Jonter Digital D40F Bluetooth speaker User Manual JONTER
Shenzhen Jonter Digital Co., Ltd Bluetooth speaker JONTER
User Manual
Jonter
D40F User Manual
Thanks to purchase our product. Please read the operation manual carefully
for better operation and enjoy your music.
Attachements:
1. Bluetooth Speaker x 1 pcs
2. Instruction manual x 1 pcs
Key identification:
1. : Vol-/Prev music
Short press for decrease volume, long press for change to previous music
2. ：Vol+/Next music
Short press for increase volume, long press for change to next music
3. ：Pause/Play/disconnect Bluetooth
Short press for play and pause, long press for disconnect bluetooth
4. :Turn on/off
Bluetooth Mode:
1. Power on the unit, the light on the top of speaker will flash quickly with the
voice which means the speaker is in defaulted bluetooth mode and waiting for
pairing.
2. Then you can searching the Bluetooth device “D40F” on your cell phone or
other devices, then you will hear”didi” sound when the unit is paired
successfully.
3. Short Press the key to pause or play the music.long press for
disconnect the bluetooth.
4 LongPress / key for next/previous track selection
5 short Press / key for Volume up/down
.
Handfree function:
In Bluetooth mode, when there have a phone call coming, you can press the
key on the speaker to pick up the call directly and press it again to hang
up.
To reject call, quickly press twice to reject
AUX Mode:
Power on the unit, using a 3.5mm audio cable to connect your phone or other
devices with the “D40F”, the LED of this speaker will become red which was
indicate the speaker turns into AUX mode. Then you can play the music via
your phone or computer.
Attention: only worked for volume adjust. Pls change the music
through your device.
TF Mode:
Power on the unit, insert TF card into the speaker slot, the LED of this speaker
will become red which was indicate the speaker turns into TF card mode.
Charging:
The unit has built in a rechargeable battery inside, before play the speaker,
please follow up below step to charge the unit first.
1. Using the supplied USB cable to connect the DC 5V jack, and another
terminal connect with USB power like PC or other universal USB power.
2. During the charging, the red color LED indicator on the side will turn on,
and it will be off when the unit is fully charged.
NOTE: This equipment has been tested and found to comply with the limits for
a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which
can be determined by turning the equipment off and on, the user is
encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance
could void the user's authority to operate the equipment. This device complies
with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may
cause undesired operation.
FCC ID: 2AB9SD40F
