Caution
You must use the appropriate Intermec power supply with this device
or equipment damage may occur.
Conseil
Vous devez utiliser la source d’alimentation Intermec adéquate avec cet
appareil sinon vous risquez d’endommager l’équipement.
Caution
Government regulatory agencies mandate that the antenna not be
alterable. Therefore, the access point uses a custom antenna connector.
Do not attempt to use a different antenna or you may damage the
connector and the access point.
Conseil
Les agences responsables de la réglementation gouvernementale
exigent que l’antenne ne soit pas modifiable. Par conséquent, le point
d’accès est doté d’un connecteur d’antenne personnalisé. Ne pas
essayer d’utiliser une antenne différente au risque d’endommager le
connecteur et le point d’accès.
Quick Start Guide
MobileLAN™access 2106
More Information
About the 2106
Safety First
Specifications
Physical 14.66 cm x 9.32 cm x 3.53 cm Operating 0°C to +40°C
Dimensions (5.77 in x 3.67 in x 1.39 in) Temperature (+32°F to +104°F)
Weight 205 g (0.45 lb) Electrical rating ~100 to 240V
1.0 to 0.5A
50 to 60 Hz
For more information on using the 2106, please see:
• 21XX Universal Access Point Technical Reference Manual (Part No. 067150)
• Intermec Web Site at www.intermec.com
Part No. 072215-001
*072215-001*
*072215-001*
072215-001
6001 36th Avenue West
Everett, WA 98203-9280
© 2001 Intermec Technologies Corp.
All Rights Reserved
Intermec’s 2106 access point is a wireless local area network (LAN)
product that lets your wireless end devices roam anywhere
throughout an enterprise while maintaining a continuous, high-quality
network connection.
Your 2106 has been certified with an IEEE 802.11a radio.
CAUTION
!
CAUTION
!
MobileLAN™access 2106 Quick Start Guide
Power
After the 2106 boots, this LED remains steadily on.
Wired LAN
This LED flashes when a frame is
transmitted or received on the
Ethernet port.
Root/error
This LED flashes if this
access point is configured
as the root. It remains
steadily on if an error has
occurred.
Radio
This LED flashes when a frame is transmitted
or received on the Radio port.
1. Install the MobileLAN access Utility by clicking Install Software from the enclosed CD and
following the instructions that appear on your screen. You can also install the software from
www.mobilelan.intermec.com.
2. Reboot the access point and configure parameters A through C in the MobileLAN access
Utility main screen.
Note: You must configure parameters A through C within 60 seconds after the
access point has started. In addition, if the access point you are setting is connected
wirelessly, you must have an active radio connection.
Your PC must also be on the same Ethernet segment and subnet as the
access point.
11
3
Use this position
when storing the
2106.
Use this position
when the 2106 is
mounted on a
desktop.
Use this
position
when the
2106 is
mounted to
a wall.
0°
90°
180°
Defining the LEDs, Ports, and Antenna Positions Connecting, Mounting, and Applying
Power to the 2106
Setting an Initial IP Address
Plug the AC power
cord into an
AC power outlet.
Plug the power
supply into the
power port of the
2106.
Power
Supply
Ethernet
connection
A
Enter the IP address
of the access point.
B
Enter the MAC
address of the access
point (located on the
bottom of the access
point).
C
Click Set AP.
Click Configure AP to
use the Web browser
interface to continue
configuring the
access point.
Power
port
10/100 BaseT
Ethernet port
Congratulations!
Your 2106 is now ready to begin transmitting data packets between your end
devices and your wired network.
Mounting
screw (not
provided)
(2 places)
Screws fasten
into mounting
surface.
Fit the slots on the back of the 2106
over the hooks on the mounting
bracket.
