Intel VLMRX58G Intel Video Link Module Rx 5.8 GHz User Manual
Intel Corporation Intel Video Link Module Rx 5.8 GHz
Intel >
User manual
Page 1 of 4
Intel® Video Link Module Rx 5.8 GHz
Model: VLMRX58G
Manual (USA)
Revision 2.0
Revision History
Revision
Description
Date
2.0
VLMRX58G – C2PC, Intel
FA5, Micro-UFL, USA
2017-04-01
Overview
The VLMRX58G is the image receiving g device of a wireless video link system consisting of a
VLMTX58G transmitter and a VLMRX58G receiver/transceiver.
Instruction
Do only use
- with specified antennas
- within specified supply voltage range
- interfacing via provided HDMI, USB port.
Page 2 of 4
Specification:
Supported frequency
ranges
5.15 GHz – 5.25 GHz
5.25 GHz – 5.35 GHz (DFS)
5.470 GHz – 5.725 GHz (DFS)
5.725 GHz – 5.85 GHz
DFS Operation
Master (with radar detection)
Modulation
OFDM 16QAM (similar to 802.11a/n) on a proprietary protocol
Bandwidth
40 MHz
Data Rates
40 MHz mode: 72.46 Mbps
Supply Input range
Min. 6 VDC , Typ. 10 VDC , Max. 28 VDC
Antenna connection
µUFL
Connector type: 50 Ohm nominal
Permissive antenna
type/gain
Intel FA5 antenna
Model: Antenna-002
Peak Gain: 8.02dBi
Type: (Circularly polarized) patch antenna
Antenna configuration
3 antennas (2 receiving antennas, 1 antenna multiplexed to 1x
receiving RF 1x transmitting antenna port
Transmitter Output Power
Band
USA
output power (conducted)
Band 1
5.15 GHz – 5.25 GHz
5190MHz (CH38): 13.93 dBm
5230MHz (CH46): 14.24 dBm
Band 2
5.25 GHz - 5.35 GHz
5270MHz (CH54): 14.41 dBm
5310MHz (CH62): 15.11 dBm
Band 3
5.470 GHz - 5.725 GHz
5510MHz (CH 102): 12.57 dBm
5550MHz (CH 110): 12.68 dBm
5590MHz (CH118): 12.13 dBm
5670MHz (CH134): 12.74 dBm
Band 4
5.725 GHz – 5.85 GHz
5755MHz (CH 151): 12.78dBm
5795MHz (CH159): 14.30dBm
Page 3 of 4
Connection
Figure 1 VLMRX58G Top View
Figure 2 VLMRX58G Bottom View
FCC Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not in-stalled and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV technician for help.
Important Note
Changes or modifications made to this equipment not expressly approved by Intel Corporation may
void the FCC and ISED authorization to operate this equipment.
5V
5V
GND
GND
HDMI
N/C
USB
Page 4 of 4
The product is provided with an approved antenna. Use only supplied or approved antenna by Intel
Corporation. Any changes or modifications to the Antenna may void the FCC and ISED regulatory
approvals obtained for the product.
End-users and installers must be provided with antenna installation instructions and transmitter
operating conditions for satisfying RF exposure compliance.
The antenna(s) used for this transmitter must be installed to provide a separation distance of at least
20 cm from all persons. RF exposure compliance must be ensured by integrator.
Contact
Intel Corporation
2200 Mission College Boulevard
Santa Clara, CA 95054
