Users Manual
XX-B19 - IB (English)
Size: 90 x 150 (mm)
Material: 90gsm WF paper
Color: 1C + 1C (Black)
Date: Apr 09, 2015
XX-B19_040915-A Printed in China
Listening to Music Via Bluetooth
For iPhone
B19 B19
B19 B19
For other
Computer
connected
to working outlet Computer USB port
OR
USB Adaptor (not included)
Charging The Speaker
Listening to Music Via AUX-In
TOP VIEW
BACK VIEW
Using The Speaker
M
1234
4
Top View Key:
1. Mode
2. Volume Down/Track Reverse
3. Volume Up/Track Forward
4. Play/Pause/Speakerphone
Back View Key:
1. AUX Jack
2. On/Off Switch
3. Micro USB Charging Port
4. Battery Door
M
FRONT VIEW
B19
Rechargeable
Bluetooth Speaker
Questions? Visit www.ekids.com
For any other questions: 1-888-TOP-TOYS Toll Free
Distributed by ekids
1299 Main Street Rahway NJ 07065
1. Connect the Micro USB cable to the micro USB charging port on the back of the speaker.
2. Connect the standard USB plug end of the cable to a power USB port on a computer or
other USB charging device. The blue LED on the speaker will flash while the unit is
charging and will glow steadily once fully charged.
Connect one end of a standard 3.5mm audio cable to the headphone jack of your device,
and the other end to the AUX jack of the speaker. Press the Mode button on the top of the
speaker
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
CAN ICES-3 (B)/NMB-3(B)
FCC Information
AUX ON OFF DC5V
AUX ON OFF DC5V
123
1. Make sure your Bluetooth device is fully charged. Turn on your Bluetooth
device and make it ‘discoverable’ by turning on Bluetooth mode (check in
Options or Settings).
2. Press the Mode button on the speaker. The blue LED will flash while the
speaker attempts to pair with your Bluetooth device. “B19” should appear
on your device’s Bluetooth screen. If “Not Connected” or a similar
message appears on your screen, select “B19” to connect to the speaker.
3. If pairing is successful, the blue LED on the speaker will glow steadily. Press Play on both
the speaker and your device to start listening to music.
Using The Speakerphone Via Bluetooth
When you are listening to music via Bluetooth and your receive a call, you can answer the
call through the speaker by pressing the Play/Pause/Speakerphone button. The music will
be disabled during the call, and will resume once you end the call by pressing the
Play/Pause/Speakerphone button again.
LED Indicator
