Users Manual Part 1

1
IMPORTANT SAFETY PRECAUTIONS
WARNING
INSTALLATION INSTRUCTION PRECAUTIONS:
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is specifically designed
for wet locations.
• Never touch uninsulated telephone wires or terminals unless the telephone line has
been disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
Before using your telephone equipment, basic safety precautions must always be followed
to reduce the risk of fire, electric shock and injury to persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on this product.
3. Unplug this product from the wall telephone jack and power outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water- for example, near a bathtub, washbowl, kitchen
sink, or laundry tub, in a wet basement, or near a swimming pool.
5. Do not place this product on an unstable cart, stand, tripod, bracket, or table. The
product may fall, causing serious injury and serious damage to the product.
6. Slots and openings in the cabinet and in the back or bottom are provided for
ventilation and to ensure reliable operation of the product and to protect it from
overheating. These openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed, sofa, rug, or other similar
surface. This product should never be placed near or over a radiator or heat
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The lightning flash with
arrowhead symbol,
within an equilateral
triangle is intended to
alert the user to the
presence of uninsulated
‘dangerous voltage’
within the product’s
enclosure that may be of
sufficient magnitude to
constitute a risk of elec-
tric shock to persons.
CAUTION: TO REDUCE
THE RISK OF ELECTRIC
SHOCK DO NOT
REMOVE COVER (OR
BACK), NO USER
SERVICEABLE PARTS
INSIDE. REFER
SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
The exclamation point
within an equilateral
triangle is intended to
alert the user to the
presence of important
operating and
maintenance (servicing)
instructions in the
literature accompanying
the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
HK250.O/M.QXD 8/30/02 1:19 PM Page 1
source. This product should not be placed in an enclosed environment unless
proper ventilation is provided.
7. This product should be operated only from the type of power source indicated on
the marking label. If you are not sure of the type of power supply to your home,
consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this product where
the cord will be abused by persons walking on it. Do not attach power cord to
building surfaces.
9. Do not overload wall outlets and extension cords as this can result in the risk of fire
or electric shock.
10. Never push objects of any kind into this product through openings as they may
touch dangerous voltage points or short out parts that could result in fire or electric
shock. Never spill or spray any type of liquid on the product.
11. To reduce the risk of electric shock, do not disassemble this product, but take it to a
qualified serviceman when some service or repair work is required. Opening or
removing covers may expose you to dangerous voltages or other risks. Incorrect
re-assembly can cause electric shock when the appliance is subsequently used.
12. Unplug the product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a. When the power-supply cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions, as an adjustment of other controls may result in damage and
will often require extensive work by a qualified technician to restore the
product to its normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance.
13. Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electric shock from lightning.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
SAVE THESE INSTRUCTIONS
BATTERY PRECAUTIONS
To reduce the risk of fire or injury to persons, read and follow these instructions.
1. Use only a 3.6V, 600MaH Ni-MH rechargeable battery in this unit.
2. Do not dispose of the battery in a fire, the cells may explode. Check with local codes
for possible special disposal instructions.
3. Do not open or mutilate the battery as released electrolyte is corrosive and may
cause damage to the eyes or skin. It may be toxic if swallowed.
4. Exercise care in handling the batteries in order not to short the battery with
conducting material such as rings, bracelets and keys. The battery or conductors
may overheat and cause burns.
2
IMPORTANT SAFETY PRECAUTIONS (CONTINUED)
HK250.O/M.QXD 8/30/02 1:19 PM Page 2
FCC wants you to know
This equipment complied with part 68 of the FCC rules ACTA technical requirements.
On the bottom of the base of this equipment is a label that contains, among other
information, the FCC Registration Number and Ringer Equivalence Number (REN) for
this equipment. You must, upon request, provide this information to your telephone
company.
The USOC number of the registration jack for the equipment is RJ11C.
The FCC compliant telephone cord and modular plug is provided with this equipment.
This equipment is designed to be connected to the telephone network or premises
wiring using a compatible modular jack which is TIA/EIA-IS-968 compliant.
The REN is useful to determine the quantity of devices you may connect to your
telephone line and still have all of those devices ring when your telephone number is
called. In most, by not all areas, the sum of the RENs of all devices connected to one
line should not exceed five (5.0). To be certain of the number of devices you may
connect to your line, as determined by the REN, you should contact your local
telephone company to determine the maximum REN for your calling area.
If your telephone equipment causes harm to the telephone network, the telephone
company may discontinue your service temporarily. If possible, they will notify you in
advance. But, if advance notice isn’t practical, you will be notified as soon as possible.
You will be informed of your right to file a complaint with the FCC.
Your telephone company may make changes in its facilities, equipment, operations or
procedures that could affect the proper functioning of your equipment. If they do, you
will be notified in advance to give you an opportunity to maintain uninterrupted
telephone service. If you experience trouble with this telephone equipment, the
telephone company may ask that you disconnect this equipment from the network until
the problem has been corrected or until you are sure that the equipment is not
malfunctioning.
This equipment cannot be used on telephone company provided coin service.
Connection to Party Line Service is subject to state tariffs.
This equipment is hearing aid compatible.
Warnings:
•Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
• When your telephone is not in use, make sure the handset is engaged into the base unit.
• If it is determined that your telephone is malfunctioning, the FCC requires that it be
disconnected from the modular outlet until the problem has been corrected.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
3
IMPORTANT SAFETY PRECAUTIONS (CONTINUED)
HK250.O/M.QXD 8/30/02 1:19 PM Page 3
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is needed.
• Consult the dealer or an experienced radio/TV technician for help.
1. If your local telephone exchange only accepts Pulse dialing, you may have to
switch the Tone/Pulse switch to Tone to access certain services that require
Tone signalling (such as home banking). After the initial line is connected to the
number you are calling, switch the Tone/Pulse switch to Tone to access Tone
signalling. When you have completed your call, switch the Tone/Pulse switch
back to Pulse.
2. Hearing aid compatibility - Your telephone is compatible for use with hearing
aids.
3. If there is a problem with this unit, the telephone company may ask you to
disconnect this equipment from the network until the problem has been corrected
or you are sure that the equipment is not malfunctioning.
4
IMPORTANT SAFETY PRECAUTIONS (CONTINUED)
Welcome to the world of Hello Kitty
My friends at Emerson Radio Corp. are producing this Hello Kitty Caller ID*Cordless
Telephone, under license from Sanrio Company Ltd. We have taken great care to
make sure your telephone was in perfect working order when it left our factory. It has
been designed to give you many years of enjoyment and trouble free operation.
Read this manual before operating this unit to become familiar with its features. In
the event you require technical assistance, please contact my friends at the Emerson
Radio Consumer Affairs Department at 1-800-898-9020. Retain this manual for
future reference.
In the space provided, record the serial number.
Model: HK250
Serial Number _______________________________________
* You must subscribe to caller ID service from your local telephone company to
receive caller identification.
WELCOME
HK250.O/M.QXD 8/30/02 1:19 PM Page 4
5
LOCATION OF CONTROLS AND INDICATORS
1
2
3
5
7
10
11
13
19
20
18
16
17
15
14
21
12
8
9
6
4
HANDSET
24
26
25
23
22 27
28
BASE
HANDSET:
1. Belt Clip
2. Earpiece
3. Display
4. REVIEW/VOLUME /❷Buttons
5. CID Button
6. TALK Button
7. ERASE Button
8. RINGER ON/OFF Switch
9. Key Buttons (0-9)
10. */TONE/➛Button
11. FLASH Button
12. MEMO (Memory) Button
13. Microphone
14. Antenna
15. PROG (Program) Button
16. CHN (Channel) Button
17. Headset Jack
18. #/❿Button
19. REDIAL Button
20. PAUSE Button
21. Battery Compartment (Rear of Unit)
BASE:
22. TEL LINE Jack (Bottom of Base)
23. Hello Kitty Figure
24. PAGE Button
25. IN USE/Incoming Call Indicator
26. CHARGE Indicator
27. DC IN Jack (Rear of Base)
28. TONE/PULSE Switch
HK250.O/M.QXD 8/30/02 1:19 PM Page 5
6
LOCATION OF CONTROLS AND INDICATORS (CONTINUED)
7
8
9
2
1
34 56
JUDI SMITH
973-555-1234
1. MEM (Memory) Indicator - Indicates the unit is in Memory Dial Programming
mode or Memory Dialing mode.
2. REP (Repeat) Indicator - Indicates how many phone calls have been made
from the same telephone number.
3. NEW Indicator - Indicates the number of new caller ID data items that have not
been reviewed.
4. TOTAL Indicator - Indicates the total number of stored ID data items.
5. Arrow Indicators - Indicates which arrow button can be used.
6. PROG (Program) Indicator - Indicates the unit is in Programming mode.
7. Message (“ ”) Indicator - Indicates that mailbox in the central office has a
message. If you have subscribed to Voice Mail message service and you have
requested Visual Message Indication from your phone company, “ ” will
appear on the LCD screen when in the Standby mode.
8. VIP Indicator - Indicates that priority ringer has been set for the displayed
number.
9. Name/Number Indicator - Name and number of incoming call.
LCD BACK LIGHT
The LCD is back lit under the following conditions:
1. While receiving an incoming call (during ringing).
2. For 10 seconds, when the handset is picked up from the cradle.
3. For 10 seconds, when any button is pressed in the Programming mode, Caller
ID Review mode or Stored Number Review mode.
4. For 10 seconds, when any button is pressed in any mode other than those
listed above.
The LCD back light will go off 10 seconds after the Talk mode is terminated by
pressing the TALK button or immediately after the handset is placed in the base.
DISPLAY
HK250.O/M.QXD 8/30/02 1:19 PM Page 6
1. Carefully unpack and remove your unit from the box.
2. Make sure all of the following items have been included:
3. Make sure the Rechargeable Battery is installed or install the Rechargeable
Battery as described on the next page.
PLEASE REFER TO THE FOLLOWING DIAGRAM FOR STEPS 4 THROUGH 7:
4. Slide the TONE/PULSE switch on the side of the Base unit to TONE or PULSE
to match the service provided on your telephone line. If you are not sure of your
service, please contact your telephone company. The factory preset position for
this switch is TONE.
5. Connect one end of the telephone line cord into the TEL LINE jack on the
bottom of the base unit and the other end into a modular telephone jack.
6. Insert the small plug at the end of the AC adapter into the DC IN jack located at
the rear of the base unit.
NOTE: Use only the AC adapter provided with your unit.
7. Plug the AC adapter into a standard 120V AC wall outlet.
7
INSTALLATION INSTRUCTIONS
• Base Unit
• Handset Unit
• Rechargeable Ni-MH Battery Pack
• AC Adapter
• Telephone Cord
• Memory Label
HK250.O/M.QXD 8/30/02 1:19 PM Page 7
8
INSTALLATION INSTRUCTIONS (CONTINUED)
Remove the battery cover located on
the rear of the handset by pressing on
the top cover and sliding it downward.
1
Plug the new battery into the recharge-
able battery plug and insert the
rechargeable battery into the battery
compartment.
NOTE: The plug will fit only one way. If
you have difficulty, be sure the plug
and socket are aligned properly.
2
Put the battery cover back on by
sliding it upward until it clicks into
place.
3
Installation of the Rechargeable Battery
Charging the Rechargeable Battery
Be sure the rechargeable battery be fully charged 12 hours prior to initial
use. The handset’s rechargeable battery will be charged when it’s on the base’s
charge contacts; the CHARGE indicator will light when it is placed in the base.
NOTES:
• LOW BATTERY will appear in the display and the handset will beep every 30
seconds when the battery power is low and needs recharging. If the battery
becomes weak while you are on a call, the TALK indicator will blink and the
handset will beep once; end the call immediately and return to the base for
recharging.
• Every few months, or when charging becomes abnormal, clean the contacts of
the handset and the base with a standard pencil eraser.
• To maximize battery life, fully discharge the battery every month or two. To do
this, simply unplug the telephone line cord and press the TALK button until the
battery is discharged, and then recharge it.
HK250.O/M.QXD 8/30/02 1:19 PM Page 8
9
SET-UP INSTRUCTIONS
SETTING THE LANGUAGE
Set the language (ENGLISH, SPANISH, FRENCH) as follows:
Press and hold the ERASE button ❶
for more than two seconds or press
the TALK button ❷ twice to clear any
displayed number and return to the
Standby mode.
2
1
1
While in the Standby mode, press the
PROG button.
2
Press the REVIEW/VOLUME
button ❶ once or the REVIEW/
VOLUME❷button ❷ three times to
enter the Language menu.
1
2
3
Press the ➛or ❿button ❶ to select
the desired language (ENGLISH,
SPANISH, FRENCH).
4
Press the PROG button again to store
the language; “Save ok” will appear in
the display for three seconds and a
confirmation tone will be heard.
5
HK250.O/M.QXD 8/30/02 1:19 PM Page 9
10
SET-UP INSTRUCTIONS (CONTINUED)
SETTING THE AREA CODE
In order for the Caller ID redial feature to work properly, you must set the phone to
your local area code as described below. If you live in a town with more than one
area code, do not enter an area code for this option.
Press and hold the ERASE button ❶
for more than two seconds or press
the TALK button ❷ twice to clear any
displayed number and return to the
Standby mode.
2
1
1
While in the Standby mode, press the
PROG button.
2
Press the REVIEW/VOLUME
button ❶ twice or the REVIEW/
VOLUME❷button ❷ twice to enter the
Area Code menu.
1
2
3
Use the Key buttons to enter in the
area code.
4
Press the PROG button again to store
the area code; “Save ok” will appear in
the display for three seconds and a
confirmation tone will be heard.
5
HK250.O/M.QXD 8/30/02 1:19 PM Page 10
11
SETTING THE LCD CONTRAST
If you find the LCD screen difficult to read, set the contrast level as follows:
Press and hold the ERASE button ❶
for more than two seconds or press
the TALK button ❷ twice to clear any
displayed number and return to the
Standby mode.
2
1
1
While in the Standby mode, press the
PROG button.
2
Press the REVIEW/VOLUME
button ❶ three times or the REVIEW/
VOLUME❷button ❷ once to enter the
Contrast menu.
1
2
3
Press the ➛or ❿button to select one
of the three contrast levels (3 being
the darkest, 1 being the lightest).
4
Press the PROG button again to store
the contrast level; “Save ok” will
appear in the display for three seconds
and a confirmation tone will be heard.
5
SET-UP INSTRUCTIONS (CONTINUED)
HK250.O/M.QXD 8/30/02 1:19 PM Page 11
12
BASIC OPERATION
PLACING A CALL
After the battery has been fully charged,
press the TALK button and listen for a
dial tone; the timer will appear in the
display.
1
Press the Key buttons (0-9) to dial the
phone number you wish to call. Ten
seconds after dialing, the display will
show the amount of time you have
been on the phone.
2
RINGER SWITCH
AUTO TALK AND AUTO STANDBY
The Auto Talk feature will allow you to answer a call by simply removing it from the
base, there is no need to press the TALK button.
The Auto Standby feature allows you to hang up the phone by simply returning it to
the base.
Slide the RINGER ON/OFF switch on
the side of the handset to the ON
position to turn the ringer on. Slide the
RINGER switch to the OFF position to
turn the ringer off.
1
TONE/PULSE SWITCH
Slide the TONE/PULSE switch on the
side of the base to TONE or PULSE to
match the service provided on your
telephone line. If you are not sure of
your service, please contact your
telephone company.
1
CONNECTING THE HEADSET
For hands-free conversation, a headset (not included) can be connected to the
2.5mm headset jack on the side of the handset unit. The handset receiver and
microphone are disabled when a headset is connected. When the headset is
connected, press the TALK button to answer or place a call. Refer to the headset
manufacturer’s manual for more details.
HK250.O/M.QXD 8/30/02 1:19 PM Page 12
13
RECEIVING A CALL
The last 99 incoming calls are saved in the Caller ID log.
Make sure that the Caller ID service is turned on by your phone company. When
you receive a call, the display will show the name of the caller and number of the
call. To answer the call if the handset is out of the base, press the TALK button. If
the handset is in the base, simply remove it from the base. The display will show
the amount of time you have been on the phone.
1
NOTES:
• The incoming call indicator will blink on the base unit, even if the RINGER
switch is off and a call is received.
• If you subscribe to Caller ID, the time and date are automatically set when the
first call is received.
• If a call is received from an area which does not provide caller ID service, the
display will show, “UNKNOWN”. If a call is received from outside the Caller ID
area, the display will show, “OUT OF AREA”.
• If a call is received from a caller that has blocked his/her information, the
display will show, “PRIVATE CALL”.
• Calls picked up on the first ring will not be logged in the Caller ID log.
• Call Waiting calls are shown in the Caller ID log if you subscribe to the extra
feature from the phone company that allows this.
• If there are new calls, “NEW” will blink in the display.
• If a call is received from the same number more than once since the last
records were reviewed, no new entry is made, but the repeat (REP) indicator
and the number of repeat calls is displayed.
BASIC OPERATION (CONTINUED)
HK250.O/M.QXD 8/30/02 1:19 PM Page 13
14
BASIC OPERATION (CONTINUED)
REDIALING A NUMBER
Press the TALK button ❶, followed by
the REDIAL button ❷ to automatically
redial the last number dialed on this
handset (up to 32 digits).
NOTE: Please note that only the last
number you called on this handset can
be stored in the Redial memory.
2
1
1
ENDING A CALL
To end a call, simply return the
handset to the base, or press the
TALK button on the handset.
1
ADJUSTING EARPIECE VOLUME
To adjust the volume in the earpiece,
simply press the REVIEW/VOLUME
/❷buttons during a call until the
desired volume level is reached.
1
CHANNEL SELECTION
This telephone allows you to select a
channel from the frequencies available
to transmit signals from the base unit
to the handset. If the existing channel
becomes noisy or starts having
interference while in the Talk mode,
press the CHN (Channel) button on
the handset for better reception.
1
OUT OF RANGE WARNING
The handset and base communicate up to a maximum range. The distance can
be affected by the weather, power lines or other cordless telephones. You are out
of range and should move closer when:
• You hear noise or static.
• Pressing the TALK button generates three short beeps.
• Pressing the CID button when a number is displayed generates three short
beeps.
• You cannot receive an incoming call.
HK250.O/M.QXD 8/30/02 1:19 PM Page 14

Navigation menu
