User manual
®
BT-80
Operation Guide
www.iKey.com • 1.800.866.6506
Pairing Instructions
iKey’s BT-80 unit is compatible with any
Apple iOS device that has built in Bluetooth®
functionality.
1. Hold down the “Power” button on the
keyboard until the light flashes red.
2. Hold down the “Bluetooth®” button on the
keyboard until the light flashes blue.
3. Press the “Settings” icon on your Apple iOS
device.
4. Select “Bluetooth®” from the “Settings”
menu (Bluetooth® is the third choice in the
menu).
5. Your Apple iOS device is now in
‘discoverable’ mode. Initially, the
“Bluetooth®” button on the BT-80 may
give a very short flash, but will then
continue to blink steadily until the unit is
paired with the device.
6. Tap “IKEY Bluetooth Keyboard” from the list
of devices that will appear on your screen.
Charging Instructions
• To charge the keyboard, insert the provided
Micro USB charging cable into the back of the
keyboard and plug the other end of the cable
into a powered USB port on any computer.
The Charging LED indicator will illuminate
orange when charging and will turn off when
fully charged. In a fully discharged state, the
battery takes 5 hours to completely recharge.
• With average usage of the keyboard, the
anticipated battery life is eight weeks.
Note: The BT-80 ships from iKey with the internal battery
fully charged and ready to use out of the box.
Power Button
Bluetooth® Button
7. Enter the numeric code given by the wizard
using the BT-80 keyboard, then press the
“Enter” key.
8. The BT-80 will then be paired with the
Apple iOS device and is ready for use by
placing the cursor anywhere you wish to
type.
Backlight Button
®
BT-80
Operation Guide
©2013 iKey, Ltd. All rights reserved.
Functionality and Features
• To conserve power, the keyboard can be
turned off when not in use by holding down
the “Power” button. The red LED will flash
once indicating the keyboard has turned off.
The same key will then turn the power back
on. Each time the keyboard is powered off it
will need to be paired with the host again.
• To turn the red LED backlighting on, press
the “Light Bulb” button in the upper left corner
of the keyboard. To make it brighter press the
“Light Bulb” button two more times.
Standby/Sleep Mode
• After 10 seconds of inactivity, the unit will
go into Sleep Mode. This is a power saving
feature on the keyboard that will put it in a
low power state until needed again. To wake
the unit from sleep mode press any key. We
recommend pressing the space bar to prevent
interference with any programs on your
computer.
Apple Hot Keys
Home Key — Used to wake up the
device, exit out of applications and
navigate to the first page of icons.
Signal Distance
• The BT-80 can function up to a distance of
10 meters (~30 feet) from the host computer.
The signal may be lost if the keyboard gets
out of range, but the unit should start working
again if you move back within the 10 meter
signal distance. If the unit still does not work it
may need to be re-paired.
Search Key — Allows users to search
their device for files and apps.
Photo Frame Key — Instantly turns
your photo album into a slideshow.
On-Screen Keyboard Key — Allows
users to go back to using the
keyboard on the device.
Previous Track/Scene Key — Allows
users to go back to the previous song
track or movie scene.
Play/Pause Key — Allows users to
play or pause a song track or movie
scene.
Next Track/Scene Key — Allows
users to go to the next song track or
movie scene.
Mute Key — Instantly cuts off the
volume on the device.
Volume Down Key — Allows users to
decrease the volume on the device.
Volume Up Key — Allows users to
increase the volume on the device.
Lock Key — Allows users to lock
the device’s screen. If the device is
password protected, the password
will need to be entered to use it
again. If it’s not password protected,
just slide the arrow to unlock the
screen.
Questions? Contact iKey:
512.837.0283
800.866.6506
info@iKey.com
www.iKey.com
910805 1
Notice : The changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, no change
to the antenna or the device is permitted. Any change to the antenna or the
device could result in the device exceeding the RF exposure requirements
and void user’s authority to operate the device.
FCC INFORMATION
The Federal Communication Commission Radio Frequency Interference
Statement includes the following paragraph:
The equipment has been tested and found to comply with the limits for a Class
B Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction, may cause
harmful interference to radio communication. However, there is no grantee that
interference will not occur in a particular installation. If this equipment dose cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on , the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
The user should not modify or change this equipment without written approval
Form iKEY, Ltd. Modification could void authority to use this equipment.
