Jonter Digital D8 Bluetooth speaker User Manual
Shenzhen Jonter Digital Co., Ltd Bluetooth speaker
User Manual
MODEL: D8
User Manual
Bluetooth speaker
1
ACCESSORIES
×1
USE R MANUA L
×1×1 ×1
USB Cord ×1
Instrction Book ×1
Wireless Speaker ×1
Audio cable ×1
SPECIFCATION
Bluetooth Version
Frequency Range
Bluetooth Mode
Bluetooth Range
Battery Capacity
Playing time
Waterproof level
Size
V2.1+EDR
2.402-2.4835GHz
A2DP/AVRCP/HFP/HSP
>10m
800mAH
6~8hours
IPX7
L80×W80×H35 mm
Weight 182g
PRODUCT DIAGRAM
Power on/off Button
Play/Pause
Button
SOS Button
Line-in
USB Charging
port
Indicator light
2
CHARGING THE SPEAKER
You must charge the speaker fully before using the speaker
for the first time.
Connect the USB charging cable to the USB charge port
of the speaker. The red indicator will turn on when charging
and turn off when charging completed.
The full charge takes about 2~3hours.
1.
2.
When the battery low alert tone sounds about every 60 seconds
Indicate that the battery has run out. Please change Mpow
AquaPro as soon as possible.
LOW-VOLTAGE ALERT
POWER ON/OFF
POWER ON: Long press the “ ”for about 2 seconds until
the blue indicator light turns on with indication tone.
POWER OFF: Long press the“ ”for about 3 seconds until
the blue indicator light turns off with indication tone.
PAIR TO YOUR PHONE
Di stan ce <1m
Long press the “ ”for about 2
seconds until the blue indicator light
turns on with indication tone.
Then long press “ ”for
about 2seconds with
indication tone.
1
2
Set ti ng B lu et oo th
Blue to oth
Turn on the Bluetooth function of your phone, Search for the
Bluetooth devices and select “Mpow AquaPro”with indication
tone.
Setti ng B lu et oo th
Blue to ot h
DEVICES
Mpow Aq ua Pr o
Mpow AquaPro
3Enter the code “0000” if needed.
CONN EC TED
4If paring is successful, the
blue indicator turns on.
AUTOMATIC CONNECT
It will connect to the last connected phone automatically
when it turns on.(Please make sure the Bluetooth function
of your phone is on before turn on the speaker.)
PLAYING MUSIC
Play/Pause:Short press “ ”
Next song: Long press “ ”
Previous song: Long press “ ”
Volume up: Short press “ ”
Volume down: short press “ ”
ANSWERING/ENDING A CALL
press “ ” to answer an incoming call and press again to
end a call. Double press “ ” to answer rejecet an
incoming call.
SOS Button
Long pres
SO
s “ ” 2
S
second to activate “SOS function”.
Long pres
SO
s “ ” 2
S
second to shut off“SOS function”.
45
3
FCC NOTE：
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS OR
CHANGE TO THIS EQUIPMENT. SUCH MODIFICATIONS OR CHANGE COULD
VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
6
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and
receiver.
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help.
Caution: Any changes or modifications not expressly approved
by the party responsible for compliance could void the user's
authority to operate this equipment.
