Jonter Digital M61F BLUETOOTH SPEAKER User Manual
Shenzhen Jonter Digital Co., Ltd BLUETOOTH SPEAKER
User Manual
M61F English Manual
Package:
1. Bluetooth Speaker x 1 pc
2. Micro USB cable x 1 pc
3. 3.5mm Audio cable x 1 pc
4. User manual x 1 pc
Function panel:
1. : Power ON/Power OFF
2. : Volume Down/ Last Track
3. : Volume Up/Next Track
4. : Play/Pause/BT disconnect
5. : Hands Free/Switch Modes
6. : DC 5V IN Charging Port
7. : Aux in
8. ：SD card slot
Bluetooth Mode:
1. Press and hold button to turn the speaker ON/OFF. Under the Bluetooth mode, the
LED light will be Blue, when the speaker is on, the LED light will keep flashing quickly.
2. Turn on the BT function of your mobile device to find “M61F” , then make speaker and mobile
device connected. When it connected, the Blue LED light will keep lighting.
3. Press and hold button to disconnect Bluetooth; Press button to Pause or Play
media. When playing, the Blue LED will flash slowly.
4. Press button to decrease volume; press and hold it to play the last track.
5. Press button to increase volume; press and hold it to play the next track.
6. When there is a coming call, press button to answer it, then press it again to hang it up.
Press and hold it to reject a coming call.
AUX IN Mode:
1. After turn the speaker on, connect your mobile device with speaker via the audio cable, Under
the AUX in mode, the LED light will be blue and keep bright.
2. Press button to Pause or Play media
3. Press button to decrease volume; press and hold it to play the last track.
4. Press button to increase volume; press and hold it to play the next track.
5. When there is a coming call, press button to answer it, then press it again to hang it
up. Press and hold it to reject a coming call.
6. Press and hold to switch to Bluetooth mode.
SD card Mode:
1. As long as you insert your SD card into the SD card slot, the speaker will turn into SD card
mode and play automatically, when playing it will flash quickly.
2. Press button to Pause or Play media
3. Press button to decrease volume; press and hold it to play the last track.
4. Press button to increase volume; press and hold it to play the next track.
Pls. Note, under SD card mode, mode switching and hands free function is not available.
Charging:
The speaker is with built in rechargeable battery, before using it, please make it full charged using
the USB cable. During the charging time, the LED light next to the charging port will be red, and it
will turn off when the speaker is full charged. It will make 2-3 hours to make the speaker full
charged.
CAUTION：
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
the battery shall not be exposed to excessive heat such as sunshine, fire or the like
NOTE: This equipment has been tested and found to comply with
the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are
designed to provide reasonable protection against harmful
interference in a
residential installation. This equipment generates uses and can
radiate radio
frequency energy and, if not installed and used in accordance with
the instructions,
may cause harmful interference to radio communications. However,
there is no
guarantee that interference will not occur in a particular installation.
If this
equipment does cause harmful interference to radio or television
reception, which
can be determined by turning the equipment off and on, the user is
encouraged to
try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party
responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may
cause undesired operation.
