Jeckson Electric 547-47-1013-T Remote Controller User Manual 47 1013A 090312
Jeckson Electric Co., Ltd Remote Controller 47 1013A 090312
Manual
1
Owner's Manual
Wall Switch Style RF Controller, 433MHz
MODEL: 47-1013A-T, 47-1013B-T
FCC ID: ELY547-47-1013-T IC 1492 A-471013T
REMOTE CONTROL
The remote control has a range of approximately 50 ft. (15.25m), it does not have to be
pointed at the fireplace and can pass through most obstacles (including walls).
BATTERY INSTALLATION
1. Depress tab on the battery cover on the side of the remote transmitter and remove
battery cover.
2. Install 2 AAA batteries into the remote control. (included)
3. Replace the battery cover.
AC24V INSTALLATION
1. Depress tab on the cover on the back of the remote transmitter and remove the wire
compartment cover.
2. Remove the 2 lead wires from the wire compartment.
3. Connect the wires to the AC24V hard wires.
4. Replace the cover.
Note: There is an internal electronic switch to disconnect the AAA Battery
power supply when the AC24V~ hard wire hook up is made.
FLAME ON/OFF BUTTON
Press the right to turn the Flame ON or press the left to turn the Flame OFF.
PURIFIRE ON/OFF BUTTON (For 47-1013A-T version only)
Press the right to turn the Purifire ON or press the left to turn the Purifire OFF.
COUNTDOWN TIMER (For 47-1013B-T version only)
To set the Countdown timer, press the left or right buttons to decrease or
increase by 30 minute decrements or increments. The countdown timer can be set from 30
2
minutes to 6 hours. The fireplace will automatically turn OFF when the sleep timer reaches
0 minutes.
SET TEMPERATURE
Press the left or right direction button together of to select between °F
and °C.
Press the left or right direction button to decrease or to increase temperature.
Temperature Range 0°C - 37°C (32°F - 99°F).
CAUTION
1. For indoor use in dry areas only.
2. 24 volt AC supply.
3
WARNING
Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
SPECIFICATIONS
Input Rating…….………………………………………...AC 24V~ or DC3V (Alkaline AA x 2)
Operation Temperature…………………………………….……..……………….... -10 to 70℃
Storage Temperature ………………………………………..….…………………….-25 - 60℃
