Inseego NVWSA1100 Wireless Communicator User Manual SA 2100 User Guide

Novatel Wireless Inc Wireless Communicator SA 2100 User Guide

Contents

Uaer Manual

SA1100UG001
SA 1100
User Guide
Version: 1.03 17 September, 2014
i novatelwireless.com
General
TERMS OF USE OF NEW MATERIALS - PLEASE READ CAREFULLY
From time to time, Novatel Wireless, in its sole discretion, may make available for download on its website
(www.novatelwireless.com), or may transmit via mail or email, updates or upgrades to, or new releases of, the
firmware, software or documentation for its products (collectively, 'New Materials'). Use of such New Materials is
subject to the terms and conditions set forth below, and may be subject to additional terms and conditions as set
forth in Novatel Wireless's Technical Support Policy (posted on its website) and/or any written agreement
between the user and Novatel Wireless.
All New Materials are provided AS IS. Novatel Wireless makes no warranty or representation with respect to the
merchantability, suitability, functionality, accuracy or completeness of any such New Materials. The user of such
New Materials assumes all risk (known or unknown) of such use. Novatel Wireless reserves all rights in such New
Materials. The user shall have only a revocable and limited license to use such New Materials in connection with
the products for which they are intended. Distribution or modification of any New Materials without Novatel
Wireless's consent is strictly prohibited.
IN NO EVENT WILL NOVATELWIRELESS BE RESPONSIBLE FOR ANY INCIDENTAL, INDIRECT, CONSEQUENTIAL OR
SPECIAL DAMAGES AS A RESULT OF THE USE OF ANY NEW MATERIALS. NOVATELWIRELESS'S MAXIMUM
LIABILITY FOR ANY CLAIM BASED ON THE NEW MATERIALS SHALL NOT EXCEED FIFTY U.S. DOLLARS ($50).
Version Verification
Please ensure you have the latest version of this document by downloading it from www.novatelwireless.com
ii novatelwireless.com
Copyright
© 2014 Novatel Wireless. All rights reserved. Complying with all applicable copyright laws is the responsibility of
the user. Without limiting the rights under copyright, no part of this document may be reproduced, stored in or
introduced into a retrieval system, or transmitted in any form or by any means (electronic, mechanical,
photocopying, recording or otherwise), or for any purpose, without the express written permission of Novatel
Wireless.
Novatel Wireless and the Novatel Wireless logo are either registered trademarks or trademarks of Novatel
Wireless, Inc. in the United States.
251 Renner Pkwy, Suite 200
Richardson, TX 75080 USA
Phone: (972) 633-4400
Fax: (972) 633-4444
Email: info@nvtl.com
www.novatelwireless.com
iii novatelwireless.com
Warranty Information
This warranty applies to (a) products sold directly by Novatel Wireless, unless a different warranty is specified in a
written agreement between Novatel Wireless and the purchaser; and (b) products sold to end users through a
distributor authorized by Novatel Wireless, but only where the authorized distributor does not provide a separate
warranty on such products, and Novatel Wireless has agreed to provide this warranty to such end users. If you
purchased the product from an authorized distributor, please check whether this warranty from Novatel Wireless,
or a separate warranty from the distributor, applies to your purchase. This warranty does not apply to any (i)
accessories or batteries for the products; or (ii) demonstration samples or prototypes of the products. Unless
otherwise provided in a written agreement between Novatel Wireless and the purchaser, all such accessories,
batteries, samples or prototypes are provided by Novatel Wireless AS IS without any warranty of any kind.
Novatel Wireless warrants to the original purchaser of the product from Novatel Wireless or its authorized
distributor (as applicable) that, for a period of one (1) year from the date of shipment of the product from Novatel
Wireless, the product hardware will be substantially free from defects in material or workmanship under normal
operation, and the product firmware will perform substantially in accordance with the product documentation
provided by Novatel Wireless. Novatel Wireless does not warrant that (a) the product hardware or firmware will
meet the purchaser's requirements; (b) the operation of the product hardware or firmware will be uninterrupted
or error-free; or (c) the product, when integrated in, or combined with, other products or software not supplied
by Novatel Wireless, will continue to perform substantially in accordance with the product documentation. This
limited warranty is for the benefit of the original purchaser, and is not transferable.
During the warranty period, Novatel Wireless, at its expense and in its sole discretion, will repair the product, or
replace the product with a corresponding or equivalent product, if it is determined to have a covered defect,
provided that the purchaser first notifies Novatel Wireless (directly or through its authorized distributor from
which the product was purchased) of any such defect, furnishes Novatel Wireless with a proof of purchase (if
required), requests and obtains a return merchandize authorization (RMA) number from Novatel Wireless, and
returns the product under that RMA to Novatel Wireless (or, at Novatel Wireless's option, to its authorized
distributor), with the shipping charges being prepaid by purchaser. If, upon reasonable examination of the
returned product, Novatel Wireless does not substantiate the defect claimed by purchaser, or determines that the
defect is not covered under this limited warranty, Novatel Wireless will not be required to repair or replace the
product, but may instead reship the product to the purchaser (or, at Novatel Wireless's option, to its authorized
distributor where the product can be made available to purchaser), in which case the purchaser shall be
responsible for paying Novatel Wireless's cost for reshipping the product to purchaser (or to Novatel Wireless's
authorized distributor), and Novatel Wireless's usual charges for unpacking, testing, and repacking the product
for reshipment to purchaser (or to Novatel Wireless's authorized distributor). Purchaser shall bear the risk of loss
or damage in transit to any product returned by purchaser to Novatel Wireless, or any returned product not
found to be defective or covered under this warranty, and reshipped by Novatel Wireless to purchaser (or to
Novatel Wireless's authorized distributor). In the event Novatel Wireless repairs or replaces a defective product
covered by this limited warranty, the repaired or replacement product will be covered under this limited warranty
iv novatelwireless.com
for the remainder of the original warranty period on the defective product, or a period of ninety (90) days,
whichever is longer. If Novatel Wireless is unable to repair or replace a defective product covered by this limited
warranty, Novatel Wireless will provide to purchaser a credit or a refund (at Novatel Wireless's option) of the
original purchase price (excluding taxes and shipping charges). Any returned and replaced product, or any
product for which Novatel Wireless has furnished a credit or a refund, becomes the property of Novatel Wireless.
Novatel Wireless shall not have any obligation to provide any firmware bug fixes, upgrades or new releases except
as may be necessary to correct any covered defect of which purchaser notifies Novatel Wireless in writing during
the warranty period. Novatel Wireless, from time to time and in its sole discretion, may make available for
download on its website (www.nvtl.com), or may provide via email, certain firmware bug fixes, upgrades or new
releases for the product. Download and use of any such bug fixes, upgrades or new releases is subject to all of the
applicable terms and conditions of Novatel Wireless's technical support policy as posted and updated on its
website. Novatel Wireless shall have no obligation under this limited warranty for (a) normal wear and tear; (b) the
cost of procurement of substitute products; or (c) any defect that is (i) discovered by purchaser during the
warranty period but for which purchaser does not request an RMA number from Novatel Wireless, as required
above, until after the end of the warranty period, (ii) caused by any accident, misuse, abuse, improper installation,
handling or testing, or unauthorized repair or modification of the product, (iii) caused by use of any materials not
supplied by Novatel Wireless, or by use of the product other than in accordance with its documentation, or (iv)
the result of electrostatic discharge, electrical surge, fire, flood or similar causes. The purchaser (or its customers,
as applicable) shall be solely responsible for the proper configuration, testing and verification of the Novatel
Wireless product prior to deployment in the field, and for ensuring that any end user product or system into
which the Novatel Wireless product is integrated or incorporated operates as intended and meets the
requirements of purchaser (or its customers). Novatel Wireless shall have no responsibility whatsoever for the
integration, configuration, testing, verification, installation, upgrade, support or maintenance of any such end
user product or system, or for any liabilities, damages, costs or expenses associated therewith.
NOVATELWIRELESS'S SOLE RESPONSIBILITY AND PURCHASER'S SOLE REMEDY UNDER THIS LIMITED WARRANTY
SHALL BE FOR NOVATELWIRELESS TO REPAIR OR REPLACE THE PRODUCT (OR IF REPAIR OR REPLACEMENT IS
NOT POSSIBLE, PROVIDE A CREDIT OR REFUND OF THE PURCHASE PRICE) AS PROVIDED ABOVE.
NOVATELWIRELESS EXPRESSLY DISCLAIMS ALL OTHER WARRANTIES OF ANY KIND, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY,
SATISFACTORY PERFORMANCE AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL
NOVATELWIRELESS BE LIABLE FOR ANY INDIRECT, SPECIAL, EXEMPLARY, INCIDENTAL OR CONSEQUENTIAL
DAMAGES (INCLUDING WITHOUT LIMITATION LOSS OR INTERRUPTION OF USE, DATA, REVENUES OR PROFITS)
RESULTING FROM A BREACH OF THIS WARRANTY OR BASED ON ANY OTHER LEGAL THEORY, EVEN IF
NOVATELWIRELESS HAS BEEN ADVISED OF THE POSSIBILITY OR LIKELIHOOD OF SUCH DAMAGES.
Some jurisdictions may require a longer warranty period than specified above and, accordingly, for products sold
in those jurisdictions the applicable warranty period shall be extended as required under the laws of those
jurisdictions. Furthermore, some jurisdictions may not allow the disclaimer of implied warranties or the exclusion
or limitation of incidental or consequential damages, so the above disclaimer, limitation or exclusion may not
v novatelwireless.com
apply to products sold in those jurisdictions. This limited warranty gives the purchaser specific legal rights and the
purchaser may have other legal rights that vary from jurisdiction to jurisdiction. This limited warranty shall be
governed by the laws of the State of Texas, United States of America, without regard to conflict of laws principles.
This limited warranty shall not be governed in any respect by the United Nations Convention on Contracts for the
International Sale of Goods.
vi novatelwireless.com
Regulatory Compliance
Regulatory Compliance
This section summarizes the responsibilities and actions required of manufacturers and integrators who
incorporate OEM versions of the Novatel Wireless HS 3002 module into their products. In certain situations and
applications, these products will require additional FCC, CE, GCF, PTCRB or other regulatory approvals prior to
sale or operation. Appropriate instructions, documentation and labels are required for all products. For more
information concerning regulatory requirements, please contact Novatel Wireless.
PTCRB APPROVAL (FORMERLY FTA)
The Novatel Wireless HS 3002 module is type approved in accordance with the requirements of and through the
procedures set forth by the GSM industry association. The relevant conformance specification is 3GPP TS 51010-
1. Any OEM changes in the SIM interface, antenna port, software or the physical makeup of the unit may require
an incremental FTA to ensure continued compliance with the above-mentioned standard. For more information
concerning type approval, please contact Novatel Wireless.
FCC CERTIFICATION
Novatel Wireless certifies that the HS 3002 Radio Module (FCC ID: PKRNVWSA1100) complies with the RF
requirements applicable to broadband PCS equipment operating under the authority of 47 CFR Part 24, Subpart E
and Part 22 Subpart H of the FCC Rules and Regulations. This certification is contingent upon installation,
operation and use of the HS 3002 module and its host product in accordance with all instructions provided to
both the OEM and end user. When installed and operated in a manner consistent with the instructions provided,
the HS 3002 module meets the maximum permissible exposure (MPE) limits for general population / uncontrolled
exposure at defined in Section 1.1310 of the FCC Rules and Regulations.
The HS 3002 modem is designed for use in a variety of host units, "enabling" the host platform to perform wireless
data communications. However, there are certain criteria relative to integrating the modem into a host platform
such as a PC, laptop, hand held, monitor and control unit, etc. that must be considered to ensure continued
compliance with FCC compliance requirements.
vii novatelwireless.com
Important Information for Canada/USA OEM Integrators
This section provides guidance for using the SA 1100 in host devices through the FCC Permissive Change
process. When utilizing the permissive change process, Novatel Wireless, the grantee, is responsible for all
integrations and must be consulted on all regulatory matters involving the SA 1100.
The SA 1100 is granted with FCC/IC as a certified transmitter for mobile1and fixed use applications, and may be
installed as a standalone2transmitter in final products meeting the following conditions. If the following
conditions are followed, it may be used in final products without additional FCC/IC certification. Otherwise,
additional FCC/IC approvals must be obtained.
lThe SA 1100 transmitter antennas must be installed to provide at least 20cm separation from the human
body at all times.
lThe SA 1100 transmitter antennas must not be co-located with any other transmitter or antenna within a
host device, except in accordance with FCC/IC multi-transmitter RF Exposure procedures.
lThe transmitter antennas used with the SA 1100 must not exceed the following levels:
lGSM850/WCDMA Band 5: the maximum gain is 6.9dBi..
lGSM1900/WCDMA Band 2: the maximum gain is 2.0dBi.
lOnly antennas of the same type and with equal or less gains as shown below may be used with this WLAN
device. Other types of antennas and/or higher gain antennas may require additional testing and/or
authorization for operation.
lWLAN 2.4GHz: the maximum gain is 3.62dBi.
lPIFA Antenna Type for 802.11b/g/n.
lTo comply with the aspects of KDB 996369, strict adherence to the design parameters in the Section
Antenna and RF Signal Trace must be observed. This Section provides PCB RF trace design guidelines for
the coplanar micro strip between the transmitters RF compression pads and the SMA coaxial connector.
lA label containing the SA 1100 FCC ID and Industry Canada certification number must be permanently
affixed to the exterior of the host device into which the SA 1100 transmitter is installed. The label may also
be in a user accessible location such as under a panel or battery pack if it is a handheld device, readily
accessible, not placed on a removable part and the FCC ID and Industry Canada certification number are
visible at the time of purchase. The label must contain a statement similar to the following:
lThis device contains FCC ID: PKRNVWSA1100
lThis device contains IC: 3229A-SA1100
If the SA 1100 certified transmitter is intended for use in a portable use device, the OEM integrator is responsible
to design the product to comply with RF exposure requirements, and must work with Novatel Wireless (the
grantee) to satisfy FCC/IC SAR requirements. Refer to Industry Canada RSS-102 and FCC KDB publication 447498
D01 and the applicable SAR/RF Exposure KDB publications available at:
https://apps.fcc.gov/oetcf/kdb/reports/GuidedPublicationList.cfm. 3
The system user manuals and other documentation must clearly indicate operating conditions that must be
observed to ensure compliance with FCC/IC RF exposure guidelines and also include appropriate caution and
warning statements and information.
1Mobile Device Definition – FCC defines as a transmitting antenna located at a distance ≥ 20cm from the user
2Standalone is defined as a single transmitter transmitting as opposed to 2 or more transmitters transmitting
simultaneously.
3Portable Device Definition – FCC defines as a transmitting antenna located at a distance ≤ 20cm from the user.
viii novatelwireless.com
The host device containing the SA 1100 certified transmitter may also require compliance to FCC Part 15 Subpart
B – Unintentional Radiator rule part as well as Industry Canada ICES-003.
Cette section fournit des conseils pour l'utilisation de la SA 1100 dans des dispositifs d'accueil à travers le
changement à autorisation FCC processus . Lors de l'utilisation du processus de changement permissive , Novatel
Wireless , le néficiaire est responsable de tous les intégrations et doivent être consultés sur toutes les questions
réglementaires touchant la SA 1100 .
Le SA 1100 est accordée aux normes FCC / IC comme un émetteur certifié pour mobile1et utilisez les applications
fixes , et peut être installé comme un émetteur de standalone2dans les produits finaux répondant aux conditions
suivantes . Si les conditions suivantes sont respectées, il peut être utili dans les produits finaux sans certification
FCC / IC supplémentaire . Sinon , les approbations FCC / IC supplémentaires doivent être obtenues .
lLes SA 1100 antennes d'émission doivent être installés pour fournir au moins 20 cm la séparation du corps
humain à tout moment.
lLes SA 1100 antennes émettrices ne doivent pas être co- localisés avec un autre émetteur ou antenne dans
un dispositif d'accueil , sauf en conformité avec la FCC / IC procédures d'exposition RF multi- émetteurs .
lLes antennes d'émission utilisés avec la SA 1100 ne doivent pas dépasser les niveaux suivants :
lGSM850 / WCDMA Bande 5 : le gain maximum est 6.9dBi.
lGSM1900 / WCDMA Band 2 : le gain maximum est 2.0dBi.
lSeuls les antennes du même type et avec des gains égaux ou moins , comme indiq ci-dessous peuvent
être utilis avec cet appareil WLAN . Autres types d'antennes et / ou des antennes à gain plus élevés
peuvent nécessiter des tests et / ou autorisation supplémentaire pour operation.
lWLAN 2,4 GHz : le gain maximum est 3.62dBi .
lType d'antenne PIFA pour 802.11b / g / n .
lPour se conformer aux aspects de la KDB 996 369 , le strict respect des paramètres de conception de la
section de l'antenne et du signal RF Trace doit être respectée. Cette section fournit des lignes directrices de
conception de traces de PCB RF pour la bande coplanaire micro entre les plaquettes de compression
émetteurs RF et le connecteur coaxial SMA .
lUne étiquette contenant la FCC ID et Industrie Canada nombre SA 1100 certification doit être apposée de
façon permanente à l'extérieur de l'appareil hôte dans laquelle le SA 1100 émetteur est installé . L'étiquette
peut également être dans un endroit accessible à l'utilisateur comme sous un paquet de panneau ou de la
batterie si elle est un appareil portable , facilement accessible , pas placé sur une partie amovible et le
numéro de certification de la FCC ID et Industrie Canada sont visibles au moment de l'achat . L'étiquette
doit contenir une déclaration semblable à la suivante :
lCet appareil contient FCC ID : PKRNVWSA1100
lCet appareil contient des IC : 3229A - SA1100
1Définition de dispositif mobile – la FCC finit comme une antenne d'émission située à une distance ≥ 20cm de
l'utilisateur.
2Autonome est défini comme un seul émetteur transmettant au lieu de deux ou plusieurs émetteurs émettant
simultanément.
ix novatelwireless.com
Si lmetteur certifiée SA 1100 est destiné à être utilisé dans un dispositif à usage portable , l'intégrateur OEM est
responsable de la conception du produit à se conformer aux exigences d'exposition RF et doit travailler avec
Novatel Wireless ( le ficiaire ) pour satisfaire aux exigences de la FCC / IC SAR . Reportez-vous à Industrie
Canada RSS -102 et FCC KDB publication 447498 D01 et la SAR applicable / publications KDB d'exposition RF
disponibles à : https://apps.fcc.gov/oetcf/kdb/reports/GuidedPublicationList.cfm . 1
Les manuels d'utilisation du système et d'autres documents doivent indiquer clairement les conditions de
fonctionnement qui doivent être respectées pour assurer la conformité avec les lignes directrices d'exposition de
la FCC / IC RF et comprennent également des déclarations et informations avertissements et consignes
appropriées .
Le dispositif hôte contenant l'émetteur certifiée SA 1100 peut également exiger le respect de la FCC Partie 15
Sous-partie B - Source de rayonnement involontaire partie de la règle ainsi que Industrie Canada ICES-003.
Industry Canada
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil est conforme aux normes d’Industrie Canada exempts de license(s) RSS. Son fonctionnement est
soumis aux deux conditions suivantes : (1) cet appareil ne doit pas provoquer d’interférences, et (2) cet appareil
doit accepter toute interférence, y compris les interférences pouvant provoquer un fonctionnement indésirable
de l’appareil.
Cet appareil numérique de classe B est conforme à la norme canadienne ICES-003.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference
to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une
antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but
de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type
d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité
cessaire à l'établissement d'une communication satisfaisante.
1Définition de dispositifportable – la FCC finit comme une antenne d'émission située à une distance ≤ 20cm de
l'utilisateur.
x novatelwireless.com
FCC NOTICE TO USERS
Novatel Wireless has not approved any changes or modifications to this device by the user. Any changes or
modifications could void the users authority to operate the device. See 47 CFR Sec. 15.21. The device complies
with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation. See 47 CFR Sec. 15.19.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on the user is encouraged to try to correct the interference by one or more of the following measures:
lReorient or relocate the receiving antenna.
lIncrease the separation between the equipment and receiver.
lConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
lConsult the dealer or an experienced radio/TV technician for help.
If the FCCID of the module is not visible when installed in the host platform, then a permanently attached or
marked label must be displayed on the host unit referring to the module.
The label should contain wording such as:
Contains FCC ID: Mxxxxxxxx
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
REGULATORY REQUIREMENTS FOR OTHER COUNTRIES
In most other countries there are similar rules and regulations that may need to be met for importing the HS 3002
module and for placing it on the market in the integrated device. Each country may require a different mark of
approval as an acceptance requirement. For each of these cases the country should identified, and the
appropriate steps should be taken to meet the requirements set forth in the intended market.
ROHS COMPLIANCE
As a part of Novatel Wireless's corporate policy of environmental protection, Novatel Wireless takes every step to
ensure that the HS 3002 modules are designed and manufactured to comply to the European Union Directive
2002/95/EC for the Restriction of Hazardous Substances (RoHS).
xi novatelwireless.com
Table of Contents
1 Getting Started 1
Device Overview 2
Versions 2
Label 2
Technical Specifications 2
Interfaces 2
Outputs 3
Mechanical: Storage And Transportation 3
Mechanical: Operational 3
Application Interface 3
Power 3
Radio Features 3
Audio Features 3
Environmental 4
Packet Data Transfer 4
Regulatory 4
Reference Documents 4
Operating Power 5
SA 1100 Communications Board Input Power 5
HS 3002 Chipset Typical Input Current 5
2 Using The Device 6
SIM Card 7
Powering The Device 7
Simon XT Connector 8
USB 8
Radio Connectivity 9
1 novatelwireless.com
1
Getting Started
Device Overview
Technical Specifications
Operating Power
2 novatelwireless.com
Device Overview
The SA 1100 Communications Board incorporates the Novatel Wireless HS 3002 cellular module for data
connectivity and messaging. The SA 1100 Communications Board supports only incoming voice calls and SMS
messages. The device does not include a dial pad interface to make outbound calls.
The SA 1100 Communications Board includes a USB port to allow access to the module's AT command interface.
This is an integrated product designed to be used in conjunction with a third party end product. An 8-pin adapter
between the SA 1100 Communications Board and the third party end product provides for power and data
transfer.
This device is intended for professional installation and not for consumer use.
Versions
The SA 1100 Communications Board is available in the following configurations:
lSA 1100-20
lSA 1100-20-AT
Label
Figure 1-1 Device Label
Technical Specifications
Interfaces
Host Interface: Serial Interface
Data input/output interface: 100 position 0.4 mm pitch connector (Molex P/N 55909-1074)
Primary serial port: V.24 protocol, 1.8V levels, UART implementation, Hardware flow control
USB port: USB serial port and USB Debug (USB Debug is Novatel Wireless Use only)
Antenna Interface: B2B Spring contact
3 novatelwireless.com
Command protocol: Novatel Wireless Packet API, AT Command set
Reference clock: 32 kHz output reference clock (accessible via 100-pin connector)
ADC: 2 ADC inputs
Logic: lUART1
lPCM
lDigital Audio
lPWON
lPower Control
Outputs
Simon XT
Mechanical: Storage And Transportation
Transportation vibration, packaged: ASTM D999
Drop, packaged: ASTM D775 method A, 10 drops
Mechanical: Operational
Operational vibration Random IEC60068-2-64 / MIL-STD-202G Method 214A
50-2000 Hz, 7.56 GRMS, 3 Axis, 8 Hours per axis
Application Interface
USB: 3.4 to 4.4 Vdc (vbat)
VBUS: Supply Vripple must be less than 25 mV across all frequencies
Power
Electrical Power: 6.0 to 12.0 Vdc
Radio Features
Frequency bands: HSDPA/WCDMA: B1 (2100MHz) and B8 (900 MHz) GPRS/EDGE: 900 and 1800
Air Interfaces: UMTS/WCDMA
– R99
– HSDPA category 5/6 plus equalizer (3.6 Mbps peak rate)
GSM/GPRS/EDGE
– GSM Release 4
GPRS/EDGE Multislot Class 12, Release 4
– DTM Multislot Class 11
Audio Features
Phone Jack
4 novatelwireless.com
Environmental
Compliant Operating Temperature -20 °C to 60 °C
Operating Temperature -30 °C to 70 °C
Storage Temperature -40 °C to 85 °C
Humidity Up to 95% non condensing
Emissions FCC 47 CFR Parts 2,15,22 & 24
Packet Data Transfer
Protocol
Short Message
Services
Text, MO/MT
Regulatory
Agency approvals FCC Certification
Industry Canada
PTCRB
CE
GCF
Reference Documents
CNN0401xAT001 - HS 3002 AT Command Reference
CNN0401xTG001 - HS 3002 Transition Guide
ENF0000SD001 - HDK Guide
CNN0401AN001 - Using Digital Audio on the HS 3002
5 novatelwireless.com
Operating Power
SA 1100 Communications Board Input Power
The SA 1100 Communications Board receives 6-12 VDC power from an external power supply via a ferrite bead
dressed coaxial cable.
HS 3002 Chipset Typical Input Current
Typical Results @ 3.7 V, 25 deg C, with 1000 μF at connector input on VBAT and RF terminated into a 50 Ω resistive
load.
Band Mode Avg
(mA)
Peak
(mA) Notes
B2 HSPA WCDMA Radio Acccess Bearer channel of RMC12 Max
Power 23 dBm
540
B5 HSPA WCDMA Radio Acccess Bearer channel of RMC12 Max
Power 23 dBm
525
GSM850 GPRS 2000
GSM850 EGPRS 1200
GSM1900 GPRS 1300
GSM1900 EGPRS 900
*4:1 VSWR
6 novatelwireless.com
2
Using The Device
SIM Card
Powering the Device
Simon XT Connector
USB
Radio Connectivity
7 novatelwireless.com
SIM Card
To insert the SIM card into the SIM card slot located on the SA 1100 Communications Board, follow these steps:
1. Unlock the SIM card holder by sliding the holder in the "open" direction as marked on the SIM card holder.
2. Insert the SIM card into the holder. Make sure the gold contact points on the SIM card are facing down (toward
the board).
3. Lock the SIM card holder by sliding the holder in the "lock" direction as marked on the SIM card holder.
Powering The Device
The SA 1100 requires 6-12 VDC power.
The 8-pin adapter between the SA 1100 Communication Board and the third party end device provides both
power and data.
To power the SA 1100, connect the 8-pin connector to the Security Panel Main Board connector.
8 novatelwireless.com
The SA 1100 power pins are shown in the illustration below.
Simon XT Connector
The Simon XT connector provides for data connectivity between the SA 1100 Communications Board and the
third party end product.
USB
USB is provided solely for the communication with the module.
9 novatelwireless.com
Radio Connectivity
Radio connectivity is provided solely by an Novatel Wireless HS 3002 module which has all APIs integrated with
the module software.

Navigation menu
