TM

DeskLincTM

Where Smart is Standard

DeskLinc™ is the portable front desk operating system that fits

in the palm of your hand. Using the latest advances in smart

card and Mifare technology, DeskLinc is uniquely designed to

offer small and mid-size property managers all the functions and

convenience of a large-property front desk system, without the

need for bulky computer equipment and an elaborate set-up.

The DeskLinc system anticipates property managers’

needs by bringing information back from the lock by

way of the credential, saving both time and money.

As a multi-technology system, DeskLinc is compatible

with smart, magstripe, and RFID credentials.

DeskLinc consists of a handheld unit and an encoder. No computer

is required to operate the system, and this system easily integrates with

existing PMS structures.

The encoders are multi-station capable. The insertion and Type 7

encoders quickly and accurately encode smart and magstripe

credentials while the RFID and Type 7 encoders

are available for encoding Mifare credentials.

The handheld unit is used to program information to the

keycard. DeskLinc handheld features include:

• The ability to download lock diagnostics at the door

• Reports can be downloaded to a USB drive

• An enlarged backlit display screen

• A built-in emergency lock power supply (ELPS) that is now part of

the handheld unit can be used to open a door with an expired battery

• An extended sign-on function that allows users to remain logged in as

long as they do not sign off

• The ability to create limited-use keys with two-time-use within a set time frame

• The ability to program a lock to automatically open and close at specified times

• Employee Master keys can be programmed to only work during specified

work hours

• Multi-station communication using existing network infrastructure

• A selectable pass option that allows for optional access authorization to specific areas

Form and Function

Property managers are faced with many questions in day-to-day operations:

Did Sally visit and replace the light bulb in the assigned room?

How long did it take Jim to visit all the rooms to perform

regular upkeep?

Tracking staff activity and ensuring more effective building management

are just some of the issues easily addressed by DeskLinc. When smart and

Mifare credentials are issued to staff, managers can track their activities

throughout the property. Managers can retrieve information on all the locks

visited by the employee by interrogating the credentials at the DeskLinc unit.

They do not have to waste time independently visiting each lock.

A report of key use in the locks can also be generated and downloaded

to a USB drive. The report includes the date and time of key use, the locks

the keycard attempted to open, why the keycard was not allowed to open

certain doors, and which locks require battery changes or had privacy

activated.

DeskLinc will identify the key, indicate the user, and when the key expires.

Additional information, such as when the key was first made and its I.D.

number, is also displayed.

Revolutionary Technology

Insertion

Encoder

Type 7

Encoder

RFID

Encoder

Equipment Specifications

A worldwide leader in the development and manufacturing of access control

systems, SAFLOK has the experience, stability, and depth of resources to help

you achieve increased flexibility, efficiency, and security. Our products ensure...

“Their Security. Your Control.”

• Guestroom level

• Suite level

• Fail-safe level

• Section level

• Floor level

• Inhibit level

• Latch/Unlatch level

• Limited-use level

• Grand master level

• Electronic lockout level

• Emergency/Security level

DeskLinc is capable of providing up to 11 independent key levels such as:

Replace a bulky set-up with DeskLinc

that fits in the palm of your hand.

M3558_ac_5_10

Handheld Insertion Encoder Type 7 Encoder RFID Encoder

Height 1.9” (47 mm) 4.9” (124 mm) 3.62” (92 mm) 6” (152 mm)

Depth 9.0” (228 mm) 3.9” (99 mm) 7.1” (180 mm) 3.27” (83 mm)

Width 4.6” (117 mm) 4” (102 mm) 4.05” (103 mm) 1.49” (38 mm)

Screen LCD 128 x 64 N/A N/A N/A

Keycards Encoded N/A Magstripe, Smart/Memory Varies by configuration Mifare Mini, 1K, 4K

A DC power supply is included with each encoder.
