UNSURPASSED FUNCTIONALITY. USER-FRIENDLY FEATURES.

OUT OF THE BOX FUNCTIONALITY.

Frutiger 95 Ultra Black

Eight slots for plug-in,

hot-swappable port processors

Slim profile for rack mounting

Easily integrates with other

network equipment

M

Mu

ul

lt

ti

i-

-p

pr

ro

ot

to

oc

co

ol

l

u

POS dial access termination for up to six T1/E1s

T

T1

1/

/E

E1

1 i

in

nt

te

er

rf

fa

ac

ci

in

ng

g

u

Up to 180 dial lines

R

Re

ed

du

un

nd

da

an

nt

t p

po

ow

we

er

r s

su

up

pp

pl

li

ie

es

s

u

Hot-swappable

M

Mo

od

du

ul

la

at

ti

io

on

ns

s u

up

p t

to

o V

V.

.9

92

2

u

Includes Hypercom Fast POS®

M

Mu

ul

lt

ti

ip

pl

le

e s

sl

lo

ot

ts

s

u

Up to eight

H

Hi

ig

gh

h-

-s

sp

pe

ee

ed

d b

bu

us

s

u

Parallel packet bus, Serial packet bus, PCM highway

u

Applications

•Medium to large branch

and regional offices

•Corporate data centers

•Global networks

T

Th

he

e P

PO

OS

SC

Co

on

nc

ce

en

nt

tr

ra

at

to

or

r f

fo

or

r a

a R

Re

el

li

ia

ab

bl

le

e

N

Ne

et

tw

wo

or

rk

k S

So

ol

lu

ut

ti

io

on

n

The MegaNAC 180 high-density, dial access POS concentrator with fault-

tolerant, multi-function architecture interconnects into elegant, intelligent

networks. It handles a variety of access modes and protocols in the most

demanding environments, including T1/E1 digital interfacing, and delivers

low cost-per-port benefits. The MegaNAC 180 has hot-swappable port

processors and a reduced footprint which takes up less space.

The MegaNAC 180 chassis provides a full suite of uplink connections to

support POS host mainframes requiring support of X.25, TCP/IP or SNA

protocols. It also supports network access via CAS signaling (MFR1, MFR2

and Immediate Start) and CCS signaling for support of ISDN/PRI.

As technology moves faster and faster, the MegaNAC 180 plays a

strategic role in the Hypercom framework. Network owners know they can

freely evolve from one technology to another with the assurance that

yesterday’s systems will seamlessly integrate into tomorrow’s newest

offerings.

MegaNac 180®

INTELLIGENT PARALLEL PROCESSING POWER.

PMS BLUE 654

PMS COOL GREY8

Frutiger 95 Ultra Black

WWOORRLLDD HHEEAADDQQUUAARRTTEERRSS::

HHyyppeerrccoomm CCoorrppoorraattiioonn

2851 West Kathleen Road

Phoenix, Arizona 85053 USA

Tel: +1.602.504.5000

Fax: +1.602.504.4655

www.hypercom.com

R

Re

el

li

ia

ab

bi

il

li

it

ty

y B

Bu

ui

il

lt

t I

In

n

uBuilt on a framework that relies on requirements and

industry standards

uChassis can be used separately or combined to scale to

meet any network requirement

uUtilizes a unique internal transport mechanism and encryption

technology, which as the ability to transport data in its native

mode, saving bandwidth and providing secure transmission

for transactions

F

Fl

le

ex

xi

ib

bl

le

e D

De

ev

ve

el

lo

op

pm

me

en

nt

t a

an

nd

d G

Gr

ro

ow

wt

th

h

uAllows users to start small and expand their framework as new

requirements arise

uProvides freedom to implement more cost-effective services, to

continuously integrate newer applications and to tailor a

complete network solution that extends existing investments

uSupports data and POS

uInterchangeable port processors allow everything to be

changed, without disrupting service. New services can be

added or existing ones upgraded with dedicated port

processors without time-consuming network redesigns or

forklift upgrades

uAllows offices to centralize or compartmentalize traffic from a

combination of WANs, including Frame Relay and IP.

P

Po

ow

we

er

rf

fu

ul

l N

Ne

et

tw

wo

or

rk

k M

Ma

an

na

ag

ge

em

me

en

nt

t

uHypercomView®, Hypercom’s network management system, delivers

all of the tools needed to keep POS networks running smoothly

uHypercom FastPOS offers high-speed, 9600bps modem

technology specifically engineered for the POS network

uSets new standards in GUI-based management for detail,

simplicity and speed.

uClient/server architecture provides comprehensive activity and

performance statistics, alerts and alarms and remote

downloads and upgrades.

TECHNICAL

SPECIFICATIONS:

CCHHAASSSSIISS

•8 slots for plug-in, hot swappable port

processor modules

CCOOMMMMUUNNIICCAATTIIOONNSS

•Bus: High-speed parallel packet bus, serial packet

bus, PCM highway

•Modem: V.21 Bell 10B/212A, Autodial 300/1200/

2400 asynchronous & SDLC, V.22bis, V.29

Hypercom FastPOS, V.32, V.32bis

•POS dial ports: Visa I/II, APACS, SDLC, HDLC,

asynchronous

•Concentrator ports: Ethernet 10Base-T

(10Mbps), RS-232, V.35 (up to 1 Mbps)

PPRROOTTOOCCOOLLSS

•End user: TCP/IP, SNA/SDLC (LU.0 & LU.2),

Bisynch 3270 & 3280, Burroughs Poll/Select,

IP, X.25

•WAN: IP, Frame Relay, X.25, SDLC

•WAN backup: V.32, V.32bis, (optional) V.34, V.90

PPOOWWEERR

•AC: 115-280 V, 4.0/2.0 A, 50/60 Hz

FFOOOOTTPPRRIINNTT

•19.0 in x 13.0 in x 5.3 in

•48.3 cm x 33.0 cm x 13.5 cm

WWEEIIGGHHTT

•27.8 lbs / 12.6 kg

EENNVVIIRROONNMMEENNTT

•Temperature: 0-40°C/32-104°F

•Humidity: 25% to 95%, non-condensing

•Heat Dissipation: 450 BTU/hr

CCEERRTTIIFFIICCAATTIIOONNSS

•FCC Part 15, UL (USA), UCL (Canada), CB & CE

© 2007 Hypercom Corporation, all rights reserved. Hypercom is a registered trademark of Hypercom Corporation.

The Hypercom logo is a trademark of Hypercom Corporation. All other products or services mentioned in this

document are trademarks, service marks, registered trademarks or registered service marks of their respective owners.

Product Specifications subject to change without notice.

940271-001, Rev G March 2007

GLOBAL LOCATIONS:

North America | Central America | Latin America | Asia/Pacific Rim | Europe | Middle East | Africa

MegaNac 180®
