Kid Galaxy V039-2G4R 20V RC EPIC CLIMBER User Manual 10318 KG 20V Jeep US IM 11x17 V2 20180518 CS6

Kid Galaxy Inc. 20V RC EPIC CLIMBER 10318 KG 20V Jeep US IM 11x17 V2 20180518 CS6

User Manual

EXTREMELY POWERFUL VEHICLE. ONLY USE OUTDOORS IN LARGE, OPEN AREA.
CAN BE USED ON AREAS WITH SHORT GRASS, SMALL ROCKS, DIRT AND SAND.
REVERSE
FORWARD
FORWARD
REVERSE
POWER ON
TURN LEFT
FORWARD
TURN RIGHT
TURN LEFT TURN RIGHT
CONTROLLER BATTERY INSTALLATION
Install included AAA batteries into controller.
UNLOCK VEHICLE SURFACE
Remove vehicle surface locks/pins.
To re-attach body, push pins all the way to lock body in place.
LOAD THE BATTERY
CHARGE THE BATTERY
The included charger is designed to charge the included 20V battery.
Allow for at least a 3 hrs and 45 mins charge before use. Alternatively, you can
use any fully charged 20 volt compatible battery from Black & Decker,
Dewalt, Porter-Cable, or Stanley. Many 20V batteries from these
manufacturers that are under 3.0Ah should fit.
1. Attach the charger to the 20v battery.
2. Plug charger in wall.
3. Battery is charging and shows level
of charge as lights blink. Fully
charged when lights are solid.
CHARGE TIME:
3 hours and 45 minutes
Push until
“CLICKS”
RELEASE BATTERY
Press the lock at the end
of the battery to release
from the car.
Examine battery charger regularly for any damage to cord, plug, enclosure, and other parts.
In the event of such damage, discontinue use until repaired.
QUICK
START
GUIDE
QUICK
START
GUIDE
Item number.: 10318
TROUBLESHOOT HELP. CALL US! 1-800-816-1135 or email: customerservice@kidgalaxy.com
CONTROLLER: FORWARD/REVERSE
1. Pull inward on lever of transmitter to propel
vehicle forward.
2. Release lever to neutral position to allow
car to stop.
3. Push outward on lever of transmitter to
propel vehicle in reverse.
4. Avoid moving lever inward or outward
without allowing vehicle to come to a
complete stop.
CONTROLLER: TURNING
Turn wheel to change direction while traveling.
WARNING:
HIGH PERFORMANCE MOTOR
Do not overload the motor in
branches, sand, mud, swamps, etc.
that prevent the car from moving
and creates extra work for the motor.
When car is stuck, avoid running
the motor repeatedly. Walk to vehicle
(sorry) and remove the vehicle
from the obstacle.
ALLOW MOTOR TO COOL PROLONGS
MOTOR LIFE
Periodically, allow the motor and
battery to cool between races. Use
of a higher amperage battery requires
intermittent breaks. If the motor
is very hot to the touch, discontinue
use until the motor has cooled.
BATTERY USE
Included battery should be charged
only with included charger. Use of
compatible 20 volt batteries that fit
is encouraged, and these batteries
should only be charged with their
respective charger. Flip battery
connecter mechanism as it does not
lock into place. If not aligned, battery
cannot be installed.
SAFETY FIRST
You are the owner of an extremely
powerful radio control product.
Use with care to avoid product
damage or personal injury.
POST RACE
Turn vehicle off.
Disconnect battery from vehicle
and remove it.
Turn transmitter off.
Live to race another day.
2
1
2
1
TURN RIGHT
TURN LEFT
FORWARD
BACKWARD
POWER ON
POWER OFF TRIM KNOB
TURN WHEELS MORE
TO THE LEFT
TURN WHEELS MORE
TO THE RIGHT
1. If the vehicle is not moving, turn the “ON/OFF” switch on the CONTROLLER and the VEHICLE to the “OFF” position.
Powering down for 10 seconds for reset purposes.
2. Turn both power switches to “ON” again to play.
TROUBLESHOOT TIPS
Turn to “ON” position
TURN ON/ADJUST VEHICLE
Always turn on transmitter before turning on vehicle. LED on transmitter will illuminate.
Make sure all motors are functional and car can turn left/right.
Front wheels should face forward and if not, adjust steering trim until they point forward.
Turn to “ON” position
1 2
CONTROLLER
The battery adaptor does not lock into place. Alignment critical for proper battery installation.
ROTATE ADAPTER/ALTERNATE BATTERY INSTALLATION
Adapter is aligned for included battery and power packs from
1. Align arrows.
2. Load battery.
Just flip adapter for use with
1. Align arrows.
2. Load battery.
DeWalt
®
power packs.
Black & Decker ,
Stanley Fat Max
®
,
or Porter Cable
®
.
Black & Decker ™, Stanley Fat Max
®
, Porter Cable
®
, DeWalt
®
are trademarks of Stanley Black & Decker, Inc.
20V Power Drive is not manufactured or distributed by Stanley Black & Decker, Inc.
TRIM ADJUSTMENT
Before each use - adjust the trim adjustment knob so that
the front wheels are rolling in a straight line
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
