KAONMEDIA CG2001-AN22CC Docsis cable modem User Manual

KAONMEDIA Co., Ltd. Docsis cable modem

User Manual

CG2001-AN22CC
CG2001-AN22CC
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two condions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operaon.
Cauon: Any changes or modificaons to the equipment not expressly approved by the
party responsible for compliance could void user’s authority to operate the equipment.
This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or
transmitter. A minimum separation distance of 20 must be maintained between the antenna and the person for this
appliance to satisfy the RF exposure requirements.
1 2
1 4 5 62
WPS Long Press The associaon of the modem with a PC or other
equipment
LED Status Indicaon
LAN1~4 Off The LAN port is not connected.
Flashing The LAN port is sending or receiving data.
(Green : 1Gbps, Amber : 10/100Mbps)
On The LAN port is connected.
POWER Off The modem is powered off.
On The modem is powered on.
US Off The inializaon is not started, or has failed.
Flashing The modem is upstream ranging.
On The modem is upstream locked.
DS Off The inializaon is not started, or has failed.
Flashing The modem is scanning for downstream channel.
On The modem is downstream locked.
POWER Off The modem is powered off.
On The modem is powered on.
ETH-1~4 4 RJ45 Ethernet ports to connect your PC or home network devices
RESET Switch for factory reset
RF DOCSIS Cable connector
Power ON/OFF Switch for power On/Off
Power Connects the unit to DC 12V power
Tablet
Adaptor
Coax jumper
RCA
SCART
COMPONENT output
영상출력
Power Adaptor
Coax Cable
Adaptor
Coax jumper
RCA
SCART
audio output
음성출력
HDMI
AAA BATTERY
Laptop
2.0 Connecting and Installing Devices
AAA BATTERY
3 4
3.0 Quick Guide
Instrucon for Connecon Modem-PC
1. Make sure the following.
- Connect the coaxial cable ghtly to the cable outlet.
- Your Cable Modem is powered ON. The power LED will be turned ON.
- Your PC is turned ON and connected to Cable Modem using an Ethernet cable.
- Aer Online LED is ON, Cable Modem becomes online.
2. Configure your PC to obtain an IP address from a DHCP server.
3. From your PC, start your web browser applicaon like Chrome, Internet Explorer, or etc.
4. Type a valid URL such as “www.google.com” and <Enter>.
The website should be open if connected correctly.
Wi-Fi Connecon
1. Open Wireless seng window in your Wi-Fi device or PCs.
2. Search for the right “SSID”.
The factory Default seng:
- SSID: “CG2001_XXXXXX_G1” for 2.4GHz.
- Note: XXXXXX is character that last 6 characters of Cable Modem MAC Address.
WebUI Access Guide
To access the configuraon web pages, you must do the following :
1. From your PC, start your web browser applicaon like Chrome, Internet Explorer or etc.
2. In the URL address field, enter IP address “192.168.0.1” and <ENTER>.
3. The log-in window should popped-up aer the step 3 above.
Then, log-in to the web configuraon menu with the following :
- Enter “MSO” into the “User Name” field.
- Enter “MSO” into the “password” field.
4. The main menu will be popped-up like below and you can check or change the current sengs
from appropriate menus.
REAR
Power
DC 12V (1.5A)
Front
1 x WPS Button
9 x LED
(Power, DS, US, Online, Wi-Fi, Eth1, Eth2, Eth3, Eth4)
1 x Cable In
1 x Reset Button
1 x On/Off Button
4 x GbE LAN Ports
Package
Reception Sensitivity
Modem with Wi-Fi
User Guide (Ukrainian, Russian and English)
Ethernet Cable (CAT5/RJ45)
Power Supply
Wi-Fi Standards/Tx/Rx
Radio Frequency
Antenna Type
Transmission Rate
Memory
Main Chipset
Max DOCSIS DS/US
802.11 b/g/n, 2Tx2R
802.11 a/n/ac, 3Tx3R
Flash : 16MB SPI (NOR)
RAM : 128MB DDR3
2.4 GHz_BCM43217
8 x 4 Channel Bonding
Internal Antennas (PCB Type)
2.4GHz : 300Mbps (802.11n 2x2)
BCM3383G (500 DMIPS Zephyr, 1600 DMIPS VIPER)
1GHz Full Band Capture DOCSIS3.0
11b 11Mbps : -82dBm
11g 54Mbps : -71dBm
11n HT20: -69dBm (MCS7)
11n HT40: -68dBm (MCS7)
2.4GHz
4.0 Specification
