Campus Connectivity MP Quick Start Guide Rev B
Campus Connectivity MP Quick Start Guide
2
Trapeze Networks
This guide provides basic hardware installation instructions for the MP-632.
Warning!
Warning! Installation must be performed by qualified service personnel only. Read and
follow all warning notices and instructions marked on the product or included in the
documentation. Before installing the product, read the rest of this document.
Warning!
Waarschuwing! De installatie mag alleen worden uitgevoerd door bevoegd
onderhoudspersoneel. Het is essentieel dat u kennis neemt van alle waarschuwingen en
instructies aangebracht op het product zelf en/of opgenomen in de documentatie.
Voordat u het product installeert, dient u dit document in zijn geheel te hebben gelezen.
Warning!
Warnung! Die Installation darf nur von qualifiziertem Servicepersonal vorgenommen
werden. Lesen und befolgen Sie alle Warnhinweise und -anleitungen auf dem Produkt
bzw. in der Dokumentation. Lesen Sie vor Installation des Produkts den restlichen Teil
dieses Dokuments.
Warning!
Avertissement! L’installation ne peut être effectuée que par un personnel qualifié.
Lisez et suivez tous les messages d’avertissement et les instructions inscrits sur le
produit ou inclus dans la documentation. Avant d’installer le produit, lisez le reste de ce
document.
Warning!
Attenzione! L’installazione deve essere effettuata unicamente da personale
qualificato. Leggere e rispettare tutte le segnalazioni di attenzione e le istruzioni
indicate sul prodotto o incluse nella documentazione. Prima d’installare il prodotto,
leggere tutto il documento.
Warning!
¡Advertencia! La instalación debe realizarse exclusivamente por parte de personal de
servicio cualificado. Lea y siga todas las notas de advertencia e instrucciones en el
producto o la documentación. Antes de instalar el producto deberá leer la parte restante
del presente documento.
Warning!
¡Advertencia! A instalação dever ser realizada exclusivamente por pessoal de serviço
qualificado. Leia e siga todas as notas de advertência e instrucões no produto ou na
documentação. Antes de instalar o produto deverá ler a parte restante do presente
documento.
Campus Connectivity MP Quick Start Guide 3
Trapeze Networks
Warning!
Varning! Installation får endast utföras av kvalificerad servicepersonal. Läs och följ
alla varningsmeddelanden och instruktioner markerade på produkten eller inkluderade
i dokumenteringen. Innan produkten installeras skall resten av dessa dokument läsas.
Warning!
Advarsel! Installation må kun gennemføres af faglært servicepersonale. Læs, og følg
alle de advarselsmeddelelser og anvisninger, der er anført på produktet eller i
dokumentationen. Læs resten af dette dokument før installation af produktet.
Warning!
Advarsel! Installasjon skal kun utføres av kvalifisert service personell. Les og følg alle
varsels meldinger og instrukssjons merkinger på produktet og i veiledningen. Les
resten av denne veiledningen før produktet installeres.
Warning!
Varoitus! Installatie dient uitsluitend plaats te vinden door bevoegde monteurs. Lees
alle waarschuwingen en instructies die op het product zijn aangegeven of in de
documentatie zijn opgenomen, en volg deze op. Lees voordat u het product installeert
eerst de rest van dit document.
Warning!
Viðvörun! Aðeins hæfir þjónustufulltrúar mega sinna uppsetningu tækjanna. Lesið og
fylgið öllum viðvörunum og leiðbeiningum í þessum gögnum. Lesið restina af þessum
gögnum fyrir uppsetningu.
Warning!
Warning!
Campus Connectivity MP Quick Start Guide
4
Trapeze Networks
❑For detailed compliance information see the Trapeze Regulatory Guide located at:
http://www.trapezenetworks.com/support/contact_support/. The guide can be downloaded
in PDF format.
Warning!
Warning!
Warning!
Warning!
Warning!
Warning!
Campus Connectivity MP Quick Start Guide 5
Trapeze Networks
A Campus Connectivity MP (MP-632) can be installed in a variety of locations, both indoors and
outdoors. If the location is set to indoors, then a limited number of available channels are displayed
for configuration. If the location is set to outdoors, only the regulatory allowed outdoor channels
appropriate for the country and domain can be configured on the MP. The default operational mode of
the MP is outdoor.
Indoor locations may include, but are not limited, to the following types:
❑Locales that require a robust MP for harsh operating environments such as low or high
temperatures.
❑Warehouse environments
❑Indoor stadiums or arenas
❑Auditoriums or very large classrooms
Outdoor locations may include, but are not limited to these following types:
❑Racetracks
❑Outdoor stadiums
❑Construction sites
❑Outdoor campus areas
MP-632
The MP-632 is a 802.11a/b/g/n AP that is designed for pole-mounting and wall mounting. The MP-632
supports 6 antenna ports, three for the 11a/n radio and three for the 11b/g/n radio. An MX cannot be
used to power this AP. An XPS-6201-OUT or XPS-6202-OUT power supply that uses the IP67
multi-pin DIN connector is required. The MP-632 supports a new set of external antennas that are
commercially available. The MP-632 does not support internal antennas or PoE.
Package Checklist
The MP-632 package includes:
❑One MP-632 Mobility Point (MP)
❑Mounting brackets, split washers and mounting hardware
❑Weather sealing caps for all 6 external antenna connectors
❑Installation manual
❑Separate package for XPS-6201-OUT or XPS-6202-OUT campus connectivity power supply.
❑Circular DIN to RJ45 dongle cable and waterproof caps for RJ45 dongle
❑Two-hole tabular lug for AWG #8 ground cable
❑Antenna connector terminator. Any unused antenna connector on an active radio must be
terminated.
Contact Trapeze Networks if there are any incorrect, missing or damaged parts. If possible, retain
the carton, including the original packing materials. Use them again to repack the product in case
there is a need to return it.
Warning!
The MP-632 must only be used with a Trapeze-approved XPS-6201-OUT or
XPS-6202-OUT campus connectivity power supply in order to prevent possible damage
to the unit.
Campus Connectivity MP Quick Start Guide
6
Trapeze Networks
Installing and Connecting an MP
Installation Requirements and Recommendations
For best results, follow these requirements and recommendations before installing a MP-632.
RingMaster Network Plan and Work Orders
If you are using RingMaster to plan your Trapeze Networks Mobility System installation, you might
want to create and verify a network plan for the entire Trapeze network installation and generate an
MP work order, before installing MP access points. A network plan and the MP work orders
generated from it provide the following information about MP access point installation and
configuration:
❑Number of MPs required for adequate WLAN capacity in each coverage area
❑Detailed installation location for each MP
❑Settings for all MP access points in the WLAN
MX Appliance Recommendation
Trapeze Networks recommends that you install and configure the MX before installing an MP. If the
MX is already installed and configured for the MPs, you can immediately verify the cable
connection(s) when you plug the cable(s) into the MP.
Weather Conditions
When planning a MP-632 installation, you must take into account any extreme weather conditions
that are known to affect your location. Consider the following factors:
Temperature
Operating an MP in temperatures outside of the supported range may cause the unit to fail. The
MP-632 is tested for an ambient operating temperature range of -40°C to +55°C.
Wind Velocity
You must consider the known maximum wind velocity and direction at the site and be sure that
any supporting structure, such as a pole, mast, or tower, is built to withstand this force. The
MP-632 can operate in winds up to 90 MPH and survive higher wind speeds up to 125 MPH.
Note:
Before installing an MP, you might need to generate a network plan and an MP
work order with RingMaster. (See RingMaster Network Plan and Work Orders
below.)
Warning!
The MP-632 is designed to receive power only from a Trapeze-provided power
injector.
Campus Connectivity MP Quick Start Guide 7
Trapeze Networks
Lightning
The MP-632 has built-in lightning protection. However, you should make sure that the unit, any
supporting structure, and cables are all properly grounded. Additional protection using lightning
rods, lightning arrestors, or surge suppressors may also be employed.
Rain
The MP-632 weatherproof enclosure is designed to protect against dust, rain, and water jets.
Snow and Ice
Falling snow, like rain, has no significant effect on the radio signal. However, a build up of snow or ice
on antennas may cause a degradation in performance. In this case, the snow or ice has to be cleared
from the antennas to restore proper operation of the unit.
Ethernet Cabling
When you have determined a suitable location for the MP, you must plan a cable route from the MP to
the power injector module. Consider these points:
❑The Ethernet cable length should never be longer than 100 m (328 ft) over CAT5, CAT5e, or CAT6
cable.
❑Determine a building entry point for the cable.
❑Determine if conduits, bracing, or other structures are required for safety or protection of the cable.
❑For lightning protection at the power injector end of the cable, consider using a lightning arrestor
immediately before the cable enters the building.
Grounding
It is important that the MP-632 unit, cable, lightning arrestor, and any supporting structures are
properly grounded. Be sure that grounding is available and that it meets local and national electrical
codes. The MP-632 includes two grounding screws and a tubular lug for attaching a crimped ground
wire.
MP Radio Safety Advisories
When you enable the MP radio(s) as part of MX configuration, the radios are able to receive and
transmit radio frequency energy as soon as you connect the MP to the MX, either directly or through
the network.
Campus Connectivity MP Quick Start Guide
8
Trapeze Networks
Radio Frequency Exposure
Federal Communications Commission (FCC) Docket 96-8 for Spread Spectrum Transmitters specifies
a safety standard for human exposure to radio frequency electromagnetic energy emitted by
FCC-certified equipment. When used with the proper antennas (shipped in the product), Trapeze
Networks MP access point products meet the uncontrolled environmental limits found in OET-65 and
ANSI C95.1-1991. Proper installation of the MP access point according to the instructions in this
manual will result in user exposure that is below the FCC recommended limits.
!
Caution
FCC Notice:
For indoor operations:
Devices will not permit operations on channels 120-132 for 11a and 11n/a which
overlap the 5600 - 5650 MHz band.
For outdoor operations:
In order to meet new FCC, NTIA, FAA and industry restrictions to resolve
interference to Terminal Doppler Weather Radar (TDWR) systems used at airports,
any outdoor device installed within 35 km of a TDWR location must be separated by
at least 30 MHz (center-to-center) from TDWR operating frequency (as shown in the
table below). Channels 120-132 and 5600-5650 MHz band are disabled on Trapeze
outdoor products.
Trapeze recommends that all operators and installers register the location
information of the UNII devices operating outdoors in the 5470 – 5725 MHz band
within 35 km of any TDWR location at the WISPA sponsored database
(see http://www.spectrumbridge.com/udia/home.aspx). This database may be used by
government agencies in order to expedite resolution of any interference to TDWRs.
Procedures on how to register the devices in the industry-sponsored database with
the appropriate information regarding the location and operation of the device and
installer information can be found on the database.
Table 1– 1. TDWR Location Information
State City Longitute Latitude Frequency
Terrain
Elevation
(MSL) [ft]
Antenna
Height Above
Terrain [ft]
AZ Phoenix W 112 09 46 N 33 25 14 5610 MHz 1024 64
CO Denver W 104 31 35 N 39 43 39 5615 MHz 5643 64
FL Ft. Lauderdale W 080 20 39 N 26 08 36 5645 MHz 7 113
FL Miami W 080 29 28 N 25 45 27 5605 MHz 10 113
FL Orlando W 081 19 33 N 28 20 37 5640 MHz 72 97
FL Tampa W 082 31 04 N 27 51 35 5620 MHz 14 80
FL West Palm Beach W 080 16 23 N 26 41 17 5615 MHz 20 113
GA Atlanta W 084 15 44 N 33 38 48 5615 MHz 962 113
IL McCook W 087 51 31 N 41 47 50 5615 MHz 646 97
Campus Connectivity MP Quick Start Guide 9
Trapeze Networks
IL Crestwood W 087 43 47 N 41 39 05 5645 MHz 663 113
IN Indianapolis W 086 29 08 N 39 38 14 5605 MHz 751 97
KS Wichita W 097 26 13 N 37 30 26 5603 MHz 1270 80
KY Covington
Cincinnati
W 084 34 48 N 38 553 53 5601 MHz 942 97
KY Louisville W 085 36 38 N 38 02 45 5646 MHz 617 113
LA New Orleans W 090 24 11 N 30 01 18 5645 MHz 2 97
MA Boston W 070 56 01 N 42 09 30 5610 MHz 151 113
MD Brandywine W 076 50 42 N 38 41 43 5635 MHz 233 113
MD Benfield W 076 37 48 N 39 05 23 5645 MHz 184 113
MD Clinton W 076 57 43 N 38 45 32 5615 MHz 249 97
MI Detroit W 083 30 54 N 42 06 40 5615 MHz 656 113
MN Minneapolis W 092 55 58 N 44 52 17 5610 MHz 1040 80
MO Kansas City W 094 44 31 N 39 29 55 5605 MHz 1040 64
MO Saint Louis W 090 29 21 N 38 48 20 5610 MHz 551 97
MS Desoto County W 089 59 33 N 34 53 45 5610 MHz 371 113
NC Charlotte W 080 53 06 N 35 20 14 5608 MHz 757 113
NC Raleigh Durham W 078 41 50 N 36 00 07 5647 MHz 400 113
NJ Woodbridge W 074 16 13 N 40 35 37 5620 MHz 19 113
NJ Pennsauken W 075 04 12 N 39 56 57 5610 MHz 39 113
NV Las Vegas W 115 00 26 N 36 08 37 5645 MHz 1995 64
NY Floyd Bennett
Field
W 073 52 49 N 40 35 20 5647 MHz 8 97
OH Dayton W 084 07 23 N 40 01 19 5640 MHz 922 97
OH Cleveland W 082 00 28 N 41 17 23 5645 MHz 817 113
OH Columbus W 082 42 55 N 40 00 20 5605 MHz 1037 113
OK Aero. Ctr TDWR
#1
W 097 37 31 N 35 24 19 5610 MHz 1285 80
OK Aero. Ctr TDWR
#2
W 097 37 43 N 35 23 34 5620 MHz 1293 97
OK Tulsa W 095 49 34 N 36 04 14 5605 MHz 712 113
OK Oklahoma City W 097 30 36 N 35 16 34 5603 MHz 1195 64
PA Hanover W 080 29 10 N 40 30 05 5615 MHz 1266 113
PR San Juan W 066 10 46 N 18 28 26 5610 MHz 59 113
TN Nashville W 086 39 42 N 35 58 47 5605 MHz 722 97
TX Houston
Intercontinental
W 095 34 01 N 30 03 54 5605 MHz 154 97
TX Pearland W 095 14 30 N 29 30 59 5645 MHz 36 80
Table 1– 1. TDWR Location Information
State City Longitute Latitude Frequency
Terrain
Elevation
(MSL) [ft]
Antenna
Height Above
Terrain [ft]
Campus Connectivity MP Quick Start Guide
10
Trapeze Networks
Installing an MP-632
The MP-632 includes a bracket kit for mounting the unit to a 3.81 to 5.08 cm (1.5 to 2-inch) diameter
steel pole or tube. The unit also has a wall-mounting bracket kit that can be used to install the unit on
a building wall. You also have the option to mount the MP on a larger pole (up to 30.48 cm or 12-inch
diameter) using the bracket kit and two metal band straps (straps not provided by Trapeze).
Hardware installation of the MP-632 involves these steps:
1. Mount the unit on a wall, pole, mast, or tower using the mounting bracket.
2. Mount external antennas on the same supporting structure as the MP-632 and connect them to
the unit.
3. Connect the Ethernet cable and a grounding wire to the unit.
4. Connect the other end of the circular DIN power cable to the XPS campus connectivity power
supply.
5. Connect the circular DIN Ethernet cable and prepare the RJ45 cable with the waterproof cap that
is provided. The waterproof caps must be installed on the RJ-45 cable in order to prevent water
damage.
Warning!
The MP-632 must only be used with a Trapeze-approved XPS-6201-OUT or
XPS-6202-OUT power supply in order to prevent possible damage to the unit.
Note:
Two separate cables are required for power and ethernet function on the MP-632.
Both the cable dongles are RJ-45 on one end, but one cable is specific to power and
one is specific to data. If the RJ-45 cable ends are swapped, the unit does not power
up but is not damaged. If the RJ-45 cable ends are correctly inserted, the unit
functions normally.
5GHz
Antenna Ports
Power Ethernet Port
Campus Connectivity MP Quick Start Guide 11
Trapeze Networks
Mounting the Unit
You can mount the MP-632 using either the wall-mounting bracket or the wall-mounting bracket
combined with the pole-mounting bracket (brackets are provided for both a 3.81 to 5.08 cm (1.5 to
2-inch) diameter steel pole or tube or a larger size pole or tube). Use one of the following procedures.
Using the Pole-Mounting Bracket
Perform the following steps to mount the unit to a 3.81 to 5.08 cm (1.5 to 2-inch) diameter steel pole or
tube using the mounting bracket:
1. Insert the four large screws (included in kit) through the four circular holes in the bracket as
shown below.
2. Position the flat bracket behind the pole as shown below and align the screws on the front bracket
with the holes in the flat bracket.
Campus Connectivity MP Quick Start Guide
12
Trapeze Networks
3. Insert the four screws into the holes on the flat bracket and secure the brackets to the pole using
the provided split washers and nuts.
4. Position the MP-632 unit so that the mounting holes overlap with the same-sized holes on the
pole-mounting bracket.
Campus Connectivity MP Quick Start Guide 13
Trapeze Networks
5. Use the 2 small bolts and washers (included in kit) to tightly secure the MP-632 to the
pole-mounting bracket.
Mounting on Larger Diameter Poles
There is also a method for attaching the pole-mounting bracket to a larger diameter pole using two
adjustable steel band straps (not included in the kit). The two steel band straps can be threaded
through the rectangular holes in the bracket to secure it to a larger diameter pole. This method is
shown in the following figure.
Note:
This pole mounting procedure can also be used to attached the MP-632 unit to a
horizontal pole.
Campus Connectivity MP Quick Start Guide
14
Trapeze Networks
Figure 1–1. Attaching the Bracket Using Steel Band Straps
Using the Wall-Mounting Bracket
Perform the following steps to mount the unit to a wall using the wall-mounting bracket.
Figure 1–2. Wall-Mounting Bracket
1. Position the bracket on the intended wall location and drill four large screws (not included in kit)
in through the circular holes on the bracket until it is firmly secured to the wall.
Note:
Always attach the bracket to a wall with the flat side flush against the wall (see
following figure)
Campus Connectivity MP Quick Start Guide 15
Trapeze Networks
2. Position the MP-632 unit so that the mounting holes overlap with the same-sized holes on the
wall-mounted bracket.
3. Use the 2 small bolts and washers (included in kit) to tightly secure the MP-632 to the
wall-mounted bracket.
Campus Connectivity MP Quick Start Guide
16
Trapeze Networks
Connecting External Antennas
The supported antennas models are:
❑802.11bgn Radio
❍ANT-7360A-OUT (stick, N-type jack)
If this antenna is used the unused center antenna port must be terminated.
❍ANT-77555-OUT (3 RP-SMA jack)
❍ANT-74520-OUT (3 RP-SMA)
❑802.11an Radio
❍ANT-7360A-OUT (stick)
❍ANT-74520-OUT (3 RP-SMA)
❍ANT-77555-OUT (3 RP-SMA)
❍ANT-5007-OUT (2 N-type) - mainly for outdoor application. Band 5150-5250 MHz is not avail-
able for this antenna.
The port usage depends on the antennas in use. If the OMNI antennas are used there must be 3
antennas installed for the radio. If an antenna is used then the two edge ports must be connected to
the antenna (ports 4 and 6). The middle port is turned off by the software and should be terminated. If
either the ANT-77555 or 74520 are used all three connectors must be connected to the MP for the
correct radio.
set ap apnum radio num antennatype {ANT-7360A-OUT | ANT-77555-OUT | ANT-74520-OUT |
ANT-5O07-OUT} …
The antenna location must be either indoors or outdoors. The AP may be used indoors or outdoors.
The following command is per radio.
set ap apnum antenna-location {indoors | outdoors}
Multiple External Antenna Support
The MP-632 supports the use of multiple antenna ports per radio. Since there are always multiple
antennas connected, antenna diversity is always on. The command to set the number of external
antennas does not apply to the MP-632. The number of antenna ports in use is determined by the
antenna type.
Certification Bands Required Application
FCC/IC 2412-2472 MHz Indoor/Outdoor
5150-5250 MHz Indoor
5250-5350 MHz Indoor/Outdoor
5470-5725 MHz Indoor/Outdoor
5600-5650 MHz Disabled
5725-5850 MHz Indoor/Outdoor
Warning!
You cannot configure both outdoor and indoor options for the antenna location.
The operation of antenna ANT-5007-OUT is not allowed in India.
Campus Connectivity MP Quick Start Guide 17
Trapeze Networks
set ap num radio num external-antennas num
If the external-antenna command is used for the MP-632 it is ignored at the CLI.
If the ANT-5007-OUT antenna is in use on the 11a/n radio then the radio configuration reverts to
2 x 3 mode rather than 3 x 3 mode and the middle port for the radio must not be used.
Ethernet
The MP-632 supports a single IEEE 802.3-compliant auto-sensing 10/100/1000 BaseT Ethernet
interface on the Ethernet input connector. The MP is configured as auto MDI/MDIX and is powered
from the XPS-6201-OUT or XPS-6202-OUT power supplies.
The MP-632 receives separate primary 48VDC power input and Ethernet signal from separate
48VDC and Ethernet input connectors.
The MP-632 48VDC / Ethernet inputs provides primary and secondary lightning protection on all
conductors. (The 48VDC / Ethernet inputs to the MP-632 need lightning protection because the power
supply can be up to 100m (328 ft)away.)
The Ethernet interface supports a cable length of at least 100m over CAT5, CAT5e, or CAT6 cable.
Warning!
The MP-632 must only be used with a Trapeze-approved XPS-6201-OUT or
XPS-6202-OUT power supply in order to prevent possible damage to the unit.
Warning!
Always add the waterproof cap to the RJ45 cable when installing the DIN-RJ45 dongle.
Water can cause damage to the unit and the cables.
Warning!
If you convert the 8 pin female circular DIN data port on the MP-632 bulkhead to a
standard RJ45 waterproof connection for the 10/100/1000 data port, PoE on the
10/100/1000 port must be disabled to prevent service interruption.The MP-632 does not
support PoE on the 10/100/1000 Ethernet data port.
Campus Connectivity MP Quick Start Guide
18
Trapeze Networks
Figure 1–3. Attaching the Ground-Wire Terminal Lug, Lock Washer, and Hex Nut to the Lightning Arrestor
a. Connect one end of the short RF coaxial cable to the MP-632 N-type connector, and connect the
other end to the lightning arrestor.
b. Connect one end of the 3m (9.8 ft) RF coaxial cable to the lightning arrestor, and connect the
other end to the outdoor antenna. Continue with step 4.
4. Connect the antenna to the MP-632 N-type connector using the RF coaxial cable provided in the
antenna package.
5. Apply weatherproofing tape to the antenna connectors to help prevent water entering the
connectors.
Connecting Cables to the Unit
1. Attach the Ethernet cable to the Ethernet port on the MP-632.
2. For extra protection against moisture, apply weatherproofing tape (not included) around the
Ethernet connector.
3. Be sure to ground the unit with an appropriate grounding wire (not included) by attaching it to
the grounding screw on the unit.
4. Be sure to install a lightning arrestor on the Ethernet cable between the bridge and power
injector. The lightning arrestor should be placed outdoors, immediately before the Ethernet cable
enters the building.
Warning!
Be sure that grounding is available and that it meets local and national electrical
codes. For additional lightning protection, use lightning rods, lightning arrestors, or
surge suppressors.
To External Antenna
To MP-632
6-gauge
Grounding Cable
Grounding Nut
Locking Washer
Hex Nut
Lightning Protector
Campus Connectivity MP Quick Start Guide 19
Trapeze Networks
Connecting the Power Injector
To connect the wireless bridge to a power source:
1. Connect the Ethernet cable from the wireless bridge to the PoE Output port labeled “POE Output”
on the power injector.
Note:
The Ethernet port on the wireless bridge does not support Power over Ethernet (PoE)
based on the IEEE 802.3af standard. Do not try to power the unit by connecting it
directly to a MX that provides IEEE 802.3af PoE. Always connect the unit to the
included power injector module.
Warning!
The MP-632 must only be used with a Trapeze-approved XPS-6201-OUT or
XPS-6202-OUT power supply in order to prevent possible damage to the unit.
Warning!
Always align the DIN cable with the pins in the PoE Output port. You can bend the
power injector pins and cause other damage to the unit by forcing the cable into the
port.
Note:
The DATA IN port on the power injector is not used.
Campus Connectivity MP Quick Start Guide
20
Trapeze Networks
2. Insert the power cable plug directly into the standard AC receptacle on the power injector.
3. Plug the other end of the power cable into a grounded, 3-pin socket, AC power source.
Checking the LED Indicators
The MP-632 has LEDs that provide status information for the device. The table below lists the
function of the LEDs.
The LEDs are also used to indicate RSSI signal level during mesh link calibration. RSSI meter
functionality is discussed in Chapter 4, “Campus Connectivity MP Technical Specifications” of this
guide.
Note:
For International use, you may need to change the AC line cord. You must use a line cord
set that has been approved for the receptacle type in your country.
LED Appearance Meaning
Health
Solid green All the following are true:
❑Management link with an MX is operational.
❑MP has booted.
❑MP has received a valid configuration from an MX.
❑At least one radio is enabled or is in sentry mode.
Solid amber MP is waiting to receive boot instructions and a configuration file
from an MX.
Alternating green and amber MP is booting and receiving a configuration file from an MX.
After the MP boots and receives a configuration, this LED
appearance persists until a radio is enabled or is placed in sentry
mode.
Radio 1
Radio 2
Solid green A client is associated with the radio.
Blinking green Associated client is sending or receiving traffic.
Blinking amber Non-associated client is sending or receiving traffic.
Alternating green and amber Radio is unable to transmit. This state can occur due to any of the
following:
❑Excessive radio interference in the environment is preventing
the radio from sending beacons.
❑DFS has detected radar and is restricting traffic.
❑The radio has failed.
Unlit Means one of the following:
❑Radio is disabled and active scan is enabled. (The radio is in
sentry mode.)
❑Radio is enabled, but no clients are associated with it.
Campus Connectivity MP Quick Start Guide 21
Trapeze Networks
Aligning Antennas for Bridge or Mesh Links
If you are installing MP-632 units for wireless bridge or Mesh Services operation, after the units have
been mounted, connected, and the radios are operating, the antennas must be accurately aligned to
ensure optimum performance on the bridge or mesh links.
This alignment process is particularly important for long-range point-to-point links. In a
point-to-multipoint configuration, the Mesh Portal AP uses an omnidirectional or sector antenna,
which does not require alignment, but Mesh APs still need to be correctly aligned with the Mesh
Portal antenna.
❑Point-to-Point Configurations – In a point-to-point configuration, the alignment process
requires two people at each end of the link. The use of cell phones or two-way radio communication
may help with coordination. To start, you can just point the antennas at each other, using
binoculars or a compass to set the general direction. For accurate alignment, monitor the RSSI’s
LED indicator as you move the antenna horizontally and vertically.
❑Point-to-Multipoint Configurations – In a point-to-multipoint configuration all Mesh APs must
be aligned with the Mesh Portal antenna. The alignment process is the same as for point-to-point
links, but only the Mesh AP end of the link requires the alignment.
The LEDs are viewed right to left as you look at the back of the MP. The range from 1 to 12 will cover
the signal range to accurately align the antenna. The signal strength LEDs indicate the received
radio signal strength for a particular bridge link. The more LEDs that turn on, the stronger the
signal. (RSSI level 1 should equate to the lowest useful signal). Alternatively, you can monitor the
Receive Signal Strength Indicator (RSSI) value directly from the management interface. The higher
the RSSI value, the stronger the signal.
When you move the antenna during alignment, the radio signal from the remote antenna can be seen
to have a strong central main lobe and smaller side lobes. The object of the alignment process is to set
the antenna so that it is receiving the strongest signal from the central main lobe.
Campus Connectivity MP Quick Start Guide
22
Trapeze Networks
Figure 1–4. Aligning the MP-632 Antenna According to Signal Strength
When aligning the antennas the MP with the antenna that is being aligned to must be set to send
link-calibration packets. Use the following command to setup the MP that the MP-632 is being
aligned with.
set ap num radio num link-calibration mode {enable | disable}
Link-calibration should be disabled under normal operation of the MP.
If the MP-632 is installed with two directional antennas, connect the first antenna to the primary
antenna port with antenna diversity off and align it. Then disconnect the first antenna and connect
the second antenna to the primary antenna port. If the second antenna is being aligned with a
different MP, disable link-calibration on the original MP and enable it on the new MP. Once both
antennas are properly aligned, connect them to their desired ports.
RSSI Meter Functionality
The MP-632 supports an LED-based RSSI indicator when either radio operates in mesh link
calibration mode. The RSSI reading must be able to support the indication of received signal levels
across a 35dB dynamic range, from a high of -60 dBm to a low of -95 dBm.
The RSSI is indicated by on/off/flashing LED patterns, as shown in the table below. The granularity
varies between 2dBm, 3dBm, and 6dBm.
Main Lobe
Maximum
Horizontal Scan
Vertical Scan
RSSI
Value Side Lobe
Maximum
RSSI Value
Remote
Antenna
Maximum Signal Strength Position
for Horizontal Alignment
Maximum Signal
Strength Position for
Vertical Alignment
Campus Connectivity MP Quick Start Guide 23
Trapeze Networks
Table 1– 2. 5G Ch.36
LED 1 LED 2 LED 3 RSSI
Off Off Off No signal
Flashing Slow Off Off
Very low signal
Flashing Fast Off Off
On Off Off
On Flashing Slow Off Low signal
On Flashing Fast Off
On On Off
Operational signal
On On Flashing Slow
On On Flashing Fast
On On On Strong signal
Table 1– 3. 2.4G Ch.13
LED 1 LED 2 LED 3 RSSI
Off Off Off No signal
Flashing Slow Off Off
Very low signal
Flashing Fast Off Off
On Off Off
On Flashing Slow Off Low signal
On Flashing Fast Off
On On Off
Operational signal
On On Flashing Slow
On On Flashing Fast
On On On Strong signal
Campus Connectivity MP Quick Start Guide
24
Trapeze Networks
Federal Communications Commission Interference Statement (United States)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the following measures:
❑Reorient or relocate the receiving antenna.
❑Increase the separation between the equipment and receiver.
❑Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
❑Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of
other channels is not possible.
This device and its antenna(s) must not be co-located or operation in conjunction with any other
antenna or transmitter.
This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor
environment only.
!
Caution
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
!
Caution
FCC Notice: To comply with FCC part 15 rules in the United States, the system
must be professionally installed to ensure compliance with the Part 15 certification.
It is the responsibility of the operator and professional installer to ensure that only
certified systems are deployed in the United States. The use of the system in any
other combination (such as co-located antennas transmitting the same information)
is expressly forbidden.
!
Caution
FCC Radiation Exposure Statement: This equipment complies with FCC
radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm (about 8 inches)
between the radiator and your body
Campus Connectivity MP Quick Start Guide 25
Trapeze Networks
Canadian Department of Communications Industry Canada Notice (Canada)
This digital apparatus meets the requirements of Canadian Interference-Causing Equipment
Regulation RSS-210.
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference, including interference that may cause undesired
operation of the device.
Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada.
Country Code Statement: For product available in the USA/Canada market, only channel 1~11 can
be operated. Selection of other channels is not possible.
This device and its antenna(s) must not be co-located or operation in conjunction with any other
antenna or transmitter.
To reduce potential radio interference to other users, the antenna type and its gain should be so
chosen that the equivalent isotropically radiated power (e.i.r.p) is not more than that permitted for
successful communication.
This device has been designed to operate with the antennas listed below, and having a maximum gain
of [23.5] dB. Antennas not included in this list or having a gain greater than [23.5] dB are strictly
prohibited for use with this device. The required antenna impedance is 50 ohms.
The device could automatically discontinue transmission in case of absence of information to
transmit, or operational failure. Note that this is not intended to prohibit transmission of control or
signaling information or the use of repetitive codes where required by the technology.
The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful
interference to co-channel mobile satellite systems.
The maximum antenna gain permitted (for devices in the band 5725-5825 MHz) to comply with the
e.i.r.p. limits specified for point-to-point and non point-to-point operation as appropriate, as stated in
section A9.2(3).
The maximum antenna gain permitted (for devices in the bands 5250-5350 MHz and 5470-5725 MHz)
to comply with the e.i.r.p. limit.
High-power radars are allocated as primary users (meaning they have priority) of the bands
5250-5350 MHz and 5650-5850 MHz and these radars could cause interference and/or damage to
LE-LAN devices.
!
Caution
IC Radiation Exposure Statement: This equipment complies with IC RSS-102
radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm (about 8 inches)
between the radiator & your body.
Trapeze Networks
© 2010 Trapeze Networks, Inc. All rights reserved. Trapeze Networks, the Trapeze Networks logo
design, Trapeze Smart Mobile, Trapeze Networks Mobility System Software, RingMaster,
Mobility System, Mobility Exchange, Mobility Point, SafetyNet, MX, and MP are registered
trademarks and/or registered service marks of Trapeze Networks, Inc. Trapeze, Smart Mobile,
Mobility System Software, Mobility Domain, SmartPass, NonStop Wireless, Medical Grade
Mobility and Wireless Without Limits are trademarks and/or service marks of Trapeze
Networks, Inc. All other products and services are trademarks, registered trademarks, service
marks, or registered service marks of their respective owners.
All statements, specifications, recommendations, and technical information are current or
planned as of the publication of this document. They are reliable as of the time of this writing
and are presented without warranty of any kind, expressed or implied. In an effort to
continuously improve the product and add features, Trapeze Networks reserves the right to
change any specifications contained in this document without prior notice of any kind.
26
