KOKKIA IADAPTER-X BLUETOOTH UNIVERSAL ADAPTER User Manual Quick Start Guide
KOKKIA, Inc BLUETOOTH UNIVERSAL ADAPTER Quick Start Guide
KOKKIA >
USERS MANUAL
www.kokkia.com
English
iAdapter TRANSCEIVER can be used as either a Bluetooth
Stereo Transmitter or Bluetooth Stereo Receiver.
Transmitter Mode: LED is GREEN Color.
Receiver Mode: LED is BLUE Color.
In aptX streaming, LED double quick flash once ~5secs.
In non aptX streaming, LED single quick flash once ~5secs.
Mode Change ( Transmitter Receiver )
Press and HOLD Button for ~15 seconds, until LED
changes color, GREEN BLUE.
Specifications
Operating distance up to 10 meters (33feet).
Pin-Code. Receiver Mode: ‘0000’.
Transmitter Mode: ‘0000’, ‘1111’, ‘1234’ or ‘8888’.
Works only with Bluetooth stereo devices with
A2DP/AVRCP profiles.
Charging the iAdapter
Plug USB charging cable into iAdapter USB port.
Plug other end of USB charging cable into a powered
USB 5V port. When charging, RED LED will be lit.
RED LED turns off when unit is charged (~2 hours).
NOTE: iAdapter resets when charging cable with 5V
power is inserted into iAdapter.
Pairing iAdapter (Transmitter) to Bluetooth Stereo Receiver
Turn off all previously paired Bluetooth devices to your
receiver, and iAdapter.
Turn on and put in pairing mode, the Bluetooth stereo
receiver you wish to pair with iAdapter and place it within
10 meters of iAdapter. (Refer to the Bluetooth stereo
receiver’s user guide for pairing instructions)
Press and hold the iAdapter Button, until the GREEN
LED lights up. Release the button press when GREEN
LED turns on, indicating iAdapter is in pairing/connecting
mode.
When iAdapter and stereo receiver are paired and
connected (iAdapter GREEN LED slow flashes every ~5
seconds), insert iAdapter’s audio jack into your audio
device’s audio output socket. Play the audio device’s
audio, and it will stream from iAdapter to the connected
receiver wirelessly.
Pairing iAdapter (Receiver) to Bluetooth Cell-Phone or
Transmitter
Turn off all previously paired Bluetooth devices to your
Cell-Phone or Transmitter, and iAdapter.
Turn on and put in pairing mode, the Bluetooth
Cell-Phone/Transmitter you wish to pair with iAdapter
and place it within 10 meters of iAdapter. (Refer to the
Bluetooth Cell-Phone or Transmitter user guide for
pairing instructions)
Press and hold iAdapter Button, until the BLUE LED
lights up. Release the button press when BLUE LED turns
on, indicating iAdapter is in pairing/connecting mode.
Select “KOKKIA iAdapter” on phone.
Enter pin code ‘0000’ on your Bluetooth
Cell-Phone/Transmitter, if prompted, to pair and connect
iAdapter to your phone/transmitter.
When iAdapter and Cell-Phone or Transmitter are paired
and connected (iAdapter BLUE LED slow flashes every
~5 seconds), insert iAdapter’s audio jack into your audio
device’s audio input socket. Play the audio on your
Cell-Phone or Transmitting device, and it will stream to
iAdapter wirelessly to audio input device connected to
iAdapter.
iAdapter Remote control (Transmitter Mode)
Play/Pause, Next Track, Previous Track: iAdapter
responds to these four remote AVRCP commands from
your stereo receiver / headset / speaker. Your music
device or smartphone may (or may not) respond to all or
some of these remote AVRCP commands.
iAdapter Remote control (Receiver Mode)
Play/Pause: Single Quick Press Release Button
Next Track: Double Quick Press Release Button
Previous Track: Triple Quick Press Release Button
Powering ON iAdapter to connect to previously paired
device
Press Button until LED lights up. Release button.
Powering OFF iAdapter
Press Button for ~5 seconds, LED turns on for ~1 second
and then turns off. iAdapter powers down. Release Button.
POWER ON mode, cable inserted to iAdapter with 5V
POWER ON mode is for use cases with charger cable inserted
in iAdapter, and charger cable is attached to 5V power that is
powered on/off together with other audio/video devices.
With POWER ON mode, whenever there is 5V applied to
iAdapter from charging cable, iAdapter will turn on and connect
to a previously paired device, without pressing iAdapter button.
Enabling POWER ON mode:
When iAdapter is in charging mode (USB cable is inserted
and powered with 5V), double quick press and release the
button, the GREEN or BLUE LED turns on. iAdapter will
re-connect to a previously paired device.
When 5V power is removed from iAdapter charging
cable, and 5V is later restored to the cable, iAdapter will
automatically turn on, re-connect to a previously paired
device, without pressing iAdapter button.
Disabling POWER ON mode:
When iAdapter is in charging mode (USB cable is inserted
and powered with 5V), and GREEN or BLUE LED is
flashing, press the button until the GREEN or BLUE LED
turns OFF, then release button press.
When the 5V power is removed from iAdapter charging
cable, and 5V power is later restored to the cable, iAdapter
will NOT automatically turn on.
Use button as described earlier to operate iAdapter.
iAdapter Tiny Bluetooth
Universal 3.5mm Audio
Stereo Transceiver with aptX®
3.5mm
Audio Jack
Battery
Charging Port
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications to device will void the user’s
authority to operate the device.
この機器の使用周波数帯では、電子レンジ等の産業・科学
・医療用機器のほか工場の製造ライン等で使用されてい
る移動体識別用の構内無線局（免許を要する無線局）及び
特定小電力無線局（免許を要しない無線局）並びにアマチ
ュア無線局（免許を要する無線局）が運用されています。
１ この機器を使用する前に、近くで移動体識別用の構内
無線局及び特定小電力無線局並びにアマチュア無線局が
運用されていないことを確認して下さい。
２ 万一、この機器から移動体識別用の構内無線局に対し
て有害な電波干渉の事例が発生した場合には、速やかに使
用周波数を変更するか又は電波の発射を停止した上、下記
連絡先にご連絡頂き、混信回避のための処置等(例えば、パ
ーティションの設置など)についてご相談して下さい。
３ その他、この機器から移動体識別用の特定小電力無線
局あるいはアマチュア無線局に対して有害な電波干渉の
事例が発生した場合など何かお困りのことが起きたとき
は、次の連絡先へお問い合わせ下さい。
連絡先：info@kokkia.com
CE 1588. FCC ID: XWA-IADAPTER-X
LED indicator.
Green: Transmitter
Blue: Receiver
Red: Charging
Button
