmersed
inwater.Immediatelycallalicensedplumber,alicensedgasfitter,ora
professionalservicetechniciantoinspectand/orservicetheunitifnecessary.
Donotdisconnecttheelectricalsupplyiftheambienttemperaturewilldrop
belowfreezing.TheFreezePreventionSystemonlyworksiftheunithaselectrical
power.Thewarrantywillnotbecoverediftheheatexchangerisdamageddueto
freezing.RefertothesectionontheFreezePreventionSystemonp.30formore
information.
SAFETYGUIDELINES
SAFETYDEFINITIONS
Indicatesanimminentlyhazardoussituationwhich,ifnotavoided,willresultin
deathorseriousinjury.
Indicatesanimminentlyhazardoussituationwhich,ifnotavoided,couldresult
indeathorseriousinjury.
Indicatesanimminentlyhazardoussituationwhich,ifnotavoided,couldresult
inminorormoderateinjury.
GENERAL
1. Followalllocalcodes,orintheabsenceoflocalcodes,followthemostrecenteditionofthe
NationalFuelGasCode:ANSIZ223.1/NFPA54intheUSAorCAN/CSAB149.1NaturalGas,Propane
InstallationCodeinCanada.
2. Properlygroundtheunitinaccordancewithalllocalcodesorintheabsenceoflocalcodes,with
theNationalElectricalCodes:ANSI/NFPA70intheUSAorCSAstandardC22.1CanadaElectrical
CodePart1inCanada.
3. Carefullyplanwhereyouintendtoinstallthewaterheater.Pleaseensure:
Yourwaterheaterwillhaveenoughcombustibleairandproperventilation.
Locateyourheaterwherewaterleakagewillnotdamagesurroundingareas(pleaserefer
top.7).
4. ChecktheratingplateforthecorrectGASTYPE,GASPRESSURE,WATERPRESSUREandELECTRIC
RATING.
*Ifthisunitdoesnotmatchyourrequirements,donotinstallandconsultwithHydroSmart.
5. Ifanyproblemshouldoccur,turnoffallhotwatertapsandturnoffthegas.Thencallatrained
technicianortheGasCompanyorHydroSmart.
WARNING
CAUTION
DANGER
WARNING
Installation
6Page
INSTALLATION
GENERAL
1. Followalllocalcodes,orintheabsenceoflocalcodes,followthemostrecenteditionofthe
NationalFuelGasCode:ANSIZ223.1/NFPA54intheUSAorCAN/CSAB149.1NaturalGas,
PropaneInstallationCodeinCanada.
2. Allgaswaterheatersrequirecarefulandcorrectinstallationtoensuresafeandefficient
operation.Thismanualmustbefollowedexactly.Readthe“SafetyGuidelines”section.
3. Themanifoldgaspressureispresetatthefactory.Itiscomputercontrolledandshouldnot
needadjustment.
4. Maintainproperspaceforservicing.Installtheunitsothatitcanbeconnectedorremoved
easily.RefertotheClearancesSectiononp.8forproperclearances.
5. Thewaterheatermustbeinstalledinalocationwheretheproperamountofcombustibleair
willbeavailabletoitatalltimeswithoutobstructions.
6. Theelectricalconnectionrequiresameansofdisconnection,toterminatepowertothewater
heaterforservicingandsafetypurposes.
7. Donotinstalltheunitwheretheexhaustventispointingintoanyopeninginabuildingorwhere
thenoisemaydisturbyourneighbors.Makesuretheventterminationmeetstherequired
distancebylocalcodefromanydoorwayoropeningtopreventexhaustfromenteringabuilding
(refertop.15).
8. Particlesfromflour,aerosols,andothercontaminantsmayclogtheairventorreducethe
functionsoftherotatingfanandcauseimproperburningofthegas.Regularlyensurethatthe
areaaroundtheunitisdust‐ordebrisfree;regularmaintenanceisrecommendedforthese
typesofenvironment.
9. Ifyouwillbeinstallingthewaterheaterinacontaminatedareawithahighlevelofdust,sand,
flour,aerosolsorothercontaminants/chemicals,theycanbecomeairborneandenterandbuild
upwithinthefanandburnercausingdamagetothewaterheater.
10. FortheHydroSmart115:
Theseunitsmaybeconvertedtoadirectvent(sealedcombustion)appliancebyinstallinga
directventconversionkitPartNo.9007667005(TKTV10)whichwillbringinallrequired
combustibleairfromoutsidethebuilding.Wheninstallingthedirectventconversionkit,
pleasefollowallinstructionsincludedwiththekit.
Ifthewaterheaterisusedasadirectventappliance,theunitrequiresa3”combustibleair
supplypipe.Theintakepipemustbesealedairtight.AirsupplypipecanbemadeofABS,
PVC,galvanizedsteel,corrugatedaluminum,corrugatedstainlesssteelorCategoryIII
stainlesssteel.
Terminatingtheventingthroughasidewallisrecommendedforthedirectventsystem.
Runningtheexhaustventandtheintakepipeparallelisrecommended.
Terminatingtheexhaustandintakeonthesamewall/surfaceisrecommended.
Terminatinginthesamepressurezoneallowsforpressurebalancing,whichprevents
nuisanceshutdowns.
Installation
7Page
Installationandservicemustbeperformedbyaqualifiedinstaller(for
example,alicensedplumberorgasfitter),otherwisethewarrantybyHydro
Smartwillbevoid.
Theinstaller(licensedprofessional)isresponsibleforthecorrectinstallation
ofthewaterheaterandforcompliancewithallnational,state/provincial,
andlocalcodes.
HydroSmartdoesnotrecommendinstallingthewaterheaterinapitor
locationwheregasandwatercanaccumulate.
Donothavetheventterminalpointingtowardanyoperatingwindow,door,or
openingintoabuilding.
Donotinstallnexttoanysourceofairbornedebris,suchasaclothesdryer,
thatcancausedebristobetrappedinsidethecombustionchamber,unless
thesystemisdirectvented.
HydroSmartdoesnotrecommendinstallingthewaterheaterinanatticdue
tosafetyissues.Ifyouinstallthewaterheaterinanattic:
Makesuretheunitwillhaveenoughcombustionairandproperventilation.
Keeptheareaaroundthewaterheaterclean.Whendustcollectsonthe
flamesensor,thewaterheaterwillshutdownonanerrorcode.
Iftheaboveconditionscannotbemet,usethedirectventconversionkit
PartNo.9007667005(TKTV10).
Placetheunitforeasyaccessforserviceandmaintenance.
Adrainpan,orothermeansofprotectionagainstwaterdamage,is
re
q
uiredtobeinstalledunderthewaterheaterincaseofleaks.
Thewarrantywillnotcoverdamagecausedbywaterquality.
Onlypotablewaterorpotablewater/glycolmixturescanbeusedwiththis
waterheater.Donotintroducepoolorspawater,oranychemically
treatedwaterintothewaterheater.
Waterhardnesslevelsmustnotexceed7grainspergallon(120ppm)for
singlefamilydomesticapplicationsormorethan4grainspergallon(70
ppm)forallothertypesofapplications.Waterhardnessleadstoscale
formationandmayaffect/damagethewaterheater.Hardwaterscaling
mustbeavoidedorcontrolledbyproperwatertreatment.
WaterpHlevelsmustbebetween6.5and8.5
Wellwatermustbetreated.
Donotinstalltheunitwherewater,debris,orflammablevaporsmaygetinto
theflueterminal.
HydroSmartrecommendsusingthedirectventkitwhenthewaterheateris
installedinabeautysalon.Somechemicalsusedinabeautysalonmayaffect
theflamesensor.Waterheatermaynotworkproperly.
Althoughthewaterheaterisdesignedtooperatewithminimalsound,Hydro
Smartdoesnotrecommendinstallingtheunitonawalladjacenttoa
bedroom,oraroomthatisintendedforquietstudyormeditation,etc.
Locateyourheaterclosetoadrainwherewaterleakagewillnotdodamageto
surroundingareas.Aswithanywaterheatingappliance,thepotentialfor
leakageatsometimeinthelifeoftheproductdoesexist.HydroSmartwill
notberesponsibleforanywaterdamagethatmayoccur.Ifyouinstalladrain
panundertheunit,ensurethatitwillnotrestrictthecombustionairflow.
CAUTION
WARNING
Installation
8Page
CLEARANCES
ModelTopBottomFrontBackSides
HydroSmart115*12”12”24”1”2
*Standardindoorinstallationsanddirectventindoorinstallationshavethesameclearances.
INCLUDEDACCESSORIES
Checkthattheseitemsbelowareincludedwiththewaterheater.
1.InstallationManualand
Owner’sGuide
2.
ProductRegistrationCard
3.Remotecontroller
900766605(TKRE02)
OPTIONALITEMS
ModelHydroSmart115
9007678005(TKBF01)
9007667005(TKTV10)
9007671005(TKPCJr2)
9007608005(TKKPWL4)
9007609005(TKKPWH4)
9007680005(TKKPCT43)
Bottom
Side
Top
Side
Front
Back
Maintainallclearancesaround
thewaterheater.
Qty:1Qty:1Qty:1
Installation
9Page
1.BackflowPreventer:9007678005(TKBF01)
TheBackflowpreventerprevents
thebackflowofairthroughthe
exhaustvent.Thishelpsprevent
harmfulexhaustgasesfrom
enteringthehome,aswellas
helpingtopreventtheunitfrom
freezinginareaswherecoldaircanbeblown
ordrawnintotheexhaustsystem.Installthis
ventdamperinaccordancewiththe
installationinstructionsandanyapplicable
codes.
2.DirectVentConversionKit:9007667005
(TKTV10)
Thiskitcanbeusedto
convertthewater
heaterfromastandard
ventsystemtoa
directvent(orsealed
combustion)system.
Installthisconversionkitinaccordancewith
theinstallationinstructionsandanyapplicable
codes.
3.PipeCovers:9007671005(TKPCJr2)
Thepipecoverprotectstheplumbingpipestothewaterheaterfromunexpected
adjustments.Thispipecoverisfixedtothebottomofthewaterheater,whichhides
theplumbingandimprovesthevisualaspectsofthewholeinstallationforthewater
heater.
4.TVentWallThimblewithTermination:9007608005(TKKPWL4)and9007609005(TKKPWH4)
Theseterminationsareusedwhenventingoutthroughthewall
andarecompatiblewiththeTVentpipesystem.
Theseterminationsarespecialstainlesssteelventsforgas
appliancesandareULlistedasCategoryII,IIIandIV.Thereare
twotypesofterminations:theLouverterminationandtheHood
termination.Fordifferentwallthicknesses,therearetworanges
oflengthsavailable(refertotheventingbrochurefordetails).
Installtheseventterminationsinaccordancewiththeir
installationinstructionsandanyapplicablelocalcodes.
5.DirectVentConcentricTermination:9007680005(TKKPCT43)
Usedwhenterminatingdirectvent(sealedcombustion)systems,
withdirectventmodelsthatrequirea3”intakeanda4”exhaust.
Thisconcentricterminationprovidestheconvenienceofonly
havingtomakeonepenetrationthroughasidewallinsteadoftwo
separatepenetrationsfortheintakeandexhaustpiping.The
terminationincludesabirdscreen,restrictingsmallanimals,
pests,andforeignobjectsfromenteringintotheventsystem.
Thissidewallterminationisavailableinthreedifferentsizes,to
coverallrangesofwallthicknesses.
DirectventConcentricTermination
Part#Coveringwallthickness
9007680005(TKKPCT431)3.9”7.1”
9007772005(TKKPCT432)6.9”10.1
9007773005(TKKPCT433)9.8”13.0
Louver
Termination
9007608005
(TKKPWL4)
Hood
Termination
9007609005
(TKKPWH4)
Installation
10Page
WARNINGFORINSTALLATIONS
FORYOURSAFETY,READBEFOREINSTALLATION:
DonotinstalltheHydroSmart115wherewater,
debrisorflammablevaporsmaygetintotheflue
terminal.ThismaycausedamagetotheHydro
Smart115andvoidthewarranty.
Donotinstallnexttoadryeroranysourceof
airbornedebristhatcanbetrappedinsidethe
combustionchamber,unlessthesystemisdirect
vented.
HydroSmart115isprohibitedandnot
recommendstobeinstalledinanatticdueto
safetyissues.
FORYOURSAFETY,READBEFOREINSTALLATION:
Prohibited
Prohibited
Installation
11Page
HIGHALTITUDEINSTALLATIONS
Checktheelevationwhereyourwaterheaterisinstalled.Setdipswitchesshowninthetablebelow
dependingonthealtitude.
Altitude0to2,000ft
(DEFAULT)2,000to4,000ft 4,000to6,000ft Over6,000ft
SwitchNo.3OFFON OFF
Consult
HydroSmart
at763‐
3313066
SwitchNo.4OFFOFFON
OFF
ON12345678
OFF
ON12345678
OFF
ON12345678
WARNING
Thedarksquaresindicatethe
directionthedipswitchesshould
besetto.
Dipswitches
Installation
12Page
Improperventingofthisappliancecanresultinexcessivelevelsofcarbon
monoxidewhichcanresultinseverepersonalinjuryordeath.
Improperinstallationcancausenauseaorasphyxiation,severeinjuryordeathfrom
carbonmonoxideandfluegasespoisoning.Improperinstallationwillvoidproduct
warranty.
Wheninstallingtheventsystem,allapplicablenationalandlocalcodesmustbe
followed.Ifyouinstallthimbles,firestopsorotherprotectivedevicesandthey
penetrateanycombustibleornoncombustibleconstruction,besuretofollowall
applicablenationalandlocalcodes.
VENTINGINSTRUCTIONS
General
Thewaterheatermustbeventedinaccordancewiththesection“VentingofEquipment"ofthelatest
editionoftheNationalFuelGasCode:ANSIZ223.1/NFPA54intheUnitedStatesand/orSection7ofthe
CAN/CSAB149.1NaturalGasandPropaneInstallationCodeinCanada,aswellasapplicablelocal
buildingcodes.
HydroSmartrecommendsthe“TVent”linemanufacturedbyTAKAGI(Referto“TVent”brochurefor
details).However,thefollowingarealsoULlistedmanufacturers:ProTechSystemsInc.(FasNSeal),Flex
LInc.,ZFlexInc.(ZVentIII),MetalFabInc.,andHeatFabInc.(SafTVent).
Generalrulesforventingwaterheatersare:
Placethewaterheaterascloseaspossibletotheventterminator.
Theventcollarofthewaterheatermustbefasteneddirectlytoanunobstructedventpipe.
Donotweldtheventpipetothewaterheater’sventcollar.
Donotcuttheventcollaroftheunit.
Theventmustbeeasilyremovablefromthetopofthewaterheaterfornormalserviceand
inspectionoftheunit.
Thewaterheaterventmustnotbeconnectedtoanyothergasapplianceorventstack.
Avoidusinganoversizedventpipeorusingextremelylongrunsofthepipe.
Forrooftopventing,araincaporotherformofterminationthatpreventsrainwaterfrom
enteringintothewaterheatermustbeinstalled.
Donotcommonventorconnectanyventfromotherappliancestothewaterheatervent.
Generalrulesforventterminations:
Avoidlocatingthewaterheaterventterminatornearanyairintakedevices.Thesefanscan
pickuptheexhaustflueproductsfromthewaterheaterandreturnthemtothebuilding.
Thiscancreateahealthhazard.
Locatetheventterminatorsothatitcannotbeblockedbyanydebris,atanytime.Most
codesrequirethattheterminatorbeatleast12inchesabovegrade,buttheinstallermay
determineifitshouldbehigherdependingonthejobsiteconditionandapplicablecodes.
Apropersidewallterminatorisrecommendedwhenthewaterheaterisventedthrougha
sidewall.
Regardingtheclearancesfromtheexhaustterminatortotheairinletoropening,referto
thenextfewpages.
CAUTION
DANGER
Installation
13Page
Exhaustventing‐
ThisisaCategoryIIIapplianceandmustbeventedaccordingly.Theventsystemmustbesealedairtight.
AllseamsandjointswithoutgasketsmustbesealedwithhighheatresistantsiliconesealantorULlisted
aluminumadhesivetapehavingaminimumtemperatureratingof350°F.Forbestresults,aventsystem
shouldbeasshortandstraightaspossible.
ThiswaterheaterisaCategoryIIIapplianceandmustbeventedaccordinglywithany4”vent
approvedforusewithCategoryIIIorSpecialBHtypegasvent.
Followtheventpipemanufacturer’sinstructionswheninstallingtheventpipe.
Donotcommonventthisappliancewithanyotherventedappliance(Donotterminatevent
intoachimney.Iftheventmustgothroughthechimney,theventmustrunalltheway
throughthechimneywithCategoryIIIapprovedorSpecialBHventpipe).
Whenthehorizontalventrunexceeds5ft.,supporttheventrunat3ft.intervalswith
overheadhangars.
Themaximumlengthofexhaustventpipingmustnotexceed50ft.(deducting5ft.foreach
elbowusedintheventingsystem).Donotusemorethan5elbows.
DiameterMax.No.ofElbowMax.VerticalandHorizontal(Total)VentLength
4”550ft.
*Foreachelbowadded,deduct5ft.frommax.Ventlength.
No.ofElbowsMax.VerticalorHorizontalLength
050ft.
145ft.
240ft.
525ft.
VentingIllustrations‐
HorizontalInstallationDiagramVerticalInstallationDiagram
SidewallVent
Terminator
Wall
BackflowPreventer*
VerticalCondensationDrain**
Fordetailsoftheoptionalitems,refertotheInstallationmanualforeachOptionalitem.
Roo
f
VerticalCondensation
Drain**
RoofFlashing
RainCap
BackflowPreventer*
Installation
14Page
*BackflowPreventer (Recommendedforfreezingweatherconditions:36
°
Fandbelow)
**VerticalCondensationDrainmustbeinstalledaccordancewithlocalcodes.
HorizontalInstallationDiagram
WithDirectVentConcentric
Termination
HorizontalInstallationDiagram
(Withdirectventing)
VerticalInstallationDiagram
(Withdirectventing)
Thewaterheater
Intakeportof
DirectVent
ConversionKit
InstallationDiagramofDirectVent
ConversionKitwithwaterheater
Wall
Directvent
Concentric
Termination
PlateofDirectVentConversionKit
Seethepicturebelowfordetailedconnection
instructionstotheDirectVentConversionKit.
VerticalCondensationDrain**
Backflow
Preventer*
Wall
Sidewall
Vent
Terminator
RoofFlashing
Vertical
Condensation
Drain**
Backflow
Preventer*
RainCap
Roo
f
Firestop
Installation
15Page
Ventterminationclearances‐

Canada U.S.A
Directventand
otherthanDirect
Vent
Directvent OtherthanDirectVent
AClearanceabovegrade,veranda,porch,deck,
orbalcony.1foot1foot1foot
BClearancetowindowordoorthatmaybe
opened.3feet1foot
4feetfrombeloworside
opening.1footfrom
aboveopening.
CClearancetopermanentlyclosedwindow * * *
D
Verticalclearancetoventilatedsoffitlocated
abovetheventterminatorwithinahorizontal
distanceof2feet(61cm)fromthecenterline
oftheterminator.
***
EClearancetounventilatedsoffit* * *
FClearancetooutsidecorner* * *
GClearancetoinsidecorner* * *
HClearancetoeachsideofcenterlineextended
abovemeter/regulatorassembly3feet**
IClearancetoserviceregulatorventoutlet. 3feet * *
J
Clearancetononmechanicalairsupplyinlet
tobuildingorthecombustionairinlettoany
otherapplication.
3feet1foot
4feetfrombeloworside
opening.1footfrom
aboveopening.
KClearancetomechanicalairsupplyinlet. 6feet 3feet 3feet
LClearanceabovepavedsidewalkorpaved
drivewaylocatedonpublicproperty.7feet*7feet
MClearanceunderveranda,porchdeck,or
balcony.1foot**
*ForclearancesnotspecifiedinANSIZ223.1/NFPA54orCAN/CSAB149.1,pleaseuseclearancesinaccordancewith
localinstallationcodesandtherequirementsofthegassupplier.
Installation
16Page
Pleasefollowalllocalandnationalcodesinregardstoproperterminationclearances.
Intheabsenceofsuchcodes,thefollowingclearancescanbeusedasguidelines.Local
codessupersedetheseguidelines.
Forsidewallterminations
Exhausttermination
1ft.
1ft.2ft.
Inside
corner
Formultiplesidewallexhaust
terminations(e.g.multiunit
systems),anexhausttermination
mustbeatleast1ft.awayfrom
anotherexhausttermination.An
exhaustterminationmustalsobe
atleast2ft.awayfromaninside
corner(iftheadjacentwallisless
than2ft.oflength,theminimum
requireddistanceawayfromthe
insidecornerwillbeequaltothe
lengthofthatadjacentwall).
Fordirectventsidewall
terminationsthatusetwo
separatepenetrationsforthe
intakeandexhaust,distance
theintakeandexhaust
terminationsatleast3ft.away
fromeachother,nomatterthe
orientation.
Formultipleunit,directventsidewall
terminationsthatcombinetheintake
andexhaustintoasinglepenetration,
spaceeachdirectventterminationat
least1ft.awayfromeachother,no
mattertheorientation.Adirectvent
terminationmustalsobeatleast2ft.
awayfromaninsidecorner(ifthe
adjacentwallislessthan2ft.of
length,theminimumrequired
distanceawayfromtheinsidecorner
willbeequaltothelengthofthat
adjacentwall).
Formultipleunitrooftopterminations(whetherforstandardindooror
directventinstallations)spaceallexhaustandintaketerminationsin
accordancewithlocalcodes.Anexhaustterminationmustbespacedfrom
awallorsurfaceinaccordancewithlocalcodesaswell.Intheabsenceof
suchacode,anexhaustterminationmustbeahorizontaldistanceofat
least2ft.awayfromawallorsurface.
A:Inaccordancewithlocalcodes
Forrooftopterminations
Airintake
Exhausttermination
A
A
A
A
A
2ft.
Airintake
Exhaust
termination
Exhaustand/ordirectvent
sidewallterminationsshould
beatleast2ft.awayfroman
oppositesurface/wall.Do
notplacethetermination
directlyinfrontofan
openingintoabuilding.
2ft.
Exhaust
termination
Airsupplyinlet
3ft.
3ft.
3ft.
Directventtermination
1ft.
1ft.
Inside
corner
2ft.
CAUTION
Installation
17Page
Sizethegaspipeappropriatelytosupplythenecessaryvolumeofgasrequiredfor
thewaterheaterusingANSI233.1/NFPA54intheUSAorCAN/CSAB149.1inCanada
orlocalcodes.Otherwise,flowcapabilitiesandoutputtemperatureswillbelimited.
Checkthatthetypeofgasmatchestheratingplatefirst.
Ensurethatanyandallgasregulatorsusedareoperatingproperlyand
providinggaspressureswithinthespecifiedrangeshownbelow.Excessgas
inletpressuremaycauseseriousaccidents.
Conversionofthisunitfromnaturalgastopropaneorviseversawillvoidall
warranty.Contactyourlocaldistributortogetthecorrectunitforyourgas
type.Themanufacturerisnotliableforanypropertyand/orpersonal
damageresultingfromgasconversions.
GASSUPPLYANDGASPIPESIZING
General‐
Theminimumandmaximuminletgaspressuresare:
GastypeInletgaspressure
NaturalGasMin.5.0”WCMax.10.5”WC
PropaneMin.8.0”WCMax.14.0”WC
Gaspressureabovethisspecifiedrangeforthewaterheaterand/orinsufficientgasvolumewill
adverselyaffectperformance.Thesepressuresaremeasuredwhenthewaterheaterisinfull
operation.
Inletgaspressuremustnotexceedtheabovemaximumvalues;gaspressureabovethespecified
rangewillcausedangerousoperatingconditionsanddamagetotheunit.
Untiltestingofthemaingaslinesupplypressureiscompleted,ensurethegaslinetothewater
heaterisdisconnectedtoavoidanydamagetothewaterheater.
Gasconnections‐
1. Installamanualgasshutoffvalvebetweenthewaterheaterandthegassupplyline.
2. Whenthegasconnectionsarecompleted,itisnecessarytoperformagasleaktest(seebelow)
eitherbyapplyingsoapywatertoallgasfittingsandobservingforbubblesorbyusingagasleak
detectiondevice.
Thewaterheateranditsindividualshutoffvalvemustbedisconnectedfromthegassupply
pipingsystemduringanypressuretestingofthatsystemattestpressuresinexcessof1/2psi
(3.5kPa).
Thewaterheatermustbeisolatedfromthegassupplypipingsystembyclosingitsindividual
manualshutoffvalveduringanypressuretestingofthegassupplypipingsystemattest
pressuresequaltoorlessthan1/2psi(3.5kPa).
3. Alwayspurgethegaslineofanydebrisand/orwaterbeforeconnectingtothegasinlet.
WARNING
NOTICE
Installation
18Page
NaturalGasSupplyPiping‐
MaximumDeliveryCapacityofCubicFeetofGasperHourofIPSPipeCarryingNaturalGasof0.60SpecificGravity
BasedonPressureDropof0.5”WC
BasedonEnergyContentof1,000BTU/CubicFt.:Thewaterheaterrequires140CubicFt./hr.
Unit:CubicFeetperHour
PipeSizeLength
Diameter10’20’30’40’50’60’70’80’90’100’125’150’ 200’
¾”363249200171152138127118111104938472
1”684470377323286259239222208197174158 135
1¼”1,404965775663588532490456428404358324 278
1½”2,1031,445 1,161993 880 798 734 683 641 605536486 416
2”4,0502,784 2,2351,913 1,696 1,536 1,413 1,315 1,2341,1651,033 936 801
Propane(LP)SupplyPiping‐
MaximumCapacityofPropane(LP)Basedon11”WCsupplypressureata0.5”WCpressuredrop
Unit:kBTUperHour
PipeSize
Length
Diameter
10’20’30’40’50’60’70’80’90’100’125’150’ 200’
¾”567393315267237217196185173162146132112
1”1,071732590504448409378346322307275252213
1¼”2,2051,4961,2121,039913834771724677630567511440
1½”3,3072,2991,8581,5591,417 1,275 1,181 1,086 1,023 976866787675
2”6,2214,3313,4652,9922,646 2,394 2,205 2,047 1,921 1,8111,6061,496 1,260
Formoreinformation,pleaseseethebelow.
BasedonEnergyContentof1,000BTU/CubicFt:
Divideeachappliance’sBTUrequirementby1,000BTUtoget
theappliancesCubicFt.requirement.
Takeintoaccountthedistancetheapplianceisfromthegas
meter,lookintheabovegascharttoproperlysizetheline.
Forsectionsofthegaslinesupplyinggastomorethanone
appliance(Ex:PointAtoPointB),addupthecubicft.
requirementsoftheappliancesthatarebeingsuppliedbythat
section,andsizetothefarthestappliance.
ForExample:ThesectionfromAtoBsuppliesgastothe
furnace,range,anddryer.AddinguptheBTUrequirements
anddividingby1,000yieldsacubicft.requirementof220
cubicft.ofgas.Thefarthestapplianceistherange,whichis50
ft.awayfromthemeter.Lookingattheabovechart,and
underthecolumnof50ft.,SectionAtoBneedstobe1”in
ordertosupply220cubicft.
10’Length
1”PipeSizeC
GasSizingExample
(NaturalGas)
10’Length
3/4”PipeSize
15’Length
1/2”PipeSize
10’Length
1/2”PipeSize
Furnace
120,000BTU
Water
Heater
199,000BTU
5’Length
11/4”PipeSize
Range
65,000BTU
10’Length
3/4”PipeSize
Dryer
35,000BTU
15’Length
1”PipeSize
5’Length
11/4”PipeSize
GasMeter
B
A
Installation
19Page
1. Turnoffallelectricpowertothewaterheaterifserviceistobeperformed.
2. Turnthemanualgasvalvelocatedontheoutsideoftheunitclockwiseto
theoffposition.
Measuringinletgaspressure‐
Thewaterheatercannotperformproperlywithoutsufficientinletgaspressure.Belowareinstructions
onhowtochecktheinletgaspressure.THISISONLYTOBEDONEBYALICENSEDPROFESSIONAL.
1. Shutoffthemanualgasvalveonthesupplygasline.
2. Removethescrewforthepressureportlocatedon
thegasinletofthewaterheatershowninthe
diagramtotheright.
3. Connectthemanometertothepressureport.
4. Reopenthemanualgasvalve.Checktoseethat
therearenogasleaks.Opensomeofthefixtures
thatusethehighestflowratetoturnonthewater
heater.
5. Checktheinletgaspressure.Whenthewaterheater
isonmaximumburn,themanometershouldread
from5.0”to10.5WCforNaturalgas,from8.0”to
14.0”WCforPropane.
Pressureport
Installation
20Page
Donotusethiswaterheaterifanyparthasbeensubmersedunderwater.
Immediatelycallalicensedprofessionaltoinspectthewaterheatertoreplace
anydamagedparts.
Donotreversethehotoutletandcoldinletconnectionstothewaterheater.
Thiswillnotproperlyactivatethewaterheater.
WATERCONNECTIONS
Allpipes,pipefittings,valvesandothercomponents,includingsolderingmaterials,mustbesuitablefor
potablewatersystems.
1. Amanualshutoffvalvemustbeinstalledonthecoldwaterinlettothewaterheaterbetween
themainwatersupplylineandthewaterheater.
2. Inaddition,amanualshutoffvalveisalso
recommendedonthehotwateroutletofthe
unit.Ifthewaterheaterisinstalledwithin,or
subjectedto,aclosedloopwatersystem,a
thermalexpansiontankmustbeinstalled.
3. Beforeinstallingthewaterheater,flushthe
waterlinetoremovealldebris,andafter
installationiscomplete,purgetheairfromthe
line.Failuretodosomaycausedamagetothe
heater.
4. Thereisawirewithinthecoldinlettotrap
debrisfromenteringyourheater.Thiswillneed
tobecleanedperiodicallytomaintainoptimum
flow.
Pressurereliefvalve‐
Thewaterheaterhasahightemperatureshutoffswitchbuiltinasastandardsafetyfeature(calleda
HiLimitswitch)thereforea“pressureonly”reliefvalveisrequired.
Thisunitdoesnotcomewithanapprovedpressurereliefvalve.
Anapprovedpressurereliefvalvemustbeinstalledonthehotwateroutlet.
ThepressurereliefvalvemustconformtoANSIZ21.22orCAN14.4andinstallationmustfollow
localcode.
Thedischargecapacitymustbeatleast140,000BTU/h.
Thepressurereliefvalveneedstoberatedforamaximumof150psi.
Thedischargepipingforthepressurereliefvalvemustbedirectedsothatthehotwatercannot
splashonanyoneoronnearbyequipment.
Attachthedischargetubetothepressurereliefvalveandruntheendofthetubetowithin6"
fromthefloor.Thisdischargetubemustallowfreeandcompletedrainagewithoutany
restrictions.
Ifthepressurereliefvalveinstalledonthewaterheaterdischargesperiodically,thismaybedue
toadefectivethermalexpansiontankordefectivepressurereliefvalve.
Thepressurereliefvalvemustbemanuallyoperatedperiodicallytocheckforcorrectoperation.
Novalvemustbeplacedbetweenthereliefvalveandthewaterheater.
Pressure
ReliefValve
Hot
outlet
Cold
inlet
Gas
inlet
AsCloseas
Possible
CAUTION
Installation
21Page
Followtheelectricalcoderequirementsofthelocalauthorityhaving
jurisdiction.Intheabsenceofsuchrequirements,followthelatesteditionof
theNationalElectricalCodeANSI/NFPA70intheU.S.orthelatesteditionof
CSAC22.1CanadianElectricalCode,Part1,inCanada.
Whenservicingorreplacingpartswithinthewaterheater,labelallwires
priortodisconnectiontofacilitateaneasyanderrorfreereconnection.
Wiringerrorscancauseimproperanddangerousoperation.Verifyproper
operationafterservicing.
ELECTRICALCONNECTIONS
Theindoormodelcomeswithapowerpluginsteadofajunctionbox.Thefollowingprocedureisfor
outdoormodelsonly.
1. Thewaterheatermustbeelectricallygrounded.Donotattachthegroundwiretoeitherthegasor
thewaterpiping.
2. Thewaterheaterrequires120VAC/60Hzelectricalpowersupplythatisproperlygrounded.
Aproperdisconnect(i.e.on/offswitch,powerplug,etc.)controllingthemainpowertothe
waterheatermustbeprovidedforservicereasons.(Mustcomplywithlocalcodes).
Connectthepowersupplytothewaterheaterexactlyasshowninthewiringdiagram;
3. Agreenscrewisprovidedinthejunctionboxtogroundtheconnection.
4. Canbehardwiredorwiredtoaplugin.
5. Theuseofasurgeprotectorisrecommendedinordertoprotecttheunitfrompowersurges.
CAUTION
WARNING
Viewofelectricalconnectionsofwaterheater
Connect
Powersupply
120VAC/60Hz
Ground
Greenscrew
Outdoormodelonly
Bottomview
ofwaterheater
Indoormodelonly
Installation
22Page
REMOTECONTROLLERCONNECTIONS
<Howtoconnecttheremotecontrollertothewaterheater>
1.Disconnectpowersupplyfromthewaterheater.
2.Takeoffthewaterheater’sfrontcover.
3.Locatetheremotecontrollerterminal,picturedbelow(locatedaroundthelowerrighthand
sideofthecomputerboard).
4.Opentheplasticcoveroftheremotecontroller,andthenattachthetwoforkterminalsto
connectorbaseofthebacksidetheremotecontrollerwithtwoscrews.Makesurethe
terminalsarefirmlyfixed.
5.Pulltheremote’swiresthroughtheholeatthebottomofthewaterheater’scasing.
6.Properlyattachtheremote’swirestotheremotecontrollerterminalonthecomputerboard.
(Nopolarity)
*DoNOTjumporshortcircuitthewiresorcomputerwillbedamaged.
7.ReplaceFrontCoversecurely.
8.Wiresusedfortheremotecontrollerconnectionmustbe:
Minimum18AWGwire(Nopolarity)
Maximum400feetlong
*Fordetailedconnectioninstructionstotheremotecontroller,refertotheinstructionsthatare
packagedwiththeremotecontroller.
Remotecontrollerterminalinsidewater
Frontofremote Backofremote
Connectotherendtotheseterminals
Connecttothese
terminals
9007666005
(TKRE02)
Installation
23Page
Inordertopurgeairinwaterpipeswithinaclosedloopsystem,anairvent
andairseparatorshouldbeinstalledintothesystem.Requiredcirculation
flowratesarelabelednexttoeachapplicationdiagram.Theseflowrate
requirementsmustbefollowed.
Toxicchemicalsusedinboilertreatmentssuchasalcohol,glycerolandglycol
groupsmustnotbeintroducedintothesystemifthesystemincorporatesan
openlooppotablewatersystem.
Thewaterheatercanbeusedtosupplypotablewaterandspaceheatingand
shallnotbeconnectedtoanyheatingsystemorcomponent(s)previously
usedwithnonpotablewaterwhereanychemicalswereaddedtothewater
heatingappliances.
Whenthesystemrequireswaterforspaceheatingattemperatureshigher
thanrequiredforotheruses,ameanssuchasamixingvalveshallbe
installedtotemperthewaterforthoseotherusesinordertoreducescald
hazardpotential.
Watertemperatureover125F(52°C)cancausesevereburnsinstantlyor
deathfromscalds.
ChemicalssuchasdilutedGlycolcanbeusedforradiantfloor,Hydro/fancoil
airorBaseboardheatingonly.Thedilutedsolutionofglycolmustcontain
between25and55%ofGlycol.Beawarethatinclosedloopglycolsystems,
lowpressureintheheatexchangercancauselowtemperatureboiling,
resultinginexcessivenoiseanddamagetothewaterheater.Consultwith
theglycolmakerforspecificationspriortouse.
APPLICATIONS
SpaceHeatingApplications‐
WARNING
Installation
24Page
Dualpurposehotwaterheating‐
(DomesticandSpaceHeating):
PriorityControlDevicessuchasaflowswitch,anAquastatorotherelectronic
controllercanbeusedtoprioritizethedomesticwatersystemovertheheating
system.
Followalllocalcodes,orintheabsenceoflocalcodes,followthemostrecent
editionoftheNationalStandardCode,ANSIZ21.10.3.
Thisillustrationisaconceptdesignonly.Thereferencetothe1/8thholeincheck
isonlyfortheStateofMassachusetts.Thereareawidevarietyofvariationsto
theapplicationofcontrolsandequipmentpresented.Designersmustaddall
necessarysafetyandauxiliaryequipmenttoconformtocoderequirementsand
designpractice.Formoredetails,contactthemanufacturer.
NOTICE
Thecirculationpumpistoprovidenolessthan2GPMandnomorethan4GPMthrougheachactivated
unitinthesystem.
Allwaterpipingshouldbeinsulated
inaccordancewith780CMR
(Massachusettsenergycode)
Hotwater
supplyand
returnto
heatingcoil
Takagi
P
T
An approved Pressure Only
Relief Valve, Tie to Location
approved by Local Codes and
Must Meet BTU Rating of Takagi
Model Used
Unions
4" Gas Exhaust Vent (Discharge
Must Comply with Local and
State Codes). Can Not Be
Common Vented with Other
Appliances
Atmospheric
Vacuum Breaker
Pump (Must Be Sized Properly
With Each Application). Pump
Shall Run 60 Seconds Every 6
Hours
Pressure
Gauge
Apply Correct
Thermal
Expansion
Tank-Size Per
Application
Tempered
Water To
House
Cold Inlet
Shut-Off
Valve
Check Valve Will
Have 1/8" Hole in
Check, As Per
Mass. Code
Thermometer
Thermostatic Mixing Valve
Shut-Off
Valves
Check Valve
Hot
Water
Outlet
Cold
Water
Inlet
T-Handle Gas
Shut-Off Valve
**Maximum allowable distance of
50-Ft. from water heater and
heating panel
Heating Coil
(used with air-handler)
Diagramatic Layout of Radiant Heating and
Domestic Water Heater Per Mass. Code
Thermometer
Check
Valves
Gas
Inlet
Drain
Plug Water
Filter
120 VAC Switch or Outlet
AnapprovedTemperatureandPressure
ReliedValve,TietoLocationapprovedBy
LocalCodesandMustMeetBTURating
ofwaterheaterModelUsed
Coldwatersupply
Temperedwatertoplumbing
fixtures.Mustmeettemperature
requirementsof248CMR
Automatic
temperingdevice
mustbeinstalled
belowthetopof
thewaterheateras
permanufacturer’s
recommendations
Systeminstalledwithreverseacting
aquastattoshutofffan.Suggested
butnotrequiredby248CMR
NSF61product
approvedpump
Electronicallycontrolled pumptimer.
Activatesevery6hoursfor60seconds.
Wireto
p
roducta
pp
roved
p
um
p
Checkvalve
with1/8”hole
drillingin
cla
pp
ero
p
tional
50’0”maximumdistancefromwater
heatertofancoilandblack.(Develoed
length)Notincludingcoilinheatingunit
Pipingloop
betweenwater
heaterandfan
coilshallbein
compliance
with248CMR
InitialOperation
25Page
ChecktheGASandWATERCONNECTIONSforleaksbeforefiringunitforthefirsttime.
Openthemaingassupplyvalvetotheunitusingonlyyourhandtoavoidanyspark.Neveruse
tools.Iftheknobwillnotturnbyhand,donottrytoforceit;callaqualifiedservicetechnician.
Forcedrepairmayresultinafireorexplosionduetogasleaks.
Besuretocheckforthepresenceofleakinggastowardthebottomoftheunitbecausesome
gasesareheavierthanairandmaysettletowardsthefloor.
ChecktheGASPRESSURE.Refertop.19.
Donottrytolighttheburnermanually.Itisequippedwithanelectronicignitiondevicewhich
automaticallylightstheburner.
CheckforPROPERVENTINGandCOMBUSTIBLEAIRtothewaterheater.
PurgetheGASandWATERLINEStoremoveanyairpockets.
Donotusethiswaterheaterifanyparthasbeensubmersedunderwater.Immediatelycalla
qualifiedservicetechniciantoinspectthewaterheaterandtoreplaceanydamagedparts.
INITIALOPERATION
1. Refertop.31for
instructions.
2. Fullyopenthemanual
watercontrolvalveonthe
watersupplyline.
3. Openahotwatertapto
verifythatwateris
flowingtothattap.
Thenclosethehotwatertap.
4. Fullyopenthemanualgas
controlvalveinstalled.
5. Turnonthe120volt60Hz
powersupplytothewater
heater.
6. Nowyouarereadyto
enjoyhoursofendless
hotwater.
FORYOURSAFETY,READBEFOREOPERATING
IFYOUSMELLGAS:
Donottrytostartthewaterheater.
Donottouchanyelectricswitches;donotuseanyphoneinyourbuilding.
Immediatelycallyourgassupplierfromaneighbor’sphone.Followthegas
supplier’sinstructions.
Ifyoucannotreachyourgassupplier,callthefiredepartment.
WARNING
OperatingSafety
26Page
OPERATINGSAFETY
FORYOURSAFETYREADBEFOREOPERATING
WARNING:Ifyoudonotfollowtheseinstructionsexactly,afireorexplosionmayresultcausing
propertydamage,personalinjuryorlossoflife.
A. Thiswaterheaterdoesnothaveapilot.Itisequippedwithanignitiondevicethat
automaticallylightstheburner.Donottrytolighttheburnerbyhand.
B. BEFOREOPERATINGsmellallaroundthewaterheaterareaforevidenceofleakinggas.Be
suretosmellnexttothefloorbecausesomegasisheavierthanairandwillsettleonthe
floor.
WHATTODOIFYOUSMELLGAS.
Donottrytolightanyappliance.
Donottouchanyelectricswitch;donotuseanyphoneinyourbuilding.
Immediatelycallyourgassupplierfromaneighbor'sphone.Followthegassupplier's
instructions.
Ifyoucannotreachyourgassupplier,callthefiredepartment.
C. Useonlyyourhandtoturnthegasvalveknob.Neverusetools.Iftheknobwillnotturnby
hand,don'ttrytorepairit,callaqualifiedservicetechnician.Forceorattemptedrepairmay
resultinafireofexplosion.
D. Donotusethiswaterheaterifanyparthasbeenunderwater.Immediatelycallaqualified
servicetechniciantoinspectthewaterheaterandtoreplaceanydamagedparts.
OPERATINGINSTRUCTIONS
1. STOP!ReadthesafetyinformationaboveorintheOwnersManual.
2. Turnoffallelectricpowertothewaterheater.
3. Donotattempttolighttheburnerbyhand.
4. Turnthemanualgasvalvelocatedontheoutsideoftheunitclockwisetotheoffposition.
5. Waitfive(5)minutestoclearoutanygas.Ifyouthensmellgas.STOP!Follow"B"inthesafety
informationaboveonthislabel.Ifyoudon'tsmellgas,gotonextstep.
6. TurnthemanualgasvalvelocatedontheoutsideoftheunitcounterclockwisetotheON
position.
7. Turnonallelectricalpowertothewaterheater.
8. Ifthewaterheaterwillnotoperate,followtheinstructions“toTurnOffGastowaterheater"
andCallyourservicetechnicianorgassupplier.
TOTURNOFFGASTOAPPLIANCE
1. Turnoffallelectricpowertothewaterheaterifserviceistobeperformed.
2. Turnthemanualgasvalvelocatedontheoutsideoftheunitclockwisetotheoff position.
O
O
O
w
w
w
n
n
n
e
e
er
r
r
s
s
s
G
G
G
u
u
u
i
i
i
d
d
d
e
e
e
OperatingSafety
27Page
DANGER
Vaporsfromflammableliquidswillexplodeandcatchfirecausingdeathorsevereburns.
Donotuseorstoreflammableproductssuchasgasoline,solventsoradhesivesinthesameroom
orareanearthewaterheater.
Keepflammableproducts:
1. Farawayfromheater
2. Inapprovedcontainers
3. Tightlyclosed
4. Outofchildren'sreach
Vapors:
1. Cannotbeseen
2. Vaporsareheavierthanair
3. Goalongwayonthefloor
4. Canbecarriedfromotherroomstothemain
burnerbyaircurrents
WARNING:Donotinstallwaterheaterwhereflammableproductswillbestored.
Readandfollowwaterheaterwarningsandinstructions.Ifowner’smanualismissing,contact
HydroSmart.
WARNING
Theoutlethotwatertemperatureofthewaterheaterisfactorysetat122°F(50°C).
Usethisheateratyourownrisk.Thesetoutletwatertemperaturecancausesevereburnsinstantlyor
deathfromscalds.Testthewaterbeforebathingorshowering.
Donotleavechildrenoraninfirmpersoninthebathunsupervised.
DANGER
HotWatertemperatureover125°F(52°C)cancausesevereburns
instantlyordeathfromscalding.Children,disabledandelderlyareatthe
highestriskofbeingscalded.Feelwatertemperaturebeforebathingor
showering.Temperaturelimitingvalvesareavailable.Askaprofessional
person.
WARNING:CaliforniaProposition65listschemicalsubstancesknowntothestatetocausecancer,
birthdefects,death,seriousillnessorotherreproductiveharm.Thisproductmaycontainsuch
substances,betheiroriginfromfuelcombustion(gas,oil)orcomponentsoftheproductitself.
NormalOperation
28Page
HotWatertemperaturesover125F(52°C)cancausesevere
burnsinstantlyordeathfromscalding.
Theoutlethotwatertemperatureofthewaterheaterisfactory
setat122°F(50°C).
NORMALOPERATION
GENERAL
OPERATION
<Settemperature>
1.Turnonthe120VACpowersupplytothewaterheater.
2.Pressthe"OPERATION"buttonontheremoteinordertoturntheremotecontrolleron.Itshowsthe
settemperatureonitsdisplayasshownthepicturetothebelow.
3.Pressthe"HOT"buttonorthe"COLD"buttontosetthetemperaturesettingoftheunit.
4.Youcansetthetemperaturefrom99°F(38°C)to167°F(75°C).
<Exteriorviewoftheremotecontroller>
<Thetemperatureoptions>
99100102104106108110 111 113 115 117 122 131140158 167
Flowratetoactivatethewaterheater:0.5gallonsperminuteatthe
defaultsettemperature
Flowratetokeepthewaterheaterrunning:0.4gallonperminute
NOTICE
WARNING
"COLD"Button
"OPERATION"Button
"HOT"Button
"INFOMATION"Button
CAUTION
Temperatureabove122°F(50°C)cancausesevereburnsordeathfrom
scalding.Children,disabledandtheelderlyareathighriskofbeinginjured.
NormalOperation
29Page
TEMPERATURESETTINGS
Withoutremotecontroller‐
Thereare4temperaturesthatyoucanselectfrombychangingthedipswitchsettingsonthe
computerboardwithouttheremotecontroller.Seethetablebelow.
Temperaturesavailable
113F122F131F140F
Fordetaileddipswitchsettingsforeachtemperature,refertothenextpage.
Thetemperaturehasbeenpresetatthefactoryto122°F(50°C).
Iftemperaturesotherthantheoneslistedabovearerequired,theremotecontrollercan
provideseveralmoretemperatureoptions.Refertop.9foralistofavailabletemperatureson
theremotecontroller.
Thiswaterheaterisanondemand,tanklesswaterheaterdesignedtoefficientlysupply
endlesshotwaterwithoutreferencetotemperaturesettings.

Dipswitches
Dipswitchsettingsforeachtemperatureonthecomputerboard
(45
OFF
ON
C)
113 F
12345678
OFF
ON12345678
(50 C)
122 F
DEFAULT
(55
OFF
ON
C)
131 F
12345678
(60
OFF
ON
C)
140 F
12345678
TemperatureSettings 
Turnoffthepowersupplytothe
waterheaterbeforechangingthe
dipswitchsettings.
Onlychangetheswitcheswiththe
darksquares.Thedarksquares
indicatewhichdirectionthe
di
p
switchshouldbesetto.
WARNING
NormalOperation
30Page
Onlypipeswithinthewaterheaterareprotectedbythefreezeprotection
system.Anywaterpipes(hotorcold)locatedoutsidetheunitwillnotbe
protected.Properlyprotectandinsulatethesepipesfromfreezing.
HouseholdFlowRates
TakenfromUPC2006
FLOW
Theflowratethroughthewaterheaterislimitedtoa
maximumof6.6GPM.
Thetemperaturesetting,alongwiththesupply
temperatureofthewaterwilldeterminetheflowrate
outputoftheunit.
Pleaserefertothetemperaturevs.gallonsperminute
chartonp.41todeterminethelikelyflowratesbased
onyourlocalgroundwatertemperatureandyour
desiredoutletwatertemperature.
BasedontheUnitedStatesDepartmentofEnergy
methodoftestingwaterheateroutput,thewaterheaterisratedfor172gallonsperhour(GPH)or2.9
gallonsperminute(GPM)forNaturalGas,and184GPHor3.1GPMforPropane,whenraisingthe
watertemperatureby77F(from58Fto135F).
Refertothetabletothetoprightfortypicalhouseholdplumbingfixtureflowratestodetermine
whatthewaterheatercandoinahouseholdapplication.
FREEZEPROTECTIONSYSTEM
Thisunitcomesequippedwithheatingblockstoprotectitagainstdamagesassociatedwithfreezing.
Forthisfreezeprotectionsystemtooperatetherehastobeelectricalpowertotheunit.Damageto
theheatexchangercausedbyfreezingtemperaturesduetopowerlossisnotcoveredunderthe
warranty.Incaseswherepowerlossescanoccur,considertheuseofabackuppowersupply.
Thefreezeprotectionsystemwillactivatewhenthesurroundingand/oroutsidetemperaturesdrop
below36.5°F(2.5°C).
FortheHydroSmart115models:
Inanyareassubjecttofreezingtemperatures,HydroSmarthighlyrecommendsanindoor
installationwithanindoormodel.Insuchaninstallation,freezingissuescanonlyoccurif
coldairentersthroughtheventingintotheheatexchanger,whetherbynegativepressures
withintheinstallationlocationorbystrongoutsidewinds.
HydroSmartalsohighlyrecommendstheuseofabackflowventdampertominimizethe
amountofcoldairenteringthroughtheexhaustventingwhenthewaterheaterisoff.
Itistheinstaller’sresponsibilitytobeawareoffreezingissuesandtakeallpreventativemeasures.
HydroSmartwillnotberesponsibleforanydamagetotheheatexchangerasaresultoffreezing.

Ifyouwillnotbeusingyourheaterforalongperiodoftime:
1. Completelydraintheunitofwater.Refertop.31.
2. Disconnectpowertoyourheater.
Thiswillkeepyourunitfromfreezingandbeingdamaged.
Appliance/UseFlowRate(GPM)
LavatoryFaucet1.0
BathTub4.010.0
Shower2.0
KitchenSink1.5
Dishwasher1.5
Washingmachine4.0
CAUTION
NormalOperation
31Page
Turnofftheelectricalpowersupplyandclosethemanualgasshutoffvalve
andthemanualwatercontrolvalvebeforeservicing.
MAINTENANCEANDSERVICE
Besurethatallopeningsforcombustionandventilationairarenotblocked.
Theventingsystemshouldbecheckedannuallyforanyleaks,corrosion,blockagesordamage.
Theburnershouldbecheckedannuallyfordust,lint,greaseordirt.
Keeptheareaaroundthewaterheaterclear.Removeanycombustiblematerials,gasolineorany
flammablevaporsandliquids.
Inaccordancewithalllocalcodesandcommonsafetypractices,Waterdischargedfromthepressure
reliefvalecancausesevereburnsinstantlyfromscalding.DONOTtouchthepressurereliefvalve.
Ifthereliefvalvedischargesperiodically,itmaybeduetothermalexpansioninaclosedwatersupply
system.Contactthewatersupplierorlocalplumbinginspectoronhowtocorrectthissituation.
Visualcheckofburnerflames(seebelow)throughtheburnerwindowintheburnerassemblylocated
atthemiddleofthewaterheater.
HydroSmartrecommendshavingtheunitcheckedonceayearorasnecessarybyalicensedtechnician.
Ifrepairsareneeded,anyrepairsshouldbedonebyalicensedtechnician.
UNITDRAINING
1. Closethemanualgasshutoffvalve.
2. Turnoffpowertotheunitandwaitacoupleof
seconds.Turnonagain.
3. Wait30seconds,andthenturnoffpowertotheunit,
yetagain.
4. Closethewatershutoffvalve.
5. Openallhotwatertapsinthehouse.Whenthe
residualwaterflowhasceased,closeallhotwater
taps.
6. Haveabucketorpantocatchthewaterfromthe
unit’sdrainplugs.Unscrewthetwodrainplugs(Large
andsmall)todrainallthewateroutoftheunit.
7. Waitafewminutestoensureallwaterhas
completelydrainedfromunit.
8. Securelyscrewthedrainplugsbackintoplace.Hand
tightenonly.
WARNING
DrainPlug
(Large)
WaterValve
DrainPlug
(Small)
GasValve
Unsatisfactory
SatisfactoryUnsatisfactory
BlueflameRedorYellow
flame
Flame
blowingup
Troubleshooting
32Page
GENERAL
TROUBLESHOOTING
TEMPERATUREandAMOUNTOFHOTWATER
PROBLEMSOLUTIONS
Ittakeslongtimetoget
hotwateratthe
fixtures.
Thetimeittakestodeliverhotwaterfromthewaterheaterto
yourfixturesdependsonthelengthofpipingbetweenthetwo.
Thelongerthedistanceorthebiggerthepipes,thelongeritwill
taketogethotwater.
Thewaterisnothot
enough.
Comparetheflowandtemperature.Seethechartsonp.41.
Checkcrossplumbingbetweencoldwaterlinesandhotwater
lines.
Isthegassupplyvalvefullyopen?(p.25)
Isthegaslinesizedproperly?(p.18)
Isthegassupplypressureenough?(p.19)
Isthesettemperaturesettoolow?(p.2829)
Thewateristoohot. Isthesettemperaturesettoohigh?(p.2829)
Thehotwaterisnot
availablewhenafixture
isopened.
Makesuretheunithas120VAC/60Hzpowersupply.
Ifyouareusingtheremotecontroller,isthepowerbuttonturned
on?
Isthegassupplyvalvefullyopen?(p.25)
Isthewatersupplyvalvefullyopen?(p.25)
Isthehotwaterfixturesufficientlyopentodrawatleast0.5GPM
throughthewaterheater?(p.28)
Istheunitfrozen?(p.30)
Isthereenoughgasinthetank/cylinder?(ForPropanemodels)
Thehotwaterturns
coldandstayscold.
Istheflowrateenoughtokeepthewaterheaterrunning?(p.28)
Doestherecirculationlinehaveenoughcheckvalves?(p.4)
Isthegassupplyvalvefullyopen?(p.25)
Arethefixturescleanofdebrisandobstructions?
Checkiftheflowrateistoolow.(p.2829)
Fluctuationinhotwater
temperature.
Isthegaslinesizedproperly?(p.18)
Isthesupplygaspressuresufficient?(p.19)
Checkforcrossconnectionbetweencoldwaterlinesandhot
waterlines.
Troubleshooting
33Page
‐WATERHEATER‐
PROBLEMSOLUTIONS
Unitdoesnotignitewhen
watergoesthroughtheunit.
Istheflowrateover0.5GPM?(p.28)
Checkforreverseconnectionandcrossconnection.
Ifyouusetheremotecontroller,isthepowerbutton
turnedon?
Checkiftheinlettemperatureistoohigh.
Thefanmotorisstill
spinningafteroperationhas
stopped.
Thisisnormal.Afteroperationhasstopped,thefanmotor
keepsrunningfrom15to70secondsinordertoreignite
quickly,aswellaspurgealltheexhaustgasoutoftheflue.
Unitsoundsabnormalwhile
inoperation
ContactHydroSmart.
Remotecontroller‐
(OPTIONAL)‐
Remotecontrollerdoesnot
displayanythingwhenthe
powerbuttonisturnedon.
Makesuretheunitissuppliedwithpower.
Makesuretheconnectiontotheunitiscorrect.(p.22) 
AnERRORcodeisdisplayed. Pleaseseep.3436.
Troubleshooting
34Page
ERRORCODES
Theunitsareselfdiagnosticforsafetyandconveniencewhentroubleshooting.
Ifthereisaproblemwiththeinstallationortheunit,dependingonthemodelorifthereisa
remotecontrollerinstalled,itwilleitherdisplayablinkingredLED,ortheerrorcodewilldisplayon
theremotecontrollerifitisinstalled.
Consultwiththetableonthefollowingpageforthecauseofeacherrorcode.
Singleunitinstallations‐
Example:Ifyourunitdisplaysthe“321”errorcode(whichsignifiesaninletthermistorfailure)
HydroSmart115:TheredLEDonthecomputerboardwillbeblinkingtwotimes.
Iftheremotecontroller9007666005(TKRE02)isinstalled:“32”willdisplayonthescreeninits
entirety.
Errorcodeonthe remote
controller9007666005(TKRE02)
Errorcodeonthecomputerboard
RedLED
Troubleshooting
35Page
FAULTANALYSISOFERRORCODES‐
RedLED Remote Malfunction
descriptionDiagnosis
One
Time03Incorrectdipswitch
setting CheckthedipswitchsettingsonthePCB.(Part#701)
Five
Times
10Warningforthe
“991”errorcode
Checkthegastypeofthewaterheater.
Checkifthereisanyblockageintheintakeairand/or
exhaust.
Ifthewaterheaterisinstalledasadirectventsystem,
checkwhetherthereisenoughdistancebetweenthe
intakeairterminalandtheexhaustterminal.
Checkthealtitude/elevationofareaofwherethe
waterheaterinstalled.
Checkifthereisgreaseand/ordirtintheburner(Part
#101)andthefanmotor(Part#103),especiallyifthe
waterheaterhasbeeninstalledinacontaminated
area.
Three
Times
11Ignitionfailure
CheckiftheHilimitswitch(Part#412)isproperly
functioning.
Checkforconnection/breakageofwires(Part#413,
708,709,710,712),burnmarksonthecomputer
board(Part#701),and/orsootontheflamerod(Part
#108).
Checkifthereisabuzzingsparkignitionsoundcoming
fromtheburner(Part#101)whenwaterheater
preparesforcombustion.
Listenforthedouble“clunk”soundcomingfromgas
valveassembly(Part#102)whenwaterheatergoes
intocombustion.
Checkifthereisleakingfromheatexchanger.(Part
#401)
Three
Times
12Lossofflame
CheckiftheHilimitswitch(Part#412)isproperly
functioning.
Checkforconnection/breakageofwires(Part#413,
708,709,710,712),burnmarksonthecomputer
board(Part#701),and/orsootontheflamerod(Part
#108).
Checkifthereisleakingfromheatexchanger.(Part
#401)
Two
Times
31Outletthermistor
failure Checkforconnection/breakageofwiresand/ordebris
onthermistor.(Part#407,408)
32Inletthermistor
failure
Two
Times
39Air–fuelRatioRod
failure
Checkforconnection/breakageofwires(Part#709)
and/orsootontheAFRrod.(Part#108)
IftheerrorcodedisplayedonthecomputerboardoftheWaterheaterorremotecontroller,
pleasecheckthefollowing.Afterchecking,Consultwiththemanufacturer.
Warranty
36Page
RedLEDRemoteMalfunction
descriptionDiagnosis
Six
Times
51AbnormalGas
SolenoidValve
Check
f
orconnection/breakageofwires(Part#708)
and/orburnmarksonthecomputerboard(Part
#701).
Six
Times
55AbnormalMain
GasValve
Check forconnection/breakageofwires(Part#708)
and/orburnmarksonthecomputerboard(Part
#701).
Four
Times
61FanMotorFault
Check forconnection/breakageofwires,dustbuildup
inthefanmotor(Part#103)and/orburnmarksonthe
computerboard(Part#701).
Checkforfrozen/corrosionofconnectors(Part#103).
One
Time
70Computerboard
Fault
Checkforconnection/breakageofwires(Part#714)
and/orburnmarksonthecomputerboard(Part
#701).
Checkthepowersupplyofthewaterheater.
SixTimes72FalseFlame
Detection
Forindoormodels,checkifcondensatedrainis
installedontheventcollarofthewaterheater.
Checkifthereisleakingfromheatexchanger(Part
#401).
N/A74Miscommunication
betweenWater
heaterandremote
controller
Checkthemodeltypeoftheremotecontroller.
Inspecttheconnectionsbetweenthewaterheater
andremotecontroller.
Checkthepowersupplyofthewaterheater.
Five
Times
99Imperfect
combustion
Checkthegastypeofthewaterheater.
Inspecttheenvironmentaroundthewaterheater.
Determinehowlongtheunithasbeeninstalled.
Checkthealtitude/elevationoftheareaofwherethe
waterheaterinstalled.
Checkifthereisanyblockageintheintakeairand/or
exhaust.
Ifthewaterheaterisinstalledasadirectventsystem,
checkwhetherthereisenoughdistancebetweenthe
intakeairterminalandtheexhaustterminal.
Checkifthereisgreaseand/ordirtintheburner(Part
#101)andthefanmotor(Part#104),especiallyifthe
waterheaterhasbeeninstalledinacontaminated
area.
Warranty
37Page
COMPONENTSDIAGRAM
Caseassembly
701
707
709
714
710
708
103
402402
407408719
Waterwayassembly
Computerboard
Assembly
456
460
409
455
410
454
408
064
C
402
461
458
052
415
064
460
456
404
405
454
407
457
B
463
413 453
414
412
063
451
B
C
401
414
452
450
Waterinletsection
Wateroutletsection
002
050
702
052
007
052
052
003 052
001
004
051
720
704
721
Temperature
remotecontroller
722
Warranty
38Page
Burnerassembly
Burnerassembly
106107
108
109
110
065
712
701
053
120
053
712
711
053
714
062
055
119
151
118
052
121
703
053
704
705
401
104
105
101
709
111
052
053
112
113
114
708
053
067
055
053
706
053
059
103
115
058
713
150
061
059
101
709
111
102
Manifold
assembly
Warranty
39Page
PARTSLIST
Item#DescriptionPart#
001
002
003
004
005
Caseassembly
Frontcover
Airblockageplate
Bracket
Junctionbox
319143159
319143163
319143150
319143184
319143014
006
007
Junctionboxinnerplate
Backguardpanel
319143128
319143338
050
051
052
053
055
ScrewM4×12 (W/Washer)
ScrewM4×10(W/Washer)
ScrewM4×10(Coated)
ScrewM4x10
HexheadscrewM4x8
319143025
319143325
319143026
319143060
319143063
056
058
059
061
062
ScrewM4x10
ScrewM3x10
PanscrewM4x12(W/Washer)
TaptightscrewM4x12FEZN
PanscrewM4x10
319143372
319143327
319143061
319143201
319143062
063
064
065
066
067
ScrewM3x6
ScrewM4x6
PanscrewM4x8
Nylonclamp
Wireclamp60
319143087
319143328
319143059
319143143
319143048
101
102
103
104
105
Burnerassembly
ManifoldwithgasvalveassemblyLP
ManifoldwithgasvalveassemblyNA
Fanmotor
Burnerholdergasket
Burnergasket
319143161
319143169
319143165
319143347
319143341
319143031
106
107
108
109
110
Burnerwindow
Rodholdergasket
Flamerod
Igniterrod
Rodholder
319143033
319143034
319143339
319143373
319143340
111
112
113
114
115
Rodcap
Burnerdamper
ManifoldgasketA
ManifoldgasketB
Fandamper
319143038
319143170
319143044
319143045
319143160
118
119
120
121
Gasinlet
Gasinletring
Igniterplate
Surgeboxplate
319143050
319143049
319143051
319143213
150
151
OringP18 NBR(Black)
OringP20 NBR(Black)
319143350
319143057
Warranty
40Page
Item#DescriptionPart#
401
402
404
405
407
Heatexchangerassembly
Flowadjustmentvalve/Flowsensor
Waterinlet
Inletdrainplug
Inletthermistor
319143162
319143167
319143193
319143197
319143214
408
409
410
412
413
Outletthermistor
Wateroutlet
Outletdrainplug
HiLimitswitch
Overheatcutofffuse
319143218
319143194
319143199
319143228
319143149
414
415
Heater
Inletheater
319143200
319143078
450
451
452
453
454
Pipeheaterfixingplate
Heaterfixingplate16
Fusefixingplate18
Fusefixingplate14
OringP4FKM
319143088
319143125
319143066
319143146
319143082
455
456
457
458
460
OringP6FKM
OringP14FKM
OringP15FKM
OringP16FKM
Fastener“1422
319143080
319143100
319143091
319143083
319143105
461
463
Fastener“16A”
Siliconring
319143226
319143065
701
702
703
704
705
Computerboard
Transformer
Surgebox
AC120Vwire
Transformerwire
319143164
319143182
319143168
319143427
319143155
706
707
708
709
710
AC120VPowerONOFFswitch
Switchwire
Gasvalvewire
Flamerodwire
EHIGwire
319143141
319143154
319143207
319143171
319143209
711
712
713
714
719
Igniter
Highvoltageignitercable
Freezeprotectionthermostat
Proportionalgasvalvewire
Computerboardcover
319143052
319143039
319143185
319143220
319143212
720
721
Rubbergrommet
Cablestrap
319143426
319143425
722Temperatureremotecontroller 319143352
Warranty
41Page
OUTPUTTEMPERATURECHART
Output Temperature vs. GPM (Max. 6.6 GPM) with Various Inlet Water Temperature
0.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
Out Put Hot Water GPM
40 F 50 F 60 F 70 F
40 F 3.8 3.5 3.3 3.1 2.9 2.7 2.5 2.4 2.3 2.1 1.9 1.8
50 F 4.6 4.2 3.8 3.5 3.3 3.1 2.9 2.7 2.5 2.3 2.1 2.0
60 F 5.7 5.1 4.6 4.2 3.8 3.5 3.3 3.1 2.9 2.5 2.3 2.2
70 F 6.6 6.6 5.7 5.1 4.6 4.2 3.8 3.5 3.3 2.9 2.5 2.4
100 105 110 115 120 125 130 135 140 150 160 165
Chartisbasedonproperlysizesgasline
Warranty
42Page
LIMITEDWARRANTY
1. Generaltermsoflimitedwarranty:
Thislimitedwarrantygivesyouspecificlegalrights,andyoumayalsohaveotherrightswhichvaryfromState
toState.Themanufacturer,HydroSmartInc.willhonorthewarrantytotheoriginalretailbuyeratthe
originallocationonly,anditisnottransferable.THISWARRANTYCOVERSONLYFAILEDMECHANICALAND
ELECTRICALPARTSDUETOFACTORYDEFECTSUNDERNORMALUSAGEFORTHEPRODUCT’SINTENDED
PURPOSES.ONLYDIRECTDAMAGESSHALLBERECOVERABLEBYACLAIMANTUNDERTHISLIMITED
WARRANTYAND,INNOEVENT,WHETHERASARESULTOFBREACHOFCONTRACT,BREACHOFWARRANTY,
TORTLIABILITY(INCLUDINGNEGLIGENCE),STRICTLIABILITY,INDEMNITYOROTHERWISEWILLHydroSmart
BELIABLEFORANYSPECIAL,INCIDENTAL,ORINDIRECTCONSEQUENTIALDAMAGESINCLUDINGPROPERTY
DAMAGE,PERSONALDAMAGES,LOSSOFUSE,ORINCONVENIENCE.SOMESTATESDONOTALLOWTHE
EXCLUSIONORLIMITATIONOFINCIDENTALORCONSEQUENTIALDAMAGES,SOTHEABOVELIMITATION
MAYNOTAPPLYTOYOU.
2. PartsWarranty
Ifallofmechanicaland/orelectricalpartfailswithintwo(2)yearsinnormaloperationwith“IntegratorPanel”
andproperinstallation(seeinstructionfrominstallationmanual)fromthepurchasingdate,HydroSmartInc.
willfurnishareplacementpart(s)excludingfieldlaborandshipping.

3. Repair,ReplacementorRefund:
Themanufacturer,HydroSmartInc.oritsauthorizedServiceRepresentativewill,atitssolediscretion,repair
orreplaceanyfailedordefectivemechanicalorelectricalparts,orcomponentsthereof,or,ifHydroSmartor
itsauthorizedServiceRepresentativecannotreplacesaidparts,andrepairisnotcommerciallypracticable,
HydroSmartoritsauthorizedServiceRepresentativewillrefundthepurchaseprice.HydroSmartorits
authorizedServiceRepresentativemay,atitssolediscretion,usenew,refurbishedorreconditionedparts.
4. LimitationonDurationofImpliedWarranties:
ANYIMPLIEDWARRANTIESARISINGUNDERSTATELAW,INCLUDINGTHEIMPLIEDWARRANTIESOFFITNESS
FORAPARTICULARPURPOSEANDMERCHANTABILITY,SHALLINNOEVENTEXTENDPASTTHEEXPIRATION
OFANYWARRANTYPERIODHEREUNDER.SOMESTATESDONOALLOWLIMITATIONSONHOWLONGAN
IMPLIEDWARRANTYLASTS,SOTHEABOVELIMITATIONMAYNOTAPPLYTOYOU.
5. THISWARRANTYWILLNOTCOVERTHEFOLLOWING:
AnyHydroSmartunitthatisnotinstalledbyalicensedplumber,gasinstaller,orcontractor.
Damagesduetoaccidents,abuse,misuse,improperinstallation,misapplication,orincorrectsizing.
Damagesduetofires,flooding,freezing,electricalsurges,oranyActsofGod.
Damagesduetounauthorizedalterations,attachments,and/orrepairs.
Damagesduetoalackofmaintenance.(e.g.watertreatmentsystem,ventblockage,etc.)
AnyHydroSmartunitinstalledinanimproperenvironment(e.g.corrosive,dusty,chemically
contaminated,excessivelint,etc.).
Freezedamagethatoccurswithouttakingproperpreventivemeasuresasdescribedintheinstallation
manual.
Condensatedamageduetoimproperlyinstalledorlackofacondensatetrap(drain).
AnyHydroSmartunitnotinstalledincompliancewithallapplicablelocal&statecodes,ordinances,and
goodtradepractices.
AnyHydroSmartunitsoldtoorinstalledinareasoutsideofthefiftystates(andtheDistrictof
Columbia)oftheUnitedStatesofAmericaandCanada.
AnyHydroSmartunitinstalledinapplicationsthatcausethewaterheatertoactivatemorethan300
timesperday(thisaveragestoanactivationevery5minutesina24hourperiod).
Anyfailuresthatarenotduetodefectsinmaterialsorworkmanship(mechanicaland/orelectricalparts).
Damagesduetoimproperinstallation:
Gas:incorrectgaspipesizing,incorrectgasmetersizing,incorrectgastype,and/orgaspressures
thatfalloutsidetheproduct’sspecifiedrange.
Water:incorrectwaterpipesizing,waterpressuresthatfalloutsidetheproduct’sspecifiedrange,
recirculationflowratesthatfalloutsidetheproduct’sspecifiedrange(airremoval),and/orlackof
propermethodsofairremovalinaclosedloop,circulationsystem(seeinstallationmanualfor
details).
Electric:supplypowervoltagesthatfalloutsidetheproduct’sspecifiedrange.
Warranty
43Page
Damagesduetowaterquality:
Introductionofliquidsotherthanpotablewaterorpotablewater/glycolmixturesintotheproduct.
Introductionofpoolwater,spawater,oranychemicallytreatedwaterintotheproduct.
Introductionofhardwatermeasuringmorethan7grainspergallon(120ppm)forsinglefamily
domesticapplicationsormorethan4grainspergallon(70ppm)forallothertypesofapplications
intotheproduct.
Introductionofuntreatedorpoorlytreatedwellwaterintotheproduct.
IntroductionofwaterwithpHlevelslessthan6.5andgreaterthan8.5intotheproduct.
FailureofHydroSmartduetouseotherthanmicroboilerwith“IntegratorPanel”orifnotusewith
“IntegratorPanel”.
Warranty
44Page

75E0121
HS115

Navigation menu
