KINGTA TECHNOLOGY PB252B Bluetooth Speaker User Manual
KINGTA TECHNOLOGY CO., LTD Bluetooth Speaker
User manual
Begin Streaming Music
Press ” ” to start playing music
Press and Hold ” ” 2 seconds to play the next track
Press and Hold ” ” 2 seconds to play previous track
Press either ” ” or ” ” for volume control
Making and Receiving Phone Calls
When the unit is connected and paired to your device,
the unit allows you to make or receive phone calls with its
built-in microphone.
Press “ ” to accept a call
To end a call press ” ”
To reject a call, press and hold ” ” for 2 seconds
Plug in the supplied 3.5 mm cable into the unit. The other end is
connected to your device. the Blue LED will slow blink when in
“Aux”mode.
Please note music and volume can be controlled by your device.
Attach the USB cable to the unit, and plug into any USB charger.
If the unit is completely discharged, it will take approximately 3
hours to fully charge.
The Red LED will illuminate during charging, when it has
completed, the Red LED will turn off.
Note: There will be a beep when the battery is low and needs to
be recharged.
Aux-In Mode
Charging
LED Status
Blue LED rapid blink & Blue LED solid Bluetooth Mode
Blue LED slow blink
Red LED
Aux Mode
Charging
Troubleshooting
Unit doesn’t connect
to device
Speaker needs to be connected/
re-paired to device
A tone is heard every few seconds Speaker needs to be charged
Unit will not power on Speaker needs to be charged
Unit doesn’t control
track(s)/volume
Speaker needs to be in Bluetooth
mode for full control
Unit distorts at
high volume
The devices’ volume needs to
be lowered
12 3
4
5
6
PB252B
Bluetooth Speaker
User’s Manual
Introduction:
Description:
Included:
Specifications:
Thank you for choosing the PB252B as your source for entertainment!
you can use this item with iPads , iPhones,iPods and many types of
smartphone to stream music ,and enjoy handsfree calling.In order to
get the best results when using the device,please read this manual
first before using.
1.Speaker
2.USB Micro Charging Cable
3.3.5 mm Audio Cable
4.User Manual
Supported Profiles: A2DP, HFP, AVRCP
Bluetooth Range:33ft (10m)
Dimensions: 185 mm x 25 mm x 82 mm
Battery: Li-Ion 3.7V, 2000 mAh
Charging: DC 5V @ 500 mA
Weight: 320g
Operation:
Powering On
Press and Hold "ON/OFF" button 2 seconds to power ON, the
Blue LED will start to rapid blink .
If an Aux (3.5 mm) cable is connected to the unit, the Blue LED
will slow blink, the unit is in Aux-In mode.
Powering Off
Paired mode:Press and Hold "ON/OFF" button 2 seconds to
disconnect the Bluetooth, then Press and Hold "ON/OFF"
button again to power off .
Pairing/AUX mode:Press and Hold "ON/OFF" button 2
seconds to power off
Bluetooth Mode
Pairing
The unit will automatically go into “Pairing Mode” when it is
powered ON.
Go into your Bluetooth device settings menu and look for
“PB252B”.
After the unit has paired and connected, it will re-connect
automatically when the unit is powered on and the device
is in range.
Note: Bluetooth Timeout :10 minutes
1.ON/OFF /Play/Pause/Phone button
2.Previous/Volume –
3.Next/Volume +
4.Blue LED(Bluetooth) / Red LED(Charging)
5.MIC
6.Micro USB Charging Port / AUX in Port
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
