User manual
®
BT-80-TP
Operation Guide
www.iKey.com • 1.512.837.0283
Pairing Instructions
iKey’s BT-80-TP unit is compatible with
any device that has built in Bluetooth®
functionality.
1. Hold down the “Power” button on the
keyboard until the light flashes red.
2. Hold down the “Bluetooth®” button on the
keyboard until the light flashes blue.
3. Press the “Settings” icon on your host
device with which you are attempting to pair.
4. Select “Bluetooth®” from the “Settings”
menu (Bluetooth® is the third choice in the
menu).
5. Your device is now in
‘discoverable’ mode. Initially, the
“Bluetooth®” button on the BT-80-TP may
give a very short flash, but will then
continue to blink steadily until the unit is
paired with the device.
6. Tap “IKEY Bluetooth Keyboard” from the list
of devices that will appear on your screen.
Charging Instructions
• To charge the keyboard, insert the provided
Micro USB charging cable into the back of the
keyboard and plug the other end of the cable
into a powered USB port on any computer.
The Charging LED indicator will illuminate
orange when charging and will turn off when
fully charged. In a fully discharged state, the
battery takes 5 hours to completely recharge.
• With average usage of the keyboard, the
anticipated battery life is eight weeks.
Note: The BT-80-TP ships from iKey with the internal battery
fully charged and ready to use out of the box.
7. Enter the numeric code given by the wizard
using the BT-80-TP keyboard, then press the
“Enter” key.
8. The BT-80-TP will then be paired with the
device and is ready for use by placing the
cursor anywhere you wish to type.
Power Button
Bluetooth® ButtonBacklight Button
NOTICE :
The changes or modifications not expressly approved by the party responsible
for compliance could void user’s authority to operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the
antenna(s) used for this transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter. No change to the antenna or the device is permitted. Any
change to the antenna or the device could result in the device exceeding the RF exposure
requirements and void user’s authority to operate the device.
The equipment has been tested and found to comply with the limits for a Class
B Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction, may cause
harmful interference to radio communication. However, there is no grantee that
interference will not occur in a particular installation. If this equipment dose cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on , the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
