Technical data
Communication interface
Meter reading 3-wire RS485, using MODBUS protocol
READy Gateway configuration Optical eye
Data transfer to smartphone/tablet Wireless M-Bus, C-mode according to
EN13757-4:2013
Data transfer to concentrator Wireless M-Bus, C-mode, according to
EN13757-4:2013
Further interfaces
User interface Optical eye (reading out log data)
Display
Frequency
Wireless M-Bus, C-mode 912.5/915.0/918.5 MHz
Mechanical data
READy Gateway
LxWxD (inches) 4.8 x 3.5 x 3.5
Weight incl. bracket (oz) 23.3
IP protection class IP68
Bracket for READy Gateway
LxWxD (inches) 3.9 x 2.4 x 3.3
Weight (oz) 3.2
Temperature range
Operation -4 - +140 °F
Storage -40 - +158 °F
Flooding temperature +35.6 - +140 °F
Power supply
Internal battery supply 2 x D-cell batteries (3.6 VDC)
Battery lifetime 6 years
Markings/Standards
FCC ID: OUY-READYGW1
RoHS
FCC part 15B
Safety information/Disposal
Do not expose READy Gateway to open fire.
Do not short circuit the connector on READy Gateway.
Please return READy Gateway to Kamstrup if the above specifications cannot be
fulfilled.
Maintenance
The READY gateway must always be properly assembled when cleaning is carried out
in order to protect the internal parts of the meter. Use only water when cleaning.
Activities including installation, adjustments, putting into service, use, assembly,
disassembly and maintenance are required to be carried out by suitably trained
personnel in accordance with applicable code of practice.
If the equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
READY Gateway - Technical data
Kamstrup A/S • 55121761_B1_US_12.2015
Battery replacement
When you need to replace the batteries you must always use the proper battery
replacement kit supplied from Kamstrup. See details for replacement in the manual
delivered with the battery replacement kit.
Caution: Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
During battery replacement, keep battery dry at all time and dispose used batteries
according to regulations.
The battery voltage is 3.67 V maximum, provided by 2 D-cell (Kamstrup part number
1606064).
Minimum operational battery voltage : 3.0 V. A lower voltage is detected as battery low
condition. Operation for 24 hours with a low battery condition will be reported by an
alarm and is an indication that battery replacement is required.
Below 2.7 V the device will cease normal operation and be kept in power down.
FCC Cautions
Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user´s authority to operate the equipment.
This device complies with Part 15 of the FCC rules.Operation is subject to the following
2 conditions:1. This device may not cause harmful interference, and2. This device
must accept any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communication. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by tuning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Order information
Top number: READyGateway
Type number: 6696XXXXXXXX
Accessories
READy Converter (Walk-by/Drive-by solution) READyConverterI
READy Concentrator (Fixed network solution) READyConcentratorI
Battery replacement pack 6699 031
Do not dispose the appliance in the trashcan, but according to the regulations
Technical assistance
Technical assistance may be obtained from
Kamstrup
Industrivej 28
DK-8660 Skanderborg
Please visit Kamstrup website for the nearest local representative
kamstrup.com/en-en/contact
