IKUSI ELECTRONICA S L TR2400-EMB RADIO TRANSCEIVER User Manual R11

IKUSI ELECTRONICA, S.L. RADIO TRANSCEIVER Users Manual R11

Contents

Users Manual R11

R11
USER’s MANUAL
Paseo Miramón 170 - 20014 Donostia - San Sebastián, Guipúzcoa /Spain - tlc@ikusi.com
Tx Cr 1
Cr 1
These instruc ons must be read carefully in order to install and use the set properly and to
keep it in perfect working condi on and to reduce the risks of misuse.
Do not use this set on machines in poten ally explosive atmospheres, except the models
cer fi ed ATEX/RATEX to work in that condi ons.
a) Strictly adhere to the instruc ons for installa on contained in this manual.
b) Make sure that professional and competent personnel carry out the installa on.
c) Ensure that all site and prevailing safety regula ons are fully respected.
d) Make sure that this manual is permanently available to the operator and maintenance personnel.
e) Keep the transmi er out of reach of unauthorised personnel.
g) On star ng each working day, check to make sure that the STOP bu on and other safety measures
are working.
h) When in doubt, press the STOP bu on.
i) Whenever several sets have been installed, make sure the transmi er you are going to use is the
right one. Iden fy the machine controlled on the label for this purpose on the transmi er or by
using the display (in case it has one).
j) Service the equipment periodically.
k) When carrying out repairs, only use spare parts supplied by IKUSI dealers.
WARNING
• The equipment must be operated by qualifi ed personnel.
• A er use, never leave the equipment ON (one or several transmi ers). Always set the STOP bu on to
switch off posi on of the equipment to avoid accidentally to ac vate manoeuvres –specially in crane
maintenance purposes-.
• Do not use the set when visibility is limited.
• Avoid knocking or dropping the set.
• Do not use the set if failure is detected.
REMEMBER
Changes or modifi ca ons not expressly approved by IKUSI could void the user’s authority to operate this
equipment.
Remove the EEPROM in order to
disable the transmitter When in doubt, press the STOP
button Make sure the transmitter works
with the machine to be handled
Do not use the set when visibility
is limited Avoid knocking or dropping the
set
01- SAFETY INSTRUCTIONS
01- SAFETY INSTRUCTIONS
FCC/ISED Regulatory no ces
Modifi ca on statement
IKUSI ELECTRONICA, S.L. has not approved any changes or modifi ca ons to this device by the user. Any changes or
modifi ca ons could void the user’s authority to operate the equipment.
IKUSI ELECTRONICA, S.L. n’approuve aucune modifi ca on apportée à l’appareil par l’u lisateur, quelle qu’en soit la na-
ture. Tout changement ou modifi ca on peuvent annuler le droit d’u lisa on de l’appareil par l’u lisateur.
Interference statement (if it is not placed in the device)
This device complies with Part 15 of the FCC Rules and Industry Canada license-exempt RSS standard(s). Opera on is
subject to the following two condi ons: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired opera on of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploita on est autorisée aux deux condi ons suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2)
l’u lisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est suscep ble d’en
comprome re le fonc onnement.
Wireless no ce
This device complies with FCC/ISED radia on exposure limits set forth for an uncontrolled environment and meets the
FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the ISED radio frequency (RF) Exposure rules.
This transmi er must not be co-located or opera ng in conjunc on with any other antenna or transmi er.
Le présent appareil est conforme à l’exposi on aux radia ons FCC / ISED défi nies pour un environnement non contrôlé
et répond aux direc ves d’exposi on de la fréquence de la FCC radiofréquence (RF) et RSS-102 de la fréquence radio
(RF) ISED règles d’exposi on.
L’émetteur ne doit pas être colocalisé ni fonctionner conjointement avec à autre antenne ou autre émetteur.Ç
FCC Class B digital device no ce
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protec on against harmful interference in a residen al
installa on. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruc ons, may cause harmful interference to radio communica ons. However, there is no guar-
antee that interference will not occur in a par cular installa on. If this equipment does cause harmful interference to
radio or television recep on, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separa on between the equipment and receiver.
- Connect the equipment into an outlet on a circuit diff erent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-3 (B) / NMB-3 (B)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de classe B est conforme à la norme canadienne ICES-003.
02- TECHNICAL DESCRIPTION
02- TECHNICAL DESCRIPTION
164
163,50
127,08
173,29
Ă5,50
36,41
37,02
30 30
60
1.- Fixing slots (fi xed
assembly or an -vibra on
or an -vibra on with
magnets*)
2.- M32 Cable Gland
3.- Power Supply
4.- LR11 logic board
5.- Removable EEPROM
6.- Signalling LEDs
7.- 2,4 GHz Radio
8.- Wiring connec on
*The use of the an vibra on kit is
recommended in any case.
1
2
8
5
4
3
7
6
SPECIFICATIONS
R11
Ingress Protection IP65 / NEMA 4
Frequency Band 2,4 GHz
AC Power Supply 48-240 Vac (Multivoltage)
DC Power Supply 8-36 Vdc
Power (W) 10 W
Antenna Internal.
Removable EEPROM Internal.
Señalizaciones na.
ON/OFF Outputs (Max.) 11
Maximum output current (A) 8 A
Maximun voltage (V AC) 250 V
Analogue Outputs (Max.) na.
CANOpen, Profi bus-DP, SAE J1939 na.
ON/OFF Inputs (Max.) na.
Analogue Inputs (Max.) na.
STOP FUNCTION
Performance Level EN 13849 Category 3 PL d
Maximum output current (A) 6 A
Output voltage (V AC) 250 V
Temperature range -20ºC +70ºC
Relative Humidity Máx. 95% (without condensation)
Storage temperatura range (24h) -25ºC / +75ºC (-13F/167ºF)
Storage temperatura range —long periods- -25ºC / +55ºC (-13F / 131 ºF)
02- TECHNICAL DESCRIPTION
1
03- RECEIVER’s INSTALLATION
03- RECEIVER INSTALLATION
WARNING
Manage the complete shut down of the machine throughout the whole installa on of
the receiver, following the legisla on on occupa onal risk presen on in force.
Check the power supply and shut down the main switch, disconnec ng the interface
cable between the receiver and the machine’s electrical box.
Remember that the receiver has more than one circuit of low tension. Even if the power
supply of the receiver is not connected, there is s ll risk of electric shock.
HOW TO LOCATE THE RECEIVER
3
1. Find a easily accesible and clear loca on, if possible with a direct vision between the receiver’s antenna and
the transmi er’s working area.
2. In cases where a high level of vibra on is expected, it is recommended the use of shock-absorvers. It can be
supplied as an accessory a magnet kit, which allow a esay and fast assembly, and the shock absorver kit.
3. Proceed the connec on of the power supply and the receiver’s outputs. Use the connec on block diagram
provided with the system, where it is detailed the correspondence between the transmi er maneuvres and
the receiver’s outputs.
4. Check the electrical installarion and verify if there’s an op on to connect the neutral or the ground cable. In
that case, don’t forget to connect the ground cable.
The use of fi reproof or fl ame retardant cables is recommended for the connec on.
The troubleshoo ng LEDs are located on the receiver board. In order to reach the signalling, the receiver must be
accesible and connected and the two screws located on the base of the receiver must be released, using the suitable
tool.
LED LED COLOUR /
FREQUENCY
PULSE
FREQUENCY
MEANING ACTION
POWER Green /
Con nuous Switched ON if powered. Check power supply if
it is switched OFF
STATUS Blue /
Fast pulses Star ng the system, stablishing commu-
nica on with radio and EEPROM. Wait
Blue/
Con nuous Wai ng for tranmis er communica on.
Coming from ACTIVE STOP. Release STOP pushbut-
ton and press START
Blue/
Slow pulses Wai ng for tranmis er communica on.
Coming from PASIVE STOP. Press START
Green /
Con nuous Working. Operate
Red /
Slow pulses EEPROM Error. EEPROM module mising
or corrupt. Check EEPROM and
reprogram if necessary
Red /
Double pulses Radio Errror. Radio communica on error. Replace receiver
Red /
Triple pulses Secondary micro error or error between
micro communica on. Replace receiver
STATUS+
DIAG 1
Red/
4 pulses
Orange/
Slow pulses
Low tension in the receivers power
supply Supply the system with
the correct voltage
Red/
4 pulses
Orange/
Double pulses
Hardware error Replace receiver
Red/
4 pulses
Orange/
Triple pulses
Red/
4 pulses
Orange/
4 pulses
DIAG 1 Green /
Slow pulses Low link quality
Green /
Double pulses Medium link quality
Green /
Triple pulses High link quality
ORDER Green /
Con nuous
RELAY Green /
Con nuous STOP relay ac vated
04- TROUBLESHOOTING
04- TROUBLESHOOTING
LEDs on the receiver board.
POWER STATUS DIAG1 DIAG2 ORDER RELAY
