Installing the Wireless Monitoring System
When installing the camera, check the reception of the monitor before final installation.
Have someone to hold the camera in the area to be monitored. Have another person move
the monitor to a variety of locations throughout the house to check reception. If interference
or other problems occur, refer to the Troubleshooting Guide.
To install the system, follow these steps:
Camera:
1. Plug the 10V AC/DC adapter cord into the DC Input Jack on the back of the camera.
2. Plug the adapter into a standard (110V-240V) AC outlet. Push the Power ON/OFF switch
to ON position. The power indicator LED should light.
3. Or use battery for power supply (The life time for 4 pcs "AA" size battery operation
is 45 minutes)
Monitor:
1. Plug the 5V AC/DC adapter cord into the DC Input Jack on the side of the monitor.
2. Plug the adapter into a standard (110V-240V) AC outlet. Press the power button to turn on
the monitor.
3. A/V outputs on the LCD monitor can be connected to the A/V input on a TV set for a large
screen display, or to the A/V inputs on a VCR for recording.
4. A/V inputs on the LCD monitor can be directly connected to the camera with A/V cable
(included in the package), or connect to the A/V output on a VCR for watching video on the
monitor.
5. You can use either AC/DC adapter for long time use or 4 AA" battery for mobile use. The
life time of 4 AA" battery operation is 45 minutes.
System Installation:
1. Select the channel (Channel 1-4) to be used on both the camera and monitor.
NOTE: Make sure the camera and monitor are set to the same channel (1, 2, 3 or 4).
2. Set the selected channel by gently pushing the dip-switch for that channel to the ON
position on the camera.
For example, to set both the camera and monitor on Channel 1:
(a) Push the Channel 1 dip-switch located on the back of the
camera and the front of the monitor to the ON position.
(b) Make sure the remaining dip-switches are in the OFF
position. In this case, channels 2, 3 and 4 should be in
the OFF position.
(c) Press the Channel Slection Key on the monitor to select
Channel.
3. Position the camera angle for best view of monitored area.
4. Position the camera antenna toward the monitor antenna. Rotate/adjust the antennas on
both the camera and monitor for best performance.
5. Adjust the Volume Control on the side of the monitor to desired level.
6. Adjust the Brightness by using Brightness Control on the side of the monitor.
ON
1 2 3 4
Specifications
MONITOR:
SCREEN SIZE 2.5" TFT LCD
DOT PITCH 0.1025 x 0.163mm
RESOLUTION 480 x 234
POWER SUPPLY 5V DC, 1.5A
OPERATING TEMP. 32°F - 122°F
0°C - 50°C
Screen Size 2.45 Diagonal Inch
BATTERY 4 "AA" Size Batteries
(Last for 45 minutes, Batteries Not Included)
AUDIO OUTPUT 600 ohms / 1V p-p
Active Area 49.2 x 38.142 mm
CAMERA:
IMAGE SENSOR 1/3" Color CMOS
Image Sensor
RESOLUTION 300 Horizontal
TV Lines
LENS 6mm
ILLUMINATION O Lux with IR
up to 10 feet
POWER 10V DC, 600 mA
CONSUMPTION 1.3 Watts
OPERATING TEMP. 32°F - 122°F
0°C - 50°C
WEIGHT Approx. 0.46LB/206g
BATTERY 4 "AA" Size Batteries
(Last for 45 minutes, Batteries Not Included)
DIMENSIONS Approx. 4.5" x 2.8" x 2.4"
11.4 x 7.3 x 6cm (LxWxH)
FCC/CE WARNING
This equipment generates and uses radio frequency energy and if not installed and used properly,
that is, in strict accordance with the manufacture's instructions, may cause interference to radio and
television reception. It has been tested and found to comply with limits for a Class B digital device in
accordance with Part 15 of FCC Rules and CE I-ETS 300 440, which are designed to provide
reasonable protection against such interference in a residential installation. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
1. Reorient the TV/radio antenna.
2. Relocate the Receiver away from the TV/radio receiver.
3. Plug the Receiver into a different wall outlet so that the Receiver is on a different branch circuit.
4. If necessary, the user should consult the dealer or an experienced radio/television technician for
additional suggestions.
The user may find the following booklet prepared by the Federal Communication Commission helpful:
"How to Identify and Resolve TV Interference Problems." This booklet is available from the US
Government Printing Office, Washington, D.C. 20402, Stock No. 004-000-00345-4.
FCC/CE NOTICE
The user is cautioned that changes or modifications not expressly approved by the manufacturer
could void the user's authority to operate the equipment. Linear radio controls provide a reliable
communications link and fill an important need in portable wireless signaling. However, there are
some limitations which must be observed.
The radios are required to comply with FCC Rules and Regulations as Part 15 devices and CE I-ETS
300 440. As such, they have limited transmitter power and therefore limited range. A receiver cannot
respond to more than one transmitted signal at a time and may be blocked by radio signals that occur
on or near their operating frequencies. Changes or modifications to the device may void FCC and CE
compliance. Infrequently used radio links should be tested regularly to protect against undetected
interference or fault.
