Inkbird Tech IBT-2X Bluetooth Cooking Thermometer User Manual BBQ GO
Shenzhen Inkbird Tech. Co. Limited Bluetooth Cooking Thermometer BBQ GO
user manual
IBT-2X
BBQ GO
Inkbird Tech. C.L.
Shenzhen, GD, 518000, China
www.ink-bird.com
cs@ink-bird.com
Bluetooth Cooking Thermometer
Get to know the device
Power ON/OFF
Pairing Button
Stop Alarm Button
Temperature Unit ( °C / °F )
1
Probe Indicator
Bluetooth Indicator
Probe Sockets
Battery Cover
1 2
AAA Battery x 2
Probe with cable
This device provides 2 sockets for probes, which enable you to monitor
2 items at same time. If you need another probe besides the one in the
standard package, please contact the dealer.
2
Current Temperature Value
(Not Included)
Put in the battery
Two AAA size batteries are needed for this device. Make sure they
are put in the right direction by following the icons on the unit.
Open the battery cover.
Put in batteries, noticing the icons
that show directions.
Lock the battery cover.
Download the APP
Search the keyword ‘bbq go’ in Appstore or Google Play, or scan
the following QR code with your phone.
Download and install it for free.
BBQ GO APP
Make sure your phone meet the requirements:
iPhone 4S, and later models;
iPod touch 5th, ipad 3rd generations and later models,
all ipad mini;
Android devices running version 4.4 or later, with blue-tooth
4.0 module.
Install the probes
The device will keep scanning the sockets when its power is
switched on, the Probe Indicators will blink one by one from 1 to 2
where probes are plugged in.
Then insert the probes into the food, make sure the front tip of the
probe is in the center of the food to get accurate temperature.
Pair with your phone
Keep the bluetooth switch of your phone on.
Launch the app, and follow the instructions
in the app to pair and activate the device.
Press and hold the power button on the
device for 3 seconds to power it on.
4Connected successfully.
Once paired the device with your phone, you don’t need to do it
again, unless you change to other phones.
Bluetooth Indicator
No Icon
Icon Blinking
Icon Fixed
1
2
Probe 1
Probe 2
Enjoy your barbecue time
Power ON/OFF
Options Temperature
History
Preference
Display
Probe
Number
Current
Temperature
Target
Temperature
Connection
Status
Timer
Preference
Setup
Choose the food type and preference for the food where each probe
is inserted, the app and the device will display its current and target
temperature.
The user interface of the app may be changed when upgraded.
Please follow the instructions in the app.
Power ON:
Press and hold the power button for 3 seconds.
Power OFF:
Press and hold the power button for 3 seconds.
Auto-off after 8 hours out of connection with phone.
When the food is ready, the app and the device will alarm.
Device Setting
Warning
The heat resistance varies in different components of the probe, DO
NOT put the probes directly in the fire frame. And probes are NOT
dishwasher safe. Please DO NOT put the teflon cable and the
connecting part (between the sensor and teflon cable) into the water.
Sensor
Teflon cable
With stainless steel mesh
(Length: about 115cm / 3.8ft)
300°C / 572°F
For instantaneous test
250°C / 482°F
For long-time monitoring
250°C / 482°F
For long-time monitoring
Annex I Accuracy Table of IBT-2X
Temperature Range
Accuracy
Centigrade Fahrenheit
0~6°C / 32~43°F
7~15°C / 44~59°F
16~30°C / 60~86°F
31~170°C / 87~338°F
171~190°C / 339~374°F
191~220°C / 375~428°F
221~250°C / 429~482°F
4°C 6°F
3°C 4°F
2°C 3°F
1°C 2°F
2°C 3°F
3°C 4°F
4°C 6°F
Non water-proof
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
