The Guardian™ Instruction Manual

Included In Your Package

Before We Get Started

Sold Separately

The Guardian™

Control Panel Cover

Battery Cover AC Adapter

Remote control

Strobe Light

SELECT-A-PEST Dial

The SELECT-A-PEST dial sets the ultrasonic sound frequency

and has four main groups. These groups are labeled with pest

names to provide a starting point to target your specic pest.

Each group has more than one setting to help you dial in The

Guardian™ to your needs. Please keep in mind that, just like

humans, all animals have dierent hearing ranges. Dierent

animals are aected by dierent sounds - or settings. Most

importantly, make sure you are giving The Guardian™ at

least one week on a specic setting before making changes.

Power Mode

Start by selecting one of two options: CONSTANT or MOTION

DETECTOR. CONSTANT mode sends out a continuous stream of

unpleasant sounds or wild cat calls. MOTION DETECTOR will only

send out sounds when The Guardian™ detects movement.

Predator Sounds

Moving the PREDATOR SOUNDS switch to YES disables the

SELECT-A-PEST mode, using predator sounds only. The

volume of the predator sounds can be easily adjusted

using the PREDATOR VOLUME dial.

What is ultrasonic sound?

Ultrasonic sounds are frequencies which are higher than the

range of human hearing. However, these sounds are very

irritating to nuisance pests, causing them to ee.

Will I be able to hear it?

The range of sounds produced by The Guardian™ include both

audible and inaudible sounds. Many people can hear sounds

from both settings 1 and 2, on the SELECT-A-PEST dial.

How long before they’re gone?

Although some customers report positive results in a few days,

we do recommend giving The Guardian™ two to three weeks

for best results.

How does the infrared motion sensor work?

The Guardian™ uses an infrared sensor which detects the

movement of a heat source, such as an animal. The

Guardian™ will detect movement up to 100 ft. in front of the

unit, with a clear line of sight.

Why should I use predator sounds?

The Guardian™ uses pre-recorded mountain lion calls which

creates a “danger” zone large pests will not want to enter.

What is the coverage area?

The Guardian™ will detect movement and send sounds up to 100

ft. in front of the unit in a clear line of sight.

OFF NO

MIN MAX

BIRDS, DEER

OPOSSUMSCHIPMUNKS

RACCOONS,

YES

CONSTANT

POWER MODE PREDATOR SOUNDS

PREDATOR VOLUMESELECT-A-PEST

MOTION

DETECTOR

SQUIRRELS, CATS, 3

BATS, MICE,

RATS, DOGS

1 2

The Control Panel

100ft

The Guardian™ Instruction Manual

Note

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason-

able protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in ac-

cordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which

can be determined by turning the equipment o and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

-- Reorient or relocate the receiving antenna.

-- Increase the separation between the equipment and receiver.

-- Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

-- Consult the dealer or an experienced radio/TV technician for help.
