User Manual
IMPORTANT SAFEGUARDS
WARNING-- To reduce the risk of fire, electric shock, or serious personal injury
• Do not immerse the product in liquids
• This product is not intended for use by children and contains small parts that may pose a choking hazard to
children under the age of three. Keep the product out of the reach of children and pets.
• Do not use an electrical device or appliance with this product whose electrical specifications exceed those
specified in the “Electrical Specifications” section of this manual.
• Indoor use only.
CAUTION-- To reduce the risk of personal injury or product/ property damage:
• This product is intended for non-commercial, non-industrial use in the remote control of two electrical outlets.
Do not use this product for any other purpose.
Maintenance
1. Plug receiver into a standard 125-volt AC electrical outlet.
2. Confirm that the electrical specifications of an item you wish to use with this product do not exceed those specified in the “Electrical Ratings” section. plug the item into an outlet of the receiver.
3. Remove the plastic battery tab from the battery compartment in the back of the remote control to activate the DC 12V Type A23 pre-installed battery.
Battery Handling and Usage
WARNING: Keep batteries away from children and pets.
• Follow the battery manufacturer’s safety and usage instructions.
• Insert the battery observing the proper polarity (+/-) as indicated inside the Battery
Compartment.
• Remote a spent or discharged battery from the product. remove the battery when not using
the product for an extended period.
• Never throw batteries into a fire. Do not expose batteries to fire or other heat sources.
• Battery contains mercury. Do not put in trash. Recycle or manage as hazardous waste.
• Dispose or recycle spent / discharged batteries in compliance with all applicable laws. For
detailed information contact your local solid waste authority.
Replacing the battery
• Remove the Battery compartment cover from the back
of the remote control by sliding the cover in the
direction that its trends curve.
• Remove the spent battery and place a new DC 12V
Type A23 battery into the Battery Compartment
correctly observing the polarity indications (+/-) inside
the Battery Compartment.
• Replace the Battery Compartment Cover.
• Clear the battery contacts and also those of the device
prior to battery installation
RC-040 + TR-025 Indoor Wireless Remote Control
When using electrical products, always follow basic safety precautions including the following:
Made in China
SAVE THESE INSTRUCTIONS!
RECEIVER MODEL: RC-040
TRANSMITTER MODEL: TR-025
FCC ID: PAGTR-025
IC: 4494A-TR025
Operating Instructions
1. To set up the receiver (outlet) with connecting device.
2. Removes the plastic battery tab from the battery compartment in the back of the remote
control to active the DC 12V Type A23 pre-installed battery.
3. To activate the Receiver, press the ON Button of the Remote Control. The red LED of the
Remote Control will illuminate momentarily and the LED of the Receiver will remain
illuminated.
4. To turn the Receiver off, press the OFF Button of the Remote Control. The LED on the
Receiver will shut off.
NOTE: These are general definitions only; all may not pertain to the actual product purchased.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. Usage of this signal word is limited to the most extreme situations.
WARNING: Indicates potentially hazardous situation, which, if not avoided, may result in minor / moderate injury or product/ property damage. It also alerts against unsafe practices.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in minor/moderate injury or product/ property damage. It also alerts against unsafe practices.
Replacing the battery
ELECTRICAL RATINGS
Features: Controls one electrical outlet up to a distance of 100 feet.
Federal Communications Commission Interference Statement
This equipment has been tested and found to comply with the limits for Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Industry Canada statement:
This Class B digital apparatus complies with Canadian ICES-003.
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
* Maximum combined wattage for items using a tungsten bulb plugged into the Receiver is
1000W.
* Maximum combined wattage for appliances plugged into the Receiver is 1625W.
Voltage Frequency Wattage Amperage Horse Power
*1000W-1625W 60Hz120VAC 13A 1/3HP
1 2 3
1 2 3
CAUTION: Failure to properly align the battery polarity can cause personal injury and/or
property damage.
Manual On/Off:
Press Manual button on the body of Receiver to turn on or off. The manual button is available if
the Remote Control is absence.
