Jada Toys JT49RX91000 9” Chub City RC and 4.5” Chub City RC. User Manual 83047 IS US01 Back

Jada Toys Company Limited 9” Chub City RC and 4.5” Chub City RC. 83047 IS US01 Back

Contents

User Manual 2

Operations Tips:
Locate the transmitter antenna mount
on the top of the transmitter. Insert the
antenna into the mount opening and
rotate in a clockwise direction until snug.
Car: ON / OFF switch located on the
bottom of the car.
Transmitter: ON / OFF switch located on
the front of the transmitter.
When you ready to run, please make sure
push the ON / OFF switches to “ON”
position on both. Go to get fun.
TRANSMITTER CONTROLLER
BOTTOM OF
TRANSMITTER CONTROLLER
©2006 Jada Toys, Inc.
City of Industry, CA 91748 USA
CHUB CITY® is a registered trademarks of
Jada Toys, Inc.
All Rights Reserved.
83047-IS-US02
To replace batteries
remove screw on battery
cover as shown in
illustration and replace
batteries
FRONT
REAR
6 x AA Batteries
(Not Included)
Steering Dial
TO ADJUST STEERING ALIGNMENT
Adjust the steering alignment lever on
the underside of the vehicle when the
vehicle doesn’t run straight forward.
steering alignment lever
Keep these instructions for future reference: they contain
important information.
IMPORTANT: Please read all “Consumer
Information” before operating your vehicle.
CAUTION:
ELECTRICALLY OPERATED PRODUCT
Not recommended for children under 8 years of age. As
with all electric products, precautions should be observed
during handling and use to prevent electric shock.
ADULT SUPERVISION REQUIRED.
Surfaces may become hot and cause burns if electronics
get wet. Do not operate vehicle through water or snow.
Consumer Information:
Note to Adults: to ensure that the child’s play is both
safe and fun, please review all operating instructions and
safety rules with your child.
CONTENTS
Vehicle
Transmitter Controller
Antenna for Transmitter Controller
Safety Tips
• NEVER drive your vehicle on streets! They’re for real
cars!
• DO NOT pick up vehicle while in motion.
• Avoid collisions with wall or hard surfaces.
• Keep fingers, hair and loose clothing away from tires
and the wheel hubs while the vehicle is switched ON.
• Adult supervision is recommended when this vehicle is
being operated.
• To avoid accidental operation, remove all batteries when
not in use.
• Be sure to rest your vehicle for at least 5 minutes
after every 15 minutes of operation.
BEFORE BATTERY INSTALLATION
Your new R/C is designed to work with standard 6 (six)
“AA” alkaline batteries, sold separately.
Controller is designed to work with a 9-volt alkaline battery,
sold separately.
INSTALLING BATTERIES IN THE R/C
6 (six) “AA” Alkaline batteries (Not included)
1. Push the ON/OFF to “OFF” position on vehicle.
2. Using a Phillips screwdriver (not included), to
remove the battery compartment door underneath
the vehicle. (See diagram 1)
3. Take out the battery cartridge from the battery
compartment.
4. Insert the 6 “AA” batteries, with polarity (+/-) as
shown inside battery cartridge.
5. Insert the battery cartridge with correct polarity (+/-)
into the battery compartment.
6. Replace the battery compartment door and use
Phillips screwdriver to lock the compartment door.
INSTALLING CONTROLLER –
9 VOLT BATTERY
1 (one) 9V Alkaline battery (not included)
1. Open the battery cover as shown (See Diagram 2 )
2. Install one 9V battery with polarity (+/-) as shown
inside battery compartment.
3. Replace battery cover.
Battery Safety Information
• Insure that battery polarity is correct.
• Use only batteries of the type recommended
(or equivalent).
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
• Remove used-up batteries immediately. Remove
batteries if vehicle will not be used for a long period of
time to prevent possible leakage.
• Do not recharge non-rechargeable batteries.
• Do not short-circuit terminals.
• Dispose of batteries safely. Do not dispose of batteries
(or products containing non-replaceable batteries) in
fire, as batteries may explode or leak.
QUICK TIPS
• When your vehicle starts to lose power, it may lose
functions or performance. It’s time for fresh batteries
(or a recharge). Your vehicle’s running time may vary
depending on your driving style.
• Radio interference can make your vehicle run badly.
Interference can be caused by other R/C vehicles
running on the same frequency; electrical wires, large
buildings; or CB radios. Try to stay away from these!
• Point your transmitter controller antenna up – not down
toward your vehicle. If your vehicle gets too far away, it
won’t work properly.
• Don’t drive your vehicle in sand or through water or
snow.
• Don’t store your vehicle near heat or in direct sunlight.
Always turn switches OFF and remove all batteries
for storage.
Cleaning instruction:
To clean, wipe excess dirt from toy. Remove batteries first.
Wipe toy clean with wet cloth using plain water. Wipe dry.
DO NOT IMMERSE IN WATER and DO NOT CLEAN
VEHICLE WITH ANY CHEMICALS. Let the toy completely
dry up before putting batteries back into clean, dry battery
compartment.
Power on
LED Light Up Left / Right
Screw On
On / Off
Reverse
Forward
Insert 9 volt
battery into
transmitter
