KYE SYSTEMS GG000S Bluetooth Stereo Headset User Manual
KYE Systems Corp Bluetooth Stereo Headset Users Manual
Users Manual
Low battery warning
The red LED flash
Volume down
Turn off
Press the “ ” button for 3 seconds when
the device is on.(a tone voice beep and
all LED is off)
Charging Plug the charger to port of the device.
(Red LED is on)
Press is for volume down
Desired Result Required Action
Transfer call voice
Answer call
End call
Reject call
Double click the “ ” button for 2seconds
to transfer the callvoice between the mobile
phone and device when on going call
Press the “ ” button for 1second while
the call coming
Press the “ ” button for 1second to end call
Press the “ ” button for 2seconds to
reject call when the call is ringing
Previous
Next
Press is for previous music.
Press is for next music.
Table of contents
1 Introduction
2 Kit Contents
3 Connection Diagram
4 How to use
4.1 General function
4.2 Pairing to mobile phone
4.3 Charging your device
5 Technical specification
6 Service and Support
7 FAQ
1
1
1
2
2
2
3
5
6
6
5
1
3.Connection Diagram
6.Service and Support
You must select a qualified charger from a regular
manufacturer.
You must charge the Bluetooth Headset if it has been
not used for more than 12 months.
Warning:
BLUETOOTH STEREO HEADPHONE
HS-920BT USER MANUAL
1. Introduction
Congratulations, and thank you for choosing the Bluetooth
Stereo Headphone. This manual will help you operate the
Bluetooth Stereo Headphone, but you should first
familiarize yourself with the Bluetooth functionality of your
mobile phone or other devices before using the Bluetooth
Stereo Headphone
Safety Rules
1\ Please follow the rules depicted in this manual closely
to ensure your safety. Before using this Bluetooth
Stereo Headphone, we would strongly encourage you
to read
through this user manual.
2\ Be more wary of any edges, uneven surfaces, metal
parts, accessories and its packaging so as to prevent
any possible injury or damage.
3\ Do not modify, repair or dismantle this Bluetooth
Stereo Headphone. Doing so may result in fires, electric
shocks, complete breakdown of this Bluetooth Stereo
Headphone, etc. All of which, are not covered under
warranty.
4\ Do not use any diluents or volatile liquid to clean the
Bluetooth Stereo Headphone.
5\ Do not use the Bluetooth Stereo Headphone in a
hazardous location.
2.Kit Contents
1X Bluetooth Headset
1X USB Charger wire
1X User Manual
Turn on the Bluetooth Stereo Headphonego to the paring mode.
Search your Bluetooth devices onyour phone by following the
phone's instructions. Refer to your phone's user manual for
more information.
After a few second the phone will list the device as a discover
device. Select it and follow your phone instruction to select this
pairing.
Then your phone will request a passkey or PIN, enter 0000 as
your PIN or passkey.
Your phone will confirm the pairing, and then press Yes/Ok.
Finally, select to connect with device from your phone.
You can play music; watch TV/movie and play game with
your phone, then your can hear all the sound or music
form the device. Also you can control the player by
operating the device. Example, volume up and next music.
4
4.3. Charging your device
The device is convenient to connect to AC charger or a USB
charger with Micro USB port marked with.Make sure that
your device is full charged for at least 6 hours before initial
use. Insert one terminal of your charger to AC main or USB
port of PC and other terminal to Micro USB. While charging,
he red LED light constantly. When charging is completed,
the red LED turns off and blue LED turn on.
5 6
Parameter Value
Charging Time About 2.5 hours
Dimension (LxWxH)
Weight
Talking time About 12 hours
THD+N ≤1.0%
Play / pause
Press to play when the device is pausing
and press to pause when the device is
playing.
Volume up Press is for volume up
4.How to use
4.1.General Functions
Turn on
Enter the pairing
mode
Pairing
Desired Result Required Action
Press the “ ” button for 3 seconds when
the device is off. (Red LED slowly flashes
and a tone voice beep)
In power off mode Press the “ ” button
and hold on for 6 seconds.(Blue LED and
Red LED quickly flash alternately with two
beep tone voice).
In pairing Mode use a Bluetooth function
mobile phone or other Bluetooth Master
Device and to perform pairing action
(detail refer to the chapter about pairing)
Pairing to a phone and Entertainment:
Turn on your phone and ensure its Bluetooth function
is activated
Pairing to a computer and Entertainment:
If there is no Bluetooth function supported by your computer, a
Bluetooth adapter is necessary. Fix the adapter with your
computer and ensure its Bluetooth function is activated.
Turn on the device go to the paring mode.
Open the Bluetooth software (such as BlueSoleil) installed on
your computer, and selects “Search your Bluetooth devices”
function. Refer to user manual of the Bluetooth software for
more information.
After a few second the “ device name” will list in Bluetooth
software of your computer as a discover device.
Select this icon and click right button of mouse to select
“pairing” item,then select “connect with audio device”
with same operation.
Open your media player soft to play music, watch TV/move
and play game, then all the sound will be playback on
your device.
5.Technical specification
Bluetooth
Specification
Bluetooth Profile
Parameter Value
80Hz-20KHz
RF Range
≥90dB
Frequency
Response
Speaker rated
power 20mW
Signal-To-Noise
10 m
USER MANUAL USER MANUAL USER MANUAL USER MANUAL USER MANUAL USER MANUAL
Bluetooth 4.0
A2DP1.2/AVRCP1.4/HSP1.2/HFP1.6
To use your Bluetooth Stereo Headphone, you must first pair
your Stereo Headphone with a phone or a computer. Once
your Bluetooth Stereo Headphone is paired to a specific
mobile phone, they will remain paired and automatically
recognize each other whenever they are within range.
4.2. Pairing to Mobile phone or other device
Last number redial
Fast backward
Fast forward
Multi-point connection
Factory reset
Double click the “ ” button In the
connected state or there is music
Press the “<”button don’t loose
Press the “>”button don’t loose
In pairing mode, short click the “ ” to
enable the multipoint and double click the
“ ” to disable the Multipoint.
Under the pairing mode Long press “ ”
and”-” button for 5 second at the same time .
4\Why the headset cannot connect to second phone
Ans: Please set the headset to pairing mode and short press
the “ ” to enable multipoint mode Connect the
headset to phone A, Restart the headset to pairing mode
and connect the Headset to phone B, and then use phone
A paired device list to reconnect to the headset
1\ Why is there no power even when the Stereo Headphone
is power on?
Ans: Ensure the battery is being charged up to 6 hours for
first time using. The LED is lighted when it starts
charging.
If your device is not performing as it should,please take it to
your local service providers or dealer for service.
7. FAQ
2\There is no sound when playback.
Ans: Check the connection between your device with
phone or computer, if the connection is not
established, pleasereconnect again. Make sure the
Stereo Headphone device is paired and connected
target phone or other master device.
3\How can I know the Bluetooth Stereo Headphone has
been fully charged?
Ans: When the indicator LED turns red to blue when it is
charging, it has been fully charged.
135g(H2X)
156.9×163.5×49mm(H2X)
Turn on/
Enter the pairing mode/
Play / pause/
Turn off /
Answer call/
End call/
Reject call/
Transfer call voice/
Last number redial
Charging
Volume down
Volume up
MIC
Previous/
Fast backward
Next/
Fast forward
2 3 7
USER MANUAL
8.FCC Warning
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However,there is no
guarantee that interference will not occur in a particular
installation.If this equipment does cause harmful interference
to radio or television reception,which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician
for help.
