KYE SYSTEMS KT001 TrackPad User Manual Manual 20120709
KYE Systems Corp TrackPad Manual 20120709
User Manual
1. Put your receiver into PC. 2. Pull out the insulation sheet.
2. Pair
The LED for dongle will blink flash 8 times, then you can use on you PC.
3. Functions
3.1 Mouse functions
a. Mouse cursor and button
Item Mouse Cursor
Mouse button
Left button
Right button
Middle button
Method one Method two
Have ● ● ● ● ●
Action Slide Tap Tap Tap Tap
Method Slide
Tap
+
button
Tap
+
button
Two fingers tap
+
button
Three fingers tap
+
button
Area
Enjoy the perfect trackpad combo for
your PC.
Reduce desktop clutter with wireless
connection and enhance workspace
comfort with modern design.
HP Wireless Trackpad (ATOLL)
b. Mouse wheel
Item
Mouse wheel
Vertical Scroll
Horizontal Scroll
(Tilt Wheel)
Method one Method two Method one Method two
Have ● ● ● ●
Action Slide Slide Slide Slide
Method One finger slide Two fingers slide One finger slide Two fingers slide
Area
c. Mouse left functions
Item
Mouse left functions
Single tap Double tap Double tap then hold
Have ● ● ●
Action Tap Tap Tap
Method Single tap Double tap Double tap then hold
Area
3.2 Gesture function
Item
Zoom Rotate Edge swipe
Out In Lift Right
Toggle the
charms
Toggle the
app bar
Switch to last
application
Have ● ● ● ● ● ● ●
Action Slide Slide Slide Slide Slide Slide Slide
Method
Two
fingers
slide
Two
fingers
slide
Two
fingers
slide
Two
fingers
slide
One
finger
slide
One
finger
slide
One
finger
slide
Area
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate this equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. End users must follow the specific
operating instructions for satisfying RF exposure compliance.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Industry Canada statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est
sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout
brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable.
