IMI-3000 User Manual
October 8, 2002
Immediate Marketing
Listen Here………
IMI-3000 User Instructions
Table of Contents
I. Product Description
II. FCC Regulations and Disclaimer
III. How to Get Started
IV. How to Change Frequency Settings
V. How to Change CompactFlash Card
VI. Installation Requirements
VII. Support
VIII. Attachments
I. Product Description
The IMI-3000 is a Part 15 intentional radiator designed to be installed in
business locations to produce a short-range FM radio broadcast. ImMEDIAte
Marketing’s customers utilize the IMI-3000 for promotion and advertising
broadcast to their customer while they are on premise in their automobiles.
The functions and components of the IMI-3000 consist of an integrated MP3
player, intentional radiator (or transmitter), and 1 to 4 distributed antennas.
The IMI-3000L is the same product from an intentional radiator and
distributed antenna perspective with the difference being the broadcast play-
source. The IMI-3000L has an audio input connector, allowing customers to
broadcast from a play-source of their choice (i.e. CD player, satellite receiver,
etc.).
The antennas will be professionally installed outside of the buildings and
mounted to fixed positions around the customer’s property in order to cover a
defined area of broadcast. Regardless of antenna locations or orientations, at
no point in the broadcast area will the field strength limits of FCC 47 Code of
Federal Regulation (CFR) Part 15 be exceeded. Furthermore, the antennas
will not be mounted nearer to one another than 10 meters (physical distance).
This is to avoid signal strength contribution from additional antennas that
would increase field strength beyond the specifications.
There is a single CompactFlash memory card socket in the IMI-3000. The
broadcast play list is stored on the memory cards and can be changed
manually by the customer. Instructions on how to change the memory card
are detailed in a later section of this document.
The standard mode of operation when the IMI-3000 is powered and contains a
CompactFlash card is continuous play/broadcast. In other words, the
broadcast message is playing and broadcasting in endless loop when the IMI-
3000 is powered ON. The same is true of the IMI-3000L with the exception
of the audio source. The audio source must be correctly plugged into the IMI-
3000L and providing audio to be broadcast.
II. FCC Regulations and Disclaimer
The Federal Communications Commission (FCC) 47 Code of Federal
Regulation (CFR) Part 15 details the guidelines for designing manufacturing,
and installing Unlicensed Intentional Radiators. In general, the FCC details
power thresholds of emissions within which all intentional radiators must
operate.
The IMI-3000 is designed to be used only within the power constraints of Part
15. Under no circumstances is the IMI-3000 to be modified, tuned, or
installed in such a way as to exceed the thresholds set by the FCC. This
includes the physical distance between antenna locations (no less than 10
meters). Specifically, the antennas will be distributed at distances equal to or
greater than 10 meters apart in order to insure that the field strength at a
distance of 3 meters from either antenna never exceeds the 250 micro volt
parameter.
ImMEDIAte Marketing is not liable for any modification or changes to
installation by the customer (or agent of the customer) that may cause the field
strength of the antenna output to exceed the FCC-defined threshold.
IMPORTANT FCC NOTICE:
Any changes or modifications to the IMI-3000(L) not expressly approved
by ImMEDIAte Marketing Inc. (IMI) could void the users authority to
operate the IMI equipment.
III. How to get started
Once the IMI-3000 has been mounted to a wall by a professional installation
crew, the unit is ready to be powered and broadcasting.
Step 1 – remove the cover door from the IMI-3000 by loosening the two
screws on the front cover using a Philips head screwdriver. Then slide the
door up and pull out to remove.
Step 2 – make sure the CompactFlash card is inserted properly into the
memory socket. The label on the memory card should be facing to your right
hand side.
Step 3 – locate the power input plug near the bottom of the printed circuit
board inside the IMI-3000. Insert the power cord and plug the block end of
the adapter in to the wall.
Step 4 – verify that the unit is on by looking for lights on the board to be
illuminated.
Step 5 – replace the cover door and tighten the screws.
NOTE: Bending the power cord will be necessary in order to replace the front
cover. Gently bend the power cord in a downward direction trying not to
apply excessive pressure to the power adapter plug.
IV. How to change the broadcast frequency
Step 1 – unplug the power adapter from the wall
Step 2 – remove the front cover from the IMI-3000 by loosening the 2 screws.
Step 3 – verify that the unit is not powered by looking for illuminated lights
on the board.
Step 4 – locate the dipswitch blocks mounted toward the rear of the board.
Step 5 – adjust the dipswitches according to the attached table for the desired
frequency.
NOTE – verify that the desired frequency is not in use by a licensed operator
prior to setting the IMI-3000. ImMEDIAte Marketing is NOT responsible for
frequency changes by the customer that result in interference with existing
radio station broadcasts or other RF equipment.
Step 6 – plug the power adapter back into the wall outlet and verify that the
IMI-3000 powers up. Lights on the board will illuminate when the unit has
power.
Step 7 – replace the front cover and tighten the screws.
NOTE: Bending the power cord will be necessary in order to replace the front
cover. Gently bend the power cord in a downward direction trying not to
apply excessive pressure to the power adapter plug.
V. How to change the CompactFlash Memory Card
Step 1 – unplug the power adapter from the wall
Step 2 – remove the front cover from the IMI-3000 by loosening the 2 screws
Step 3 – verify that the unit is not powered by looking for illuminated lights
on the board
Step 4 – locate the CompactFlash memory card in the socket on the upper
portion of the board
Step 5 – remove the memory card by pulling gently. DO NOT twist or pull
too hard on the card
Step 6 – insert the new memory card into the socket by pushing firmly. Make
sure that the label is facing to the right. Do NOT force the CompactFlash card
into the socket. It should go in with the same amount of resistance as it did
coming out.
Step 7 – plug the power adapter back into the wall outlet and verify that the
IMI-3000 powers up. Lights on the board will illuminate when the unit has
power.
Step 8 – replace the front cover and tighten the screws.
VI. Installation Requirements
Installation of the IMI-3000 and distributed antenna system will be done
professionally by insured installation crews that are either employees of or
sub-contracted by ImMEDIAte Marketing. Installations will include the
following:
• Locate appropriate location for IMI-3000 inside the customer
building (reference the site survey provided by ImMEDIAte
Marketing for general area selected).
• Mount the IMI-3000 to the wall near in proximity to an electrical
outlet (within reach of provided 6-foot power cord.
• Connect up to 4 100-foot coax cables to the IMI-3000 being certain
to tighten the F-connectors securely to the female connections on the
IMI-3000 printed circuit board.
• Run coax to nearest existing exit holes from the building (typically
inside of drop ceiling used for cables connecting satellite, power,
etc.)
• Mount distributed antennas in pre-defined locations per the site
survey provided by ImMEDIAte Marketing.
• Connect coax cables to the antennas making sure to tighten the F-
connectors securely
• Seal or reseal the hole(s) through which the coax cables exit the
building using weather-proof electrical sealant.
• Dress the coax cables appropriately both inside and outside the
building.
Installation Parameters:
• All coax cables must be no less than 100 feet long. Cables longer
than 100 feet can be used to accommodate runs requiring more than
100 feet from the IMI-3000 to the antenna(s).
• Antenna locations can be no less than 10 meters (33 feet) from any
other IMI-3000 antenna.
• Antennas must be mounted only in a vertical position – the antenna
tube perpendicular to the ground. Specifically, they must be mounted
to a horizontal surface with the tube either pointing directly up or
directly down (i.e under eaves).
• Any excess cable length must be coiled and stored somewhere inside
the customer building. Above the drop ceiling is the most common
available space for placing the cable excess.
VII. Support
For any questions regarding installation or operation of the IMI-3000 or IMI-
3000L, please call ImMEDIAte Marketing directly at 214-668-7986.
VIII. Attachments
Frequency Setting Chart
"***********************************************************
IMI-3000 Switch Settings for Commercial FM Frequency Band;
***********************************************************
************** SW3 ************** ***** SW1 *******
ON = switch UP * 1 2 3 4 5 6 7 8 * * 1 2 3 4 *
********************************* *****************
RESET PLL/PIC off X X X X X X X X X X X
Freq= 88.1MHZ ON ON ON ON ON ON ON ON off off off ON
Freq= 88.3MHZ ON ON ON ON ON ON ON off off off off ON
Freq= 88.5MHZ ON ON ON ON ON ON off ON off off off ON
Freq= 88.7MHZ ON ON ON ON ON ON off off off off off ON
Freq= 88.9MHZ ON ON ON ON ON off ON ON off off off ON
Freq= 89.1MHZ ON ON ON ON ON off ON off off off off ON
Freq= 89.3MHZ ON ON ON ON ON off off ON off off off ON
Freq= 89.5MHZ ON ON ON ON ON off off off off off off ON
Freq= 89.7MHZ ON ON ON ON off ON ON ON off off off ON
Freq= 89.9MHZ ON ON ON ON off ON ON off off off off ON
Freq= 90.1MHZ ON ON ON ON off ON off ON off off off ON
Freq= 90.3MHZ ON ON ON ON off ON off off off off off ON
Freq= 90.5MHZ ON ON ON ON off off ON ON off off off ON
Freq= 90.7MHZ ON ON ON ON off off ON off off off off ON
Freq= 90.9MHZ ON ON ON ON off off off ON off off off ON
Freq= 91.1MHZ ON ON ON ON off off off off off off off ON
Freq= 91.3MHZ ON ON ON off ON ON ON ON off off off ON
Freq= 91.5MHZ ON ON ON off ON ON ON off off off off ON
Freq= 91.7MHZ ON ON ON off ON ON off ON off off off ON
Freq= 91.9MHZ ON ON ON off ON ON off off off off off ON
Freq= 92.1MHZ ON ON ON off ON off ON ON off off off ON
Freq= 92.3MHZ ON ON ON off ON off ON off off off off ON
Freq= 92.5MHZ ON ON ON off ON off off ON off off off ON
Freq= 92.7MHZ ON ON ON off ON off off off off off off ON
Freq= 92.9MHZ ON ON ON off off ON ON ON off off off ON
Freq= 93.1MHZ ON ON ON off off ON ON off off off off ON
Freq= 93.3MHZ ON ON ON off off ON off ON off off off ON
Freq= 93.5MHZ ON ON ON off off ON off off off off off ON
Freq= 93.7MHZ ON ON ON off off off ON ON off off off ON
Freq= 93.9MHZ ON ON ON off off off ON off off off off ON
Freq= 94.1MHZ ON ON ON off off off off ON off off off ON
Freq= 94.3MHZ ON ON ON off off off off off off off off ON
Freq= 94.5MHZ ON ON off ON ON ON ON ON off off off ON
Freq= 94.7MHZ ON ON off ON ON ON ON off off off off ON
Freq= 94.9MHZ ON ON off ON ON ON off ON off off off ON
Freq= 95.1MHZ ON ON off ON ON ON off off off off off ON
Freq= 95.3MHZ ON ON off ON ON off ON ON off off off ON
Freq= 95.5MHZ ON ON off ON ON off ON off off off off ON
Freq= 95.7MHZ ON ON off ON ON off off ON off off off ON
Freq= 95.9MHZ ON ON off ON ON off off off off off off ON
Freq= 96.1MHZ ON ON off ON off ON ON ON off off off ON
Freq= 96.3MHZ ON ON off ON off ON ON off off off off ON
Freq= 96.5MHZ ON ON off ON off ON off ON off off off ON
Freq= 96.7MHZ ON ON off ON off ON off off off off off ON
Freq= 96.9MHZ ON ON off ON off off ON ON off off off ON
Freq= 97.1MHZ ON ON off ON off off ON off off off off ON
Freq= 97.3MHZ ON ON off ON off off off ON off off off ON
Freq= 97.5MHZ ON ON off ON off off off off off off off ON
************** SW3 ************** ***** SW1 *******
ON = switch UP * 1 2 3 4 5 6 7 8 * * 1 2 3 4 *
********************************* *****************
Freq= 97.7MHZ ON ON off off ON ON ON ON off off off ON
Freq= 97.9MHZ ON ON off off ON ON ON off off off off ON
Freq= 98.1MHZ ON ON off off ON ON off ON off off off ON
Freq= 98.3MHZ ON ON off off ON ON off off off off off ON
Freq= 98.5MHZ ON ON off off ON off ON ON off off off ON
Freq= 98.7MHZ ON ON off off ON off ON off off off off ON
Freq= 98.9MHZ ON ON off off ON off off ON off off off ON
Freq= 99.1MHZ ON ON off off ON off off off off off off ON
Freq= 99.3MHZ ON ON off off off ON ON ON off off off ON
Freq= 99.5MHZ ON ON off off off ON ON off off off off ON
Freq= 99.7MHZ ON ON off off off ON off ON off off off ON
Freq= 99.9MHZ ON ON off off off ON off off off off off ON
Freq= 100.1MHZ ON ON off off off off ON ON off off off off
Freq= 100.3MHZ ON ON off off off off ON off off off off off
Freq= 100.5MHZ ON ON off off off off off ON off off off off
Freq= 100.7MHZ ON ON off off off off off off off off off off
Freq= 100.9MHZ ON off ON ON ON ON ON ON off off off off
Freq= 101.1MHZ ON off ON ON ON ON ON off off off off off
Freq= 101.3MHZ ON off ON ON ON ON off ON off off off off
Freq= 101.5MHZ ON off ON ON ON ON off off off off off off
Freq= 101.7MHZ ON off ON ON ON off ON ON off off off off
Freq= 101.9MHZ ON off ON ON ON off ON off off off off off
Freq= 102.1MHZ ON off ON ON ON off off ON off off off off
Freq= 102.3MHZ ON off ON ON ON off off off off off off off
Freq= 102.5MHZ ON off ON ON off ON ON ON off off off off
Freq= 102.7MHZ ON off ON ON off ON ON off off off off off
Freq= 102.9MHZ ON off ON ON off ON off ON off off off off
Freq= 103.1MHZ ON off ON ON off ON off off off off off off
Freq= 103.3MHZ ON off ON ON off off ON ON off off off off
Freq= 103.5MHZ ON off ON ON off off ON off off off off off
Freq= 103.7MHZ ON off ON ON off off off ON off off off off
Freq= 103.9MHZ ON off ON ON off off off off off off off off
Freq= 104.1MHZ ON off ON off ON ON ON ON off off off off
Freq= 104.3MHZ ON off ON off ON ON ON off off off off off
Freq= 104.5MHZ ON off ON off ON ON off ON off off off off
Freq= 104.7MHZ ON off ON off ON ON off off off off off off
Freq= 104.9MHZ ON off ON off ON off ON ON off off off off
Freq= 105.1MHZ ON off ON off ON off ON off off off off off
Freq= 105.3MHZ ON off ON off ON off off ON off off off off
Freq= 105.5MHZ ON off ON off ON off off off off off off off
Freq= 105.7MHZ ON off ON off off ON ON ON off off off off
Freq= 105.9MHZ ON off ON off off ON ON off off off off off
Freq= 106.1MHZ ON off ON off off ON off ON off off off off
Freq= 106.3MHZ ON off ON off off ON off off off off off off
Freq= 106.5MHZ ON off ON off off off ON ON off off off off
Freq= 106.7MHZ ON off ON off off off ON off off off off off
Freq= 106.9MHZ ON off ON off off off off ON off off off off
Freq= 107.1MHZ ON off ON off off off off off off off off off
Freq= 107.3MHZ ON off off ON ON ON ON ON off off off off
Freq= 107.5MHZ ON off off ON ON ON ON off off off off off
Freq= 107.7MHZ ON off off ON ON ON off ON off off off off
Freq= 107.9MHZ ON off off ON ON ON off off off off off off
Any other switch setting combination will result as Freq = 88.1

Navigation menu
