HP Wireless Display Adapter
User Guide
© Copyright 2014 Hewlett-Packard
Development Company, L.P.
Mac OS is a registered trademark of Apple
Inc. Chrome OS is a trademark of Google
Inc. Intel, Intel Pro WiDi, and Intel WiDi are
trademarks of Intel Corporation in the U.S.
and other countries. Windows is a U.S.
registered trademark of the Microsoft group
of companies.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: April 2014
Document Part Number: 749635–001
Table of contents
1 Getting started .................................................................................................................................................. 1
Identifying components ........................................................................................................................ 1
Kit contents .......................................................................................................................... 1
Display adapter guidelines ................................................................................................................... 1
Setting up the HP Wireless Display Adapter ........................................................................................ 2
Step 1: Connecting to power ............................................................................................... 2
Step 2: Connecting to a display device ................................................................................ 2
Step 3: Connecting to a computer or other electronic device .............................................. 2
Step 4: Preventing Sleep or Hibernation ............................................................................. 3
Disconnecting the display adapter ....................................................................................................... 3
2 Using the software ............................................................................................................................................ 4
Updating the firmware .......................................................................................................................... 4
Restoring the default password ............................................................................................................ 4
Restoring the default settings ............................................................................................................... 4
3 Troubleshooting ................................................................................................................................................ 5
Solving common problems ................................................................................................................... 5
General use and connection problems ................................................................................ 5
For more information ............................................................................................................................ 6
iii
iv
1 Getting started
Identifying components
This chapter identifies the visible hardware features of the HP Wireless Display Adapter and provides
setup instructions for the adapter.
NOTE: Some features of the HP Wireless Display Adapter may not be available on your computer.
Kit contents
●HP Wireless Display Adapter and cap
●HDMI-to-VGA adapter
●Micro USB-to-USB cable
●Power adapter and localized plugs
●Carrying bag
Display adapter guidelines
●Compatibility—The display adapter is compatible with Intel
®
Pro WiDi, Intel WiDi, and other
Miracast capable devices as well as devices with WiFi capability. You do not have to be
connected to a network to connect to the display adapter. The following table lists operating
system compatibility.
Operating system Connection type
Windows XP
®
and later Intel WiDi 3.5 and later, Miracast using WiFi 802.11n or
later, AP WiFi using 802.11g or later
Android 4.2 and later Intel WiDi 3.5 or later, Miracast
Chrome OS
™
WiFi 802.11n
Linux WiFi 802.11n
Mac OS
®
WiFi 802.11n limited
The display device must have VGA or HDMI support.
●Power—To use display adapter features, power must be connected to the display adapter.
●Connecting and disconnecting—The display adapter can be wirelessly connected to or
disconnected from the computer whether the display device is on or off. (See Step 2: Connecting
to a display device on page 2 and Disconnecting the display adapter on page 3.)
Identifying components 1
Setting up the HP Wireless Display Adapter
Step 1: Connecting to power
WARNING! To reduce the risk of electric shock or damage to your equipment:
Plug the power cord into a grounded (earthed) outlet that is easily accessible at all times.
Disconnect power from the equipment by unplugging the power cord from the electrical outlet.
Do not disable the power cord grounding plug. The grounding plug is an important safety feature.
To ensure the correct performance of all display adapter features, connect the display adapter to a
power source using the included USB cable.
1. If you are using an electrical outlet, do the following:
a. Connect the proper plug for your outlet to the power adapter.
b. Connect the USB 2.0 end of the cable to the power adapter, and then plug the power
adapter into an electrical outlet
If you are not using an electrical outlet, connect the USB 2.0 end of the USB cable to a powered
USB port.
2. Connect the micro USB end of the USB cable to the display adapter.
Step 2: Connecting to a display device
▲To connect a display device such as a monitor or projector to the display adapter, determine
whether the device has an HDMI port or a VGA port.
●If your display device has a VGA port, first connect the display adapter to the HDMI-to-VGA
adapter, and then connect the display adapter to the VGA port on the device.
●If your display device has an HDMI port, connect the display adapter directly to the HDMI
port on the device.
Step 3: Connecting to a computer or other electronic device
The HP Wireless Display adapter can run in two modes: Miracast/Intel WiDi and presentation mode
(WiFi). You can connect wirelessly to the display adapter using electronic devices such as computers,
tablets, and smartphones. See your device’s documentation to determine whether the device is Intel
WiDi, Miracast, or WiFi capable.
NOTE: After the display adapter starts up, a home screen on the display device (the remote display)
provides the connection information for the two available modes.
To connect using Intel WiDi:
▲Run your electronic device’s Intel WiDi software and select the remote display. Then, select
Connect. If necessary, type in the PIN shown on the home screen of the remote display under
Compatible with lntel
®
Pro WiDi, Intel WiDi / Miracast. See your device's documentation for more
information about creating an Intel WiDi connection.
To connect using Miracast:
▲Run your electronic device’s Miracast software and select the SSID for the display adapter. See
your device’s documentation for more information about creating a Miracast connection.
Miracast software names include Screen Mirroring, Screencasting, and Wi-Fi Direct.
2 Chapter 1 Getting started
For example, Windows 8.1 devices are Wi-Fi Direct native. To connect, display the charms. Select
Devices, and then select Project. The first time you connect, select Add a wireless display. Then,
select the display adapter. Ignore the dialog box that tells you to press a button on the device.
To connect using WiFi:
NOTE: To use presentation mode on a device with a Mac or Linux operating system, you must
install Oracle Java 7 and change the Java security level to medium.
1. On your electronic device, connect to the SSID as shown on the home screen.
2. Open your browser if it does not open automatically. If you are connecting for the first time,
select Continue when the welcome page appears. If you are not connecting for the first time,
select the Admin tab, enter the password, and go to step 7.
3. Enter a PIN in the PIN Code box. Enter the same PIN in the Confirm PIN Code box.
4. Enter a PIN in the Admin. password box. Enter the same PIN in the Confirm Admin. Password
box.
5. Select OK.
6. If an error message appears, repeat steps 3–5. Otherwise, click Continue.
7. If you do not need to connect to the Internet, go to step 10. Otherwise, select the Admin tab,
enter the administrator password, select OK. Select Apply after you have configured the
settings. After the settings validate, select Continue to configure other settings or Reboot Device
to apply the settings.
8. To connect to the internet, select the Home tab, and then select Connect. Select the configured
network from the list of Wi-Fi Networks.
9. Enter your password, and then select OK.
10. Select Use Presentation Mode Application. Download and run the utility.
11. Select the START button to project the electronic device’s screen on the remote display, the
STOP button to stop projecting, or the EXIT button to close the utility. The appearance of these
buttons might change depending on your operating system.
Step 4: Preventing Sleep or Hibernation
If your computer or other electronic device enters Sleep, Hibernation, or an equivalent mode, the
display adapter will be disconnected. See your device’s documentation for instructions on preventing
Sleep or Hibernation.
Disconnecting the display adapter
1. Disconnect the display adapter from the device.
2. Disconnect the USB cable from the display adapter and then from the power source.
3. Store the display adapter and accessories in the carrying bag.
Disconnecting the display adapter 3
2 Using the software
Updating the firmware
This can only be done after connecting a Windows
®
computer to the display adapter using WiFi.
1. After wirelessly connecting your computer to the display adapter, select Admin and then select
Firmware on your electronic device.
2. Select File, and then select the firmware image to be uploaded to the display adapter.
3. Select Upload new Firmware.
4. The system reboots twice. Do not turn off the power during the upgrade.
Restoring the default password
To restore the password to the default, “admin”:
▲As the display adapter starts up, repeatedly press the button on the side of the display adapter.
A screen confirming the password reset will appear on the remote display. Do not turn off the
power during the password reset.
Restoring the default settings
1. After wirelessly connecting your computer to the display adapter, select Admin and then select
Restore Defaults on your electronic device.
2. Select Restore.
4 Chapter 2 Using the software
3 Troubleshooting
Solving common problems
The following table lists possible problems and the recommended solutions.
General use and connection problems
Problem Possible cause Solution
There is no welcome or home screen
on my remote display.
The display adapter is not connected to
power.
Connect the display adapter to power.
The display adapter is not connected to
AC power correctly.
Use the included USB cable and power
adapter with the localized plug for your
country to make sure that adequate
power is provided to the display
adapter. See Step 1: Connecting to
power on page 2.
The display adapter is not connected to
a USB port with enough power.
Make sure that the USB port provides
at least 5 V and 1 A. See your device’s
documentation for information about the
power provided.
I do not know if the display adapter is
powered.
There is no power light on the display
adapter.
When the display adapter is powered
correctly, the home screen appears on
the remote display.
My Intel WiDi- or Miracast-capable
device does not scan for or locate the
display adapter.
This is usually a problem with the utility
on your device.
Restart either your utility, your device,
or both. See your device’s
documentation if the issue is not
resolved.
If your device has Bluetooth, it could be
conflicting with your utility.
Disable Bluetooth, and then create a
connection.
My browser does not automatically
direct me to the display adapter
website.
This could be because of your browser
settings.
Enter 192.168.16.1 in the URL box to
go the website manually.
I want to start a new session. If you want to start a new session and
are still running your current session,
wait 5 seconds after closing your
current session before starting a new
one. You can start your new session in
a different mode.
If you want to start a new session and
you have closed the utility, locate where
you downloaded the utility and then
open it. If you did not download the
utility, go to the display adapter website.
I cannot connect to the Internet in
presentation mode.
You might need to connect through a
second network adapter.
If you have a second network adapter
on your electronic device, use the
following procedure to connect to the
internet:
Solving common problems 5
1. Connect the display adapter to the
remote display and your electronic
device.
2. On the display adapter website,
select Admin, and then select
Basic.
3. Clear Auto Connect Soft AP, and
then select Apply.
4. Connect to the Internet.
An installation prompt appears on my
electronic device when I connect in
presentation mode.
Your device does not require any
external drivers to use the legacy WiFi
support; however, there is a utility that
needs to be downloaded from the
display adapter to your electronic
device.
Download the program when prompted.
For more information
For U.S. support, go to http://www.hp.com/go/contactHP. For worldwide support, go to
http://welcome.hp.com/country/us/en/wwcontact_us.html.
For the fastest possible resolution of your problem, have the following information available when you
contact support.
NOTE: The serial number and other information for the display adapter can be found on the service
label located on the bottom of the display adapter.
●Model name and number for the computer and display device used with the display adapter
●Serial numbers for the computer, display device, and display adapter
●Dates the computer, display device, and display adapter were purchased
●Conditions under which the problem occurred
●Error messages that have been displayed
●Hardware and software you are using
●The manufacturer and model of components connected to the computer and display device
Choose from the following types of support:
●Chat online with an HP technician.
NOTE: When chat is not available in a particular language, it is available in English.
●Find HP support worldwide telephone numbers.
●Locate an HP service center.
6 Chapter 3 Troubleshooting
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
For operation within 5.15 ~ 5.25GHz frequency range, it is restricted to indoor environment. This
device meets all the other requirements specified in Part 15E, Section 15.407 of the FCC Rules.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
FOR COUNTRY CODE SELECTION USAGE (WLAN DEVICES)
Note: The country code selection is for non-US model only and is not available to all US model. Per
FCC regulation, all WiFi product marketed in US must fixed to US operation channels only.
Industry Canada statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio
exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne
doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y
compris un brouillage susceptible de provoquer un fonctionnement indésirable.
Caution :
the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential
for harmful interference to co-channel mobile satellite systems;
Avertissement:
les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement pour une
utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux;
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator &your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm
de distance entre la source de rayonnement et votre corps.
