INFINIX MOBILITY XB02 Smart Bracelet User Manual
INFINIX MOBILITY LIMITED Smart Bracelet Users Manual
Users Manual
![](/img.php?id=3847005&img=bg1.png)
XBO2 smart bracelet User manual
1. Compatible system of phone&BLE version
Android 4.4 or above
iOS 7.0 or above
Bluetooth 4.0 supply
1.Use preparation OLED Touch Screen
Please ensure the device is full charged for the first time use,you need charge it by charging clip
if the device can't power on.
Please Charge by aiming at the charging point of wrist band: when connected to the
power supply, it will be activated and display charging status.
※After unpacking the bracelet→ turn it on to check if there is power; If it
cannot be turned on→please use it after being charged for 2 hours.
1. Connect
Under the requirement of the adaptation platform (e.g. 1), download the
corresponding mobile APP first:
3.1 APP Download: (1)Please search “WearFit 2.0”in APP store or Google Play and android
A Hidden touch button
is here!
sense light
Charge contact
![](/img.php?id=3847005&img=bg2.png)
market. (2)
Or scan the QR code to download.(Tip: The download of other
channels cannot guarantee that the APP is the latest version)
3.2 connect : Boot (long press on the touch button (place on the picture) for 3
seconds)→ turn on the Bluetooth of the mobile phone→ open the app on the cell
phone "Wearfit2.0 → if to turn on the GPS (it can be chosen to be turned on when
using a wrist band but the Bluetooth signal can not bee searched by the app)"→ to
connect and bind (directly click into→mine →the connection management→ search the
Bluetooth ID (click the one you selected )→ Click "search" again if there is not
any available→connect the wrist band→automatically switch to the main interface.)
3.3 login instructions: it can be logged in directly、by the third party (the third
party platform)、 binding the wristband (click on the "binding wristband"→connect
the wristband→ click on the "search"→ click on your selected Bluetooth ID→
automatically return to the "home page", see if there is a "connected" notification
above "+").
1. Start use
1.
Once WearFit 2.0 is connected with smart bracelet, it will synchronize with the phone time
and smart bracelet continuous testing record.
2. It can be refreshed at the top of the APP homepage.
Beacelet
operating:
It will switch to following order as per single click the OLED touch button
(The touch button refer to the photo of function please):
time mode→Heart rate mode→Step mode→Distancemode→Calorie mode→Sleep mode→
Stopwatchmode→Search mode→Message reminder→Power off mode→Bluetooth ID
1. Bracelet
Features:
5.1 Time mode: 3 seconds after pressing the touch button (with vibration),
there will be three kinds of time display modes; Single click on the touch button
can switch the time mode; Press the touch button for 3 seconds (with vibration) on
Version download
the selected time display mode interface to choose. (the wristband has no time
settings, it can only synchronize with the APP.)
5.2
Heart rate
measuring:
After wearing the wristband, wait for about 60 seconds
to show your heart rate. The wristband can measure the heartbeat continuously for
every time. The heart rate displayed on the wristband interface is the latest
measurement data. (During the measurement, the actual displayed heart rate may have
minor deviation with the actual data due to the reasons that the wristband is not
close to the skin, area being measured has dirt, arm hair is dense(hair (1 cm)
light color and medium dense), dark color of the skin (standards on brown, golden,
medium white and lighter).
5.3
Step
、
Distance
、
Calorie
(only the displaying function) : automatically records
daily steps, mileage and calories consumed while walking; And automatically
synchronize the data to the APP.
5.4 sleep
measuring:
Enter the app→ Mine- personal data →sleep time settings
→save (notification of" successful ")
5.5 stopwatch function: enter (press the touch button for 3 seconds)→ enter the
timer function (click to start and stop)→exit and clear (long press the touch
button for 3 seconds).
5.6 Wristband looking for the phone (the successful connection ) : enter (long
press the touch button for 3 seconds)→look up (start and stop with single click on
the touch button)→ exit (long press the touch button for 3 seconds).
5.7 SMS reminder: enter the app→Mine→ Device management→Intelligent reminder
→SMS reminders to turn on and off. Start the SMS alert switch, and the wristband
will vibrate when there a new text message.
5.8 Call reminder: Enter the app → Mine-equipment management→ call
notifications→single click to turn on or off.
Callreminder: Enter the app → Mine-equipment management→ call
notifications→single click to turn on or off.
5.9 Power off: enter (press the touch button for 3 seconds)→ select "YES" (" NO
"is returning to the previous level without turning off the machine)→ (long press
the touch button 3 seconds).
5.10 APP「Wearfit2.0」
Features
:
5.10.1 Tiredness level: click "single point measurement" to show your tiredness
rate after 30S; And record it to display according to the day, week or month mode;
You can also share the results with your friends. (click on the small icon on the
upper right corner→ select the platform→ and enter the selected friends (which
![](/img.php?id=3847005&img=bg4.png)
will be sent automatically in the screenshot).
5.10.2 Find the wristband: click "+" on the home page→ click "find the
wristband", and the wristband will vibrate. (APP and wristband are successfully
connected)
5.10.3 Anti -loosing notification: mine → equipment management → intelligent
reminder → click the anti→loosing notification "off" (close \ open); When the
wrist band is disconnected from the APP, the wristband will vibrate to remind you.
5.10.4
Alarm clock:
mine
→
equipment management
→
smart reminder
→
click "+" to set the
alarm setting (<=8 times)
5.10.5 Long sitting reminder: mine →equipment management→intelligent
reminder→turn on the long sitting reminder→ set starting time and ending time and
save. The wristband will automatically monitor the state of the activity. If the
wristband does not generate the number of steps during the set period, the
wristband will be automatically reminded.
5.10.6 No disturbing mode: mine→ equipment management→ smart reminder→ no
disturbing mode→ turn on the mode, set starting and ending time and save. During
this time, the wristband will stop receiving notifications from the phone.
5.10.7 Shake to take the picture: click "+" on the front page→ choose "shake
to take a picture"→ shake the wristband to take a picture.
5.10.8 Raise your wristband to lighten the screen: mine→ equipment
management→ turn on the "raise your hand to lighten the screen"→ raise the wrist
and the screen will automatically be lit up (the lit screen will be 5s).Method 1:
wave your arm from 90 degree to 30-85 degree (normal angle for reading the screen),
your band will automatically light up. Method 2: turn the screen surface away from
your body, then turn the screen back to 30-80 degrees (normal angel for reading the
screen), your band will light up.
1.Common problem
6.1While binding the bracelet, you still can ’ t find your bracelet or can ’ t
connect to the band?
Android System:
①Please make sure you turn on Bluetooth on your phone, and the band doesn’t show
bluetooth symbol (if the band shows the Bluetooth symbol, it indicates the band
connected with your phone successfully). Stay close to you band, and try to search
and connect again. Also please make sure your phone system is Android 4.4 or above.
②If still can ’t connect, go to your phone Setting — Application Management —
Permission Management — Authority Management, then find Wearfit 2.0. Choose
“allowed” for all permission; then again enter Phone Setting — GPS, turn onypur
phone GPS, restart your phone, and try to connect again.
IOS System:
Please make sure you turn on bluetooth on your phone, and the band doesn’t have
Bluetooth symbol (if he band has Bluetooth symbol, it means the band successfully
connected to other device). After onetime connection, your phone will remember the
band. Every time you turn on the Bluetooth on your phone, the band and your phone
will automatically connect with each other. If you want your phone to ignore the
device next time, please go to phone Setting—Bluetooth— Ignore the device. Then
App can search your band again.
6.2 After binding the band but shows no connection, or shows connected but battery
is 0%?
In this situation, your phone doesn’t bind the band successfully, please try to
bind again.
6.3 No data in the App?
Pull down the Main surface and refresh, sync the data manually, then the App will
show the data. When you first connect the band with your phone, the App will
automatically sync the data. Later, the App will sync the data automatically at
every integral time (ex: 7pm, 8pm) In addition, you need to turn on integral time
measurement, all the step, heart rate, fatigue (graph) data are from integral time
measurement. If you don’t turn on the integral time measurement, there is no graph
data in fatigue measure.
6.4 After the APP refresh, the data cannot be loaded?
App Settings -- restore the factory Settings of the bracelet, click restore factory
Settings, turn off the bracelet, then restart the bracelet to connect the app, and
use the bracelet normally, the data can be loaded.
6.5 The time is not accurate?
When there is no electricity in the bracelet, the time of bracelet may appear error
after refilling. Please connect to the mobile phone, and the bracelet will
automatically synchronize the time of the phone to calibrate.
6.6 The time is not sync with your phone when you connect the app?
![](/img.php?id=3847005&img=bg6.png)
phone Settings -- application management/permission management, open the
permissions of the app, re-link the bracelet, and refresh the app under the
main interface of the app.
7 basic parameters:
Screen size 0.66
bluetooth Bluetooth 4.0
Waterproof level IP67
Bettery Type Polymer lithium battery
Battery capacity 105mAh
Charge time 1.5-2H
Type aize 248mm*24.2mm*11mm
Charging way Special charger
Packaging Smart bracelet + charging clip +
user manual.
Attention:
1、If there is a product quality problem or if there is any confusion about the use
of the product, please contact our store directly and we will deal with it quickly.
1.The measurement results of this product are for reference only, not for any
medical use and basis. Please follow the doctor's instructions and do not diagnose
and treat yourself according to this measurement.
2.This product grade of IP67 waterproof, can be used for life cannot be used for
diving and soak in water for a long time. In addition, this product does not
prevent hot water, because the steam will affect the bracelet.
3.company reserves the right to modify the contents of this manual without prior
notice. Some functions are different in the corresponding software version, which
is normal.
FCC Caution.
§ 15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
* RF warning for Portable device:
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
