Johnson Controls Interiors HMIHL4 HomeLink Universal Garage Door Opener User Manual

Users Manual



DaimlerNEWHMIHomelink

DiamlerHMLKHMI2067207FCCID:CB2HMIHL4CanadianID:279B‐HMIHL4Model:HMIHL4

Clearallchannels:

1. Pressbutton1and3atthesametimefor>10seconds.(LEDis“yellow“)

2. LEDswitchestoconst.“green“,ifallchannelsarecleared.

Trainanoriginaltransmitter(OT):

1. Allchannelsarecleared

2. PresstheHomeLinkbutton,whichshouldbeprogrammed,forca.1secondandreleasethebutton.

(LEDblinks“yellow“)

3. Presstheappropriatebuttonoftheoriginaltransmitter(OT)

4. LEDswitchesconst.to“green“,ifaFix‐CodeSystemissuccessfullytrained.

5. LEDswitchesconstto“yellow“,ifaRolling‐CodeSystemissuccessfullytrained.The“yellow”LED

indicatesthattheHomeLinkmustbesynchronizedwiththeOTreceiver.Ifyoupressthebuttonagain

theLEDblinksfast“green”

6. Failureduringprogramming=LEDswitchesto“red“

WhenaHomelink©IVbuttonispressed

1. AVoltageControlledOscillator(VCO)issettodesiredRFcarrierfrequency(recalledfromtheNVM).

2. Theantennaisfinetunedbysweepingaroundthestoredtuningpointwithaseriesoffinepulsesof

approximately300uSindurationwith9.6mSoff.

3. TheVCOsignalisthenmodulatedwiththeappropriategaragedooropenerbitcodefromtheNVM.

FCCComplianceandWarning

ThisdevicecomplieswithPart15oftheFCCrulesandwithRSS‐210oftheIndustryCanada.Operationis

subjecttothefollowingtwoconditions:

(1) Thisdevicemaynotcauseharmfulinterference,

(2) Thisdevicemustacceptanyinterferencethatmaybereceivedincludinginterferencethatmaycause

undesiredoperation.



WARNING:ThetransmitterhasbeentestedandcomplieswithFCCandIndustryCanadarules.Changesor

modificationsnotexpresslyapprovedbythepartyresponsibleforthecompliancecouldvoidtheuser’s

authoritytooperatethedevice.”


