JBL Bar 5.1
OWNER’S MANUAL
2
TABLE OF CONTENTS
1. INTRODUCTION 3
2. WHAT’S IN THE BOX 3
3. PLACE YOUR SOUNDBAR 3
PLACE THE SOUNDBAR ON THE TABLE 3
WALL MOUNT THE SOUNDBAR 4
WALL MOUNTING THE SURROUND SPEAKER
(OPTIONAL) 4
4. CONNECT YOUR SOUNDBAR 4
CONNECTING THE SOUNDBAR TO YOUR TV 4
CONNECTING THE SOUNDBAR TO OTHER DEVICES 4
5. POWER ON YOUR SYSTEM 5
PAIR WITH THE SUBWOOFER 5
6. USE YOUR SOUNDBAR SYSTEM 5
TO CONTROL 5
USING THE WIRELESS SPEAKERS 6
HOW TO USE BLUETOOTH 6
HOW TO USE SOUNDSHIFT WITH BLUETOOTH 7
HOW TO USE USB AUDIO 7
7. SOUND SETTING 8
BEFORE YOU START 8
ADJUST THE VOLUME 8
CHOOSE SOUND EFFECT 8
1. BASS 8
2. SOUND MODE 8
3. NIGHT MODE 8
SYNCHRONIZE VIDEO AND SOUND 8
8. AUDIO CALIBRATION 8
9
. HOW TO USE YOUR TV REMOTE CONTROL
TO CONTROL THE SOUNDBAR 9
FOR MOST SAMSUNG, LG, SONY AND VIZIO TVS 9
FOR OTHER TVS, DO IR REMOTE LEARNING 9
10. SYSTEM 9
1. AUTO STANDBY 9
2. AUTO WAKE UP 9
3. SET DISPLAY BRIGHTNESS 9
4. APPLY FACTORY SETTINGS 9
5. CHECK SOFTWARE VERSION 9
6. SOFTWARE UPDATE 9
11. PRODUCT SPECIFICATIONS 10
GENERAL 10
INPUT AND OUTPUT 10
BLUETOOTH SPECIFICATION 10
USB SPECIFICATION 10
PRODUCT DIMENSION AND WEIGHT 10
WIRELESS TRANSMITTER/RECEIVER SECTION 10
12. TROUBLESHOOTING 10
SYSTEM 10
SOUND 10
VIDEO 11
BLUETOOTH 11
REMOTE CONTROL 11
3
www.jbl.com
English
1. INTRODUCTION
Thank you for purchasing the JBL Bar 5.1. The JBL Bar 5.1
is designed to bring an extraordinary sound experience to your
home entertainment system. We urge you to take a few minutes
to read through this manual, which describes the product
and includes step-by-step instructions to help you set up and
get started.
CONTACT US: If you have any questions about JBL Bar 5.1,
its installation or its operation, please contact your retailer or
custom installer, or visit our website at www.JBL.com.
2. WHAT’S IN THE BOX
Soundbar
x1
Subwoofer
x1
Remote Control and Batteries
x1
Wireless Surround Speakers
x1
Power Cables* (4ft, 1200mm)
x1
*Power cable numbers varied by regions
HDMI Cable (4ft, 1200mm)
x1
AUX Cable (4ft, 1200mm)
x1
Optical Cable (4ft, 1200mm)
x1
Calibration Microphone
x1
Wall-Mount Brackets
x1
Product Information & Wall-mounted guide
x1
3. PLACE YOUR SOUNDBAR
3a. Place the soundbar on the table
4
3b. Wall mount the Soundbar
Use tape to stick the wall-mounted paper guide on the wall, push
a pen tip through the center of each mounting hole to mark the
wall-mounted bracket location and remove the paper.
TV
Screw the L-shaped wall mount brackets on the pen mark; screw
the threaded mounting post into the back of the soundbar; then
hook the soundbar on the wall.
≤8 mm/
0.31" 4mm/0.16"
≥35 mm/1.4"
1
2
3
3c. Wall mounting the Surround Speaker (optional)
1. Choose a location to mount the surround speakers. In a
standard surround sound conguration, the best locations are
the sides or behind the main seating area.
2. Screw the small wall mount brackets to the wall in the desired
location
3. Hook the surround speakers to the bracket
1
2
3
4. CONNECT YOUR SOUNDBAR
This section helps you connect your soundbar to a TV and other
devices, and set up the whole system.
Connecting the Soundbar to your TV
Connect your soundbar to a TV. You can listen to audio from TV
programs through your soundbar.
Connecting to TV through HDMI (ARC)
An HDMI connection supports digital audio and is the best option to
connect to your soundbar. If your TV supports HDMI ARC, you can
hear the TV audio through your soundbar by using a single HDMI
cable. This HDMI connection is required if you intend to connect
other video devices to the soundbar inputs to display on your TV.
HDMI (ARC)
HDMI
cable
Note: Do conrm that the HDMI CEC function on your TV is turned on.
Connect to TV through Optical
OPTICAL
cable
An Optical connection supports digital audio and is an alternative
to an HDMI audio connection. An optical audio connection can
typically be used if all of your video devices are connected directly
to the television--not through the soundbar HDMI inputs.
Note: Conrm to set your TV audio settings to support “external
speakers” and disable the built-in TV speakers.
Connecting the soundbar to other devices
Option 1: Connect digital devices through HDMI
HDMI IN / HDMI (ARC) HDMI OUT
HDMI INHDMI OUT (ARC)
HDMI
cable
Connect a digital device such as a set-top box, DVD/Blu-ray
player, or games console to your soundbar through a single HDMI
connection. When you connect the devices in this way and play
a le or game, the
• video is automatically displayed on your TV, and
• audio is automatically played on your soundbar.
Using a High Speed HDMI cable, connect the HDMI OUT
connector on your digital device to the HDMI IN on your
soundbar. Connect your soundbar to TV through HDMI
OUT (ARC).
5
www.jbl.com
English
Option 2: Connect devices through analog audio cables
AUX cable
AUX-IN
AUX-OUT
1. Some devices may not feature a digital audio connection. If your
device features both digital and analog audio connections, a
digital connection is preferred--do not connect both digital and
analog at the same time. Using an analog cable, connect the
AUX IN (3.5mm jack) on your SoundBar to the AUX IN/ 3.5mm
connectors on your portable devices.
2. Press repeatedly SOURCE button on the remote control until
AUX is displayed on the display panel.
5. POWER ON YOUR SYSTEM
2
3
1
4
Pairing with the subwoofer
The wireless subwoofer automatically connects with the soundbar when
both units are powered on. If the subwoofer is on and connected, the LED
lights white continuously.
If no audio from the wireless subwoofer can be heard, manually
pair the subwoofer:
1. Turn on the soundbar and the subwoofer. If the connection is
lost, the LED indicator on the subwoofer blinks slowly.
2. Press the CONNECT button on the subwoofer to enter pairing
mode. The LED indicator on the subwoofer blinks quickly.
3. Press and hold DIM DISPLAY button on remote control for
5 seconds, followed by short press on BASS+, and BASS-
button in sequence. Panel display will show “PAIRING”
If the pairing succeeds, the LED indicator on the subwoofer
lights up and the soundbar display will show “DONE”.
If the pairing fails, the indicator on the subwoofer blinks slowly.
4. If the pairing fails, repeat the steps above.
6. USE YOUR SOUNDBAR SYSTEM
1. How to control your soundbar
a. Top panel
b. Remote Control
7
6
5
2
1
4
3
8
9
13
15
17
19
21
10
11
12
14
16
18
20
* Switch between HDMI ARC/ HDMI 1/ HDMI 2/ HDMI 3/ Optical/ AUX/ Bluetooth/
USB
** Switch between Standard/ music/voice/ movie/ sports sound mode or press and
hold 5 seconds to reset default audio setting
*** For USB playback only; switch between shufe/ repeat all/ repeat one/ off
1) Power
2) Source*
3) Play / Pause
4) Volume -
5) Volume +
6) Previous
7) Next
8)
Wireless Surround Level+
9)
Wireless Surround Level-
10) Mute
11) Bass +
12) Bass -
13) Sound mode**
14) Soundshift On / off
15) Shufe / Repeat
16) Calibrate Audio
17) Night mode On / off
18) Dim display
19) Bluetooth
20) Audio Sync +
21) Audio Sync -
Power Volume
Down
Volume
Up
Source
6
2. Using the Wireless Speakers
The JBL Bar 5.1 features two wireless surround speakers that
transform the soundbar to a full 5.1 surround sound experience.
The soundbar system will reproduce the experience you hear in the
movie theater and create an immersive music experience.
How to use your wireless surround speakers:
1. Detach the speakers from the main soundbar and freely place
them to the sides or behind the main seating area.
2. Note that the narrow side of the speaker emits the sound. Point
this side towards the listening location.
3. The wireless surround speaker volume level is set to a default
setting. Press the WIRELESS SURROUND +/- buttons on the
remote control to adjust the surround speaker volume level
4. Review the “Audio Calibration” section to calibrate the wireless
speaker system to your specic speaker placement and room
orientation.
Surround Speaker LED Lighting Indication
• WHITE (Solid) : Connected
• WHITE (Slow Blinking) : Lost connection
• WHITE (Fast Blinking) : Searching for soundbar
• RED (Solid) : Charging
• RED (Blinking) : Low battery
Battery and Charging
• Each wireless surround speaker features 10 hours of playtime.
• Each wireless surround speaker will reach a charge in less than
3 hours of charging.
• Each wireless surround speaker will charge when attached to the
soundbar and the system is in STANDBY mode. The surround
speakers will stop charging when the soundbar is power ON.
• As an option, each wireless surround speaker can charge via the
USB connector, located on the bottom of the speaker.
Speaker charging
Standby Mode
1. The wireless surround speakers feature standby mode. In this
condition the speakers should automatically reconnect to the
main soundbar without any other action.
2. The wireless surround speakers automatically enter standby for
a total of 10 minutes if one presses POWER OFF on the remote
control or the soundbar top-panel buttons.
3. The wireless surround speakers automatically switch to standby
after 10 minutes of button inactivity and no audio/video play from
a connected device.
4. The wireless surround speakers automatically power off after
20 minutes of button inactivity and no audio/video play from a
connected device.
Reconnecting to the Main Soundbar
To re-connect the wireless surround speakers to the soundbar,
rst conrm the main soundbar is POWER ON, then press the
RECONNECT button on the wireless surround speaker.
Reconnect to soundbar /
Power Off
3. How to use Bluetooth
2a. Press Bluetooth (BT) button on your remote control
to start Bluetooth pairing
PAIRING
2b. Choose “JBL Bar 5.1” to connect
CONNECTED
Settings Bluetooth
Bluetooth
DEVICES
JBL Bar 5.1
Now Discoverable
Connected
7
www.jbl.com
English
Remark: Press and hold Bluetooth (BT) button on your remote
control for 3 seconds if you want to pair another mobile device.
NOTES
- If asked for a PIN code when connecting a Bluetooth device,
enter <0000>.
- In Bluetooth connection mode, the Bluetooth connection will
be lost if the distance between the Soundbar and the Bluetooth
device exceeds 32.8 ft/10m.
- The Soundbar automatically turns off after 10 minutes in the
Ready state.
- Electronic devices may cause radio interference. Devices
that generate electromagnetic waves must be kept away
from the Soundbar main unit - e.g., microwaves, wireless
LAN devices, etc.
3. How to use Soundshift with Bluetooth
By default, Soundshift is OFF, Bluetooth
music cannot break in your current source.
Press SOUNDSHIFT button on your remote
control to enable Soundshift feature.
While Soundshift is on, play and pause your music source to enjoy
auto-switch between your mobile devices - Bluetooth source (A)
and TV - Previous source (B).
(A)
(B)
4. How to use USB Audio
Play music les located on USB storage devices through the
soundbar.
1. Connect a 2.0 USB drive to this product.
2. Press repeatedly SOURCE button on the remote control
until USB is displayed on the display panel.
If USB is detected, display will show LOADING and music
start playing automatically.
Songs will appear in the order of the last le added to the
USB drive.
How to Control USB playback
Use Play/ Pause/ Previous/ Next/ Shufe to control USB playback
Before you connect a USB device, be aware of the following:
• This soundbar can display le or folder names that contain
numbers or English characters only. Other languages and
symbol is not supported.
• If the le name of a le on a USB device exceeds 15 characters,
it is not displayed on the Soundbar’s display.
• Do not remove the USB device while it is transferring les.
• DRM-protected music les (MP3, WMA) from commercial web
sites cannot be played.
Compatible USB devices
• MP3 Player : Flash type MP3 player.
• USB Flash Drive : Devices that support USB 2.0.
• Some USB devices may not be supported.
USB device requirement
• Devices which require additional program installation connected
to a computer, are not supported.
• Do not extract the USB device while in operation.
• For a large capacity USB, it may take longer than a few minutes
to be searched.This unit is not supported when the total number
of les is 2000 or more.
• The Soundbar USB Port cannot be connected to PC and it
cannot be used as a storage device.
• The exFAT and NTFS le system is not supported on this unit.
(FAT16/FAT32 systems are available.)
• Depending on some devices, it may not available to recognize
the followings on this unit.
-- External HDD
-- Card readers
-- Locked devices
-- Hard type USB devices
-- USB hub
-- Using USB extension cable
-- iPhone/iPod/iPad
-- Android device
Mode Description Display
Off Play songs on USB
device on order
OFF
Shufe
Play songs randomly SHUFFLE
Repeat
once
Play a same song
repeatedly
ONE
Repeat all
Play all songs on USB
repeatedly by order of
the folder logic
., ALL
8
7. SOUND SETTING
This section helps you choose the ideal sound for your video or
music.
Before you start
• Make the necessary connections described in the user manual.
• On the soundbar, switch to corresponding source for other
devices.
Adjust the volume
• Press VOLUME +/- button to increase or decrease a volume
level.
• To mute sound, press MUTE button.
• To restore the sound, press MUTE button again or press
VOLUME +/- button
Choose sound effect
1. Bass
• Change low frequency (bass) settings of the soundbar.
• Press BASS +/- to change the subwoofer volume level.
2. Sound mode
• Select predened sound modes to suit your video or music.
• Press SOUND button to select a sound option from the
display panel.
• Select the STANDARD mode if you want to enjoy the
original sound.
• Select the MUSIC, MOVIE, VOICE, SPORT mode
depending on the content you want to listen to.
• When the wireless surround speakers are detached from
the main bar, sound modes feature specic behaviors:
Sound Mode What you hear in the detached
wireless surround speakers
Standard Ambience and special effects
Music Mono Mix
Movie Ambience and special effects
Voice Mono Mix
Sports Ambience and special effects
3. Night mode
• For quiet listening, night mode decreases the volume of
loud sounds when audio is played.
• Night mode is only available for Dolby Digital or DTS
soundtracks.
• Press NIGHT MODE button to turn night mode on or off.
Press and hold 5 seconds SOUND button to reset default
audio setting.
Synchronize video and sound
• If the audio and video are not synchronized, delay the audio
to match the video.
• Press AUDIO SYNC +/- button to synchronize the audio
with the video.
8. AUDIO CALIBRATION
Audio Calibration will optimize the wireless speaker sound settings
for a better surround sound experience.
Remove the wireless surround speakers from the soundbar.
Connect the microphone into the connector on the right side of
the soundbar.
Place the microphone at ear-level at the listening position. For best
surround sound effect, position the wireless surround speakers to
the sides and slightly behind the listening area.
Be sure to point the narrow side of the surround speaker towards
the listening area, and remove any obstruction between the
microphone and the wireless surround speakers.
Press and hold the calibration button for 3 seconds. The calibration
sequence will begin with a countdown.
>3 s
1
2
3
DONE
9
www.jbl.com
English
NOTE: any ambient noise or sounds may disrupt the calibration
sequence. Step out of the way and remain silent during the
calibration.
After the calibration is complete, unplug the microphone and save
for later.
NOTE: Audio calibration settings are saved for specic wireless
speaker locations. If the wireless speakers are moved to
different locations, then the audio calibration settings should be
re-measured.
9. HOW TO USE YOUR TV REMOTE
CONTROL TO CONTROL THE
SOUNDBAR
Use your own TV remote control to control your soundbar
7a. For most Samsung, LG, Sony and Vizio TVs*
The soundbar responds to your TV remote control automatically.
Controllable functions are volume up/down and mute. Press and
hold SHUFFLE button on soundbar remote control if you want to
disable this function.
TV REMOTE ON
>3 s
Note:
– Make sure that the sound output of your TV is set to “External
speaker”.
– Depending on the remote control, this function may not work
well.
– This function does not operate on LG TV’s magic remote
control.
– This function may not work well when HDMI CEC is ON.
– Some remote control may not operate if you press repeatedly
the volume button.
– If your TV remote control is not supported, follow section 7b and
do IR remote learning.
7b. For other TVs, do IR remote learning
To program the soundbar to respond to your TV remote control,
follow these steps. First, press and hold VOLUME+ and SOURCE
button to enter learning mode.
>5 s
LEARNING
1
Then, press POWER button on the soundbar and press POWER
button on the TV remote control
Follow the same procedure for VOLUME - and
VOLUME + . For mute, press both VOLUME +
and VOLUME - button on soundbar and press
MUTE button on TV remote control. Press and
hold VOLUME+ and SOURCE button on
soundbar again and now your soundbar
responds to your TV remote control.
DONE
3
2
TV
SOURCE
10. SYSTEM
1. Auto standby
This soundbar automatically switches to standby after 10
minutes of button inactivity and no audio/video play from a
connected device.
2. Auto wake up
The soundbar is powered on whenever a sound signal is
received. This is most useful when connecting to the TV using
the optical cable, as most HDMI™ ARC connections enable
this feature by default.
3. Set display brightness
Press DIM button on remote control repeatedly to select a
different brightness level of the display panel on this product
4. Apply factory settings
• Reset this soundbar to the default settings programmed at
the factory.
• In any source mode, press and hold VOLUME -, VOLUME+
and SOURCE button on soundbar top panel until text
display shows RESET.
• When the factory settings restore is complete, the product
automatically switches off and restarts.
5. Check Software version
• Press and hold DIM DISPLAY button for 5 seconds in any
source, Hold and press DIM DISPLAY button for 5 seconds,
followed by SOUND MODE and NIGHT MODE button.
• To check subwoofer software version, pls connect
subwoofer to soundbar via a 3.5mm AUX in cable and
follow the above procedure.
6. Software Update
JBL may offer updates for Soundbar’s system rmware in the
future. If an update is offered, you can update the rmware by
connecting a USB device with the rmware update stored on
it to the USB port on your soundbar.
Please visit www.JBL.com or contact JBL call center to
receive more information about downloading update les.
10
11. PRODUCT SPECIFICATIONS
General
• Total Maximun Power : 510W
• Soundbar Maximum Power : 150W
• Subwoofer Maximum Power : 300W
• Surround Speaker Maximum
Power : 30W x 2
• Surround Speaker Play Time : 10 hours
• Battery charge time : <3 hours
• Soundbar Transducer Size : 6 x 2.25” racetrack drivers
3 x 1.25” tweeter
• Subwoofer Transducer Size : 10”
• Max SPL : 104db
• Frequency Response : 35Hz to 20KHz
• Operating Temperature : 0°C - 45°C
Input and Output
• Audio inputs : 1 Analog, 1 Optical,
Bluetooth, USB
• HDMI Video Inputs : 3
• HDMI Video Output
(with Audio Return Channel) : 1
• HDMI HDCP Version : 2.2
Bluetooth specication
• Bluetooth Version : 4.2
• Bluetooth Prole : A2DP V1.3 / AVRCP V1.6
USB specication
(USB) port: Type A
File Format Type Compatibility list:
Extension Codec Sampling
Rate Bitrate
*.mp3
MPEG 1
Layer2
16KHz ~
48KHz 80kbps~320kbps
MPEG 1
Layer3
16KHz ~
48KHz 80kbps~320kbps
MPEG 2
Layer3
16KHz ~
48KHz 80kbps~320kbps
MPEG 2.5
Layer3
16KHz ~
48KHz 80kbps~320kbps
*.wav - 16KHz ~
48KHz up to 3000kbps
Product dimension and weight
• Soundbar Dimensions (W x H x D) : 1148 x 58 x 93 (mm) \
45" x 2.3" x 3.7"
• Soundbar Weight : 3.9kg \ 8.6 lbs
• Subwoofer Dimensions (W x H x D) : 440 x 305 x 305 (mm) \
16" x 12" x 12"
• Subwoofer Weight : 13kg \ 28.7 lbs
• Surround Speaker Dimensions : 165 x 59 x 93 (mm) \
(W x H x D) 6.5" x 2.3" x 3.7"
• Surround Speaker Weight : 0.6kg \ 1.3 lbs
• Packaging Dimensions (W x H x D) : 1008 x 379 x 455 (mm) \
39.7" x 14.9" x 17.9"
• Packaging Weight (Gross) : 20.95kg \ 46.1 lbs
Wireless transmitter/receiver section
• Bluetooth Frequency Range : 2402MHz-2480MHz
• Bluetooth Max Transmitting : 9dbm (EIRP)
power
• Bluetooth Transmitter : GFSK, /4 DQPSK, 8DPSK
modulation
•
5.8G Wireless Frequency Range
: 5725MHz- 5875MHz
•
5.8G Max Transmitting power
: 9dBm (EIRP)
12. TROUBLESHOOTING
If you have problems using this product, check the following points
before you request service.
System
The unit will not turn on.
• Check if power cord is plugged into the outlet and the soundbar
Sound
No sound from soundbar.
• Make sure that the soundbar is not muted.
• On the remote control, select the correct audio input source
• Connect the audio cable from your soundbar to your TV or other
devices.
• However, you do not need a separate audio connection
when:
– the soundbar and TV are connected through HDMI ARC
connection, or
– a device is connected to the HDMI IN connector on your
soundbar.
• Reset your soundbar to its factory settings via press and hold
VOLUME -, VOLUME+ and SOURCE button on soundbar top
panel
Sound is strange after sound setting adjustment
• Reset audio setting by press and hold SOUND button on remote
control for 5 seconds
No sound from the wireless subwoofer.
• Check if the Subwoofer LED is in solid white colour. If white LED
is blinking, connection is lost. Pls manually pair the Subwoofer
to soundbar (see ‘Pair with the subwoofer’ on page 4).
Distorted sound or echo.
• If you play audio from the TV through the soundbar, make sure
that the TV is muted.
11
www.jbl.com
English
Audio and video are not synchronized.
• Press AUDIO SYNC +/- to synchronize the audio with the video.
Error message is displayed on the display panel.
• When “ERROR” is displayed, it indicates that an input audio
format is not supported.
• When “ERROR” is displayed in USB source, it indicates that the
connected USB device or Audio le is not supported
Video
If there is no picture on the TV Screen
• Check that the soundbar power is ON, the intended source is
ON, and the input is set correctly on the soundbar.
Bluetooth
A device cannot connect with the soundbar.
• You have not enabled the Bluetooth function of the device. See
the user manual of the device on how to enable the function.
• The soundbar is already connected with another Bluetooth
device. Press and hold BT button on remote control to
disconnect the connected device, then try again.
• The device is not correctly connected. Connect the device
correctly.
Quality of audio play from a connected Bluetooth device is poor.
• The Bluetooth reception is poor. Move the device closer to the
soundbar, or remove any obstacle between the device and the
soundbar.
The connected Bluetooth device connects and disconnects
constantly.
• The Bluetooth reception is poor. Move the device closer to the
soundbar, or remove any obstacle between the device and the
soundbar.
• For some Bluetooth device, the Bluetooth connection can be
deactivated automatically to save power. This does not indicate
any malfunction of the soundbar.
Remote Control
The remote control does not work.
• Check if the batteries are drained and replace with new batteries.
• If the distance between the remote control and the main unit
is too far, move it closer to the unit.
12
HARMAN International Industries,
Incorporated 8500 Balboa
Boulevard, Northridge, CA 91329
USA
www.jbl.com
TR04336_A
Торговая марка : JBL
Назначение товара : Активная акустическая система
Изготовитель : Харман Интернешнл Индастриз Инкорпорейтед, США, 06901 Коннектикут, г.Стэмфорд,
Атлантик Стрит 400, офис 1500
Страна происхождения : Китай
Импортер в Россию : OOO “ХАРМАН РУС СиАйЭс“, Россия, 127018, г.Москва, ул. Двинцев, д.12, к 1
Гарантийный период : 1 год
Информация о сервисных центрах : www.harman.com/ru тел. +7-800-700-0467
Срок службы : 5 лет
Товар сертифицирован
Дата производства : Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы
символов серийного номера изделия, следующих после разделительного знака «-». Кодировка
соответствует порядку букв латинского алфавита, начиная с января 2010 года: 000000-MY0000000,
где «M» - месяц производства (А - январь, B - февраль, C - март и т.д.) и «Y» - год производства
(A - 2010, B - 2011, C - 2012 и т.д.).
© 2017 HARMAN International Industries, Incorporated. All rights reserved. JBL is a
trademark of HARMAN International Industries, Incorporated, registered in the United
States and/or other countries. Features, specications and appearance are subject to
change without notice. The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by HARMAN International
Industries, Incorporated is under license. Other trademarks and trade names are
those of their respective owners. The terms HDMI, the HDMI logo, and High-Denition
Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in
the United States and other countries. Dolby, Dolby Audio, Pro Logic, and the double-D
symbol are trademarks of Dolby Laboratories.
