Intel® PROSet/Wireless WiFi Connection Utility User's Guide

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/index.htm[9/24/2010 5:51:48 PM]

Intel® Wireless Adapter Information Guide

Supported wireless adapters:

Intel® Centrino® Ultimate-N 6300

Intel® Centrino® Advanced-N + WiMAX 6250

Intel® Centrino® Advanced-N 6230

Intel® Centrino® Advanced-N 6205

Intel® Centrino® Advanced-N 6200

Intel® Centrino® Wireless-N + WiMAX 6150

Intel® WiFi Link 5300

Intel® WiMAX/WiFi Link 5150

Intel® WiFi Link 5100

Intel® WiFi Link 1000

Intel® Wireless WiFi Link 4965AGN

Intel® Wireless WiFi Link 4965AG

Intel® PRO/Wireless 3945ABG Network Connection

Intel® PRO/Wireless 3945BG Network Connection

Intel® Centrino® Wireless-N 1030

Intel® Centrino® Wireless-N 130

Intel® Centrino® Wireless-N 100

With your WiFi network card, you can access WiFi networks, share files or printers, or even share your Internet

connection. All of these features can be explored using a WiFi network in your home or office. This WiFi network

solution is designed for both home and business use. Additional users and features can be added as your

networking needs grow and change.

This guide contains basic information about Intel adapters. It includes information about several adapter properties

that you can set to control and enhance the performance of your adapter with your particular wireless network

and environment. Intel® wireless adapters enable fast connectivity without wires for desktop and notebook PCs.

Adapter Settings

Regulatory Information

Specifications

Important Information

Support

Warranty

Glossary

Information in this document is subject to change without notice.

Hillsboro, OR 97124-6497 USA

The copying or reproducing of any material in this document in any manner whatsoever without the written

permission of Intel Corporation is strictly forbidden. Intel® is a trademark or registered trademark of Intel

Corporation or its subsidiaries in the United States and other countries. Other trademarks and trade names may

be used in this document to refer to either the entities claiming the marks and names or their products. Intel

disclaims any proprietary interest in trademarks and trade names other than its own. Microsoft and Windows are

registered trademarks of Microsoft Corporation. Windows Vista is either a registered trademark or trademark of

Microsoft Corporation in the United States and/or other countries.

*Other names and brands may be claimed as the property of others.

Intel Corporation assumes no responsibility for errors or omissions in this document. Nor does Intel make any

commitment to update the information contained herein.

"IMPORTANT NOTICE FOR ALL USERS OR DISTRIBUTORS:

Intel wireless LAN adapters are engineered, manufactured, tested, and quality checked to ensure that they meet

Intel® PROSet/Wireless WiFi Connection Utility User's Guide

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/index.htm[9/24/2010 5:51:48 PM]

all necessary local and governmental regulatory agency requirements for the regions that they are designated

and/or marked to ship into. Because wireless LANs are generally unlicensed devices that share spectrum with

radars, satellites, and other licensed and unlicensed devices, it is sometimes necessary to dynamically detect,

avoid, and limit usage to avoid interference with these devices. In many instances Intel is required to provide test

data to prove regional and local compliance to regional and governmental regulations before certification or

approval to use the product is granted. Intel's wireless LAN's EEPROM, firmware, and software driver are designed

to carefully control parameters that affect radio operation and to ensure electromagnetic compliance (EMC). These

parameters include, without limitation, RF power, spectrum usage, channel scanning, and human exposure.

For these reasons Intel cannot permit any manipulation by third parties of the software provided in binary format

with the wireless LAN adapters (e.g., the EEPROM and firmware). Furthermore, if you use any patches, utilities, or

code with the Intel wireless LAN adapters that have been manipulated by an unauthorized party (i.e., patches,

utilities, or code (including open source code modifications) which have not been validated by Intel), (i) you will be

solely responsible for ensuring the regulatory compliance of the products, (ii) Intel will bear no liability, under any

theory of liability for any issues associated with the modified products, including without limitation, claims under

the warranty and/or issues arising from regulatory non-compliance, and (iii) Intel will not provide or be required to

assist in providing support to any third parties for such modified products.

Note: Many regulatory agencies consider Wireless LAN adapters to be "modules", and accordingly, condition

system-level regulatory approval upon receipt and review of test data documenting that the antennas and system

configuration do not cause the EMC and radio operation to be non-compliant."

September 23, 2010

Adapter Settings

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/adaptusr.htm[9/24/2010 5:51:48 PM]

Back to Contents

Adapter Settings

The Advanced tab displays the device properties for the WiFi adapter installed on your computer. This version of

Intel® PROSet/Wireless WiFi Software is compatible with the following adapters:

Intel® Centrino® Ultimate-N 6300

Intel® Centrino® Advanced-N + WiMAX 6250

Intel® Centrino® Advanced-N 6230

Intel® Centrino® Advanced-N 6205

Intel® Centrino® Advanced-N 6200

Intel® Centrino® Wireless-N + WiMAX 6150

Intel® WiFi Link 5300

Intel® WiMAX/WiFi Link 5150

Intel® WiFi Link 5100

Intel® WiFi Link 1000

Intel® Wireless WiFi Link 4965AGN

Intel® Wireless WiFi Link 4965AG

Intel® PRO/Wireless 3945ABG Network Connection

Intel® PRO/Wireless 3945BG Network Connection

Intel® Centrino® Wireless-N 1030

Intel® Centrino® Wireless-N 130

Intel® Centrino® Wireless-N 100

How to Access

Windows* XP users: At the Intel® PROSet/Wireless WiFi Connection Utility, Advanced Menu click Adapter

Settings. Select the Advanced tab.

PROSet/Wireless Enterprise Software, at the Intel® PROSet/Wireless WiFi Connection Utility, Advanced Menu click

Adapter Settings. Select the Advanced tab.

Open the Device Manager and click on the WiFi network adapter. Then select the Advanced tab.

WiFi Adapter Settings Description

Name Description

802.11n

Channel Width

(2.4 GHz)

Set high throughput channel width to maximize performance. Set the channel width to Auto or

20MHz. Use 20MHz if 802.11n channels are restricted. This setting applies to 802.11n capable

adapters only.

NOTE: This setting does not apply to the following adapters:

Intel® Wireless WiFi Link 4965AGN (uses 20 MHz channel width only)

802.11n

Channel Width

(5.2 GHz)

Set high throughput channel width to maximize performance. Set the channel width to Auto or

20MHz. Use 20MHz if 802.11n channels are restricted. This setting applies to 802.11n capable

adapters only.

NOTE: This setting does not apply to the following adapters:

Intel® WiFi Link 1000

Intel® Wireless WiFi Link 4965AGN

802.11n Mode The 802.11n standard builds on previous 802.11 standards by adding multiple-input multiple-

Adapter Settings

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/adaptusr.htm[9/24/2010 5:51:48 PM]

output (MIMO). MIMO increases data throughput to improve transfer rate. Select Enabled or

Disabled to set the 802.11n mode of the WiFi adapter. Enabled is the default setting. This

setting applies to 802.11n capable adapters only.

NOTE: To achieve transfer rates greater than 54 Mbps on 802.11n connections, WPA2*-AES

security must be selected. No security (None) can be selected to enable network setup and

troubleshooting.

An administrator can enable or disable support for high throughput mode to reduce power-

consumption or conflicts with other bands or compatibility issues.

Ad Hoc

Channel Unless the other computers in the ad hoc network use a different channel from the default

channel, there is no need to change the channel.

Value: Select the permitted operating channel from the list.

802.11b/g: Select this option when 802.11b and 802.11g (2.4 GHz) ad hoc band

frequency is used.

802.11a: Select this option when 802.11a (5 GHz) ad hoc band frequency is used. This

setting does not apply to the Intel® WiFi Link 1000 adapter.

NOTE: When an 802.11a channel is not displayed, initiating ad hoc networks is not supported

for 802.11a channels.

Ad Hoc Power

Management Set power saving features for device to device (ad hoc) networks.

Disable: Select when connecting to ad hoc networks that contain stations that do not

support ad hoc power management

Maximum Power Savings: Select to optimize battery life.

Noisy Environment: Select to optimize performance or connecting with multiple clients.

Ad Hoc QoS

Mode Quality of Service (QoS) control in ad hoc networks. QoS provides prioritization of traffic from

the access point over a wireless LAN based on traffic classification. WMM (Wi-Fi Multimedia) is

the QoS certification of the Wi-Fi Alliance (WFA). When WMM is enabled, the WiFi adapter uses

WMM to support priority tagging and queuing capabilities for Wi-Fi networks.

WMM Enabled (Default)

WMM Disabled

Fat Channel

Intolerant This setting communicates to surrounding networks that this WiFi adapter is not tolerant of

40MHz channels in the 2.4GHz band. The default setting is for this to be turned off (disabled),

so that the adapter does not send this notification.

NOTE: This setting does not apply to the following adapters:

Intel® Wireless WiFi Link 4965AG_

Intel® PRO/Wireless 3945ABG Network Connection

Mixed mode

protection Use to avoid data collisions in a mixed 802.11b and 802.11g environment. Request to

Send/Clear to Send (RTS/CTS) should be used in an environment where clients may not hear

each other. CTS-to-self can be used to gain more throughput in an environment where clients

are in close proximity and can hear each other.

Power

Management Lets you select a balance between power consumption and WiFi adapter performance. The WiFi

adapter power settings slider sets a balance between the computer's power source and the

battery.

Use default value: (Default) Power settings are based on the computer's power source.

Manual: Adjust the slider for the desired setting. Use the lowest setting for maximum

battery life. Use the highest setting for maximum performance.

NOTE: Power consumption savings vary based on Network (Infrastructure) settings.

Roaming This setting lets you define how aggressively your wireless client roams to improve connection

Adapter Settings

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/adaptusr.htm[9/24/2010 5:51:48 PM]

Aggressiveness to an access point.

Default: Balanced setting between not roaming and performance.

Lowest: Your wireless client will not roam. Only significant link quality degradation

causes it to roam to another access point.

Highest: Your wireless client continuously tracks the link quality. If any degradation

occurs, it tries to find and roam to a better access point.

Throughput

Enhancement Changes the value of the Packet Burst Control.

Enable: Select to enable throughput enhancement.

Disable: (Default) Select to disable throughput enhancement.

Transmit

Power Default Setting: Highest power setting.

Lowest: Minimum Coverage: Set the adapter to the lowest transmit power. Enables you to

expand the number of coverage areas or confine a coverage area. Reduces the coverage area

in high traffic areas to improve overall transmission quality and avoids congestion and

interference with other devices.

Highest: Maximum Coverage: Set the adapter to a maximum transmit power level. Select

for maximum performance and range in environments with limited additional WiFi radio

devices.

NOTE: The optimal setting is for a user to always set the transmit power at the lowest

possible level that is still compatible with the quality of their communication. This allows the

maximum number of wireless devices to operate in dense areas and reduce interference with

other devices that it shares the same radio spectrum with.

NOTE: This setting takes effect when either Network (Infrastructure) or Device to Device (ad

hoc) mode is used.

Wireless Mode Select which mode to use for connection to a wireless network:

802.11a only: Connect the wireless WiFi adapter to 802.11a networks only. Not

applicable for all adapters.

802.11b only: Connect the wireless WiFi adapter to 802.11b networks only. Not

applicable for all adapters.

802.11g only: Connect the wireless WiFi adapter to 802.11g networks only.

802.11a and 802.11g: Connect the WiFi adapter to 802.11a and 802.11g networks

only. Not applicable for all adapters.

802.11b and 802.11g: Connect the WiFi adapter to 802.11b and 802.11g networks

only. Not applicable for all adapters.

802.11a, 802.11b, and 802.11g: (Default) - Connect to either 802.11a, 802.11b or

802.11g wireless networks. Not applicable for all adapters.

OK Saves settings and returns to the previous page.

Cancel Closes and cancels any changes.

Microsoft Windows* Advanced Options (Adapter Settings)

To access the Windows* XP Advanced options:

1. Start Windows and log on with administrative privileges.

2. From your desktop, right-click My Computer and click Properties.

3. Click the Hardware tab.

4. Click Device Manager.

5. Double-click Network adapters.

6. Right-click the name of the installed WiFi adapter that is in use.

7. Click Properties.

Adapter Settings

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/adaptusr.htm[9/24/2010 5:51:48 PM]

8. Select the Advanced tab.

9. Select the property you want (for example, Mixed Mode Protection, Power Management).

10. To select a new value or setting, click Use default value to clear the checkbox. Then select a new value or

setting. To return to the default value, click the Use default value checkbox. (The Use default value box

is not present for all properties, for example, Ad Hoc Channel. In this case, simply select the setting you

want.)

11. To save your settings and exit the window, click OK.

Back to Contents

Trademarks and Disclaimers

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

Back to Contents

Specifications

Intel® Centrino® Ultimate-N 6300

Intel® Centrino® Advanced-N + WiMAX 6250

Intel® Centrino® Advanced-N 6230

Intel® Centrino® Advanced-N 6205

Intel® Centrino® Advanced-N 6200

Intel® Centrino® Wireless-N + WiMAX 6150

Intel® WiFi Link 5300

Intel® WiMAX/WiFi Link 5150

Intel® WiFi Link 5100

Intel® WiFi Link 1000

Intel® Wireless WiFi Link 4965AGN

Intel® Wireless WiFi Link 4965AG

Intel® PRO/Wireless 3945ABG Network Connection

Intel® PRO/Wireless 3945BG Network Connection

Intel® Centrino® Wireless-N 1030

Intel® Centrino® Wireless-N 130

Intel® Centrino® Wireless-N 100

Intel® Centrino® Advanced-N 6200

Intel® Centrino® Advanced-N 6205

Intel® Centrino® Ultimate-N 6300

Form Factor Intel® Centrino® Advanced-N 6200, Intel® Centrino® Ultimate-N 6300:

PCI Express* Full-Mini Card and Half-Mini Card.

Intel® Centrino® Advanced-N 6205: PCI Express* Half-Mini Card.

Dimensions Full-Mini Card: Width 2.00 in x Length 1.18 in x Height 0.18 in (50.95 mm x 30 mm x 4.5 mm)

Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5

mm)

Antenna

Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna

Diversity On-board diversity

Connector

Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)

Frequency

Modulation 5 GHz (802.11a/n) 2.4 GHz (802.11b/g/n)

Frequency band 5.15 GHz - 5.85 GHz (dependent on country) 2.400 - 2.4835 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK

Wireless

Medium 5 GHz UNII: Orthogonal Frequency Division

Multiplexing (OFDM) 2.4 GHz ISM: Orthogonal Frequency Division

Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

IEEE 802.11n

Data Rates Intel® Centrino® Ultimate-N 6300:

Tx/Rx: 450, 405, 360, 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120,

117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 Mbps

Intel® Centrino® Advanced-N 6200, Intel® Centrino® Advanced-N 6205:

Tx/Rx: 300, 270, 243, 240, 180, 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65,

60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 Mbps

IEEE 802.11a

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b

Data Rates 11, 5.5, 2, 1 Mbps

General

Operating

Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, 802.11a, 802.11h, 802.11d, WPA-Personal, WPA-

Enterprise, WPA2-Personal, WPA2-Enterprise, WMM, WMM Power Save, EAP-SIM, LEAP, PEAP,

TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Cisco

Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

WLAN Standard IEEE 802.11g, 802.11b, 802.11a, 802.11n

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-

bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Product Safety UL, C-UL, CB (IEC 60590)

Intel® Centrino® Advanced-N + WiMAX 6250 and

Intel® Centrino® Wireless-N + WiMAX 6150

Form Factor PCI Express* Half-Mini Card

Dimensions Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5

mm)

Antenna

Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna

Diversity On-board diversity

Connector

Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)

WiFi

Frequency Intel® Centrino® Advanced-N + WiMAX 6250 Intel® Centrino® Wireless-N + WiMAX 6150

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

Modulation 2.4 GHz (802.11b/g/n), 5 GHz (802.11a/n) 2.4 GHz (802.11b/g/n)

Frequency band 5.15 GHz - 5.85 GHz (dependent on country) 2.400 - 2.4835 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK

Wireless

Medium 5 GHz UNII: Orthogonal Frequency Division

Multiplexing (OFDM) 2.4 GHz ISM: Orthogonal Frequency Division

Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

IEEE 802.11n

Data Rates Intel® Centrino® Wireless-N + WiMAX 6150

MIMO Configuration: 1X2

Rx: 300, 270, 243, 240, 180 Mbps

Rx/Tx: 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30,

28.9, 21.7, 15, 14.4, 7.2 Mbps

Intel® Centrino® Advanced-N + WiMAX 6250

MIMO Configuration: 2X2

Tx/Rx: 300, 270, 243, 240, 180, 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65,

60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 Mbps

IEEE 802.11a

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b

Data Rates 11, 5.5, 2, 1 Mbps

General

Operating

Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, 802.11a, 802.11h, 802.11d, WPA-Personal, WPA-

Enterprise, WPA2-Personal, WPA2-Enterprise, WMM, WMM Power Save, EAP-SIM, LEAP, PEAP,

TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Cisco

Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

IEEE Feature

Sets Intel® Centrino® Wireless-N + WiMAX 6150:

IEEE 802.11b, 802.11g, 802.11n, 802.11e, 802.11i, 802.11h, 802.11d

Intel® Centrino® Advanced-N + WiMAX 6250:

802.11a, IEEE 802.11b, 802.11g, 802.11n, 802.11e, 802.11i, 802.11h, 802.11d

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-

bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Product Safety UL, C-UL, CB (IEC 60590)

WiMAX

General

Operating

Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Standard 802.16e-2005 Corrigenda 2 (D4)

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

Compliance

WiMAX System

Profile Feature

set

Intel® Centrino® Wireless-N + WiMAX 6150:

Mobile WiMAX release 1, Wave II. Supports 3A and 1A/B profiles

Intel® Centrino® Advanced-N + WiMAX 6250:

Mobile WiMAX release 1, Wave II. Supports 3A, 5A/C, 1A/B, and 5BL profiles

Security Key Management Protocol (PKMv2)

Encryption 128-bit CCMP (Counter-Mode/CBC-MAC) based on AES encryption

WiMAX

Frequency band Intel® Centrino® Wireless-N + WiMAX 6150: 2.3-2.4 GHz / 2.496-2.690 GHz

Intel® Centrino® Advanced-N + WiMAX 6250: 2.3-2.4 GHz / 2.496-2.690 GHz / 3.4-3.8 GHz

Modulation UL - QPSK, 16 QAM

DL - QPSK, 16 QAM, 64 QAM

Wireless

Medium Duplex mode: TDD operations Scalable OFDMA (SOFDMA): 512 and 1024 FFT

sub-carrier permutation: PUSC Intel® Centrino® Wireless-N + WiMAX 6150:

Channel bandwidths: 5 and 10 MHz

Intel® Centrino® Advanced-N + WiMAX 6250:

Channel bandwidths: 5, 7, 8.75 and 10 MHz

WiMAX Network

Release Feature

set

SPWG/NWG Release 1.5

Rate

Performance Intel® Centrino® Wireless-N + WiMAX 6150:

Up to 10 Mbps DL and 4 Mbps UL @ peak rate

(OTA performance, 10MHz channel)

Intel® Centrino® Advanced-N + WiMAX 6250:

Up to 20 Mbps DL and 6 Mbps UL @ peak rate

(OTA performance, 10MHz channel)

RF Transmitter

Output Power Compliance with Power class 2

Intel® Centrino® Wireless-N 1030 and Intel® Centrino® Advanced-N

6230

Form Factor PCI Express* Half-Mini Card

Dimensions Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5

mm)

Antenna

Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna

Diversity On-board diversity

Network

Standards 802.11a/b/g/n (varies by adapter) and Bluetooth 3.0 + HS

Connector

Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)

WiFi Network

Standards Intel® Centrino® Wireless-N 1030: 802.11b/g/n

Intel® Centrino® Advanced-N 6230: 802.11a/g/n

Frequency

Modulation 5 GHz (802.11a/n) 2.4 GHz (802.11b/g/n)

Frequency band 5.15 GHz - 5.85 GHz (dependent on country) 2.400 - 2.4835 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK

Wireless

Medium 5 GHz UNII: Orthogonal Frequency Division

Multiplexing (OFDM) 2.4 GHz ISM: Orthogonal Frequency Division

Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

IEEE 802.11n

Data Rates Intel® Centrino® Advanced-N 6230:

Tx/Rx (Mbps): 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117,

115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2

Intel® Centrino® Wireless-N 1030:

Rx (Mbps): 300, 270, 243, 240, 180

Rx/Tx (Mbps): 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3,

30, 28.9, 21.7, 15, 14.4, 7.2

IEEE 802.11a

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b

Data Rates 11, 5.5, 2, 1 Mbps

Bluetooth Bluetooth Version 3.0 + HS

General

Operating

Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, 802.11a, 802.11h, 802.11d, WPA-Personal, WPA-

Enterprise, WPA2-Personal, WPA2-Enterprise, WPS, WMM, WMM Power Save, EAP-SIM, LEAP,

PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA, P2P

Cisco

Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

WLAN Standard IEEE 802.11g, 802.11b, 802.11a, 802.11n

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-

bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Product Safety UL, C-UL, CB (IEC 60590)

Intel® Centrino® Wireless-N 100 and

Intel® Centrino® Wireless-N 130

Form Factor PCI Express* Half-Mini Card

Dimensions Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5

mm)

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

Antenna

Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna Diversity On-board diversity

Connector

Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)

WiFi

Frequency

Modulation 2.4 GHz (802.11b/g/n)

Frequency band 2.400 - 2.4835 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK

Wireless Medium 2.4 GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

IEEE 802.11n

Data Rates MIMO Configuration: 1X1

Tx/Rx: 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30,

28.9, 21.7, 15, 14.4, 7.2 Mbps

IEEE 802.11g

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b

Data Rates 11, 5.5, 2, 1 Mbps

Bluetooth

Support Intel® Centrino® Wireless-N 130: Bluetooth

Intel® Centrino® Wireless-N 100: None

General

Operating

Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, 802.11d, WPA-Personal, WPA-Enterprise, WPA2-

Personal, WPA2-Enterprise, WMM, WMM Power Save, EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST,

EAP-TLS, EAP-TTLS, EAP-AKA

Cisco Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

IEEE Feature

Sets IEEE 802.11b, 802.11g, 802.11n, 802.11e, 802.11i, 802.11d

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP

128-bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-

AKA

Product Safety UL, C-UL, CB (IEC 60590)

Intel® WiMAX/WiFi Link 5150

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

Intel® WiFi Link 5100 and Intel® WiFi Link 5300

Form Factor PCI Express* Full-Mini Card and Half-Mini Card

Dimensions Full-Mini Card: Width 2.00 in x Length 1.18 in x Height 0.18 in (50.95 mm x 30 mm x 4.5 mm)

Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5

mm)

Antenna

Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna

Diversity On-board diversity

Connector

Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)

Frequency

Modulation 5 GHz (802.11a/n) 2.4 GHz (802.11b/g/n)

Frequency band 5.15 GHz - 5.85 GHz (dependent on country) 2.400 - 2.4835 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK

Wireless

Medium 5 GHz UNII: Orthogonal Frequency Division

Multiplexing (OFDM) 2.4 GHz ISM: Orthogonal Frequency Division

Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

IEEE 802.11n

Data Rates Intel® WiFi Link 5300

450, 405, 360, 300, 270, 243, 240, 216.7, 195, 180, 173.3, 150, 144, 135, 130, 120, 117,

115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 Mbps

Intel® WiFi Link 5100

300, 270, 243, 240, 180, 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8,

45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 Mbps

IEEE 802.11a

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b

Data Rates 11, 5.5, 2, 1 Mbps

General

Operating

Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, 802.11a, 802.11h, 802.11d, WPA-Personal, WPA-

Enterprise, WPA2-Personal, WPA2-Enterprise, WMM, WMM Power Save, EAP-SIM, LEAP, PEAP,

TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Cisco

Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

WLAN Standard IEEE 802.11g, 802.11b, 802.11a, 802.11n

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-

bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Product Safety UL, C-UL, CB (IEC 60590)

Intel® WiFi Link 1000

WiFi / WiMAX

Form Factor PCI Express* Mini Card and Half-Mini Card

SKUs Intel® WiFi Link 1000 - 1X2 MC/HMC

Dimensions Mini Card: Width 2.0 in x Length 1.18 in x Height 0.18 in (50.80 mm x 30 mm x 4.5 mm)

Half-Mini Card: Width 1.049 in x Length 1.18 in x Height 0.18 in (26.64 mm x 30 mm x 4.5

mm)

Antenna

Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna Diversity On-board diversity

Connector

Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Humidity 50% to 90% non-condensing (at temperatures of 25 ºC to 35 ºC)

WiFi

Frequency

Modulation 2.4 GHz (802.11b/g/n)

Frequency band 2.41-2.474 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM, CCK, DQPSK, DBPSK

Wireless Medium 2.4 GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

IEEE 802.11n

Data Rates 300, 270, 243, 240, 180, 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60,

57.8, 45, 43.3, 30, 28.9, 21.7, 15, 14.4, 7.2 Mbps

IEEE 802.11g

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b

Data Rates 11, 5.5, 2, 1 Mbps

WiFi General

Operating

Systems Microsoft Windows* XP (32 and 64 bit) and Windows Vista* (32 and 64 bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, 802.11h, 802.11d, WPA-Personal, WPA-Enterprise,

WPA2-Personal, WPA2-Enterprise, WMM, WMM Power Save, EAP-SIM, LEAP, PEAP, TKIP, EAP-

FAST, EAP-TLS, EAP-TTLS

Cisco Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

WLAN Standard IEEE 802.11g, 802.11b, 802.11n

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, 802.1X: EAP-SIM, LEAP,

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

PEAP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Encryption AES-CCMP 128-bit, WEP 128-bit and 64-bit, CKIP, TKIP

Product Safety UL, C-UL, CB (IEC 60590)

Intel® Wireless WiFi Link 4965AGN

Form Factor PCI Express* Mini Card

Dimensions Width 2.00 in x Length 1.18 in x Height 0.18 in (50.95 mm x 30 mm x 4.5 mm)

Antenna

Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna

Diversity On-board diversity

Connector

Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)

Frequency

Modulation 5 GHz (802.11a/n) 2.4 GHz (802.11b/g/n)

Frequency band 5.15 GHz - 5.85 GHz (dependent on country) 2.400 - 2.4835 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK

Wireless

Medium 5 GHz UNII: Orthogonal Frequency Division

Multiplexing (OFDM) 2.4 GHz ISM: Orthogonal Frequency Division

Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

IEEE 802.11n

Data Rates Rx: 300, 270, 243, 240, 180

Rx/Tx: 150, 144, 135, 130, 120, 117, 115.5, 90, 86.667, 72.2, 65, 60, 57.8, 45, 43.3, 30,

28.9, 21.7, 15, 14.4, 7.2

IEEE 802.11a

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b

Data Rates 11, 5.5, 2, 1 Mbps

General

Operating

Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, 802.11a, 802.11h, 802.11d, WPA-Personal, WPA-

Enterprise, WPA2-Personal, WPA2-Enterprise, WMM, WMM Power Save, EAP-SIM, LEAP, PEAP,

TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Cisco

Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

WLAN Standard IEEE 802.11g, 802.11b, 802.11a, 802.11n

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Product Safety UL, C-UL, CB (IEC 60590)

Intel® Wireless WiFi Link 4965AG

This is a version of Intel Wireless WiFi 4965AGN with 8-2.11n capabilities disabled. 802.11n refers to: IEEE

P802.11n / D2.0 Draft Amendment to STANDARD [FOR] Information Technology-Telecommunications and

information exchange between systems-Local and Metropolitan networks-Specific requirements-Part 11: Wireless

LAN Medium Access Control (MAC) and Physical Layer (PHY) specifications: Enhancements for Higher Throughput.

Form Factor PCI Express Mini Card

Dimensions Width 2.00 in x Length 1.18 in x Height 0.18 in (50.95 mm x 30 mm x 4.5 mm)

Antenna Interface

Connector Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Antenna Diversity On-board diversity

Connector

Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Humidity 50% to 95% non-condensing (at temperatures of 25 ºC to 35 ºC)

Frequency

Modulation 5 GHz (802.11a) 2.4 GHz (802.11b/g)

Frequency band 5.15 GHz - 5.85 GHz (dependent on country) 2.400 - 2.4835 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK

Wireless Medium 5 GHz UNII: Orthogonal Frequency Division

Multiplexing (OFDM) 2.4 GHz ISM: Orthogonal Frequency Division

Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

IEEE 802.11a Data

Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11g Data

Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps

IEEE 802.11b Data

Rates 11, 5.5, 2, 1 Mbps

General

Operating Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, 802.11a, WPA, WPA2, WMM, EAP-SIM

Cisco Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

WLAN Standard IEEE 802.11g, 802.11b, 802.11a

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP

128-bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS,

EAP-AKA

Product Safety UL, C-UL, CB (IEC 60590)

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

Intel® PRO/Wireless 3945ABG Network Connection

Form Factor PCI Express Mini Card

Dimensions Width 2.00 in x Length 1.18 in x Height 0.18 in (50.95 mm x 30 mm x 4.5 mm)

Antenna

Interface

Connector

Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Dual Diversity

Antenna On-board dual diversity switching

Connector

Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Humidity 50 to 92% non-condensing (at temperatures of 25 ºC to 55 ºC)

Frequency

Modulation 5 GHz (802.11a) 2.4 GHz (802.11b/g)

Frequency band 5.15 GHz - 5.85 GHz 2.400 - 2.4835 GHz (dependent on country)

Modulation BPSK, QPSK, 16 QAM, 64 QAM CCK, DQPSK, DBPSK

Wireless

Medium 5 GHz UNII: Orthogonal Frequency Division

Multiplexing (OFDM) 2.4 GHz ISM: Orthogonal Frequency Division

Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

Data Rates 54, 48, 36, 24, 18, 12, 9, 6 Mbps 11, 5.5, 2, 1 Mbps

General

Operating

Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, 802.11a, 802.11h, 802.11d, WPA-Personal, WPA-

Enterprise, WPA2-Personal, WPA2-Enterprise, WMM, WMM Power Save, EAP-SIM, LEAP, PEAP,

TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Cisco

Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

WLAN Standard IEEE 802.11g, 802.11b, 802.11a

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP 128-

bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Product Safety UL, C-UL, CB (IEC 60590)

Intel® PRO/Wireless 3945BG Network Connection

Form Factor PCI Express Mini Card

Dimensions Width 2.00 in x Length 1.18 in x Height 0.18 in (50.95 mm x 30 mm x 4.5 mm)

Antenna Interface

Connector Hirose U.FL-R-SMT mates with cable connector U.FL-LP-066

Dual Diversity On-board dual diversity switching

Specifications

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/specs.htm[9/24/2010 5:51:49 PM]

Antenna

Connector Interface 52-pin Mini Card edge connector

Voltage 3.3 V

Operating

Temperature 0 to +80 degrees Celsius

Humidity 50 to 92% non-condensing (at temperatures of 25 ºC to 55 ºC)

Frequency

Modulation 2.4 GHz (802.11b/g)

Frequency band 2.400 - 2.4835 GHz (dependent on country)

Modulation CCK, DQPSK, DBPSK

Wireless Medium 2.4 GHz ISM: Orthogonal Frequency Division Multiplexing (OFDM)

Channels All channels as defined by the relevant specification and country rules.

IEEE 802.11g Data

Rates 54, 48, 36, 24, 18, 12, 9, 6, 5.5, 2, 1 Mbps

IEEE 802.11g Data

Rates 11, 5.5, 2, 1 Mbps

General

Operating Systems Microsoft Windows* XP (32-bit and 64-bit)

Windows Vista* (32-bit and 64-bit)

Windows* 7 (32-bit and 64-bit)

Wi-Fi Alliance*

certification Wi-Fi* certification for 802.11b, 802.11g, WPA, WPA2, WMM, EAP-SIM, LEAP, PEAP, TKIP,

EAP-FAST, EAP-TLS, EAP-TTLS, EAP-AKA

Cisco Compatible

Extensions

certification

Cisco Compatible Extensions, v4.0

WLAN Standard IEEE 802.11g, 802.11b

Architecture Infrastructure or ad hoc (peer-to-peer) operating modes

Security WPA-Personal, WPA2-Personal, WPA-Enterprise, WPA2-Enterprise, AES-CCMP 128-bit, WEP

128-bit and 64-bit; 802.1X: EAP-SIM, LEAP, PEAP, TKIP, EAP-FAST, EAP-TLS, EAP-TTLS,

EAP-AKA

Product Safety UL, C-UL, CB (IEC 60590)

Back to Contents

Trademarks and Disclaimers

Regulatory Information

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/regs.htm[9/24/2010 5:51:49 PM]

Back to Contents

Regulatory Information

NOTE: Due to the evolving state of regulations and standards in the wireless LAN field (IEEE 802.11

and similar standards), the information provided herein is subject to change. Intel Corporation

assumes no responsibility for errors or omissions in this document.

Intel® Centrino® Ultimate-N 6300

Intel® Centrino® Advanced-N + WiMAX 6250

Intel® Centrino® Advanced-N 6230

Intel® Centrino® Advanced-N 6205

Intel® Centrino® Advanced-N 6200

Intel® Centrino® Wireless-N + WiMAX 6150

Intel® WiFi Link 5300

Intel® WiMAX/WiFi Link 5150

Intel® WiFi Link 5100

Intel® WiFi Link 1000

Intel® Wireless WiFi Link 4965AGN

Intel® Wireless WiFi Link 4965AG

Intel® PRO/Wireless 3945ABG Network Connection

Intel® PRO/Wireless 3945BG Network Connection

Intel® Centrino® Wireless-N 1030

Intel® Centrino® Wireless-N 130

Intel® Centrino® Wireless-N 100

Intel WiFi/WiMAX Wireless Adapters

Information in this section supports the following wireless adapters:

Intel® Centrino® Advanced-N + WiMAX 6250 (model number 622ANXHMWG)

Intel® Centrino® Wireless-N + WiMAX 6150

Intel® WiMAX/WiFi Link 5150 (model numbers 512ANX_MMW, 512ANX_HMW)

See Specifications for complete wireless adapter specifications.

NOTE: In this section, all references to the "wireless adapter" refer to all adapters listed above.

The following information is provided:

Information for the User

Regulatory Information

Information for the User

Safety Notices

USA—FCC and FAA

The FCC with its action in ET Docket 96-8 has adopted a safety standard for human exposure to radio frequency

(RF) electromagnetic energy emitted by FCC certified equipment. The wireless adapter meets the Human Exposure

limits found in OET Bulletin 65, supplement C, 2001, and ANSI/IEEE C95.1, 1992. Proper operation of this radio

according to the instructions found in this manual will result in exposure substantially below the FCC’s

recommended limits.

The following safety precautions should be observed:

Do not touch or move antenna while the unit is transmitting or receiving.

Regulatory Information

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/regs.htm[9/24/2010 5:51:49 PM]

Do not hold any component containing the radio such that the antenna is very close or touching any

exposed parts of the body, especially the face or eyes, while transmitting.

Do not operate the radio or attempt to transmit data unless the antenna is connected; this behavior may

cause damage to the radio.

Use in specific environments:

The use of wireless adapters in hazardous locations is limited by the constraints posed by the safety

directors of such environments.

The use of wireless adapters on airplanes is governed by the Federal Aviation Administration (FAA).

The use of wireless adapters in hospitals is restricted to the limits set forth by each hospital.

Antenna Use

In order to comply with FCC RF exposure limits, low gain integrated antennas should be located at a

minimum distance of 20 cm (8 inches) or more from the body of all persons.

Explosive Device Proximity Warning

Warning: Do not operate a portable transmitter (including this wireless adapter) near unshielded blasting

caps or in an explosive environment unless the transmitter has been modified to be qualified for such use.

Antenna Warnings

Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is recommended that for the

wireless adapter installed in a desktop or portable computer, the antenna for this wireless adapter to be installed

so as to provide a separation distance of at least 20 cm (8 inches) from all persons. It is recommended that the

user limit exposure time if the antenna is positioned closer than 20 cm (8 inches).

Warning: The wireless adapter is not designed for use with high-gain directional antennas.

Use On Aircraft Caution

Caution: Regulations of the FCC and FAA prohibit airborne operation of radio-frequency wireless devices

(wireless adapters) because their signals could interfere with critical aircraft instruments.

Other Wireless Devices

Safety Notices for Other Devices in the Wireless Network: See the documentation supplied with wireless

adapters or other devices in the wireless network.

Local Restrictions on 802.11a, 802.11b, 802.11g, 802.11n, and 802.16e Radio Usage

Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, 802.11g, 802.11n, and 802.16e

wireless LAN devices may not yet be harmonized in all countries, 802.11a, 802.11b, 802.11g, 802.11n, and

802.16e products are designed for use only in specific countries, and are not allowed to be operated in countries

other than those of designated use. As a user of these products, you are responsible for ensuring that the

products are used only in the countries for which they were intended and for verifying that they are configured

with the correct selection of frequency and channel for the country of use. The device transmit power control

(TPC) interface is part of the Intel® PROSet/Wireless WiFi Connection Utility Software. Operational restrictions for

Equivalent Isotropic Radiated Power (EIRP) are provided by the system manufacturer. Any deviation from the

permissible power and frequency settings for the country of use is an infringement of national law and may be

punished as such.

For country-specific information, see the additional compliance information supplied with the product.

Wireless Interoperability

The wireless adapter is designed to be interoperable with other wireless LAN products that are based on direct

sequence spread spectrum (DSSS) radio technology and to comply with the following standards:

Regulatory Information

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/regs.htm[9/24/2010 5:51:49 PM]

IEEE Std. 802.11b compliant Standard on Wireless LAN

IEEE Std. 802.11g compliant Standard on Wireless LAN

IEEE Std. 802.11a compliant Standard on Wireless LAN

IEEE Std. 802.11n draft 2.0 compliant on Wireless LAN

IEEE 802.16e-2005 Wave 2 compliant

Wireless Fidelity certification, as defined by the Wi-Fi Alliance

WiMAX certification as defined by the WiMAX Forum

The Wireless Adapter and Your Health

The wireless adapter, like other radio devices, emits radio frequency electromagnetic energy. The level of energy

emitted by the wireless adapter, however, is less than the electromagnetic energy emitted by other wireless

devices such as mobile phones. The wireless adapter operates within the guidelines found in radio frequency safety

standards and recommendations. These standards and recommendations reflect the consensus of the scientific

community and result from deliberations of panels and committees of scientists who continually review and

interpret the extensive research literature. In some situations or environments, the use of the wireless adapter

may be restricted by the proprietor of the building or responsible representatives of the applicable organization.

Examples of such situations may include:

Using the wireless adapter on board airplanes, or

Using the wireless adapter in any other environment where the risk of interference with other devices or

services is perceived or identified as being harmful.

If you are uncertain of the policy that applies to the use of wireless adapters in a specific organization or

environment (an airport, for example), you are encouraged to ask for authorization to use the adapter before you

turn it on.

WEEE

Regulatory Information

Information for the OEMs and Integrators

The following statement must be included with all versions of this document supplied to an OEM or integrator, but

should not be distributed to the end user.

This device is intended for OEM integrators only.

Please see the full Grant of Equipment document for other restrictions.

This device must be operated and used with a locally approved access point.

Information To Be Supplied to the End User by the OEM or Integrator

The following regulatory and safety notices must be published in documentation supplied to the end user of the

product or system incorporating the Intel® wireless adapter, in compliance with local regulations. Host system

must be labeled with "Contains FCC ID: XXXXXXXX", FCC ID displayed on label.

The Intel® wireless adapter must be installed and used in strict accordance with the manufacturer's instructions as

described in the user documentation that comes with the product. Intel Corporation is not responsible for any

radio or television interference caused by unauthorized modification of the devices included with the wireless

adapter kit or the substitution or attachment of connecting cables and equipment other than that specified by Intel

Corporation. The correction of interference caused by such unauthorized modification, substitution or attachment is

the responsibility of the user. Intel Corporation and authorized resellers or distributors are not liable for any

Regulatory Information

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/regs.htm[9/24/2010 5:51:49 PM]

damage or violation of government regulations that may arise from the user failing to comply with these

guidelines.

Local Restriction of 802.11a, 802.11b, 802.11g, and 802.11n Radio Usage

The following statement on local restrictions must be published as part of the compliance documentation for all

802.11a, 802.11b, 802.11g and 802.11n products.

Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, 802.11g, 802.11n, and 802.16e

wireless LAN devices may not yet be harmonized in all countries, 802.11a, 802.11b, 802.11g, 802.11n, and

802.16e products are designed for use only in specific countries, and are not allowed to be operated in countries

other than those of designated use. As a user of these products, you are responsible for ensuring that the

products are used only in the countries for which they were intended and for verifying that they are configured

with the correct selection of frequency and channel for the country of use. Any deviation from the permissible

power and frequency settings for the country of use is an infringement of national law and may be punished as

such.

FCC Radio Frequency Interference Requirements

This wireless adapter is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz frequency range. FCC

requires this wireless adapter to be used indoors for the frequency range 5.15 to 5.25 GHz to reduce the potential

for harmful interference to co-channel Mobile Satellite systems. High power radars are allocated as primary users

of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and /or

damage this device.

This wireless adapter is intended for OEM integrators only.

This wireless adapter cannot be co-located with any other transmitter unless approved by the FCC.

USA—Federal Communications Commission (FCC)

This wireless adapter complies with Part 15 of the FCC Rules. Operation of the device is subject to the following

two conditions:

This device may not cause harmful interference.

This device must accept any interference that may cause undesired operation.

NOTE: The radiated output power of the adapter is far below the FCC radio frequency exposure limits.

Nevertheless, the adapter should be used in such a manner that the potential for human contact

during normal operation is minimized. To avoid the possibility of exceeding the FCC radio frequency

exposure limits, you should keep a distance of at least 20 cm between you (or any other person in the

vicinity) and the antenna that is built into the computer. Details of the authorized configurations can

be found at http://www.fcc.gov/oet/ea/ by entering the FCC ID number on the device.

Interference Statement

This wireless adapter has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

in a residential installation. This wireless adapter generates, uses, and can radiate radio frequency energy. If the

wireless adapter is not installed and used in accordance with the instructions, the wireless adapter may cause

harmful interference to radio communications. There is no guarantee, however, that such interference will not

occur in a particular installation. If this wireless adapter does cause harmful interference to radio or television

reception (which can be determined by turning the equipment off and on), the user is encouraged to try to correct

the interference by taking one or more of the following measures:

Reorient or relocate the receiving antenna of the equipment experiencing the interference.

Increase the distance between the wireless adapter and the equipment experiencing the interference.

Connect the computer with the wireless adapter to an outlet on a circuit different from that to which the

equipment experiencing the interference is connected.

Consult the dealer or an experienced radio/TV technician for help.

NOTE: The adapter must be installed and used in strict accordance with the manufacturer's

Regulatory Information

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/regs.htm[9/24/2010 5:51:49 PM]

instructions as described in the user documentation that comes with the product. Any other installation

or use will violate FCC Part 15 regulations.

Underwriters Laboratories Inc. (UL) Regulatory Warning

For use in (or with) UL Listed personal computers or compatible.

Halogen-Free Label

Some adapters are packaged with a Halogen-Free label. This claim applies only to halogenated flame retardants

and PVC in components. Halogens are below 900 PPM bromine and 900 PPM chlorine.

Taiwan

Radio Approvals

To determine whether you are allowed to use your wireless network device in a specific country, please check to

see if the radio type number that is printed on the identification label of your device is listed in the manufacturer's

OEM Regulatory Guidance document.

Regulatory Markings

A list of required regulatory markings can be found on the web at http://www.intel.com/support/wireless/wlan/

To find the regulatory information for your adapter, click on the link for your adapter. Then click Additional

Information > Regulatory Documents.

Intel WiFi-Only Adapters, 802.11n Compliant

The information in this section applies to the following products:

Intel® Centrino® Ultimate-N 6300 (model number 633ANHMW)

Intel® Centrino® Advanced-N 6205 (model numbers 62205ANHMW, 62205AGHRU)

Intel® Centrino® Advanced-N 6230 (model numbers 62230ANHMW, 62230AGHRU)

Intel® Centrino® Advanced-N 6200 (model numbers 622ANHMW, 622AGHRU)

Intel® WiFi Link 5300 (model numbers 533AN_HMW, 533AN_MMW)

Intel® WiFi Link 1000

See Specifications for wireless adapter specifications.

NOTE: In this section, all references to the "wireless adapter" refer to all adapters listed above.

The following information is provided:

Information for the User

Regulatory Information

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/regs.htm[9/24/2010 5:51:49 PM]

Regulatory Information

Information for the User

Safety Notices

USA—FCC and FAA

The FCC with its action in ET Docket 96-8 has adopted a safety standard for human exposure to radio frequency

(RF) electromagnetic energy emitted by FCC certified equipment. The wireless adapter meets the Human Exposure

limits found in OET Bulletin 65, supplement C, 2001, and ANSI/IEEE C95.1, 1992. Proper operation of this radio

according to the instructions found in this manual will result in exposure substantially below the FCC’s

recommended limits.

The following safety precautions should be observed:

Do not touch or move antenna while the unit is transmitting or receiving.

Do not hold any component containing the radio such that the antenna is very close or touching any

exposed parts of the body, especially the face or eyes, while transmitting.

Do not operate the radio or attempt to transmit data unless the antenna is connected; this behavior may

cause damage to the radio.

Use in specific environments:

The use of wireless adapters in hazardous locations is limited by the constraints posed by the safety

directors of such environments.

The use of wireless adapters on airplanes is governed by the Federal Aviation Administration (FAA).

The use of wireless adapters in hospitals is restricted to the limits set forth by each hospital.

Antenna Use

In order to comply with FCC RF exposure limits, low gain integrated antennas should be located at a

minimum distance of 20 cm (8 inches) or more from the body of all persons.

Explosive Device Proximity Warning

Warning: Do not operate a portable transmitter (including this wireless adapter) near unshielded blasting

caps or in an explosive environment unless the transmitter has been modified to be qualified for such use.

Antenna Warnings

Warning: To comply with the FCC and ANSI C95.1 RF exposure limits, it is recommended that for the

wireless adapter installed in a desktop or portable computer, the antenna for this wireless adapter to be installed

so as to provide a separation distance of at least 20 cm (8 inches) from all persons. It is recommended that the

user limit exposure time if the antenna is positioned closer than 20 cm (8 inches).

Warning: The wireless adapter is not designed for use with high-gain directional antennas.

Use On Aircraft Caution

Caution: Regulations of the FCC and FAA prohibit airborne operation of radio-frequency wireless devices

(wireless adapters) because their signals could interfere with critical aircraft instruments.

Other Wireless Devices

Safety Notices for Other Devices in the Wireless Network: See the documentation supplied with wireless

adapters or other devices in the wireless network.

Local Restrictions on 802.11a, 802.11b, 802.11g and 802.11n Radio Usage

Regulatory Information

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/regs.htm[9/24/2010 5:51:49 PM]

Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, 802.11g and 802.11n wireless LAN

devices may not yet be harmonized in all countries, 802.11a, 802.11b, 802.11g and 802.11n products are

designed for use only in specific countries, and are not allowed to be operated in countries other than those of

designated use. As a user of these products, you are responsible for ensuring that the products are used only in

the countries for which they were intended and for verifying that they are configured with the correct selection of

frequency and channel for the country of use. The device transmit power control (TPC) interface is part of the

Intel® PROSet/Wireless WiFi Connection Utility Software. Operational restrictions for Equivalent Isotropic Radiated

Power (EIRP) are provided by the system manufacturer. Any deviation from the permissible power and frequency

settings for the country of use is an infringement of national law and may be punished as such.

For country-specific information, see the additional compliance information supplied with the product.

Wireless Interoperability

The wireless adapter is designed to be interoperable with other wireless LAN products that are based on direct

sequence spread spectrum (DSSS) radio technology and to comply with the following standards:

IEEE Std. 802.11b compliant Standard on Wireless LAN

IEEE Std. 802.11g compliant Standard on Wireless LAN

IEEE Std. 802.11a compliant Standard on Wireless LAN

IEEE Std. 802.11n draft 2.0 compliant on Wireless LAN

Wireless Fidelity certification, as defined by the Wi-Fi Alliance

The Wireless Adapter and Your Health

The wireless adapter, like other radio devices, emits radio frequency electromagnetic energy. The level of energy

emitted by the wireless adapter, however, is less than the electromagnetic energy emitted by other wireless

devices such as mobile phones. The wireless adapter operates within the guidelines found in radio frequency safety

standards and recommendations. These standards and recommendations reflect the consensus of the scientific

community and result from deliberations of panels and committees of scientists who continually review and

interpret the extensive research literature. In some situations or environments, the use of the wireless adapter

may be restricted by the proprietor of the building or responsible representatives of the applicable organization.

Examples of such situations may include:

Using the wireless adapter on board airplanes, or

Using the wireless adapter in any other environment where the risk of interference with other devices or

services is perceived or identified as being harmful.

If you are uncertain of the policy that applies to the use of wireless adapters in a specific organization or

environment (an airport, for example), you are encouraged to ask for authorization to use the adapter before you

turn it on.

WEEE

Regulatory Information

Information for the OEMs and Integrators

The following statement must be included with all versions of this document supplied to an OEM or integrator, but

should not be distributed to the end user.

This device is intended for OEM integrators only.

Regulatory Information

file:///C|/Documents%20and%20Settings/dcobb1/Desktop/Holbert%2014.0%20Proset%20User%20Guide/html/regs.htm[9/24/2010 5:51:49 PM]

Please see the full Grant of Equipment document for other restrictions.

This device must be operated and used with a locally approved access point.

Information To Be Supplied to the End User by the OEM or Integrator

The following regulatory and safety notices must be published in documentation supplied to the end user of the

product or system incorporating the Intel® wireless adapter, in compliance with local regulations. Host system

must be labeled with "Contains FCC ID: XXXXXXXX", FCC ID displayed on label.

The wireless adapter must be installed and used in strict accordance with the manufacturer's instructions as

described in the user documentation that comes with the product. For country-specific approvals, see Radio

Approvals. Intel Corporation is not responsible for any radio or television interference caused by unauthorized

modification of the devices included with the wireless adapter kit or the substitution or attachment of connecting

cables and equipment other than that specified by Intel Corporation. The correction of interference caused by such

unauthorized modification, substitution or attachment is the responsibility of the user. Intel Corporation and

authorized resellers or distributors are not liable for any damage or violation of government regulations that may

arise from the user failing to comply with these guidelines.

Local Restriction of 802.11a, 802.11b, 802.11g, and 802.11n Radio Usage

The following statement on local restrictions must be published as part of the compliance documentation for all

802.11a, 802.11b, 802.11g and 802.11n products.

Caution: Due to the fact that the frequencies used by 802.11a, 802.11b, 802.11g and 802.11n wireless LAN

devices may not yet be harmonized in all countries, 802.11a, 802.11b, 802.11g and 802.11n products are

designed for use only in specific countries, and are not allowed to be operated in countries other than those of

designated use. As a user of these products, you are responsible for ensuring that the products are used only in

the countries for which they were intended and for verifying that they are configured with the correct selection of

frequency and channel for the country of use. Any deviation from permissible settings and restrictions in the

country of use could be an infringement of national law and may be punished as such.

FCC Radio Frequency Interference Requirements

This device is restricted to indoor use due to its operation in the 5.15 to 5.25 GHz and 5.470 to 5.725 GHz

frequency ranges. FCC requires this product to be used indoors for the frequency ranges 5.15 to 5.25 GHz and

5.470 to 5.725 GHz to reduce the potential for harmful interference to co-channel Mobile Satellite systems. High

power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar

stations can cause interference with and /or damage ths device. No configuration controls are provided for this

wireless adapter allowing any change in the frequency of operations outside the FCC grant of authorization for U.S

operation according to Part 15.407 of the FCC rules.

This device is intended for OEM integrators only.

This device cannot be co-located with any other transmitter unless approved by the FCC.

USA—Federal Communications Commission (FCC)

This device complies with Part 15 of the FCC Rules. Operation of the device is subject to the following two

conditions:

This device may not cause harmful interference.

This device must accept any interference that may cause undesired operation.

NOTE: The radiated output power of the adapter is far below the FCC radio frequency exposure limits.

Nevertheless, the adapter should be used in such a manner that the potential for human contact

during normal operation is minimized. To avoid the possibility of exceeding the FCC radio frequency

exposure limits, you should keep a distance of at least 20 cm between you (or any other person in the

vicinity) and the antenna that is built into the computer. Details of the authorized configurations can

be found at http://www.fcc.gov/oet/ea/ by entering the FCC ID number on the device.

Interference Statement
