User Manual

Issue department：Bedding Division Date： 2018-03-26

ProductFunction

instruction

Author： Kyle

No：

MC142 Version： 1.1

Page 1 of 3

1

MC142Functioninstruction

1. Electricalconfigurationdiagram：

2. FunctionPicture

3.Processoftest

3.1. HEADport

Connecttoheadactuator,controlbyremotesingle:

Clickhead upbuttonontheremote,headactuatormovesout,stopwhenreleased；

Clickheaddownbutton，headactuatormovesin,stopwhenreleased；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

FCC ID: 2AK23MC142

IC: 22406-MC142

IC: 22406-RF358B

FCC: 2AK23RF358B

Lumbar

68001402

68001449

Bettery backup

68000221

Massage Motor Splitter Cable

68000221

WIFI

68001404

Massage Unit part number

68000024

USB Charger USB

68000089

68000838

Power Outlet USB/110V

Power Cord AC

Power Supply

68000289

Head Motor

68001380

Foot Motor

68001381

68000220

Input Cable DC

Issue department：Bedding Division Date： 2018-03-26

ProductFunction

instruction

Author： Kyle

No：

MC142 Version： 1.1

Page 2 of 3

2

3.4. MULTIFUNCTIONport

ConnectwiththesameotherControlboxorOtheraccessories;

3.5. PowerLED&PAIRINGLED

Powersupplyforcontrolbox,PAIRINGLEDofcontrolboxflashesfor4times,andthenturnsoff,POWERLEDturns

on。

3.6. Power

Connecttothe29VDC;

3.7. PairFunction

Powerupcontrolbox，pairingLEDwillbeflash，thecontrolboxentersintomodeofcodeparing；

PressandholdtheparingLEDofRemote,thebacklightofparingLEDflashes,thebacklightofremoteflashes,the

remoteentersintomodeofcodeparing;

ThebacklightofparingLEDofremotestopsflashing,andtheparingledofcontrolboxstopflash,itindicatesthat

thecodeparingissuccessful;

Iffails,repeatalltheprocessesabove;

3.2. FOOTport

Connecttofootactuator,controlbyremotesingle:

Clickfoot up button，footactuatormovesout，stopwhenreleased；

Clickfoot downbutton，footactuatormovesin，stopwhenreleased；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

3.3. Massage

Connecttoheadmassage,controlbyremote:

Clickheadmassage+button,headmassagestrengthensbyonelevel;

Clickheadmassage‐button,headmassageweakenbyonelevel;

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

Issue department：Bedding Division Date： 2018-03-26

ProductFunction

instruction

Author： Kyle

No：

MC142 Version： 1.1

Page 3 of 3

3

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

FCC：

Any Changes or modifications not expressly approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This

device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

ISED RSS Warning:

This device complies with Innovation,Science and Economic Development Canada licenceexempt

RSS standard(s). Operation is subject to the following two conditions: (1) this device

may not cause interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d'ISED applicables aux appareils radio

exempts de licence.

L'exploitation est autorisée aux deux conditions suivantes:

(1) l'appareil ne doit pas produire de brouillage, et

(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d'en compromettre le fonctionnement.

ISED RF exposure statement:

This equipment complies with ISED radiation exposure limits set forth for an uncontrolled

environment.

This equipment should be installed and operated with minimum distance 20cm between the

radiator& your body.This transmitter must not be co-located or operating in conjunction with

any other antenna or transmitter. Le rayonnement de la classe b repecte ISED fixaient un

environnement non contrôlés.Installation et mise en œuvre de ce matériel devrait avec

échangeur distance minimale entre 20 cm ton corps.Lanceurs ou ne peuvent pas coexister cette

antenne ou capteurs avec d’autres.

3.8. FLATfunction

PressandreleasetheFLAT buttononremote，theheadandfootactuatorsmovestolowerposition(whenthe

actuatorisfree,canturnoffthevibrationmotorandturnofftheindicatorlightwhenpressonce)，stopwhen

pressanybuton；

Thisfunctiontakeseffectonlybypressingthecorrespondingbuttonontheremote.

3.9. ZEROGpositionfunction

PressandreleaseZERO Gbuttononremote，theheadandfootactuatormovestopresetmemoryposition，stop

whenpressanybutton；
