1. Objective
1.1 The objective of this procedure is to identify any special notes that have to do with the integration of
the Assembly RF3 Board (200077-01) into future designs.
2. References
NONE
3. Definitions
RF3 Board: is a communications module, currently used in Models MT150M and MT200
FCC: Federal Communication Commission
IC: Industry of Canada
4. Responsibilities
VP of Engineering: is responsible for making sure the instructions are adhered to. Any deviation from the
instructions below require retesting and certification of the RF3 Module.
5. Instruction
5.1 RF3 board has been certified as a module, allowing for the module to be used in multiple designs.
Currently those designs are the IntelliDOT CAREt MT150M and MT200.
5.2 Including the RF3 Module in future CAREt designs must:
5.2.1 NOT alter the module design in any way, including but not limited to the frequency of operation,
the power output requirements or the on-board antenna configuration.
5.2.2 KEEP labeling in manuals, CAREt and module labels that meet the requirements associated with
the certification and registration with the FCC and IC. This includes but is not limited to safety
warnings, registration notes and identification.
5.2.3 Only incorporate the module in designs that employ only minor construction differences from the
CAREt M150 and M200 models.
6. Distribution
All parties working on the electrical design of the RF3 board or the inclusion of the RF3 board in any hand held
design shall be provided a copy of this document.
Document Number: DN001-01 Revision: C
Title: Design Notes: Utilizing 200077-01 RF3 Boards in future designs
All Quality System Documents are Controlled on Sharepoint. All other copies (printed or soft) are considered UNCONTROLLED.
IntelliDOT CONFIDENTIAL PRINTED: 8/24/2009 Page 3 of 4
Regulatory Requirements This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
7. Regulatory Requirements
This device has been certified with a “Limited Modular Approval” Wit this certification the device can be
integrated into different hosts providing that the conditions and requirements below are met.
User Manual Requirements
The user manual for the host device must include the following statement required by FCC Part 15.105
The user manual shall NOT contain any instructions on how to remove the device from the host.
Labeling Requirements
The external surface of the host must be labeled with the following information:
“Contains FCC ID R9M-IDOT-002 IC: 7701A-IDOT002”
Additionally the external label should contain the following statement, unless the devcice is too small to
incorporate the wording. In that case the text must appear in the user manual with the text above
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this device not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation.
Document Number: DN001-01 Revision: C
Title: Design Notes: Utilizing 200077-01 RF3 Boards in future designs
All Quality System Documents are Controlled on Sharepoint. All other copies (printed or soft) are considered UNCONTROLLED.
IntelliDOT CONFIDENTIAL PRINTED: 8/24/2009 Page 4 of 4
RF Exposure Requirements
The user manual for the host device must instruct the user that any body worn accessories used with the device
may not contain any metal in close proximity to the host device.
The host device must maintain the internal separation distances outlined below between the internal antenna and
the closets external surface of the device. The host device shall not contain any metallic components in close
proximity to the antenna of the module.
1 cm
3 cm
Front of the unit
Rear of the unit
Side View
Display
Antenna
3 cm
2.7 cm
1 cm
Top View
Front View
