InBody >
User Manual
• Charge the InBodyBAND prior to initial use.
During the test, your hands MUST NOT come in contact with each other.
• For accurate measurements, please enter the correct personal information
when you sync your InBodyBAND with the InBody App.
Please read the following before initial use.
© 2016 InBody Co., Ltd. All rights reserved. BM-ENG-J0-B-161031
InBody Co., Ltd.
InBody Bldg., 54, Nonhyeon-ro 2-gil, Gangnam-gu, Seoul 06313 Korea
Website: www.inbody.com
Customer Support: homehealth@inbody.com
Charging and Powering Up
InBodyBAND Modes
InBody Test:
Measure your percent body fat
Heart Rate measurement:
Measure your HR
Step Count:
Daily step count
Active minutes:
Duration of walking/running
Calories: Burned calories
from walking/running
Active Distance:
Distance traveled
Installing the InBody App
1. Search “InBody” in the Google Play Store
or the Apple App Store.
2. Download the InBody App.
3. Load the App and follow the on-screen
instructions to sync your InBodyBAND
with your phone.
Transferring data
Step count and sleep tracking data will be
automatically updated when the InBodyBAND
is synced with the App.
※ In the event the App fails to automatically update,
you can initiate a manual sync from the Steps Menu.
Creating an Account
1. Enter your mobile phone number after
starting the InBody App.
2. Enter your gender, height, age, and
password.
3. Finish registration by pressing Done.
1234567890
Setting Up the Device
InBody Test
1. Press InBody Test at the bottom of the
main screen.
2. Enter your current weight and start the
InBody Test.
3. After the test, results will be automatically
uploaded to the App.
※ In order to keep track of your InBody Test results,
the InBody Test must be initiated through the
InBody App.
※
Proper posture for InBody TEST & Heart Rate measurment.
Instructions
1.
Please charge the InBodyBAND
using the charging dock.
2.
Once the InBodyBAND is securely
connected to the charging dock,
it will automatically turn on while charging.
※
Full charging requires approximately 1 hour
※
The device CANNOT operate while charging.
.
1.
→Select the ‘InBodyBAND2’
to bring up the setup screen.
Go to ‘Device’ in the setup menu
2. Press Confi rm after entering weight.
3.
InBodyBAND will vibrate to indicate
successful connection between the
InBody App and the device.
Symbol Definitions
Warning, Caution, Note
Direct current
European Conformity
Manufacturer
The Waste Electrical and Electrical Equipment Regulations
indicates separate collection for electrical and electronic equipment
* Specifications may change without prior notice.
Specifications
Country of Origin
Band Material
Measurement Current
Battery Life
Recharging Time
Dimensions
Weight
Wrists
Color
Input Power
Operation Conditions
Korea, Republic of
TPSIV
90 μA and below
A fully charged InBodyBAND has a maximum battery life up to two weeks.
(Battery life and charge cycles may vary depending on frequency of use,
configuration, and other factors)
Approx. 1 hour
18.0 mm(W) × 42.0 mm(L) × 10.5 mm(H)
20g
M: 15 ~ 19 cm
Black, Grey, Wine
Operating Voltage: 3.7 VDC, Charge Voltage: 5.0 VDC
10 ~ 40ºC(50 ~ 104ºF), 30 ~ 75%, 70 ~ 106kPa
Frequency Used
No. of Channels
Modulation Type
Wattage
Transport and
Storage Conditions -10 ~ 70ºC(14 ~ 158ºF), 10 ~ 80%, 50 ~ 106kPa
2402 MHz ~ 2480 MHz
40
GFSK
1 mW and below
FCC Information
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment may generate or use radio frequency energy. Change or modification to this
equipment may cause harmful interference unless the modifications are expressly approved in the
instruction manual. The user could lose the authority to operate this equipment if an unauthorized
change or modification is made.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
End product labeling
The label for end product must include “Contains FCC ID: F60INBODYBAND.”
Warning
•
Individuals with artificial electrical implants such as a defibrillator or pacemaker
should not take the InBody Test. Electrical currents of the InBodyBAND
may disrupt the functionality of life-sustaining implants.
•
Electrical currents used by the InBodyBAND is not harmful to the body,
but pregnant women are advised to consult with an expert before use.
Caution
•
May not be used for treatment or medical diagnosis.
•
Results may vary depending on physical and environmental conditions.
•
Tests should be taken indoors in the event of cold weather
(Body Composition & Heart Rate).
Testing Precautions
Caution
•
The InBodyBAND is water-resistant in simple daily activity such as washing hands or taking a shower.
•
This product has been tested in a controlled environment and is water- and dust-resistant for typical
day-to-day situations (satisfies the requirement for IP67 Level of International standard IEC 60529-Degrees
of Protection provided by Enclosure[IP Code]). However, the InBodyBAND may not resist water in all
situations and may become damaged in certain circumstances.
•
Do not disassemble or modify the equipment, including the internal parts, without written consent from the
manufacturer. This may cause electric shock or injury, product malfunction, inaccurate results, and will void
the manufacturer’s warranty.
•
Do not open the enclosure, disassemble, break, deform, bend, smash, press, or make a hole in the product.
The battery may explode.
•
Do not use your InBodyBAND if damaged It could be a cause of fire, burn, injury and electric shock.
•
Some damage, such as when water label become discolored due to use and/or negligence are not
subject to warranty.
•
Do not expose the InBodyBAND to excessive liquid, moisture, humidity or rain.
•
Do not swim with the InBodyBAND or use it in water.
•
Do not use your InBodyBAND after placing it in water for a long period of time.
•
Do not leave your InBodyBAND where large amounts of water can be splashed on the product.
•
Do not place the InBodyBAND in salt water/chemicals.
•
Do not use the InBodyBAND underwater or place it in high-pressure water environments.
•
Excessively bending the InBodyBAND may cause damage to the product.
•
Do not drop/grve impact to the InBodyBAND. Such actions may result in damage.
•
Keep out of reach of children. The InBodyBAND can be a choking hazard.
•
Those allergic to metal, rubber and silicon materials must not use the InBodyBAND.
•
Battery must not be deformed, changed, added with other substances, or exposed to water or other liquids.
•
Do not expose your InBodyBAND and charger under UV light for long periods of time.
•
Do not use your InBodyBAND in excessively humid environments.
•
Use the InBodyBAND in room temperature to maximize its battery capacity. Usage of the product in low
temperature may cause a decrease in battery capacity.
•
Users with sensitive skin and/or who wear the InBodyBAND tightly may experience skin reactions.
•
Users who are exposed to external irritants such as sweat, soap, allergens, etc. may experience skin
reactions while wearing the InBodyBAND.
•
Please ensure that the InBodyBAND remains dry and clean. This product, although in compliance with
international safety standards, can cause such as allergic reactions in some people.
•
Do not place the InBodyBAND near a bathtub, sink, sauna, pool, or steam room. Exposure of the
InBodyBAND to excessive moisture could result in deformation/failure/explosion.
•
Please use InBodyBAND properly as instructed in this manual.
•
Do not cover the InBodyBAND with any fabrics while charging. Doing so may cause a fire.
•
Do not check call notifications or other data on the product’s display while driving or in other situations
where distractions could be hazardous.
•
Clean and dry your InBodyBAND regularly, especially areas in contact with the skin. Use a clean, damp
cloth. Do not wash the product with water.
•
The InBodyBAND’s strap may be contaminated or discolored by cosmetics, direct sunlight, water, oil or etc.
•
Do not apply excessive force to InBodyBAND while it is connected to the USB cradle cable.
•
Please be careful not to break the USB cradle cable. Discontinue usage if the USB cradle cable is
damaged.
•
The InBodyBAND is classified as Class B electromagnetic radio equipment and can be used anywhere.
•
Do not use the InBodyBAND if you have life-sustaining medical implants as the radio waves emitted by
the InBodyBAND may interfere with the implants.
•
Keep the hand electrodes and the arm electrodes away from electricity conducting materials. Electrical
stimuli such as strong static electricity may cause malfunction or damage of the product.
•
Bluetooth devices may cause electromagnetic interferences with multiple electronic goods due to use
of the same frequency range.
•
Electromagnetic interferences may occur while the product is operating. Do not use the InBodyBAND
for any services related to human life. In case of a medical emergency or other urgent situation, please
use a smartphone to check any incoming communication.
•
The user is responsible for data transfer problems caused by using the Bluetooth function and illegal
use of Bluetooth function.
•
If the device is broken, get in touch with the store where you purchased from or get in touch with InBody.
The user is responsible for problems caused by any unlicensed repairs.
Note
•
Use a lint-free cloth to gently wipe the external surface of the equipment once every week.
•
Specifications and user manual may change without prior notice.
General Precautions
Please read these safety warnings carefully to ensure your personal safety and to
prevent property damage.
Testing Instructions
1. Maintain the proper posture during the test
as shown in the image on the right.
2. Your hands MUST NOT come in contact with
each other.
3. For accurate measurements, place the
product on the same spot on your wrist for
every test and test it at the same point of
time in your daily routine.
Avoid contact
